Vetta PathFinder II Wireless Quick Start Manual page 2

Time
1
2
Speed / Distance Unit
2
Service Timer
Service Timer could be programmed with a selected
number of ride time (hours or days) or distance
as the interval for servicing the bicycle or any
component on it, such as front or rear shock.
Step 1: Choose Service Timer Unit
Step 2: Set the Service Timer (Maximum
settings: hour/day/distance = 1999/199/9999)
2
1
2
1
2
2
1
2
Wheel / Tire Size
Set circumference or wheel size (see the table
of Tire Szie Vs Circ.)
1 1
2
1
2
Choose (Circumference) to set it
manually.
Press Button to adjust the flashing digit to the
desired number.
If you choose (Tire Size)
Press Button to scroll through the flashing
700c, 650c, 27in, 26in, 24in, 20in, 16in and
select the wheel size.
TIRE
CIRC
SIZE
2180
700C x 38mm
700C x 35mm 2168
700C x 32mm 2155
700C x 30mm 2145
700C x 28mm 2136
700C x 25mm 2124
700C x 23mm 2105
700C x 20mm 2074
700C Tubular 2130
650C x 23mm 1990
650C x 20mm 1945
Odometer
To restore the previous data, you can set odometer
in order to accurately record the accumulative
distance.
1
Auto Start / Stop (For PathFinder II Wireless)
When the Auto Start / Stop function is set on, the
computer will exit the Sleep Mode and display the
last normal screen when it receives signals from
1
wheel or button.
When the Auto Start / Stop function is set off, it
will only exit sleep mode when button is pressed.
1
1
SmartLite
When the SmartLite function is set on, the night
light will turn on for 3 seconds during pre-set
intervals when any button is pressed.
2
1
1
Press Button
Testing Your Installation
Pick up the front of the bicycle and spin the front
wheel. The LCD should display a speed reading
within 2-3 seconds. If there is no speed reading,
check the alignment and spacing between the
magnet and the sensor. Make sure that the Head
Unit is completely locked into position. If the problem
has not been fixed, talk to an authorized Vetta
retailer for further assistance.
TIRE TIRE
CIRC
CIRC
SIZE SIZE
20" x 1-1/4" 1618
27" x 1-1/4" 2161
27" x 1-1/8" 2155 16" x 1.75" 1195
26" x 2.25" 2115 16" x 1.50" 1185
26" x 2.10" 2095
26" x 2.00" 2074
26" x 1.90" 2055
26" x 1.75" 2035
26" x 1.50" 1985
26" x 1.25" 1953
26" x 1.0" 1913
24" x 1.9/1.95" 1916
(Maximum setting: 99999)
2
1
2
2
1
to exit the Setup Mode.
4
Once the sensor is aligned correctly, tighten the
magnet locking screw or zip-ties and the bike
mount strap.
Now your PathFinder II or PathFinder
II Wireless is ready for use!
Warranty
VETTA WARRANTS ALL VETTA (The Company)
PRODUCTS AGAINST MANUFACTURER DEFECTS FOR
A PERIOD OF 3 YEARS. Subject to the following
limitations, terms and conditions, components will be free of
manufacturing defects in materials and workmanship. The 3
year limited warranty is conditioned upon the components
being used and operated in normal riding conditions. This
warranty does not cover normal wear and tear (i.e. battery
replacement, broken wire), rider abuse, acts of God,
improper installation or product alteration.
This warranty is void if the components were
not purchased (new) from or through an
authorized VETTA retailer or dealer. Examples
of unauthorized dealers are online auction
sites or online retailers.
VETTA at its sole discretion will repair or replace items at
its own cost. Users are responsible for all freight and
shipping charges when returning items for warranty service.
In USA, you must either contact the retailer where the
product was originally purchased from, or contact VETTA
distributor in your country for customer service.
Outside USA, you should contact the local dealer or
VETTA distributor in your country for customer service.
The Company shall not be held responsible for replacing
items with new items for greater than the amount of the
original item purchase price. This limited warranty does
provide the original owner with certain legal rights and
recourse. The original owner may possess other rights or
recourse, depending on the state or country. Please check
the web to help answer any question and service manual.
