  • Page 1 RX-Series Widescreen LED-Backlit Display User Manual...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Safety Information FCC Declaimers ............................4 WEEE ............................... 5 Notice ..............................6 Precautions Cautions When Setting Up ........................6 Cautions When Using ..........................7 Cleaning and Maintenance ........................7 Notice for the LCD Display ........................8 Chapter 1: Product Description 1.1 Package Contents ..........................
  • Page 3 TABLE OF CONTENTS Chapter 4: On Screen Display Menu 4.1 Using the OSD Menu ......................... 24 4.2 OSD Menu Tree ..........................26 Chapter 5: Adjusting the Settings 5.1 Brightness Setting ..........................29 5.2 Colour Setting ............................. 31 5.3 Image Setting (PC Source only) ......................32 5.4 Image Setting (Video signals) ......................

  • Page 4: Safety Information

    SAFETY INFORMATION This FCC Class-B compliant digital device complies with the Interference-Causing Equipment Regulations of Canada. FCC Declaimers This device complies with Section 15 of the FCC listing. The operation procedures must meet the following conditions: (1) the device must not cause any damaging interference; and (2) this device must accept any received interference, including any unpredictable interference that may possibly occur.

  • Page 5: Weee

    SAFETY INFORMATION WEEE Information for users applicable in European Union countries. The symbol on the product or its packaging signifies that this product has to be disposed separately from ordinary household wastes at its end of life. Please kindly be aware that this is your responsibility to dispose electronic equipment at recycling centers so as to help conserve natural resources.

  • Page 6: Notice

    The product specifications and other information provided in this User Manual are for reference only. All information is subject to change without notice. Updated content can be downloaded from our web site at http://www.agneovo.com. • To register online, go to http://www.agneovo.com.

  • Page 7: Cautions When Using

    PRECAUTIONS Cautions When Using Use only the power cord supplied with the LCD display. The power outlet should be installed near the LCD Warning: display and be easily accessible. Unplug the power cord If an extension cord is used with the LCD display, from the power outlet and ensure that the total current consumption plugged refer to qualified service...

  • Page 8: Notice For The Lcd Display

    PRECAUTIONS Notice for the LCD Display In order to maintain the stable luminous performance, it is recommended to use low brightness setting. Due to the lifespan of the lamp, it is normal that the brightness quality of the LCD display may decrease with time.

  • Page 9: Chapter 1: Product Description

    CHAPTER 1: PRODUCT DESCRIPTION 1.1 Package Contents When unpacking, check if the following items are included in the package. If any of them is missing or damaged, contact your dealer. LCD Display Note: User Manual Power adapter Must use only the supplied power adapter: ♦...

  • Page 10: Wall Mounting Installation Preparation

    PRODUCT DESCRIPTION 1.2 Wall Mounting Installation Preparation 1.2.1 Wall Mounting Note: Remove the base stand. To protect the glass panel, place a See procedures below. towel or soft cloth before laying the LCD display down. Wall mount the LCD display. Screw the mounting bracket to the VESA holes at the rear of the LCD display.

  • Page 11: Lcd Display Overview

    PRODUCT DESCRIPTION 1.3 LCD Display Overview 1.3.1 Front View and Keypad Buttons POWER / FREEZE/ SWAP/ MENU INPUT AUTO ADJ. DOWN SELECT ROTATE SELECT Display screen The LCD display screen is protected by • Press repeatedly to select PIP option. NeoV Optical Glass.

  • Page 12: Rear View

    PRODUCT DESCRIPTION 1.3.2 Rear View S-VIDEO CVBS-1 CVBS-2 AUDIO AUDIO DC IN HDMI AUDIO IN 12V OUT DC power input COMPOSITE Video input/output connectors (1) Use to connect the power cord. Use to connect composite cables for CVBS input/output signal. HDMI connector COMPOSITE Video input/output Use to connect an input device using...

  • Page 13: Chapter 2: Making Connections

    CHAPTER 2: MAKING CONNECTIONS 2.1 Connecting the Power Connect the power cord to the power adapter. Connect the power adapter to the DC power input at the rear of the LCD display. Connect the power cord plug to a power outlet or a power supply. DC IN Caution: ♦...

