Installation Guide
Rear Trim/Curb Base Accessories
7 Series Ranges/Rangetops

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Viking Range 7 Series

Summary of Contents for Viking Range 7 Series

  • Page 1 Installation Guide Rear Trim/Curb Base Accessories 7 Series Ranges/Rangetops...
  • Page 2 Rear Trim Accessories WARNING To reduce the risk of fi re or injury to persons, check to make sure all packaging has been removed from the outside and inside parts of the rear trim device before installing. MAKE SURE ALL CORRUGATED MATERIAL IS REMOVED FROM INSIDE THE HIGH SHELF.
  • Page 3 6” (15.2 cm) of minimum clearance to a rear wall, or when a truly non- combustible material is used, will the warranty apply. In no case will Viking Range, LLC accept responsibility for any claims which may result from heat damage against a rear wall, including cosmetic damage.
  • Page 4 Rear Trim Accessories COUNTERTOP REAR TRIM 1. Locate screw hole openings (A) on the back of the island trim near the top. 2. Align screw hole openings on the countertop rear trim with the ones on the back of the island trim. 3.
  • Page 5 Curb Base Accessories STANDARD CURB BASE FRONT 1. The standard curb base front (A) is completely assembled. 2. Remove the assembly from the carton and simply clip onto the front range legs. 3. The assembly is adjustable about 2” (5.1 cm) front to back so that alignment with the cabinet toe front is possible. Loosen bracket bolts on each side, but allow snug fi...
  • Page 6 Curb Base Accessories CUSTOM CURB BASE FRONT 1. Remove the standard curb base front assembly from the carton. 2. Remove the front (A) from the mounting assembly (B). 3. Attach locally supplied front (C) to the mounting assembly (B) and simply clip onto the front range legs. Important Note: The locally supplied front must not be any taller than 3-1/8”...
  • Page 8 Viking Range, LLC 111 Front Street Greenwood, Mississippi 38930 USA (662) 455-1200 For product information, call 1-888-(845-4641) or visit the Viking Web site at vikingrange.com in the U.S. or brigade.ca in Canada. F21412 EN (083114)
