Summary of Contents for Lionel Christmas Hudson Jr.Steam Locomotive
- Page 1 73-8649-250 10/08 Christmas Hudson Jr. Christmas Hudson Jr. Steam Locomotive Steam Locomotive Owner’s Manual Owner’s Manual with with...
- Page 2 • Transformer controlled forward, neutral and reverse operation • Operating coupler on rear of tender • Puffing smoke unit • Operating headlight The following Lionel marks may be used throughout this instruction manual and are protected under law. All rights reserved. Lionel , TrainMaster...
-
Page 3: Table Of Contents
Table of Contents Transformer operations Running your locomotive with a Lionel transformer Installing the Lionel sound activation button Your locomotive’s reverse unit operation Using your locomotive’s magnetic coupler Experiencing the range of your locomotive’s TrainSounds sound system TrainSounds sound system... -
Page 4: Transformer Operations
Transformer operations Running your steam locomotive with a Lionel transformer Place your steam locomotive on Lionel or Lionel-compatible O gauge track. Add smoke fluid to the engine or switch the smoke generator off. • See page 10 for more information. -
Page 5: Installing The Lionel Sound Activation Button
Transformer operations Installing a Lionel Sound Activation Button for conventional operation f your transformer lacks HORN and BELL buttons, you will need to install Lionel no. 610-5906-001 Sound Activation Buttons (available separately) to activate the locomo- tive’s horn and bell sounds. -
Page 6: Your Locomotive's Reverse Unit Operation
Transformer operations Your locomotive’s reverse unit he reverse unit inside your Lionel locomotive is an electronic device that acts like the transmis- sion in your car. When you apply power to the track, the locomotive moves in the direction specified by the reverse unit—or it sits in neutral, awaiting another power interruption. Power interruptions are the signal that tells the reverse unit to sequence to the next operational state. -
Page 7: Using Your Locomotive's Magnetic Coupler
Transformer operations Using your locomotive’s magnetic coupler he rear of your Lionel locomotive’s tender is equipped with an operating magnetic knuck- le coupler, a revolutionary design first introduced by Lionel in 1945. Lionel magnetic couplers react to the mag- netic field generated by a Lionel remote-control track section (available separately). -
Page 8: Trainsounds Sound System
TrainSounds sound system operation Operating the TrainSounds sound system our TrainSounds Tender was designed to operate at approximately 6 to 18 volts (AC). When you power up the locomotive on the track, you will hear the sounds of the idling steam locomotive. The chuffing will increase proportionally with the locomotive’s speed. -
Page 9: Tire-Traction
Lionel locomotives with Tire-Traction grip the track, enabling them to pull heavy loads at higher speeds. To replace the traction tires, simply unscrew the drive rod nut from the wheel and slip off the old traction tire and remove it from under the drive rod. -
Page 10: Adding Fluid To Your Locomotives Smoke Generator
The smoke generator requires the periodic addition of Lionel smoke fluid in order to function. Pierce the tube end with a pin, then add four to eight drops of fluid directly into the locomotive’s stack. -
Page 11: Lubricating Your Locomotive
Maintaining your locomotive Lubricating your steam locomotive elp your Lionel steam locomotive lead a long and productive life on your railroad by maintain- ing it properly. We recommend you purchase a Lionel Lubrication and Maintenance Kit (no. 6-62927), available from your Lionel dealer. Two basic rules to keep in mind: never over-lubri- cate (a small amount will do), and avoid getting grease or oil on the locomotive’s wheels, contact... -
Page 12: Limited Warranty/Lionel Service
(requires proof of purchase from the Lionel Authorized Retailer* it was originally purchased). Any products on which warranty service is sought must be sent freight or postage prepaid (Lionel will refuse any package when postage is due). Transportation and shipping charges are not covered as part of this warranty.
