3.4.1 Playback Tab
F 3.9: Playback tab for an
IGURE
SX-4.
Component output : This option is only available on output 0 (and output 2 on the SX-4) of the SD SX
Audio level : Allows you to configure the audio level for this output. This setting affects all
3 Part II: Software Setup
server, and cannot be configured via the Cablecast Web Interface. To access the SX
Configuration utility, double-click on the icon in the system tray.
The SX Configuration utility looks like a green circle with the letters SX in the
middle (see figure 3.8 on the preceding page).
The Playback tab (seen in figure 3.9) allows you to configure two options for each
output:
servers (SX-LE, SX-2, and SX-4), and is not officially supported by Tightrope Media
Systems. When this option is enabled, the composite cable for the output (labeled
Y/CVBS Out A is transformed into the "Y" part of the three component cables.
Disabling this option returns the Y/CVBS Out A cable to carrying composite video.
content played from this output.
Changing the values of the playback controls will apply your changes in real-
time. It may not be a good idea to alter these settings while your SX server is
on-air.
SDI output is always enabled. Video will be played back on both the SDI output
and the Composite outputs, depending on which is selected. Audio will be
played back on all audio outputs.
The component video output is not supported on the Cablecast SX servers. While
you may choose to use it, Tightrope Media Systems will not be able to provide
help or support for this configuration.
On this tab, you'll also see a status column that reports the current state of the
output. As a file is playing, a progress bar will display how far into the file the
playback has progressed.
