SWG OPERATOR INSTALLATION GUIDE
REF.
NO. PART NO. DESCRIPTION
2120-361-BT Complete Enclosure Assembly
with Door
1 2110-067-BT Enclosure Assembly without Door
2120-362-BT Enclosure Door and Lock Assembly
2300-716 Stop/Reset Button Cover
2 2110-164 Mounting Plate
4 2110-163 Bearing Spacer & Bracket Assembly, 3"
14 2110-173 Bearing Spacer & Bracket Assembly, 2"
15 2100-1034 Bearing Spacer, 2"
17 2100-708 Main Frame Mounting Bracket
25 2100-1414 Reducer Spacer Plate
3 2110-566 Output Shaft Welded Assembly:
1 1/8" bore with 40-B-48 Sprocket
2100-1913-BT Crank
27 2200-016 Moisture Seal
26 2100-1344 Moisture Seal Spacer
19 2200-224 Set Collar, 1 1/8" ID
5 2200-264 Pillow Block Bearing, 1 1/8"
6 2110-144 Limit Cam
16 2110-130 Intermediate Shaft Assembly
2100-688 Intermediate Shaft
2200-279 Sprocket, 40-B-9, 3/4" bore
13 2200-222 Pillow Block Bearing, 3/4"
7 2200-584 Torque Limiter
12 2200-281 Sprocket, 40-A-36
35 2400-520 E-Ring, 3/4"
11 2200-097 Gear Reducer, 60:1
9 2200-084 Sprocket, 40-B-13, 1" bore
2100-206 #40 Chain, 30 Links
2200-467 #40 Chain, 22 1/2"
2200-006 #40 Master Link
2400-254 Key, 3/16" x 3/16" x 3"
2400-201 Key, 1/4" x 1/4" x 1 1/2"
SWG
MODEL
MECHANICAL PARTS LIST
- 24 -
REF.
NO. PART NO. DESCRIPTION
28 2500-764 Limit Switch
29 2100-586 Limit Bracket
30 2510-248 Stop/Reset Button and Bracket
Assembly
2100-1760 Stop/Reset Button Mounting Bracket
2500-1495 Stop/Reset Button
31 2100-1782 Mounting Plate (single phase only)
32 2100-1683 Left Mounting Bracket
33 2100-1773 Right Mounting Bracket with Shelf
34 2510-251-D Power On/Off Disconnect Assembly
with Receptacles (115V Models only)
2500-1956 115VAC Duplex Receptacles only
2500-1957 115VAC Switch only
2510-252-D Power On/Off Disconnect Assembly
for 230V Models
2500-2205 230VAC Switch only
2500-294 Power On/Off Disconnect Assembly
for 3 Phase Operators
2500-034 Power Switch only
C-Face Motors
10 2500-2307 1/2 HP, 115V, 1 Phase
2500-2308 1/2 HP, 208/230V, 1 Phase
2500-2309 3/4 HP, 115V, 1 Phase
2500-2310 3/4 HP, 208/230V, 1 Phase
2500-2311 1 HP, 115V, 1 Phase
2500-2312 1 HP, 208/230V, 1 Phase
2500-2313 1/2 HP, 208/230/460V, 3 Phase
2500-2314 3/4 HP, 208/230/460V, 3 Phase
2500-2315 1 HP, 208/230/460V, 3 Phase
Capacitors
2500-2336 Capacitor for 2500-2307 Motor
2500-2337 Capacitor for 2500-2308 Motor
2500-1926 Capacitor #1 for 2500-2309 Motor
2500-1930 Capacitor #2 for 2500-2309 Motor
2500-1931 Capacitor for 2500-2310 Motor
2500-2338 Capacitor for 2500-2311 Motor
2500-1932 Capacitor for 2500-2312 Motor
