Model No. : WLIVEL86172.0
Serial No ___________
Serial number decal
Write the serial number in the
space above for reference.
QUESTIONS ?
If you have questions, or if there are
missing parts, please contact us:
UK
Call: 08457 089 009
From Ireland: 053 92 36102
Website: www.iconsupport.eu
E-mail: csuk@iconeurope.com
Write:
ICON Health & Fitness, Ltd.
c/o HI Group PLC
Express Way
Whitwood, West Yorkshire
WF10 5QJ
UK
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
USERʼS MANUAL
Visit our website
www.iconsupport.eu

Advertisement

Table of Contents
loading

Related Manuals for Weslo EasyFit WLIVEL86172.0

Summary of Contents for Weslo EasyFit WLIVEL86172.0

  • Page 1 USERʼS MANUAL Model No. : WLIVEL86172.0 Serial No ___________ Serial number decal Write the serial number in the space above for reference. QUESTIONS ? If you have questions, or if there are missing parts, please contact us: Call: 08457 089 009 From Ireland: 053 92 36102 Website: www.iconsupport.eu E-mail: csuk@iconeurope.com...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS IMPORTANT PRECAUTIONS ..............3 BEFORE YOU BEGIN .

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING : To reduce the risk of serious injury, read all important precautions and instructions in this manual and all warnings on your elliptical before using your elliptical. ICON assumes no responsibility for personal injury or property damage sustained by or through the use of this product.

  • Page 4: Before You Begin

    BEFORE YOU BEGIN Thank you for purchasing the WESLO® Easy Fit. number and serial number before contacting us. The elliptical provides an array of features de- The model number is WLIVEL86172.0 and the lo- signed to make your workouts at home more ef- cation of the serial number decal are shown on the fective and enjoyable.

  • Page 5: Assembly

    ASSEMBLY Assembly requires two persons. Place all parts of the exercise cycle in a cleared area and remove the packing materials. Do not dispose of the packing materials until assembly is completed. In addition to the included tool(s), assembly requires an adjustable wrench and a Phillips screwdriver .
  • Page 6 STEP 1 Fix the Front bottom tube (2) and the Rear bottom tube (3) onto the Main frame (1) with the Allen pan head screw (7) and Curved washer (9) as shown. STEP 2 1. Insert the Handlebar post cover (14) into the Handlebar post (17) and then connect the Connec- tion Wire (15) well with the Sensor wire (12).
  • Page 7 STEP 3 1. Fix the Right swing tube(28R) onto the Handle- bar post(17) with the Bolt(55) and the Flat wash- er(54). Note: First not tight them up. 2. Fix the Right pedal support tube(41R) onto the Crank(10) with the Pedal bolt(43) and the Wave shape washer(44),and then attach the Thin spring washer(50) and the Nylon nut(51).
  • Page 8 STEP 5 1.Fasten the Handlebar(27R/L) with the Bolt(29) the Curved washer(30) and the Cap nut(25) onto the Swing tube(28L/R). 2. Connect the Pulse sensor wire (57) and the Connection wire (15) with the wires of console (19) respectively, and then fasten the console (19) onto the console bracket of the Handlebar post (17) with the Cross pan head screw (21).

  • Page 9: How To Plug The Power

    HOW TO PLUG THE POWER ADAPTER IMPORTANT: If the exercise bike has been exposed to cold temperatures, allow it to warm to room temperature before plugging in the power adapter. If you do not do this, you may damage the console displays or other electronic components.

  • Page 10: How To Operate The Elliptical

    HOW TO USE THE ELLIPTICAL HOW TO EXERCISE ON THE ELLIPTICAL MEASURE YOUR HEART RATE IF DESIRED EXERCISER You can measure you heart rate using either the To mount the elliptical exerciser, hold the upper body handgrip pulse sensor or the optional chest pulse arms and step onto the pedal that is in the lowest sensor.

  • Page 11: Features Of The Console

    CONSOLE FEATURES 2. UP: a.Press this button to increase the resistance during the workout. b. During the setting mode press this button to increase the values of Time, Distance, Calories, Age or gender or the programs. 3. DOWN : a.Press this button to decrease the resistance during the workout.
  • Page 12 HOW TO USE THE MANUAL MODE heart rate along with the other modes. If your heart rate is not shown, make sure that your hands are 1. Turn on the console. positioned as described. Be careful not to move your hand excessively or to squeeze the metal contacts To turn on the console, press the On/Reset button too tightly.
  • Page 13 HEART RATE CONTROL PROGRAMS : 1. Turn on the console To turn on the console, press any button on the console or simply begin pedaling. 2.Select your preset program Press the ENTER button during the STOP mode (STOP will flash on the display) then press UP or DOWN to select a program from 8 to 11.

  • Page 14: Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING IInspect and tighten all parts of the exercise cycle small amount of mild detergent. regularly. Important: To avoid damaging the console, keep Replace any worn parts immediately. liquids away from the console and keep the console To clean the exercise cycle, use a damp cloth and a out of direct sunlight.

  • Page 15: Exercise Guidelines

    EXERCISE GUIDELINES WARNING: Burning Fat—To burn fat effectively, you must exer- cise at a low intensity level for a sustained period of time. During the first few minutes of exercise, your Before beginning this or any exercise pro- body uses carbohydrate calories for energy. Only af- gram, consult your physician.

  • Page 16: Exploded Drawings

    EXPLODED DRAWING—Model No. WLIVEL86172.0 part 1...
  • Page 17 EXPLODED DRAWING—Model No. WLIVEL86172.0 part 2...

  • Page 18: Part List

    PART LIST—Model No. WLIVEL86172.0 Item Description Qty. Item Description Qty. Main frame Nylon nut B0.5×20 Front bottom tube Collar cap S19 Rear bottom tube Axle bushing 1 Φ26.8×28 Front end cap Flat washer Φ8.2×Φ32×2 Rear end cap Hex bolt M8x15 Cross pan head screw ST4.2X18 Pedal tube connector Allen pan head screw M8×L75...

  • Page 19: Notes

    Notes :...

  • Page 20: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
