Congratulations on your purchase of the Grand Canyon, a superior sounding,
massively powerful Delay and Looper pedal. Within the Grand Canyon are a vast
array of awe-inspiring effects. Explore a wide range of delays and textures,
including pristine or bitcrushed digital, exquisite Deluxe Memory Man, rhythmic
drum, warm tape, plate reverb, polyphonic pitch shift, and ethereal shimmer. The
Grand Canyon even has a full-featured looper which can be used simultaneously
with any of the delay effects to conjure lush, layered soundscapes. Fine tune the
effects with a broad array of intuitive controls, and you're in for a truly inspiring
and grand experience.
WARNING: Your Grand Canyon comes equipped with an Electro-Harmonix 9.6DC-200BI
power supply. The Grand Canyon requires 150mA at 9VDC with a center negative plug.
Use of the wrong adapter or a plug with the wrong polarity may damage your Grand
Canyon and void the warranty. Do not exceed 10.5VDC on the power plug. Power supplies
rated for less than 150mA will cause the Grand Canyon to act unreliably.
 12 Delay Types yield a wide range of delay and echo effects
 Up to 3 seconds of delay time
 TAP footswitch with 9 Tap Divide settings for precise delay times
 Stereo output produces stereo delay and ping pong effects
 Up to 16 minutes of recording time on the full-featured looper which includes
unlimited overdubs, undo/redo, a dedicated stop button, loop fade-out,
reverse, and speed adjustment
 The Looper can record and overdub the internal stereo delay effects
 Loop audio remains in the Grand Canyon until you erase it, even after removing
power from the unit
 Easy pushbutton access to extra features like delay tails, momentary effect
mode, and ping-pong output
 13 Presets may be saved and recalled: one preset for each delay type and one
for the looper
 Programmable expression pedal settings allow you to control any combination
of the Grand Canyon's knobs with an external expression pedal
 Connector for external 1-, 2- or 3-button footswitch allows for added control
 High quality buffered analog bypass and soft switching
GRAND CANYON
Multifunction Delay & Looper
- FEATURES -
1
