AGneovo PN-46D User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PN-46D LED-Backlit Display
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PN-46D and is the answer not in the manual?

Questions and answers

Related Manuals for AGneovo PN-46D

Summary of Contents for AGneovo PN-46D

  • Page 1 PN-46D LED-Backlit Display User Manual...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Contents SAFETY INFORMATION ................1 Federal Communications Commission (FCC) Notice (U.S. Only) ............1 CE Declaration of Conformity ........................2 Polish Center for Testing and Certification Notice ..................3 Electric, Magnetic and Electromagnetic Fields (“EMF”) ................3 Information for U.K.
  • Page 3 TABLE OF CONTENTS 2.4 Connecting External Equipment (DVD/VCR/VCD) ................25 2.4.1 Using COMPONENT Video Input ................... 25 2.4.2 Using Video Source Input ......................25 2.4.3 Using HDMI Video Input ......................26 2.5 Connecting Audio Equipment ......................26 2.5.1 Connecting External Speakers ....................26 2.5.2 Connecting an External Audio Device ..................
  • Page 4 TABLE OF CONTENTS CHAPTER 7: SPECIFICATIONS ..............62 7.1 Display Specifications ........................62 7.2 Display Dimensions ..........................64 7.2.1 PN-46D Dimensions ........................ 64...

  • Page 5: Safety Information

    SAFETY INFORMATION Federal Communications Commission (FCC) Notice (U.S. Only) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 6: Ce Declaration Of Conformity

    SAFETY INFORMATION CE Declaration of Conformity We declare under our responsibility that the product is in conformity with the following standards: • EN60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013 (Safety requirement of Information Technology Equipment). • EN55022:2010 (Radio Disturbance requirement of Information Technology Equipment). • EN55024:2010 (Immunity requirement of Information Technology Equipment). •...

  • Page 7: Polish Center For Testing And Certification Notice

    SAFETY INFORMATION Polish Center for Testing and Certification Notice The equipment should draw power from a socket with an attached protection circuit (a three-prong socket). All equipment that works together (computer, display, printer, and so on) should have the same power supply source.

  • Page 8: Information For U.k. Only

    SAFETY INFORMATION Information for U.K. only WARNING - THIS APPLIANCE MUST BE EARTHED. Important: This apparatus is supplied with an approved moulded 13A plug. To change a fuse in this type of plug proceed as follows: Remove fuse cover and fuse. Fit new fuse which should be a BS 1362 5A,A.S.T.A.

  • Page 9: North Europe (Nordic Countries) Information

    SAFETY INFORMATION How to connect a plug The wires in the mains lead are coloured in accordance with the following code: BLUE - “NEUTRAL” (“N”) BROWN - “LIVE” (“L”) GREEN & YELLOW - “EARTH” (“E”) • The GREEN & YELLOW wire must be connected to the terminal in the plug which is marked with the letter “E”...

  • Page 10: End-Of-Life Disposal

    SAFETY INFORMATION End-of-Life Disposal Your new Public Information Display contains materials that can be recycled and reused. Specialized companies can recycle your product to increase the amount of reusable materials and to minimize the amount to be disposed of. Please find out about the local regulations on how to dispose of your old display from your local dealer. (For customers in Canada and U.S.A.) This product may contain lead and/or mercury.

  • Page 11: Precautions

    Updated content can be downloaded from our web site at http://www.agneovo.com. • To register online, go to http://www.agneovo.com. • To protect your rights as a consumer, do not remove any stickers from the LCD display. Doing so may affect the determination of the warranty period.

  • Page 12: Cautions When Using

    PRECAUTIONS Cautions When Using • Use only the power cord supplied with the LCD display. • The power outlet should be installed near the LCD display and Warning: be easily accessible. • If an extension cord is used with the LCD display, ensure that the Unplug the power cord from the power outlet and total current consumption plugged into the power outlet does not...

  • Page 13: Notice For The Lcd Display

    PRECAUTIONS Notice for the LCD Display • In order to maintain the stable luminous performance, it is recommended to use low brightness setting. • Due to the lifespan of the lamp, it is normal that the brightness quality of the LCD display may decrease with time.

  • Page 14: Chapter 1: Product Description

    CHAPTER 1: PRODUCT DESCRIPTION 1.1 Package Contents When unpacking, check if the following items are included in the package. If any of them is missing or damaged, contact your dealer. LCD Display Note: User Manual Remote control ♦ Remote control is shipped with POWER the supplied AAA batteries.

  • Page 15: Preparing For The Installation

    PRODUCT DESCRIPTION 1.2 Preparing for the Installation • Due to the high power consumption, always use the plug exclusively designed for this product. If an extended line is required, please consult your service agent. Warning: • The product should be installed on a flat surface to avoid tipping. ♦...

