save it to presets. You can only access a preset's MODE assignment
when using an external switch to load presets, see page 11.
Please note: the buttons on the Super Pulsar will continue to work
normally even if they are assigned to the MODE footswitch.

CHANGING TO NORMAL MODE FROM PRESET MODE:

1. Press and hold the MODE footswitch.
2. After approximately 2 seconds of holding down MODE, the
waveform LEDs begin displaying the current modulation
waveform. You are now in Normal mode.
INPUT, OUTPUT & POWER JACKS
MONO / Left Input Jack – This is the main audio input for Super Pulsar. When
using Super Pulsar in a mono-in setup, use this input jack. When using Stereo
Pulsar in a stereo-in set up this would be your left input. The minimum input
impedance presented at this jack is 1MΩ.
Right Input Jack – This is the secondary audio input for Super Pulsar. When
using Super Pulsar in a stereo-in setup, connect your right channel to this input.
When using a mono-in setup, we recommend you do not connect to this input.
The input impedance presented at this jack is 2MΩ.
MONO / Left Output Jack – This is the main audio output for Super Pulsar.
When using Super Pulsar in a mono-out setup, use this output jack. This is the
Left output for a stereo-out configuration. The output impedance at this jack is
300Ω.
Right Output Jack – This is the secondary audio output for Super Pulsar.
When using Super Pulsar in a stereo-setup, connect your right channel to this
output. The output impedance at this jack is 300Ω.
EXP Jack – Connect an expression pedal with a TRS plug to this jack to control
the following parameters with your foot: RATE, DEPTH, SHAPE, PHASE and
VOLUME. Additionally the EXP IN jack can be connected to a CV source using a
TS plug; the acceptable control voltage range is 0V to 5V. Some suggested
Expression Pedals: EHX Expression Pedal, M-Audio
Roland ® EV-5 or Boss
have the Sleeve connected to the heel position (usually GND), Ring connected to
the toe position and the Tip connected to the wiper. The nominal expression
pedal impedance is 10kΩ though most other values will work fine. Please do not
go below 6kΩ on your expression pedal's potentiometer impedance.
TAP/CLK IN Jack – This jack accepts up to 3 external footswitches allowing
you to set the TAP time and control up to 2 other functions. Additionally, you can
set the Super Pulsar to accept clock pulses on the Tip conductor of this jack,
instead of switches, so that an external clock sets the Tap time. We recommend
powering down Super Pulsar when connecting or disconnecting your external
switches to the TAP/CLK IN jack.
® FV-500L. The polarity of the expression pedal's plug must
® EX-P, Moog
10
® EP-2 and EP-3,
