F 3.5: Setting up the first
IGURE
playback device.
Device Address : "1". Device addresses are zero-based, so the second playback device's address
Device End Action : Select "Stop"
3.3.2 Create Record Devices
3 Part II: Software Setup
Device CMS : Select the "SX Playback" Control Module Set that you created in section
on page 12.
is one.
When finished, your screen should like like figure
to return to the device list screen.
If you have an SX-4: Create two more playback devices (SX Playback 3 and
SX Playback 4), following the pattern as described for the SX-LE, SX-2, and
SX2-HD. Playback devices 1 and 2 (with device addresses of 0 and 1) are located
on the AV I/O 1 port, and playback devices 3 and 4 (device addresses 2 and 3)
are located on the AV I/O 2 port.
Next, we'll configure the record device(s).
To create the first record device:
1. Once again, click the "New" button on the device list screen to create a new
record device.
2. Click in the newly created device (labeled New Input) to enter the Edit
Device screen.
3. Enter the following information in the device fields:
Name : "SX Record 1"
on the next page. Click Save
3.6
