- Page 1 Owner’s Manual SUONO 25W Class A Single Ended Power Amplifier www.lab12.gr manual v1.1...
- Page 2 LAB12 SUONO 25W Class A Single Ended Power Amplifier Table of Contents It is yours Features Installation & Placement Front Panel Rear Panel Main connections For the safety of your equipment Specifications...
- Page 3 LAB12 SUONO 25W Class A Single Ended Power Amplifier IT IS YOURS! Thank you for selecting the LAB12 SUONO, an audiophile Class A power amplifier. Every component on it is designed to provide smooth and untreated sound. It is a full tube amplifier with 6n2p NOS Russian driver tubes and 6550 Russian on power stage.
- Page 4 LAB12 SUONO 25W Class A Single Ended Power Amplifier Features • KT150 matched tubes • Manual Bias Adjustment • Triode / ultra linear selector switch • Handcrafted custom audio grade transformers • No feedback design • High power transformer • Special audio grade matched parts in every stage •...
-
Page 5: Front Panel
LAB12 SUONO 25W Class A Single Ended Power Amplifier Front Panel SUONO Front panel At front panel you will see three indication LEDs and two VU meters. The three LEDs (C) indicates that the device is powered on. To the left of 3 LEDs you see a retro analog VU meter (A). You can accurately monitor the output level of left channel on dB scale. -
Page 6: Rear Panel
LAB12 SUONO 25W Class A Single Ended Power Amplifier Rear Panel SUONO Rear panel In rear panel you will find the connection inputs and outputs. To the right side you will find an IEC AC input. Below IEC input (A) is located the main fuse holder (B) and the Power switch (C). -
Page 7: Main Connections
LAB12 SUONO 25W Class A Single Ended Power Amplifier Main connections Connect a High Grade Power cable to the IEC input and to your wall socket. Make sure that your wall socket provides a good ground before connecting the power cable. You must supply 230 to 240 Volts AC (50Hz). -
Page 8: Specifications
LAB12 SUONO 25W Class A Single Ended Power Amplifier Specifications • Power: 230/240 Vac 50Hz • Power consumption: 300 VA max • Output power: 25 watt per channel (KT 150) • Frequency response: 20Hz-20KHz (-0.9dB) • Input impedance: 100K ohms •...
