www.weslo.com
Model No. WLEL61610.0
USER’'S MANUAL
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal (under frame)
QUESTIONS?
If you have questions, or if parts
are damaged or missing, DO NOT
CONTACT THE STORE; please
contact Customer Care.
IMPORTANT: Please register this
product (see the limited warranty
on the back cover of this manual)
before contacting Customer Care.
CALL TOLL-FREE:
1-866-699-3756
Mon.––Fri., 6 a.m.––6 p.m. MT
Sat. 8 a.m.––4 p.m. MT
ON THE WEB:
www.wesloservice.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Momentum G 3.1 Elliptical and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Weslo Momentum G 3.1 Elliptical

Summary of Contents for Weslo Momentum G 3.1 Elliptical

  • Page 1 Model No. WLEL61610.0 USER’’S MANUAL Serial No. Write the serial number in the space above for reference. Serial Number Decal (under frame) QUESTIONS? If you have questions, or if parts are damaged or missing, DO NOT CONTACT THE STORE; please contact Customer Care.

  • Page 2: Table Of Contents

    If a decal is missing or illegible, see the front cover of this manual and request a free replacement decal. Apply the decal in the location shown. Note: The decal(s) may not be shown at actual size. WESLO is a registered trademark of ICON IP, Inc.

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read all important precautions and instructions in this manual and all warnings on your elliptical before using your elliptical. ICON assumes no responsibility for personal injury or property damage sustained by or through the use of this product.

  • Page 4: Before You Begin

    Thank you for selecting the revolutionary WESLO reading this manual, please see the front cover of this ® MOMENTUM G 3.1 elliptical. The MOMENTUM G manual. To help us assist you, note the product model 3.1 elliptical provides a selection of features designed number and serial number before contacting us.

  • Page 5: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity needed for assembly.

  • Page 6: Assembly

    ASSEMBLY •• To hire an authorized service technician to •• In addition to the included tool(s), assembly assemble the elliptical, call 1-800-445-2480. requires the following tools: one Phillips screwdriver •• Assembly requires two persons. one adjustable wrench •• Place all parts in a cleared area and remove the packing materials.
  • Page 7 3. Insert the Resistance Cable (25) through the Upright (2) as shown. Then, attach the Resistance Control (25) to the Upright with an M5 x 20mm Screw (76) and an M5 Washer (77). While a second person holds the Upright (2) near the Frame (1), connect the Wire Harness (31) to the Reed Switch Wire (47).
  • Page 8 5. Attach the Water Bottle Holder (69) to the Upright (2) with two ST4.2 x 20mm Self-tapping Screws (68) and two M4 Washers (71). 6. Identify the Right Upper Body Arm (6), which is marked with a sticker, and orient it as shown. Next, orient an Upper Body Leg (64) so that the hexagonal holes are on the side shown.
  • Page 9 7. Using a plastic bag to keep your hands clean, apply a generous amount of the included grease to the right axle on the Upright (2) and to a Wave Washer (74). Next, orient an Upright Spacer (26) as shown. Slide the Upright Spacer and the Wave Washer (74) onto the right axle on the Upright (2).
  • Page 10 9. Identify the Right Pedal Arm (12), which is marked with a sticker. Orient the Right Pedal Arm and one of the Pedals (13) as shown. Attach the Pedal (13) to the Right Pedal Arm (12) with two M8 x 16mm Bolts (52), an M8 x 55mm Bolt (61), three M8 Washers (55), and three M8 Locknuts (58).
  • Page 11 11. Apply grease to an M10 x 70mm Bolt (60). Attach the Right Pedal Arm (12) to the right Upper Body Leg (64) with the M10 x 70mm Bolt (60), two M10 Special Washers (80), two M10 Split Washers (78), two M10 Washers (62), two Nylon Washers (73), and an M10 Locknut (53) as shown.

  • Page 12: How To Use The Elliptical

    HOW TO USE THE ELLIPTICAL HOW TO MOVE THE ELLIPTICAL HOW TO LEVEL THE ELLIPTICAL To move the elliptical, first stand in front of the elliptical, If the elliptical rocks slightly on your floor during use, hold the upright, and place one foot against one of the turn one or both of the leveling caps on the rear stabi- wheels.
  • Page 13 HOW TO EXERCISE ON THE ELLIPTICAL FEATURES OF THE CONSOLE To mount the elliptical, hold the upper body arms The console offers a selection of features designed to and step onto the pedal that is in the lowest position. make your workouts more effective. As you pedal, the Next, step onto the other pedal.
  • Page 14 HOW TO USE THE CONSOLE To select the speed, time, 1. Turn on the console. distance, or calories mode To turn on the console, press the Display Mode for continuous button or begin pedaling. The display will turn on display, press for a moment;...

  • Page 15: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING Inspect and tighten all parts of the elliptical regularly. Next, carefully pull the Right Shield (4) outward and Replace any worn parts immediately. upward until you can reach the Idler Adjustment Bolt (34). Be careful to avoid scratching the Right Shield To clean the elliptical, use a damp cloth and a small on the Right Thin Locknuts (36).

  • Page 16: Exercise Guidelines

    EXERCISE GUIDELINES Aerobic Exercise——If your goal is to strengthen your WARNING: cardiovascular system, you must perform aerobic Before beginning this exercise, which is activity that requires large amounts or any exercise program, consult your physi- of oxygen for prolonged periods of time. For aerobic cian.

  • Page 17: Part List

    PART LIST Model No. WLEL61610.0 R0912A Key No. Qty. Description Key No. Qty. Description Frame Small Flywheel Axle Nut Upright Reed Switch/Wire Left Shield Clip Nut Right Shield Stop Washer Left Upper Body Arm Flywheel Spacer Right Upper Body Arm M8 x 80mm Button Screw Idler Assembly M8 x 16mm Bolt...

  • Page 18: Exploded Drawing

    EXPLODED DRAWING A Model No. WLEL61610.0 R0912A...
  • Page 19 EXPLODED DRAWING B Model No. WLEL61610.0 R0912A...

  • Page 20: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: •• the model number and serial number of the product (see the front cover of this manual) ••...
