Weslo EasyFit User Manual

Hide thumbs

Table Of Contents

Model No. : WLIVEL87912.0

Serial No ___________

Serial number decal

Write the serial number in the

space above for reference.

QUESTIONS ?

If you have questions, or if there are

missing parts, please contact us:

Call: 08457 089 009

From Ireland: 053 92 36102

Website: www.iconsupport.eu

E-mail: csuk@iconeurope.com

Write:

ICON Health & Fitness, Ltd.

c/o HI Group PLC

Express Way

Whitwood, West Yorkshire

WF10 5QJ

CAUTION

Read all precautions and instruc-

tions in this manual before using

this equipment. Keep this manual

for future reference.

EasyFit.

by WESLO

Visit our website

www.iconsupport.eu

USERʼS MANUAL

Table of Contents

Need help?

Do you have a question about the EasyFit and is the answer not in the manual?

Questions and answers

Summary of Contents for Weslo EasyFit

Page 1 EasyFit. by WESLO USERʼS MANUAL Model No. : WLIVEL87912.0 Serial No ___________ Serial number decal Write the serial number in the space above for reference. QUESTIONS ? If you have questions, or if there are missing parts, please contact us:...
Page 2: Table Of Contents
TABLE OF CONTENTS IMPORTANT PRECAUTIONS ..............3 BEFORE YOU BEGIN .
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING : To reduce the risk of serious injury, read all important precautions and instructions in this manual and all warnings on your elliptical before using your elliptical. ICON assumes no responsibility for personal injury or property damage sustained by or through the use of this product.
Page 4: Before You Begin
BEFORE YOU BEGIN Thank you for purchasing the Weslo® Body 580. number and serial number before contacting us. The elliptical provides an array of features de- The model number is WLIVEL87912.0 and the lo- signed to make your workouts at home more ef- cation of the serial number decal are shown on the fective and enjoyable.
Page 5: Assembly
ASSEMBLY Assembly requires two persons. Place all parts of the exercise cycle in a cleared area and remove the packing materials. Do not dispose of the packing materials until assembly is completed. In addition to the included tool(s), assembly requires an adjustable wrench and a Phillips screwdriver .
Page 6 Step 1: 1. Fix the Front bottom tube (3) to the Main frame (1) with Bolts (20), Arc washers (21), Nuts (22). 2. Fix the Rear bottom tube (2) to the main frame (1) with Bolts (55) and Arc washers(54). Step 2: 1.
Page 7 Step 3: 1. Attach the left and right Swing tube (6L/R) to the Handlebar post (4) with Bolt (28), spring washer (27) and Flat washer (63), but don’t tighten then first. 2. Attach the left Pedal support (5L) to the Crank (60) with Bolt (51), spring washer (52), D-shape washer (30) and Wave washer (33), then tighten the bolts (51) &...
Page 8 Step 5: 1. Fix the Protective guards (18L/R) to the Pedal supports (5L/R) with Screws (36). 2. Fix the Protective guards (19a/b) to the Pedal tube joints (43L/R) with Screws (44). Step 6: 1. Fix the Handlebars (7L/R) to the Swing tubes (6L/R) respectively with Bolts (34) and Nylon nuts (35). 2.
Page 9 Step 7: 1. Connect the Connection wire (25) and Pulse wire (47) to the wires of Computer (10), and then fix the Computer (10) to the computer bracket of the Handlebar post (4) with Screws (49) and Flat washers (48). 2.
Page 10: How To Plug The Power Adapter
HOW TO PLUG THE POWER ADAPTER IMPORTANT: If the exercise bike has been exposed to cold temperatures, allow it to warm to room temperature before plugging in the power adapter. If you do not do this, you may damage the console displays or other electronic components.
Page 11: How To Operate The Elliptical
HOW TO USE THE ELLIPTICAL HOW TO EXERCISE ON THE ELLIPTICAL MEASURE YOUR HEART RATE IF DESIRED EXERCISER You can measure you heart rate using the To mount the elliptical exerciser, hold the upper body handgrip pulse sensor. arms and step onto the pedal that is in the lowest position.
Page 12: Features Of The Console
CONSOLE FEATURES Press this button to use the Pulse recovery test (only available at the end of a program). BODY FAT : Press this button to use the body fat test. Once you’ve entered your personal data (Gender, Age, Weight, Height), press this button.
Page 13 3. Select the manual mode. The profile will flash on the display and you will still Once the user is selected, the word STOP as well as be able to modify the profile course by increasing or the different programs (Manual, PROGRAM, WATT, decreasing the difficulty.
Page 14 5. When you are finished exercising, the console will WORKOUT» will appear on the display. Press ENTER to automatically turn off have the selection of programs appear. Turn the knob to If the pedals do not move for a few seconds, the word select the program : MANUAL, PROGRAM, USER PRO, STOP will appear in the display, and the console will turn HRC (Heart Rate) and WATT.
Page 15: Exercise Guidelines
EXERCISE GUIDELINES WARNING: Burning Fat—To burn fat effectively, you must exer- cise at a low intensity level for a sustained period of time. During the first few minutes of exercise, your Before beginning this or any exercise pro- body uses carbohydrate calories for energy. Only af- gram, consult your physician.
Page 16: Exploded Drawings
EXPLODED DRAWING—Model No. WLIVEL87912.0 part 1...
Page 17 EXPLODED DRAWING—Model No. WLIVEL87912.0 part 2...
Page 18: Part List
PART LIST—Model No. WLIVEL87912.0 Item Description Qty. Item Description Qty. Main frame Bolt M8×90 Rear bottom tube Protective guard Front bottom tube screw ST3.5*13 Handlebar post Post cover Pedal support screw ST4.2*18 Swing tube Crank Handlebar Nylon nut M8 Fixed handlebar Nylon nut M10 Foam grip Flat washer Φ8.2×Φ32×2...
Page 19: Maintenance And Troubleshooting
MAINTENANCE AND TROUBLESHOOTING IInspect and tighten all parts of the exercise cycle small amount of mild detergent. regularly. Important: To avoid damaging the console, keep Replace any worn parts immediately. liquids away from the console and keep the console To clean the exercise cycle, use a damp cloth and a out of direct sunlight.
Page 20: Ordering Replacement Parts
ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
