Asmedia USB 3.1 Controller [Enabled]
[Enabled]
[Disabled]
Asmedia USB 3.1 Battery Charging Support [Disabled]
This item appears only when the Asmedia USB 3.0 Controller item is set to [Enabled].
[Enabled]
[Disabled]
Intel LAN Controller [Enabled]
[Enabled]
[Disabled]
Intel PXE Option ROM [Off]
This item appears only when you set the previous item to [On] and allows you to enable or
disable the PXE OptionRom of the Intel LAN controller. Configuration options: [On] [Off]

Serial Port Configuration

The sub‑items in this menu allow you to set the serial port configuration.
Serial Port [On]
Allows you to enable or disable the serial port (COM).Configuration options: [On] [Off]
Change Settings [IO=3F8h; IRQ=4]
This item appears only when you set the Serial Port to [On] and allows you to select
the Serial Port base address. Configuration options: [IO=3F8h; IRQ=4] [IO=2F8h;
IRQ=3] [IO=3E8h; IRQ=4] [IO=2E8h; IRQ=3]
2.6.8

APM Configuration

ErP Ready [Disabled]
Allows BIOS to switch off some power at S5 to get the system ready for ErP requirement.
When set to [Enabled], all other PME options will be switched off.
Configuration options: [Enabled] [Disabled]
Deep S4 [Disabled]
When enabled, the system in S4 state will further reduce power usage and will power off the
USB and PS/2 devices. The system in deep S4 state can be woken up via the power button,
devices in LAN, or other ways except via the USB and PS/2 devices. Configuration options:
[Disabled] [Enabled]
Restore AC Power Loss [Power Off]
[Power On]
[Power Off]
[Last State]
2‑34
Enables the onboard USB 3.0 controller.
Disables the controller.
Enables the Asmedia USB 3.0 battery charging function.
Disables this function.
Enables the Intel LAN controller.
Disables the controller.
The system goes into on state after an AC power loss.
The system goes into off state after an AC power loss.
The system goes into either off or on state, whatever the system state was
before the AC power loss.
Chapter 2: BIOS information
