Page 1: Gas Cooktop
I N S T A L L A T I O N A N D O P E R A T I O N M A N U A L GAS COOKTOP S e rie s G512 G514 G516 G518... - Page 2 Moffat Limited PO Box 10001 Christchurch New Zealand (03) 389 1007 Fax: (03) 389 1276 WORLD-WIDE BRANCHES UNITED KINGDOM Blue Seal Unit 67, Gravelly Business Park Gravelly Park Birmingham West Midlands B24 8TQ (121) 327 5575 Fax: (121) 327 9711...
-
Page 3: Table Of Contents
Contents Blue Seal Gas Cooktops G512 Gas Cooktop 300mm wide. G514 Gas Cooktop 600mm wide. G516 Gas Cooktop 900mm wide. G518 Gas Cooktop 1200mm wide. Introduction ....................2 Specifications .................... 3 Model Numbers Covered in this Specification General Gas Supply Requirements Gas Connection Dimensions .................... -
Page 4: Introduction
Introduction We are confident that you will be delighted with your BLUE SEAL COOKTOP, and it will become a most valued appliance in your commercial kitchen. To ensure you receive the utmost benefit from your new BLUE SEAL COOKTOP, there are two important things you can do. -
Page 5: Specifications
Griddle options with 4 models of base unit available (except G512 model). Fitted with either 'Individual Flame Failure' (F) or 'Pilot and Flame Failure' (PF) option for each open burner. Griddles are fitted with pilot, flame failure and piezo ignition as standard. - Page 6 Specifications Gas Connection Gas supply connection point is located at the rear of the appliance, approximately 130mm from the right hand side, 32mm from the rear and 655mm from the floor (55mm for bench top – B models) and is reached from beneath the appliance. (Refer to the ‘Dimensions’ section). With the exception of the G512C and G512D models which are 100mm from the right hand side, 32mm from the rear and 70mm from the floor.
-
Page 7: Dimensions
Dimensions Dimensions for Bench Models G512-B = Rating Plate Location for this option. G514-B G516-B G518-B Refer to Page 9 for Cooktop options... - Page 8 Dimensions Dimensions for Cabinet Base Models G512 models - not available in Cabinet Base option. = Rating Plate Location for G514-CB this option. G516-CB G518-CB Refer to Page 9 for Cooktop options...
- Page 9 Dimensions Dimensions for Leg Stand Models G512 models - not available in Leg Stand Base option. = Rating Plate Location for G514-LS this option. G516-LS G518-LS Refer to Page 9 for Cooktop options...
- Page 10 Dimensions Dimensions for Refrigerated Base Models G512 and G514 models - not available in Refrigerated Base option. G516-RB = Rating Plate Location for this option. G518-RB Refer to Page 9 for Cooktop options...
- Page 11 G518-A G516-A NOTE: • G512 models are only available in Bench Model (-B) option. • G514 models are available in Bench Model (-B), Cabinet Base (-CB), or Leg Stand (-LS) model options. • G516 and G518 models are available in Bench Model (-B), Cabinet Base (-CB), Leg Stand (-LS), or Refrigeration Base (-RB) model options.
-
Page 12: Installation
Blue Seal Cooktops are designed to provide years of satisfactory service, and correct installation is essential to achieve the best performance, efficiency and trouble-free operation. This appliance must be installed in accordance with National installation codes and in addition, in accordance with relevant National / Local codes covering gas and fire safety. -
Page 13: Clearances
Installation Clearances NOTE: Only non-combustible materials can be used in close proximity to this appliance. Combustible Surface Non Combustible Surface Left / Right hand side 250mm (*) Rear 50mm Side clearances can be 50mm when the adjacent surface is at least 100mm below the cooking surface. -
Page 14: Gas Connection
NOTE: ALL GAS FITTING MUST ONLY BE CARRIED OUT BY A QUALIFIED PERSON. Blue Seal Cooktops do not require electrical connection, as they function totally on the gas supply. It is essential that the gas supply is correct for the Cooktop to be installed and that adequate supply pressure and volume are available. -
Page 15: Commissioning
Installation Commissioning Before leaving the new installation; Check the following functions in accordance with the operating instructions specified in the ‘Operation’ section of this manual. • Lighting the Griddle. • Light the Open Burners. (F - Option). • Light the Open Burners. (PF - Option). •... -
Page 16: Operation
/ operator. Blue Seal appliances have been designed to provide simplicity of operation and 100% safety protection. Improper operation is therefore almost impossible, however bad operation practices can reduce the life of the appliance and produce a poor quality product. -
Page 17: Open Burners ('F' - Flame Failure Option)
Operation Open Burners ('F' - Flame Failure Option) Lighting the Open Burners Flame Failure Protection is incorporated for each burner by way of a thermo-electric system which will shut off the gas supply to that burner in the event that the burner goes out, so that un-burnt gas is not expelled. -
Page 18: Griddle
Operation Griddle Lighting the Griddle a. Depress the gas control knob and rotate anti-clockwise to the ‘PILOT’ position. b. With the gas control knob depressed, press the piezo ignition button to ignite the pilot burner. Repeat Items 1 to 2 until the pilot is lit. c. -
Page 19: Cleaning And Maintenance
Cleaning and Maintenance AUTIO N Always turn off the gas supply before cleaning. This appliance is not water proof. Do not use water jet spray to clean interior or exterior of this appliance. General Clean the Cooktop regularly. A clean Cooktop looks better, will last longer and will perform better. Carbonised grease on the surface or between the trivets, griddle plates will hinder the transfer of heat from the cooking surface to the food. -
Page 20: Daily Cleaning
Cleaning and Maintenance Daily Cleaning The spill tray(s) should be checked and emptied frequently to prevent overflow and spillage. Remove the spill tray(s) while still warm so that the grease is in a liquid state. Empty any grease from the trays and wash thoroughly in the same manner as any cooking utensil. Remove the burner caps and bases, the trivets and thoroughly clean the splash back, interior and exterior surfaces of the range with hot water, a detergent solution and a soft scrubbing brush. - Page 21 Cleaning and Maintenance Trivets and Burners Burner a. Remove the trivets from the top of the appliance, taking note that the trivets are manufactured with a lip on one edge, the lip must always be fitted to the outer edge (front and back) of the Cooktop. (Refer to Fig 8 overleaf).
