Safe Operation Practices • Set-Up • Operation • Maintenance • Service • Troubleshooting • Warranty
OPERATOR'S MANUAL
Three Stage Snow Thrower
WARNING
READ AND FOLLOW ALL SAFETY RULES AND INSTRUCTIONS IN THIS MANUAL
BEFORE ATTEMPTING TO OPERATE THIS MACHINE.
FAILURE TO COMPLY WITH THESE INSTRUCTIONS MAY RESULT IN PERSONAL INJURY.
P. O. Box 1386, 97 KENT AVENUE, KITCHENER, ON N2G 4J1
Printed In USA
769-09096B
06.19.14
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Cub Cadet 3X
Summary of Contents for Cub Cadet 3X
- Page 1 Safe Operation Practices • Set-Up • Operation • Maintenance • Service • Troubleshooting • Warranty OPERATOR’S MANUAL Three Stage Snow Thrower WARNING READ AND FOLLOW ALL SAFETY RULES AND INSTRUCTIONS IN THIS MANUAL BEFORE ATTEMPTING TO OPERATE THIS MACHINE. FAILURE TO COMPLY WITH THESE INSTRUCTIONS MAY RESULT IN PERSONAL INJURY. P.
-
Page 2: Table Of Contents
Choose from the options below: ◊ Visit our web at www.cubcadet.ca ◊ Locate your nearest dealer from Customer Support: 1-800-668-1238 ◊ Contact Cub Cadet • P.O. Box 1386 • 97 Kent Avenue • Kitchener, Ontario, Canada • N2G 4J1... -
Page 3: Safe Operation Practices
Important Safe Operation Practices WARNING! This symbol points out important safety instructions which, if not followed, could endanger the personal safety and/or property of yourself and others. Read and follow all instructions in this manual before attempting to operate this machine. Failure to comply with these instructions may result in personal injury. - Page 4 Safe Handling of Gasoline Never run an engine indoors or in a poorly ventilated area. Engine exhaust contains carbon monoxide, an odorless To avoid personal injury or property damage use extreme care and deadly gas. in handling gasoline. Gasoline is extremely flammable and the Do not operate machine while under the influence of vapors are explosive.
- Page 5 Clearing a Clogged Discharge Chute According to the Consumer Products Safety Commission (CPSC) and the U.S. Environmental Protection Agency (EPA), Hand contact with the rotating impeller inside the discharge this product has an Average Useful Life of seven (7) years, chute is the most common cause of injury associated with snow or 60 hours of operation.
-
Page 6: Safety Symbols
Safety Symbols This page depicts and describes safety symbols that may appear on this product. Read, understand, and follow all instructions on the machine before attempting to assemble and operate. Symbol Description READ THE OPERATOR’S MANUAL(S) Read, understand, and follow all instructions in the manual(s) before attempting to assemble and operate. -
Page 7: Assembly & Set-Up
Assembly & Set-Up IMPORTANT: The snow thrower is shipped with oil and WITHOUT GASOLINE. After assembly, refer to separate engine manual for proper fuel and engine oil recommendations. NOTE: Remove all loose parts and any packing material before assembling. NOTE: References to right or left side of the snow thrower are determined from behind the unit in the operating position. NOTE: This Operator’s Manual covers several models, handle panels, lights and chute cranks are some features that may vary by model. -
Page 8: Table Of Contents
• Place chute assembly onto chute base and secure chute control assembly to chute support bracket with clevis pin and cotter pin removed earlier. See Fig. 3-4. Fig. 3-6 Fig. 3-4 • Finish securing chute control assembly to chute support bracket with wing nut and hex screw removed earlier. - Page 9 Drift Cutters (If Equipped) WARNING: Drift cutters should be used when operating the snow thrower in Never use your hands to clean snow heavy drift conditions. and ice from the chute assembly or auger housing. • On models so equipped, drift cutters and hardware are Lamp Wiring Harness (If equipped)) assembled to the auger housing inverted.
- Page 10 Tire Pressure The tires are over-inflated for shipping purposes. Check the tire pressure before operating the snow thrower. Refer to the tire side wall for tire manufacturer’s recommended psi and deflate (or inflate) the tires as necessary. WARNING: Under any circumstance do not exceed manufacturer’s recommended psi.