  • Page 14: Connecting Input Source Signals

    MAKING CONNECTIONS 2.2 Connecting Input Source Signals 2.2.1 Connecting a Computer Using VGA Cables Connect one end of a D-sub cable to the VGA connector of the LCD display and the other end to the D-sub connector of the computer. Using DVI Cables Connect one end of a DVI cable to the DVI connector of the LCD display and the other end to the DVI connector of the computer.

  • Page 15: Connecting An Audio Device

    MAKING CONNECTIONS Connecting an Audio Device Connect one end of an audio cable to the audio port at the rear of the LCD display and the other end to the audio out port of the computer. AUDIO IN 2.2.2 Connecting a Camera or Video Device Using CVBS Cables Connect one end of a CVBS cable CVBS-1...

  • Page 16: Using S-Video Cables

    MAKING CONNECTIONS Using S-Video Cables Connect one end of an S-Video S-VIDEO cable to the S-VIDEO connector of the LCD display and the other end to the S-VIDEO connector of your device. For audio input, connect an RCA cable to the audio in connector of the LCD display and the audio out connector of your device.

  • Page 17: Connecting The Dc Power Output

    MAKING CONNECTIONS 2.3 Connecting the DC Power Output The DC power output connector provides DC power to other devices using a 2.5 mm DC jack cable. Warning: 12V OUT ♦ Ensure that the device you are connecting to conforms to the specifications before making any connections.

  • Page 18: Chapter 3: Using The Lcd Display

    CHAPTER 3: USING THE LCD DISPLAY 3.1 Turning on the Power Note: ♦ The LCD display still consumes POWER button power as long as the power LED indicator cord is connected to the power outlet. Disconnect the power Plug the power cord to a power outlet or power supply. cord to completely cut off power.

  • Page 19: Adjusting The Volume

    USING THE LCD DISPLAY 3.3 Adjusting the Volume VOLUME buttons Touch the button to call out the volume bar. Touch the button to increase volume or the button to decrease volume. To mute the audio, set the volume to 0. Or, press the buttons at the same time.

  • Page 20: Setting The Aspect Ratio

    USING THE LCD DISPLAY 3.5 Setting the Aspect Ratio 3.5.1 Aspect Ratio Options Touch the button repeatedly to scroll among the aspect ratio options. Options are as follows: • Underscan: The picture is displayed in full screen. • Overscan: The picture is displayed in full screen while retaining the original aspect ratio. This results in a zoomed image and some part of the picture may appear cut-off.

  • Page 21: Using Picture-In-Picture (Pip)

    USING THE LCD DISPLAY 3.6 Using Picture-in-Picture (PIP) The Picture-in-Picture (PIP) feature allows viewing of more than one input source signal on the LCD display. 3.6.1 PIP Options Touch the button repeatedly to enable and scroll among the PIP options. Options are as follows: •...

  • Page 22: Pip Swap

    USING THE LCD DISPLAY 3.6.2 PIP Swap The main and the sub source signals set in PIP Setting can be easily swapped using the keypad. Note: ♦ PIP Swap can only be executed if PIP is enabled, see page 38. Main source Sub source Touch the...

  • Page 23: Using Freeze Function

    USING THE LCD DISPLAY 3.8 Using FREEZE Function The FREEZE function allows you to freeze the screen image but still continues real-time playback until the image is unfreeze. Touch the button to activate screen freeze, the screen freeze message is displayed on the screen. Note: ♦...

  • Page 24: Chapter 4: On Screen Display Menu

    CHAPTER 4: ON SCREEN DISPLAY MENU 4.1 Using the OSD Menu Operation Display the main menu screen. Touch N T S C 6 0 H z B R I G H T N E S S B R I G H T N E S S C O N T R A S T C O L O U R S E T T I N G...
  • Page 25 ON SCREEN DISPLAY MENU Operation Select the submenu item. Touch the buttons. 6 0 H z B R I G H T N E S S T N E S S C O N T R A S T S E T T I N G B A C K L I G H T S E T T I N G R A T I O...