-
Page 22: Periodic Maintenance
Cleaning and Maintenance NOTE: It is imperative that the trivet supports are correctly re-fitted to the appliance to ensure that the trivets locate correctly and sit flush and level. NOTE that the trivet support front end, side rail profiles are different at either side and only one of the side rails seat into the cut- out in the Cooktop. -
Page 23: Fault Finding
Fault Finding This section provides an easy reference guide to the more common problems that may occur during the operation of your equipment. The fault finding guide in this section is intended to help you correct, or at least accurately diagnose problems with your equipment. Although this section covers the most common problems reported, you may encounter a problem not covered in this section. -
Page 24: Gas Conversion And Specifications
Gas Conversion and Specifications Conversion Procedure AUTIO N Ensure that the Appliance is isolated from the gas supply before commencing servicing. NOTE: • These conversions should only be carried out by qualified persons. All connections must be checked for leaks before re-commissioning the appliance. •... - Page 25 Gas Conversion and Specifications Refit all the trivet supports to the top of the appliance. Note the orientation of the trivet support when re-fitting as the front end side rail profiles are different from the rear end side rail profiles. (Refer to Fig 12 on previous page).
- Page 26 Gas Conversion and Specifications • For the Refrigerated Base Model, the Rating Plate is located inside the right hand front panel and can be viewed through the upper grille. Refer to the ‘Gas Connection’ section and the ‘Dimensions’ section. Pilot Injectors a.
- Page 27 Gas Conversion and Specifications Griddles Gas Control Heat Shield Pilot Burner a. With the gas supply turned off at the main supply, remove the griddle plate section by lifting it straight off the Cooktop. b. Remove the gas control heat shield from around the griddle burner, this is just a push in fit.
-
Page 28: Gas Regulator
Gas Conversion and Specifications Gas Regulator - NAT Gas / LPG / Butane Only. NOTE, Pin rotated for Natural Gas NOTE, Pin rotated for LPG Fig 26 NOTE: The regulator supplied is convertible between Natural Gas and LP Gas, but it’s outlet pressure is fixed ex-factory and is NOT to be adjusted. - Page 29 Gas Conversion and Specifications Gas Type Labels On completion of the gas conversion, replace gas type labels located at:- - The rear of the unit, above the gas connection. - Beside the rating plate. Commissioning Before leaving the converted installation; Check all gas connections for leakages using soapy water or other gas detecting equipment.
-
Page 30: Gas Specifications
Gas Conversion and Specifications Gas Specifications Natural Gas Butane Town Gas Main Burner Ø 2.45mm Ø 1.50mm Ø 1.40mm Ø 4.50mm Open Burner Pilot Burner 0.30 0.20 0.20 0.60 ('PF' Models only) Main Burner Ø 2.10mm Ø 1.30mm Ø 1.20mm Ø... -
Page 31: Replacement Parts List
Replacement Parts List Replacement Parts List IMPORTANT: Only genuine authorized replacement parts should be used for the servicing and repair of this appliance. The instructions supplied with the parts should be followed when replacing components. For further information and servicing instructions, contact your nearest authorized service branch (contact details are as shown on the reverse of the front cover of this manual). - Page 32 Replacement Parts List General 227014 Pot Stand / Trivet. 230286 Spill Tray 300mm (G512 Series). 230277 Spill Tray 600mm (G514 / G518 Series). 230273 Spill Tray 450mm (G516 Series). 227855 Adjustable Legs (84mm - Bench Models). 227850 Adjustable Legs (Flush Stud) (150mm - CB / RB Models).
