Operating Instructions

Air Top Evo 3900
Air Top Evo 5500
Servicing and safety instructions
1. The Air Top Evo 3900/Air Top Evo 5500
heater unit has been type- tested and approved in accordance with EC Directives
72/245/EEC (EMC) and 2001/56/EC (heater) with the following EC permit numbers:
NOTE:
The provisions of these Directives are binding within the territory governed by
EU Directive 70/156/EEC and should also be observed in countries without
specific regulations!
2. The year in which the heater was used for the rst time must be permanently displayed
on the factory plate by deleting the inapplicable years from the plate.
3. The heaters are not designed for heating hazardous substance transport
compartments.
To install the Air Top Evo 3900 / 5500
requirements of the Directives EC/2001/56 and ECE R122 must be met.
4. Claims can only be made if it can be veri ed that the claimant has complied with the
servicing and safety instructions.
5. The heater must be switched off at filling stations and tank farms as a result of
the risk of explosion.
6. The heater may not be operated in enclosed spaces (such as garages) as a
result of the risk of poisoning and asphyxiation, even if a timer or Telestart
remote is used.
7. The heater must be checked by an expert at the latest at the start of the cold weather
period.
8. In the event of long-lasting heavy smoke development, unusual combustion noises or
a smell of fuel or if the heater su ers continuous fault cut-outs with error messages
( ashing code), it must be shut down by removing the fuse and must not be reused
until it has been inspected by Webasto-trained personnel.
9. Wherever inflammable vapours or dust may form (for example in the vicinity of
fuel, carbon, wood dust or cereal stores or the like), the heater must be switched
off as a result of the risk of explosion.
e1*72/245*2006/28*5079*__
e1*2001/56*2006/119*0219*__
e1*2001/56*2006/119*0220*__
heater unit in hazchem vehicles, the
Webasto Product N.A., Inc
15083 North Road Fenton, MI 48430
Tel.: (800) 860-7866 - http://www.webasto.us

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Air Top Evo 3900 and is the answer not in the manual?

Questions and answers

Related Manuals for Webasto Air Top Evo 3900

Summary of Contents for Webasto Air Top Evo 3900

  • Page 1: Operating Instructions

    Tel.: (800) 860-7866 - http://www.webasto.us Servicing and safety instructions 1. The Air Top Evo 3900/Air Top Evo 5500 heater unit has been type- tested and approved in accordance with EC Directives 72/245/EEC (EMC) and 2001/56/EC (heater) with the following EC permit numbers:...

  • Page 2: Servicing And Safety Instructions

    German market pursuant to DIN 51603. The Air Top Evo 3900 D/Air Top Evo 5500 D heaters are also licensed for use with PME (bio-diesel), which complies with DIN EN 14214.

  • Page 3: Control Element

    NOTE for ADR mode only: The Air Top Evo 3900 ST and Air Top Evo 5500 heater units are switched on and off manually using a switch. The use of automatic control systems is prohibited.
  • Page 4 15 minutes will appear on the display and the heater will continue to operate. On heaters that output an error code (Air Top Evo 3900/Air Top Error code Evo 5500), a number, the error code, may appear in the display. In...
  • Page 5 Manual: Press the button (continuous heating mode) Switch on Automatic: By programming the start time Manual: Press the button again Switch off Automatic: By programming the operating period When heater unit is running: By setting the remaining time Press the button for more than two seconds - the time flashes - Set time/date set the time using the...
  • Page 6 Temperature selector Mode selector knob Main switch ON / OFF Indicator Using the control panel AirTop Evo MC04/05, you can select the General functions of the Webasto air heaters AirTop Evo. information Economy mode Normal Comfort heating Plus Fast heating...
  • Page 7 Main switch ON / OFF Operation Switching on the heater By pressing the main switch ON / OFF the heater is activated.After switching on, the main switch illuminates and the indicator "ON / Status" lights to confirm the heater operation. Switching off the heater By pressing the main switch ON / OFF again the heater operation is stopped.
  • Page 8 Fault: During an operational fault a flashing code is displayed by the status indicator. This function enables a professional workshop to solve the fault in a fast way. In this case please visit a Webasto service station!

  • Page 9: Actions In Event Of Faults

    If an error occurs, first check the fuse and plug connections to ensure that they are in proper condition and connected correctly. If the actions described below do not rectify the error, have the heater checked by Webasto-trained personnel. Heater unit cuts out automatically Cause...

  • Page 10: Error Code Output On Combination Timer Or Control Element

    F 15 Setpoint generator short circuit If serious faults, such as overheating or no start, occur frequently, the heater will be set to permanent fault lock-out (F 12) and cannot be restarted until it has been repaired by Webasto-trained personnel.
