Summary of Contents for Russell Hobbs RH8CTD600
-
Page 1: Instruction Manual
8kg Condenser Tumble Dryer Instruction manual Model number: RH8CTD600(B)(R) IMPORTANT: RETAIN FOR FUTURE REFERENCE For Customer Services & Spare Parts please call 0345 208 8750 Opening times: Monday - Friday 8am – 8pm & Saturday 9am – 1pm or visit us at www.productcareuk.com... -
Page 2: Table Of Contents
Contents Safety information ………………………………… 3 - 6 Before using your appliance ………………………………… Control panel ………………………………… 8 - 9 Installation ………………………………… 10 - 11 Operating instructions ………………………………… 12 - 16 Programme table ………………………………… Care and maintenance ………………………………… 18 - 19 Trouble shooting …………………………………... -
Page 3: Safety Information
Important information • This tumble dryer is intended for NORMAL DOMESTIC USE ONLY. • Adequate ventilation must be provided around the tumble dryer. • Exhaust air must not be discharged into a flue which is used for exhausting other fumes from appliances burning gas or other fuel. •... - Page 4 Important information • The special mains cable and plug assembly must only be replaced with a genuine part from the manufacturer, please contact the customer support team below . • It is important to clean fluff from the window of the dryer and around the door seal after each drying cycle.
- Page 5 Important information • Make sure clothing is fully rinsed of detergent and stain remover, before placing in the tumble dryer. • Do not put combustible liquid or solids, such as oil, gasoline, petrol and alcohol into the appliance or nearby. •...
- Page 6 Warnings WARNING: Never stop a tumble dryer before the end of a drying cycle, unless the items are removed very quickly • Do not use a two-way adaptor, or extension lead. The dryer must be connected to its own socket. •...
-
Page 7: Before Using Your Appliance
Before using your appliance Before installation, check that all parts are present. If any parts are missing, please contact the product care service team on: 0345 208 8750. Feature Diagram Note: The drawings in the book may vary from your dryer. They are designed to show the different features of all models covered by this book. -
Page 8: Control Panel
Control panel 1. On/Off (see page 13) Press the button to turn the dryer on and off 2. Programme dial (see page 14 & 17) Choose the correct programme for the load by selecting one of the 12 programmes. 3. Gentle button & indicator (see page 13) To reduce the temperature your laundry is dried at. - Page 9 8. LED display (see page 15) The displays will show the below information: • Approximate time duration of a programme when selected • Counts down the time of a programme after it has been started • How long a programme has been delayed by (if selected). •...
-
Page 10: Installation
Installation Your condenser tumble dryer removes humidity by using two separate air flows. Air re- circulates inside the machine and is heated. Then it is passed through the damp clothes where it picks up moisture. Damp air is passed through the condenser in one direction while the room air is passed through the condenser in the other direction. -
Page 11: Installation
Installation Connection to water drain; 1. Remove the hose on the rear of the machine by pulling it out from its end. Do not use any tools to take out the hose. 2. Connect the drain hose supplied with the machine to the pipe fitting. 3. -
Page 12: Operating Instructions
Operating instructions IMPORTANT NOTE - If you are drying laundry that weighs less than 1kg (small loads) when wet, then select the 1hr function to dry clothes. Remove all the packaging material, including any material inside the drum. Before using the appliance for the first time, it is advised to place two damp clothing articles inside the drum and dry them for 1 hour. - Page 13 Operating instructions Step 3 – Switch on the dryer and select the required programme. Press the start/stop button and the airing indicator will light up on the dryer status light indicators. The drum will begin rotating and will stop when the selected programme has finished. Each setting has the availability to add anti-crease and time delay to them but these have to be selected prior to the drying cycle being confirmed (they cannot be added or changed mid-cycle).
- Page 14 Operating instructions Anti-crease This button must be pressed prior to the drying cycle being started. This function will reduce the creasing of clothes. Anti-crease indicator When lit constantly it indicates that the anti-crease function has been activated. Child Lock To use the child lock function you must hold the gentle and anti crease buttons at the same time for 4 seconds once a cycle has started.
-
Page 15: Reversing The Door
Operating instructions LED display The displays will show the below information: • Approximate time duration of a programme when selected • Counts down the time of a programme after it has been started: the REMAIN icon will light up to indicate the programme time is counting down. •... - Page 16 Operating instructions • Never tumble dry the following; Delicate items such as net curtains, woollen items, silk items, items with metal trims, nylon tights, bulky items such as blankets, or sleeping bags, feather quilts and items containing or including rubber foam. •...
-
Page 18: Care And Maintenance
Care and maintenance ALWAYS CLEAN THE FILTER AFTER EACH USE. Failure to do so could cause the safety cut- out to operate. - Pull the filter upwards from the appliance. - Open the filter and remove any threads or fluff by hand or with a soft brush. Pull to open - Close the filter and slide it back into place. -
Page 19: Care And Maintenance
Care and maintenance Emptying the water tank. The water extraction from the wet laundry that has been dried deposits in a water tank at the top left corner. Fully remove the water tank and empty the contents down a sink, then clean the tank and replace. -
Page 20: Trouble Shooting
Trouble shooting If the clothes are not dry after normal drying time: • If you are drying laundry that weighs less than 1kg (small loads) when wet. Then the Time programme must be used and the time set to 60 minutes •... - Page 21 Warnings and error codes Problem Reason Solution Empty the water tank, if the symbol still flashes after the water tank has been emptied Water tank full or then there may be a is flashing pump error problem with the pump Contact product care.
-
Page 22: Technical Specification
Technical specification Brand Russell Hobbs Model RH8CTD600(B)(R) Type of dryer Condenser Energy efficiency rating Capacity (kg) Weight (kg) 40.5 Dimensions (CMs) (H)84.5 x (W)59.5 x (D)61.5 Product fiche Energy consumption 561.0kWh per year, based on 160 drying cycles of the standard cotton programme at full and partial load, and the consumption of the low-power modes. -
Page 23: Connection To Mains Supply
Connections to the mains supply WARNING- THIS APPLIANCE MUST BE EARTHED This appliance is designed to operate from a mains supply of AC230V ~ 50HZ. Check that the voltage marked on the product corresponds with your supply voltage. This product is fitted with a 13A plug complying with BS1363. If this plug is unsuitable or needs to be replaced, please note the following: Important: The wires in the mains lead are Coloured in accordance with the following code:... -
Page 24: Guarantee
Guarantee This product is guaranteed for 12 months from the date of the original purchase. If any defect arises due to faulty materials or workmanship the faulty product must be returned to the place of purchase. Refund or replacement is at the discretion of the retailer. The following conditions apply: •... -
Page 25: Notes
Notes For Customer Services & Spare Parts please call 0345 208 8750 Opening times: Monday - Friday 8am – 8pm & Saturday 9am – 1pm or visit us at www.productcareuk.com... - Page 26 Notes For Customer Services & Spare Parts please call 0345 208 8750 Opening times: Monday - Friday 8am – 8pm & Saturday 9am – 1pm or visit us at www.productcareuk.com...
- Page 27 Notes For Customer Services & Spare Parts please call 0345 208 8750 Opening times: Monday - Friday 8am – 8pm & Saturday 9am – 1pm or visit us at www.productcareuk.com...
- Page 28 For Customer Services & Spare Parts please call 0345 208 8750 Opening times: Monday - Friday 8am – 8pm & Saturday 9am –1pm or visit us at www.productcareuk.com Revision 1 This symbol is known as the 'Crossed-out wheelie bin Symbol'. When this symbol is marked on a product/batteries, it means that the product/batteries should not be disposed of with your general household waste.
