INTrOdUCTION
Please read this Owner's Manual completely prior to operating the engine
and boat for the fi rst time. Th e Owner's Manual contains information
critical for safe operation, and to activate and keep the limited warranty
statement in eff ect throughout the applicable warranty period. Continuing
the appropriate maintenance and care going forward can ensure long-term
enjoyment of your Ilmor High-Performance Marine engine. DO NOT
OPERATE THE ENGINE WITHOUT FIRST READING THE ENTIRE
OWNER'S MANUAL AND ALL SUPPORTING DOCUMENTATION, AS
WELL AS THE BOAT OWNER'S MANUAL.
WeLCOme
Welcome to the world of Ilmor High-Performance Marine. We would
like to thank you for selecting one of the fi nest and most durable High-
Performance Marine engine packages in the world for your boating needs.
Th ese engines represent a new opportunity for the boating world to enjoy
a reliable, high-performing power plant. Based on lightweight, high-output
designs, these engine packages are designed to deliver high-performance
boating pleasure without the typical complications. Along with their
high power and torque output, Ilmor High-Performance Marine engines
are notable for their smooth acceleration, ease of handling, reduced fuel
consumption, excellent drivability and user-friendly characteristics. Please
read this manual thoroughly so that you fully understand the proper care
and maintenance of your Ilmor High-Performance Marine product.
Ilmor High-Performance Marine, LLC
i
© 7/2013, Version 1.0
