- Page 1 Deckenfächer Ceiling fans Ventilateurs de plafond w w w . m a i c o . d e EC 30 E EC 90 B EC 40 D EC 140 B Montage- und Betriebsanleitung Mounting and Operating instructions Instructions de montage et Mode d’emploi...
-
Page 6: Table Of Contents
3. Product information ....... 12 and operating instructions. 3.1 EC 30 E, EC 40 D unit overview ..12 3.2 EC 90 B, EC 140 B unit overview ..12 Bag of accessories for EC 90 B 1 M6x30 mm hex bolt [22] 3.3 Product description...... -
Page 7: Warning Symbols Used
25 Impeller hub with recesses 3. Product information 26 Impeller blade (3 items) 3.1 EC 30 E, EC 40 D unit overview 26.1 Shim (EC 90 B only) Ceiling hook (not included in scope of 26.2 Lock nut (EC 90 B only) delivery) 26.3 Bolt (EC 140 B only) -
Page 8: Product Description
Ceiling fan for air circulation in commercial and working areas. 5.1 General safety instructions EC 30 E and EC 40 D run clockwise. Read the operating instructions through EC 90 B and EC 140 B run anti-clockwise carefully before starting up. -
Page 9: Non-Permitted Operation
7. Installation 5.4 Safe and correct practices during operation 7.1 EC 30 E and EC 40 D installation Danger of injury. Do not place anything in These ceiling fans come from the factory the rotating impeller blades. -
Page 10: Ec 90 B And Ec 140 B Installation
Fit impeller blades [26]. 7.2 EC 90 B and EC 140 B installation Unit will be damaged if Incorrect installation results in impeller blades are of different a danger of injury from falling weights as this will cause unit parts. CAUTION DANGER imbalance. -
Page 11: Electrical Connection
Switch ceiling fan on and off. Check direction of rotation at same time. EC 30 E and EC 40 D: The impeller must turn clockwise (viewed from below). EC 90 B and EC 140 B: The impeller must turn anti-clockwise (viewed from below). -
Page 12: Ec 30 E, Ec 40 D Fastening Rod
Slide enclosed insulation sleeve over motor 8.1 EC 30 E, EC 40 D fastening rod connection cables. This must protrude Disconnect motor connection cables [8] around 20 mm beyond the existing from connecting terminal [7]. insulation sleeve [8]. Slide up motor cover [11]. -
Page 13: Ec 90 B, Ec 140 B Fastening Rod
[14]. Undertake electrical connection according 10.1 Six-monthly check to section 7.3. EC 30 E, EC 40 D Malfunction if the ceiling fan Check that bolts and nuts at fixing points A cannot swing freely. and B are secure, see diagram. -
Page 14: Cleaning
11. Cleaning Fault Countermeasure Danger to life. Unit is powered Check that the mains – Unit doesn’t run fuse is switched on. Switch the mains fuse off. DANGER – Thermal overload If the thermal If the impeller blades are dirty or not protection of the overload protection running smoothly (imbalance), clean the... -
Page 15: Wiring Diagrams
14. Schaltbilder / Wiring diagrams Schémas de branchement EC 30 E EC 40 D W H B K EC 90 B, EC 140 B Maico Elektroapparate-Fabrik GmbH • Steinbeisstr. 20 • 78056 Villingen-Schwenningen • Deutschland • Service-Hotline +49 1805 694 110 • info@maico.de...
