F 3.2: Control Module
IGURE
Hosts screen in a standalone
configuration.
F 3.3: Control Mod-
IGURE
ule Hosts screen in a slave
configuration
3.2 Creating Control Module Sets
3 Part II: Software Setup
3. In the Host Address field, enter the IP address
The screen should look something like figure 3.3. Click the "Save" button.
You may have more Control Module Hosts defined, depending on your specific
system setup. For more information about Control Module Hosts, please see the
Cablecast User Manual.
Having informed Cablecast of the new Cablecast SX server, we can continue to the
next step; creating a Control Module Set.
Each "Host" defined in the Control Module Hosts page can be running many
different Control Modules, each controlling different devices. In this next section,
we'll define a specific "set" of Control Modules that are in charge of controlling the
Cablecast SX server.
From the Main Menu, navigate to Location Settings, and click on the IO tab.
Another warning screen will appear the first time you select the IO tab. Again,
in this case we want to modify the system settings, so it is safe to dismiss the
warning by clicking the "Continue" button.
Once on the IO tab, select Control Module Sets.
3
You may also enter the DNS name of the Cablecast SX server in place of an IP Address.
3
of your Cablecast SX server