- Page 11 Auger Control Test WARNING : Prior to operating your snow thrower, carefully read and follow all instructions below. Perform all adjustments to verify your unit is operating safely and properly. Perform the following test before operating your snow thrower for the first time and at the start of each winter. Check the adjustment of the auger control as follows: When the auger control is released and in the disengaged “up”...
-
Page 12: Controls
Controls and Features Auger Control 2 Way Drive Control Chute Control Shift Lever Heated Grips (if equipped) Steering Trigger Control (if equipped) Headlight Chute Directional Control Chute Assembly Drift Cutters (if equipped) Clean Out Tool Skid Shoe Augers Figure 4-1 Skid Shoes Snow thrower controls and features are described below and illustrated in Figure 4-1. -
Page 13: Auger Control
Auger Control Heated Grips (If so Equipped) CAUTION: It is recommended that you wear gloves when using the heated grip. If the heated grip become too hot, turn it off. To activate the heated grips, move the switch found on the rear of the dash panel into the ON position. - Page 14 Chute Clean-Out Tool Two-Way Chute Control™ (if equipped) This two-way control lever is meant to control the distance of WARNING! Never use your hands to clear a snow discharge from the chute. Tilt the lever forward or rearward clogged chute assembly. Shut off engine and remain to adjust the distance snow will be thrown.
-
Page 15: Operation
Operation Starting and Stopping the Engine Replacing Shear Pins Refer to the Engine Operator’s Manual packed with your snow The augers are secured to the spiral shaft with shear pins and thrower for instructions on starting and stopping the engine. cotter pins. -
Page 16: Maintenance & Adjustment
Maintenance & Adjustments Maintenance Lubrication Engine Wheels Refer to the Engine Operator’s Manual. At least once a season, remove both wheels. Clean and coat the axles with a multipurpose automotive grease before reinstalling Tire Pressure wheels. Refer to Assembly and Set-up section for information regarding Auger Shaft tire pressure. - Page 17 Adjustments Shift Cable If the full range of speeds (forward and reverse) cannot be achieved, adjust the shift cable as follows: Place the shift lever in the fastest forward speed position. Loosen the hex nut on the shift cable index bracket. See Figure 6-5.
- Page 18 Drive Control Chute Assembly (Overhead Chute Control) When the drive control is released and in the disengaged “up” If the chute fails to remain stationary during operation, the position, the cable should have very little slack. It should NOT be pre-load of the chute can be adjusted by tightening the hex nut tight.
-
Page 19: Service
Service Belt Replacement Roll the auger belt off the engine pulley. See Figure 7-3. Auger Belt To remove and replace your snow thrower’s auger belt, proceed as follows: Allow the engine to run until it is out of fuel. Do not attempt to pour fuel from the engine. - Page 20 Drive Belt Loosen and remove the shoulder bolt which acts as a belt keeper. See Figure 7-5. NOTE: Special tools are required and several components must be removed in order to replace the snow thrower’s drive belt. See your authorized service dealer to have the drive belt replaced or phone Customer Support as instructed on page 2 for assistance.
-
Page 21: Replacement Parts
Bow-tie Cotter Pin 790-00091 Slide Shoe, Deluxe (Steel) 731-06931 Skid Shoe, Deluxe (Blue polymer) 931-2643 Chute Clean-out Tool 790-00120 Shave Plate (3X 24) 790-00121 Shave Plate (3X 26) 790-00118 Shave Plate (3X 28) 951-10630 Spark Plug 951-10292 NOTE: Download a complete Parts Manual, refer to customer support on page 2. Be sure to have your model number and serial... -
Page 22: Troubleshooting
Troubleshooting Problem Cause Remedy Engine fails to start 1. Choke not in CHOKE position. 1. Move choke to CHOKE position. 2. Spark plug wire disconnected. 2. Connect wire to spark plug. 3. Fuel tank empty or stale fuel. 3. Fill tank with clean, fresh gasoline. 4. -
Page 23: Replacement Parts
THREE YEAR LIMITED WARRANTY The limited warranty set forth below is given by MTD Products Limited with respect to new merchandise purchased and used in Canada and/ or its territories and possessions (either entity respectively, “MTD”). MTD warrants this product (excluding its normal wear parts as described below) against defects in material and workmanship for a period of three (3) years commencing on the date of original purchase and will, at its option, repair or replace, free of charge, any part found to be defective in materials or workmanship. - Page 24 Notes...
