Electro-Harmonix Q-TRON Operating Instructions

- WARRANTY INFORMATION -
Please register online at http://www.ehx.com/product-registration or complete and return the enclosed
warranty card within 10 days of purchase. Electro-Harmonix will repair or replace, at its discretion, a product
that fails to operate due to defects in materials or workmanship for a period of one year from date of
purchase. This applies only to original purchasers who have bought their product from an authorized Electro-
Harmonix retailer. Repaired or replaced units will then be warranted for the unexpired portion of the original
warranty term.
If you should need to return your unit for service within the warranty period, please contact the appropriate
office listed below. Customers outside the regions listed below, please contact EHX Customer Service for
information on warranty repairs at info@ehx.com or +1-718-937-8300. USA and Canadian customers: please
obtain a Return Authorization Number (RA#) from EHX Customer Service before returning your product.
Include with your returned unit: a written description of the problem as well as your name, address,
telephone number, e-mail address, and RA#; and a copy of your receipt clearly showing the purchase date.
United States & Canada
EHX CUSTOMER SERVICE
ELECTRO-HARMONIX
c/o NEW SENSOR CORP.
55-01 2ND STREET
LONG ISLAND CITY, NY 11101
Tel: 718-937-8300
Email: info@ehx.com
Europe
JOHN WILLIAMS
ELECTRO-HARMONIX UK
13 CWMDONKIN TERRACE
SWANSEA SA2 0RQ
UNITED KINGDOM
Tel: +44 179 247 3258
Email: electroharmonixuk@virginmedia.com
This warranty gives a purchaser specific legal rights. A purchaser may have even greater rights depending
upon the laws of the jurisdiction within which the product was purchased.
To hear demos on all EHX pedals visit us on the web at www.ehx.com
Email us at info@ehx.com
FCC COMPLIANCE
This equipment has been tested and found to comply with the limits for a Class B digital device,
Note:
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and receiver.
•
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
•
Consult the dealer or an experienced radio/TV technician for help.
Modifications not expressly approved by the manufacturer could void the user's authority to operate the
equipment under FCC rules.
Q-TRON
Envelope Controlled Filter
-OPERATING INSTRUCTIONS-
Congratulations on your purchase of the Q-Tron envelope controlled filter! You have
purchased a very powerful tool for musical expression.
Please take a few minutes to familiarize yourself with the Q-Tron's controls and how they
work.
Envelope controlled filters are a unique type of sound modifier where the intensity of the
effect is controlled by the user's playing dynamics.
The volume (also know as the envelope) of an incoming audio signal is used to control a
swept filter. As the volume increases or decreases so does the pitch of the filter.
-CONTROLS-
Drive Switch (Up/Down) – Selects direction of filter sweep
Range Switch (HI/Lo) – Emphasizes vowel-like sound in low position and overtones in high
position.
Gain Control (0-11) – Functions as both a volume control and a filter sensitivity control in
boost mode. In Normal mode the Gain control acts as a filter sensitivity control and has no
effect on the unit's output volume.
Boost Switch (Normal/Boost) – Normal mode disengages internal pre-amp, Boost mode
activates it. Also determines function of Gain control (see above).
Peak Control (0-11) – Determines frequency peak of filter. This control will create a more
dramatic effect when turned clockwise.
Mode Switch (LP, BP, HP, MIX) – Determines what frequency range the filter will sweep in.
Emphasizes lows in Low Pass, midrange in Band Pass, treble in High Pass. Mix mode
combines BP with dry instrument signal.
Bypass Switch (in/out) – Disengages effect.
Lastly, the Q-Tron's effect can be controlled by the user's playing dynamics. A strong attack
will yield a more dramatic effect, while softer playing will yield more subtle effects or none at
all.
