Summary of Contents for Blue Seal E512
- Page 1 I N S T A L L A T I O N A N D O P E R A T I O N M A N U A L ELECTRIC COOKTOP E 5 1 2 E 5 1 4 E 5 1 6 For use in GB &...
- Page 2 Moffat Limited PO Box 10001 Christchurch New Zealand (03) 389 1007 Fax: (03) 389 1276 WORLD-WIDE BRANCHES UNITED KINGDOM Blue Seal 67 Gravelly Industrial Park Erdington Birmingham B24 8TQU (121) 327 5575 Fax: (121) 327 9711 UNITED STATES Moffat Inc...
-
Page 3: Table Of Contents
Contents Blue Seal Electric Cooktop E512 Electric Cooktop - 300mm. E514 Electric Cooktop - 600mm. E516 Electric Cooktop - 900mm. Introduction ....................2 Specification ....................3 Model Numbers Covered in this Specification General Electrical Supply Requirements Electrical Connection Dimensions ....................5 Installation .................... -
Page 4: Introduction
Introduction We are confident that you will be delighted with your BLUE SEAL ELECTRIC COOKTOP, and it will become a most valued appliance in your commercial kitchen. To ensure you receive the utmost benefit from your new Blue Seal ELECTRIC COOKTOP, there are two important things you can do. -
Page 5: Specification
900mm griddle or open radiant element options. It is available on industrial adjustable feet. With 3 models of base unit available from the E512 to E516 models. (Model E514 is not available with Refrigeration Base option and Model E512 is only... -
Page 6: Electrical Supply Requirements
Specifications Electrical Supply Requirements Power Supply Amps Total Power Model Input Voltage Type Frequency E512D 230-240 Vac 1 P+N+E 50 / 60 Hz 4.8 kW 20.0 E512C 230-240 Vac 1 P+N+E 50 / 60 Hz 3.4 kW 14.2 E514D 400-415 Vac 2 P+N+E 50 / 60 Hz 9.6 kW... -
Page 7: Dimensions
Dimensions Dimensions for Bench Models = Rating Plate Location for this option. E512-B E514-B E516-B... - Page 8 Dimensions Dimensions for Cabinet Base Models = Rating Plate Location for this option. E514-CB E516-CB...
- Page 9 Dimensions Dimensions for Leg Stand Models = Rating Plate Location for this option. E514-LS E516-LS...
- Page 10 Dimensions Dimensions for Refrigerated Base Models = Rating Plate Location for this option. E516-RB For the Refrigeration Cabinet Operation refer to the Refrigeration Cabinet Installation and Operation Manual supplied with the appliance. Cooktop Options E512D E512-C...
- Page 11 E516B NOTE: • E512 is only available as Bench Mount (B) Model. • E514 is available as Bench Mount (B), Cabinet Base (CB) or Leg Stand (LS) model options. • E516 is available as Bench Mount (B), Cabinet Base (CB), Leg Stand (LS), or Refrigerated Base (RB) model options.