  • Page 26: Osd Menu Tree

    ON SCREEN DISPLAY MENU 4.2 OSD Menu Tree N T S C 6 0 H z B R I G H T N E S S B R I G H T N E S S C O N T R A S T C O L O U R S E T T I N G B A C K L I G H T...
  • Page 27 ON SCREEN DISPLAY MENU Main Menu Submenu Remarks Image Setting During Video input signal: See page 33. • Sharpness • Saturation • Tint • 3D Comb Filter • Noise Reduction • 3D De-interlace • Motion • Video Mode • H. Position •...
  • Page 28 ON SCREEN DISPLAY MENU Main Menu Submenu Remarks 11. Input Select • See page 46. • • HDMI • CVBS1 • CVBS2 • S-Video 12. Language Select the OSD language: EN / FR / DE / ES / IT / PY / RO / PL / CS / NL / 簡中...

  • Page 29: Brightness Setting

    CHAPTER 5: ADJUSTING THE LCD DISPLAY 5.1 Brightness Setting 1. Touch to call out the OSD window. N T S C 6 0 H z B R I G H T N E S S B R I G H T N E S S 2.
  • Page 30 ADJUSTING THE LCD DISPLAY Original Setting High Setting Low Setting Brightness Contrast Backlight...

  • Page 31: Colour Setting

    ADJUSTING THE LCD DISPLAY 5.2 Colour Setting 1. Touch to call out the OSD window. N T S C 6 0 H z C O L O U R T E M P . 6 5 0 0 K B R I G H T N E S S 2.

  • Page 32: Image Setting (Pc Source Only)

    ADJUSTING THE LCD DISPLAY 5.3 Image Setting (PC Source only) Note: Some submenu items are not available in DVI input source signal. 1. Touch to call out the OSD window. 1 0 2 4 x 7 6 8 6 0 H z S H A R P N E S S B R I G H T N E S S 2.

  • Page 33: Image Setting (Video Signals)

    ADJUSTING THE LCD DISPLAY 5.4 Image Setting (Video signals) 1. Touch to call out the OSD window. N T S C 6 0 H z S H A R P N E S S B R I G H T N E S S 2.
  • Page 34 ADJUSTING THE LCD DISPLAY Range / Item Function Operation Value Adjusts the noise reduction to help remove noise from images. This Touch the buttons to Noise Reduction helps produce clearer and crisper select the value. High images. Noise Reduction Off Noise Reduction On Enables the 3D De-interlace feature Touch the...
  • Page 35 ADJUSTING THE LCD DISPLAY Range / Item Function Operation Value Standard Depending on the content of your Text Touch the buttons to Video Mode PC, select the video mode for better Movie select the value. display. Graphic H. Position Moves the screen image to the left (Horizontal or right.

  • Page 36: Aspect Ratio Setting

    ADJUSTING THE LCD DISPLAY 5.5 Aspect Ratio Setting Note: Overscan is available only in VGA and HDMI input source signals. 1. Touch to call out the OSD window. N T S C 6 0 H z A S P E C T R A T I O U N D E R S C A N B R I G H T N E S S...
  • Page 37 ADJUSTING THE LCD DISPLAY Range / Item Function Operation Value H. Zoom Adjusts the horizontal zoom. (Horizontal Zoom) Touch the buttons to 0 to 100 adjust the value. V. Zoom Adjusts the vertical zoom. (Vertical Zoom)

  • Page 38: Pip Setting

    ADJUSTING THE LCD DISPLAY 5.6 PIP Setting 1. Touch to call out the OSD window. N T S C 6 0 H z P I P O F F P I P P A P B R I G H T N E S S 2.
  • Page 39 ADJUSTING THE LCD DISPLAY Note: Any input signal may be set as the main or the sub source signal. However, some input signals are not supported to be paired together as the main and the sub source signals. Refer to the following table for compatibility options. Table 5.1 PIP Compatibility Table Main HDMI...

