Tightrope Media Systems Cablecast SX User Manual page 7

AC power
1
2 PS2
3 USB 2.0
4 RS-232
5 Ethernet
6 USB 3.0
SXLE-HD
SX2-HD
2.2.3 Final Connections
2 Part I: Physical Setup
1
2 4
3
F
IGURE
The Cablecast SXLE-HD does not require any breakout cables.
1. Connect a cable from Out 1 to an input on your SD/HD-SDI routing switcher.
2. Connect a cable from an output of your SD/HD-SDI routing switcher to In 1.
3. Connect house tri-level or analog blackburst to Ref In.
1. Connect the video breakout cable to the large 8-coaxial pin connector. These
outputs also have embedded audio.
2. Connect the audio breakout cable to the keyed 26-pin connector labeled A if
you plan to use AES/EBU audio.
See section 2.2.5
Next, connect the SX breakout cables to your existing AV infrastructure as needed.
Each individual cable on the SX breakout "bundle" is labeled as described in
5
6
7 DVI-I and DisplayPort
8 VIDEO 1
9 AUDIO 1
10 VIDEO 2
11 AUDIO 2
2.5: The Cablecast SX-4
for an explanation of the connectors on each breakout cable.
8 10
7
9
11
6
