2 Part I: Physical Setup
2.1 In the box
AC power cables : Powers the Cablecast SX server.
SX server : The Cablecast SX server itself.
SX breakout cables : These breakout cables allow you to connect the SX server into your station's
In this section, we'll be going over the physical setup of the Cablecast SX server.
Your Cablecast SX server should come with the following items in the box:
infrastructure. See figure
cables for the SX-LE, SX-2, and SX-4. figure
example of the HD breakout cables for the SX2-HD. The SXLE-HD does not
require any breakout cables.
The SX-LE and SX-2 come with one set of two breakout cables (one video and
one audio), and the SX-4 comes with two sets of video and audio cables (two
video, two audio). The SX2-HD also has one set of two breakout cables (one
video and one audio) but they carry SDI video and AES/EBU audio.
2.1 on the following page for an example of SD breakout
2.2 on the next page shows an