  • Page 40: Anti-Burn-In

    ADJUSTING THE LCD DISPLAY 5.7 Anti-Burn-In 1. Touch to call out the OSD window. N T S C 6 0 H z E N A B L E O F F B R I G H T N E S S 2.

  • Page 41: Osd Setting

    ADJUSTING THE LCD DISPLAY 5.8 OSD Setting 1. Touch to call out the OSD window. N T S C 6 0 H z T R A N S P A R E N C Y B R I G H T N E S S 2.

  • Page 42: Audio Setting

    ADJUSTING THE LCD DISPLAY 5.9 Audio Setting 1. Touch to call out the OSD window. N T S C 6 0 H z A U D I O O F F B R I G H T N E S S 2.

  • Page 43: Other Setting

    ADJUSTING THE LCD DISPLAY 5.10 Other Setting 1. Touch to call out the OSD window. N T S C 6 0 H z P O W E R S A V I N G O F F B R I G H T N E S S 2.
  • Page 44 ADJUSTING THE LCD DISPLAY Range / Item Function Operation Value Activates the DDC/CI protocol to allow users Touch the buttons to DDC/CI to configure the monitor by a software using select the value. two wires on the VGA or DVI cables. Use to recall all to default settings, except Recall Touch the...

  • Page 45: Auto Brightness

    ADJUSTING THE LCD DISPLAY 5.11 Auto Brightness 5.11.1 EcoSmart Sensor With the built-in EcoSmart sensor, users can enable the Auto Brightness feature to automatically adjust the LCD screen brightness according to the ambient light. This feature comforts the eyes and helps optimise energy efficiency.

  • Page 46: Input Select

    ADJUSTING THE LCD DISPLAY 5.12 Input Select 1. Touch to call out the OSD window. N T S C 6 0 H z V G A P R E S S B R I G H T N E S S 2.

  • Page 47: Chapter 6: Appendix

    CHAPTER 6: APPENDIX 6.1 Warning Messages Warning Messages Cause Solution The resolution or the refresh rate of • Change the resolution or the the graphics card of the computer refresh rate of the graphics I N P U T S I G N A L O U T O F R A N G E is set too high.

  • Page 48: Troubleshooting

    APPENDIX 6.2 Troubleshooting Problem Possible Cause and Solution No picture. • Check if the LCD display is turned ON. • Check if the power cord is properly connected to the LCD display. • LED indicator is OFF. • Check if the power cord is plugged into the power outlet. •...
  • Page 49 APPENDIX Problem Possible Cause and Solution Mist formed inside the • This happens due to humid weather conditions. This is a normal glass surface. occurrence. The mist will disappear after a few days or as soon as the weather stabilizes. Faint shadows from a •...

  • Page 50: Transporting The Lcd Display

    APPENDIX 6.3 Transporting the LCD Display To transport the LCD display for repair or shipment, place the display in its original packaging carton. Put all the accessories in the box (if necessary). Place the two foam cushions on each side of the LCD display for protection. Place the LCD display down in the box.

  • Page 51: Chapter 7: Specifications

    CHAPTER 7: SPECIFICATIONS 7.1 Display Specifications RX-22 RX-24 Panel Panel Size 21.5” 23.6” Max. Resolution FHD 1920 x 1080 Pixel Pitch 0.2482 mm 0.2715 mm Brightness 250cd/m 300cd/m Contrast Ratio 1,000 (Typical) Viewing Angle (H/V) 170°/160° (Typical) Display Colour 16.7M Response Time 3ms (GTG) Frequency (H/V)

  • Page 52: Display Dimensions

    SPECIFICATIONS 7.2 Display Dimensions 7.2.1 RX-22 Dimensions 282.4mm 53.5mm 32.6mm 100mm 513.2mm 368.5mm 324.3mm 100mm 75mm 75mm 155mm 227.4mm 7.2.2 RX-24 Dimensions 282.4mm 53.5mm 32.6mm 100mm 562.4mm 396.8mm 352.6mm 100mm 75mm 75mm 155mm 227.4mm...
