Operating Instructions
Air Top Evo 3900
Air Top Evo 5500
Servicing and safety instructions
1. The Air Top Evo 3900 / Air Top Evo 5500
heaters have been type-tested and approved in accordance with Directives ECE R10 and
72/245/EEC (EMC) and ECE R122 and 2001/56/EC (heater) with the following EC permit
numbers:
NOTE:
The specifications of this Directives are binding in the scope of the basic
Directives EEC/70/156 and/or EC/2007/46 (for new vehicle models from 29/04/
2009) and should also be observed in countries in which no special regulations
exist.
2. The year in which the heater was used for the first time must be permanently displayed
on the factory plate by deleting the inapplicable years from the plate.
3. The heaters are not designed for heating hazardous substance transport
compartments.
4. Claims can only be made if it can be verified that the claimant has complied with the
servicing and safety instructions.
5. The heater must be switched off at filling stations and tank farms as a result of
the risk of explosion.
6. The heater may not be operated in enclosed spaces (such as garages) as a result
of the risk of poisoning and asphyxiation, even if a timer or Telestart remote is
used.
7. The heater must be checked by an expert at the latest at the start of the cold weather
period.
8. In the event of long-lasting heavy smoke development, unusual combustion noises or a
smell of fuel or if the heater suffers continuous fault cut-outs with error messages
(flashing code), it must be shut down by removing the fuse and must not be reused until
it has been inspected by Webasto-trained personnel.
9. Wherever inflammable vapours or dust may form (for example in the vicinity of
fuel, carbon, wood dust or cereal stores or the like), the heater must be switched
off as a result of the risk of explosion.
e1*72/245*2006/96*5529
E1 03 5529
e1*2001/56*2006/119*0255
E1 00 0255
e1*2001/56*2006/119*0256
E1 00 0256
Webasto Product North America
15083 North Rd. Fenton, MI 48430
Tel: 810-593-6000 - http://www.techwebasto.com
(Air Top Evo 3900 / 5500)
(Air Top Evo 3900 / 5500)
(Air Top Evo 3900)
(Air Top Evo 3900)
(Air Top Evo 5500)
(Air Top Evo 5500)
