BYPASS Signal Flow: Here are the signal flows for Bypass mode only:
MONO In/Out: MONO / L Input connects directly to MONO / L Output.
MONO In/STEREO Out: MONO / L connects directly to both L and R
Outputs.
STEREO IN/MONO Out: MONO / L connects directly to MONO / L
Output, the R Input is disconnected in Bypass.
STEREO IN/OUT: MONO / L Input connects directly to MONO / L
Output; R Input connects directly to R Output.
The BYPASS footswitch is also used when saving presets, see the Preset section
on page 13 for more information.
MODE FOOTSWITCH – The MODE footswitch is a utility button that may be re-
assigned by the musician. It has 2 modes of operation: Normal mode and Preset
mode. In Normal mode, which is the factory default, the MODE footswitch can
adopt the functionality of one of the following push buttons: TAP DIVIDE (factory
default), EXP MODE, xRATE or WAVE INVERT. While in Preset mode, the MODE
footswitch cycles through and loads the 8 presets. The following paragraphs
describe how to use each mode. Please note: the MODE footswitch will advance
whatever parameter it is currently assigned to upon releasing the footswitch, not
when you first press down on it.
NORMAL Mode – While in this mode, which is the factory default,
each press and release of the MODE footswitch cycles through its
assigned function. At the factory we assign MODE to TAP DIVIDE.
Here's how to assign MODE to another function:

RE-ASSIGNING MODE FOOTSWITCH TO A NEW FUNCTION:

1. First make sure you are in Normal or WYSIWYG (What You
See Is What You Get) mode. If the waveform LEDs at the top
of Super Pulsar are displaying the current modulation
waveform then you are good. If not, see the following section
called CHANGING TO NORMAL MODE FROM PRESET MODE.
2. Press and hold the button you would like to assign to
the MODE footswitch. The buttons that can be assigned to
MODE are TAP DIVIDE, EXP MODE, xRATE and WAVE INVERT.
3. Now press and hold the MODE footswitch. Continue to
press and hold both buttons until either all the LEDs for the
function light up or the sole LED for the function blinks.
4. Once you see all the LEDs for the newly assigned
function light up or blink, release both the button and
MODE footswitch. The MODE footswitch has been re-
assigned.
Please note: after re-assigning MODE to a new function, Super
Pulsar remembers the new assignment during power cycles and will
