EXP MODE BUTTON & LEDs – The EXP. MODE button chooses the destination
parameter for an external expression pedal or control-voltage to modulate. The
lit LED indicates the selected mode. Each time you push and release the EXP.
MODE button it jumps to the next Expression Mode. When no EXP. MODE LEDs
are lit, the expression pedal/CV is disconnected and does not sweep any of the
parameters. Please note: in the following table, the expression pedal's heel
position relates to 0V from the CV source, the expression pedal's toe position
relates to 5V from the CV source. See EXP Jack on Page 10 for more information.
EXP. MODE
RATE
DEPTH
SHAPE
PHASE
VOLUME
BYPASS FOOTSWITCH & STATUS LED – Press and release the BYPASS
footswitch to toggle between effect mode and true bypass mode. When the
Status LED is lit, Super Pulsar is in effect mode. When the Status LED is off,
Super Pulsar is in true bypass mode. The Status LED is located above the
BYPASS footswitch. The Super Pulsar always starts up in bypass mode.
EXP. MODE Description
Allows external control over Super Pulsar's modulation rate
whether it is set by the RATE knob or TAP footswitch.
TEMPO MASTER
RATE Knob
TAP Footswitch
Allows smooth external control over the tremolo or pan Depth.
In this mode, the heel position will yield a Depth of 0, the toe
position equals the current DEPTH knob setting.
For Sine, Triangle and Pulse waveforms, this mode allows
smooth external control over the SHAPE knob. The heel
position yields the SHAPE knob at its full counter-clockwise
setting while the toe position will be equal to the SHAPE
knob's current setting.
When WAVE is set to RHYTHM, the expression SHAPE setting
controls the RHYTHM pulse length. The heel position sets the
RHYTHM pulse length to its minimum; the toe position equals
the current position of the WAVE knob.
Allows smooth external control of the Right Channel's RT.
PHASE setting. The heel position equals a Phase of 0, the toe
position equals the current setting of the RT. PHASE knob.
Allows smooth external control over output volume of the
Super Pulsar. The heel position equals a Volume of 0, the toe
position equals the current setting of the VOLUME knob.
HEEL POSITION
RATE Knob's
minimum position
Tapped In Time
plus TAP DIVIDE
setting
8
TOE POSITION
RATE Knob's current
position
Very fast multiple of
TAP Time plus TAP
DIVIDE setting
