- Page 1 ALL CLEANER OPERATOR MANUAL Advance MODEL 56380772 1/09 Rev C Document Number 56380890...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS This machine is only suitable for commercial use, for example, in hotels, schools, hospitals, factories, shops, and offices other than normal residential housekeeping purposes. When using an electrical appliance, basic precautions should always be followed, including the following: READ ALL INSTRUCTIONS BEFORE USING THIS MACHINE. -
Page 3: Parts And Service
INTRODUCTION This manual will help you to get the most from your Nilfisk-Advance All Cleaner. Read it thoroughly before operating the machine. This product is intended for commerical use only. PARTS AND SERVICE Repairs, when required, should be performed by Nilfisk-Advance service personnel using original replacement parts and accessories. -
Page 4: Know Your Machine Descriptions
KNOW YOUR MACHINE DESCRIPTIONS Operator Handle (1): Operator holds onto this handle to move the machine from one location to another. Solution Tank Lid (2): This lid screws off so the tank can be filled. The solution fill hose is tethered to the lid, and hangs inside the arm of the Operator Handle. -
Page 5: Know Your Switch Plate
KNOW YOUR SWITCH PLATE Vacuum Switch (1): turns on the vacuum motor. Chemical Valve (2): switches between the two chemical containers. When the selector is pointed straight down, the valve is off and neither chemical is selected. When the selector is pointed directly towards one or the other symbols, that chemical is selected. -
Page 6: Operation
OPERATION Insert the appropriate metering tips into the chemical feed lines (see illustration, page 5). Fill the holding tank with warm water (not exceeding 120 °F). Do not add any chemical to the tank. Prepare the area for cleaning by emptying waste receptacles, clearing debris, removing paper products, blowing out vents, and sweeping floors. -
Page 8: Part List
PART LIST ITEM PART No. DESCRIPTION 56380775 Lid and gasket, recovery tank 56380780 Hose kit, drain, priming and vac inlet 56380782 Hose kit, water and chemical metering 56380774 Power cord, 25 ft, with GFCI 56380783 Power cord pigtail with cord retainer 56380781 Vacuum motor kit, with gasket and hose 56380785... -
Page 9: Optional Accessories
TOOLS Tool Kit, standard, complete -- #56380846 56380854 Squeegee, hand-held, 12” 56380853 Handle, 12”, for hand squeegee 56380804 Solution hose, complete, 15 ft 56380855 Brush, dual surface, polypropylene 56108027 Wand, two-piece, snap fit 56108028 Squeegee,14’, for floor 56108072 Spray gun, complete 56380802 Metering tip kit, two each of seven sizes 56108024... -
Page 10: Maintenance Schedule
MAINTENANCE Use only approved chemicals at the recommended mix ratios. All chemicals should be added through the feed system and NOT added directly to the water in the solution tank to prevent possible damage to the pump, seals, or other components. - Page 11 NOTES:...
- Page 12 Nilfisk-Advance, Inc. 14600 21st Avenue North Plymouth, MN 55447-3408 www.nilfisk-advance.com Phone: 800-989-2235 Fax: 800-989-6566 Printed in the U.S.A...
