Reversing The Door Swing - Sandstrom SWC32B11 Instruction Manual

INSTALLATION

Reversing the Door Swing

Tools required: Philips style screwdriver / Flat bladed screwdriver / Hexagonal spanner.
• Ensure the unit is unplugged and empty.
• Adjust the two levelling feet to their highest position.
• To take the door off it is necessary to tilt the unit backwards. You should rest the unit on
something solid, e.g. a chair just below the top panel.
• All parts removed must be saved to do the reinstallation of the door. You should rest the unit
on something solid so that it will not slip during the door reversing process.
• Do not lay the unit flat as this may damage the coolant system.
• We recommend that 2 people handle the unit during assembly.
4. Remove the decorated caps on the glass door.
5. Unscrew the two screws that hold the door handle and then
transfer the handle other side.
6. Place the decorated caps back to glass door.
7. Tilt the unit carefully. 2 people are required to tilt the unit
during the door reversing process.
8. Unscrew and remove the lower hinge bracket. Unscrew the
levelling feat and place it to opposite side.
9. Place the two screws, the bottom bracket and the levelling
feet to one side.
10. Lift the door and place it on a padded surface to prevent
scratching it.
11. Re-attach top hinge bracket to where they was located on
the opposite side (right to left).
6