-
Page 12: Installation
Blue Seal Cooktops are designed to provide years of satisfactory service, and correct installation is essential to achieve the best performance, efficiency and trouble-free operation. This appliance must be installed in accordance with National installation codes and in addition, in accordance with relevant National / Local codes covering gas and fire safety. -
Page 13: Assembly
Installation Assembly AUTIO N • This appliance is for professional use and is to be used by qualified persons only. • Only qualified service persons are allowed to carry out installation and servicing of this appliance. Bench Mount (B) Models Check that all the feet are fitted. -
Page 14: Electrical Connection
Installation Electrical Connection WARNING: HIS APPLIANCE MUST BE EARTHED F THE SUPPLY CORD IS DAMAGED IT MUST BE REPLACED BY A SUITABLY QUALIFIED PERSON IN ORDER TO AVOID A HAZARD NOTE: ALL ELECTRICAL CONNECTIONS MUST ONLY BE CARRIED OUT BY AN AUTHORISED PERSON. -
Page 15: Operation
Only authorised service persons should be used to carry out installation or servicing operations. Blue Seal appliances have been designed to provide simplicity of operation. A commercial heavy duty, electric Cooktop is available in 3 different sizes, 300mm, 600mm and 900mm wide and in 4 model types:- Bench Model. -
Page 16: Radiant Hotplates
Operation Radiant Hotplates The controls for the radiant hotplates may be set at any position between high and low to provide the desire level of heating. An individual amber neon for each element, will glow when the element cycles on and extinguish when the element cycles off. Start cooking at the highest setting, and change to a lower setting when the desired temperature is reached. -
Page 17: Cleaning And Maintenance
Cleaning and Maintenance AUTIO N Always turn off the electrical power supply at the mains supply before cleaning. This appliance is not water proof. Do not use water jet spray to clean interior or exterior of this appliance. General Clean the Cooktop regularly. A clean appliance looks better, will last longer and will perform better. Carbonised grease on the surface or on the griddle plate (If fitted) will hinder the transfer of heat from the cooking surface to the food. -
Page 18: Weekly Cleaning
Cleaning and Maintenance Weekly Cleaning NOTE: • If the Cooktop usage is very high, we recommend that the weekly cleaning procedure is carried out on a more frequent basis. • Ensure that protective gloves are worn during the cleaning process. •... -
Page 19: Fault Finding
Fault Finding This section provides an easy reference guide to the more common problems that may occur during the operation of your appliance. The fault finding guide in this section is intended to help you correct, or at least accurately diagnose problems with your equipment. Although this section covers the most common problems reported, you may encounter a problem not covered in this section. -
Page 20: Circuit Schematics
Circuit Schematics E512-D REAR PHASE NO MARK REAR NEUTRAL BLUE MARK FRONT NEUTRAL BLACK MARK FRONT PHASE RED MARK SUPPLY NEUTRAL PILOT PILOT REAR FRONT E512 C NOT USED NOT USED NOT USED PHASE SUPPLY NEUTRAL GREEN ORANGE RIGHT GRIDDLE T/STAT... - Page 21 Circuit Schematics E514-D LEFT RIGHT REAR PHASE REAR PHASE NO MARK NO MARK REAR NEUTRAL REAR NEUTRAL BLUE MARK BLUE MARK FRONT NEUTRAL FRONT NEUTRAL BLACK MARK BLACK MARK FRONT PHASE FRONT PHASE RED MARK RED MARK SUPPLY NEUTRAL SUPPLY NEUTRAL LEFT 25A RIGHT 25A PILOT...
- Page 22 Circuit Schematics E516-D LEFT CENTRE RIGHT REAR PHASE REAR PHASE REAR PHASE NO MARK NO MARK NO MARK REAR NEUTRAL REAR NEUTRAL REAR NEUTRAL BLUE MARK BLUE MARK BLUE MARK FRONT NEUTRAL FRONT NEUTRAL FRONT NEUTRAL BLACK MARK BLACK MARK BLACK MARK FRONT PHASE FRONT PHASE...
- Page 23 Circuit Schematics E516-B CENTRE RIGHT LEFT NOT USED NOT USED REAR PHASE NO MARK NOT USED NOT USED REAR NEUTRAL BLUE MARK NOT USED NOT USED FRONT NEUTRAL BLACK MARK PHASE PHASE FRONT PHASE RED MARK SUPPLY NEUTRAL SUPPLY NEUTRAL SUPPLY NEUTRAL CENTRE 25A RIGHT 25A...
-
Page 24: Replacement Parts List
Replacement Parts List Replacement Parts List IMPORTANT: Only genuine authorized replacement parts should be used for the servicing and repair of this appliance. The instructions supplied with the parts should be followed when replacing components. For further information and servicing instructions, contact your nearest authorized service branch (contact details are as shown on the reverse of the front cover of this manual).