  • Page 16: Wall Mounting Installation

    VESA Grid result in damage to the equipment or injury to the user Model Name VESA Grid or installer. Product warranty PN-46D 400(H) x 200(V) mm does not cover damage caused 200(H) x 200(V) mm by improper installation. ♦ For the wall-mounting kit, use...

  • Page 17: Ventilation Requirements For Enclosure Locating

    PRODUCT DESCRIPTION 1.4.2 Ventilation Requirements for Enclosure Locating To allow heat to disperse, leave space between surrounding objects as shown in the diagram below. 100 mm 100 mm 100 mm 100 mm 1.5 Mounting in Portrait Position This display can be installed in portrait position. Remove the table stand, if attached.

  • Page 18: Installing Ops Device

    PRODUCT DESCRIPTION 1.6 Installing OPS Device To install OPS device into its slot on the LCD display, do the following: Remove the screws on the handle, and then remove the handle. Remove the screws on the OPS cover, and then remove the OPS cover. Install the OPS device into its slot.

  • Page 19: Lcd Display Overview

    PRODUCT DESCRIPTION 1.7 LCD Display Overview 1.7.1 Control Panel MUTE INPUT MENU [ ] Decrease [ ] Power • Decrease the adjustment or select an option Turn the display on or put the display to while OSD menu is on. standby.
  • Page 20 PRODUCT DESCRIPTION Remote control sensor and power status indicator • Receive command signals from the remote control. • Indicate the operating status of the display without OPS: - Lights green when the display is turned on - Lights red when the display is in standby mode - Lights amber when the display enters APM mode - When SCHEDULE is enabled, the light blinks green and red - If the light blinks red, it indicates that a failure has been detected...

  • Page 21: Input/Output Terminals

    PRODUCT DESCRIPTION 1.7.2 Input/Output Terminals 12 13 14 15 16 AC IN DVI OUT / VGA OUT DVI or VGA video output. AC power input from the wall outlet. Main power switch VGA IN (D-Sub) Switch the main power on/off. VGA video input.

  • Page 22: Remote Control

    PRODUCT DESCRIPTION 1.8 Remote Control POWER Turn the display on or to put the display into standby mode. 1.8.1 General Functions ] SMART Activate Smart menu. Press the button repeatedly to select the desired option. POWER • STANDARD: Used for normal images (default setting).
  • Page 23 PRODUCT DESCRIPTION [VIDEO SOURCE] [MENU] Choose the video input source. Press the p Access the OSD menu. or q button to select one of the video sources [ ] Right/Increase among HDMI, DVI, VGA, DVD/HD,VIDEO, DP, or OPS. Press the SET button to confirm and •...

  • Page 24: Inserting The Batteries In The Remote Control

    PRODUCT DESCRIPTION 1.8.2 Inserting the Batteries in the Remote Control Caution: The remote control is powered by two 1.5V AAA batteries. The incorrect use of batteries can To install or replace batteries: result in leaks or bursting. Be sure to follow these instructions: Press and then slide the cover to open it.

  • Page 25: Chapter 2: Making Connections

    CHAPTER 2: MAKING CONNECTIONS 2.1 Connecting the Power Connect one end of the power cord to the AC IN connector at the rear of the LCD display. Connect the other end of the power cord to a power outlet or a power supply. Set the Main Power switch to ON.

  • Page 26: Using The Switch Cover

    MAKING CONNECTIONS 2.2 Using the Switch Cover A cover for the power switch is provided to prevent the display from being turned on or off accidentally. To install the switch cover, do the following: Align and install the switch cover on the top of the Main Power switch. Secure the switch cover using the screw.

  • Page 27: Connecting A Computer

    MAKING CONNECTIONS 2.3 Connecting a Computer 2.3.1 Using VGA Input Connect one end of a D-sub cable to the VGA IN connector of the LCD display and the other end of a D-sub cable to the VGA OUT (D-Sub) connector of the computer. For audio input, connect one end of an audio cable to the AUDIO IN connector of the LCD display and the other end of an audio cable to the AUDIO OUT connector of the computer.

  • Page 28: Using Hdmi Input

    MAKING CONNECTIONS 2.3.3 Using HDMI Input Connect one end of an HDMI cable to the HDMI IN connector of the LCD display and the other end of an HDMI cable to the HDMI OUT connector of the computer. Computer RJ-45 HDMI IN DisplayPort DVI IN...

  • Page 29: Connecting External Equipment (Dvd/Vcr/Vcd)

    MAKING CONNECTIONS 2.4 Connecting External Equipment (DVD/VCR/VCD) 2.4.1 Using COMPONENT Video Input Connect one end of a component cable to the COMPONENT IN connector of the LCD display and the other end of a component cable to the COMPONENT OUT connectors of the video player (DVR/VCR/VCD). For audio input, connect one end of an audio cable to the AUDIO IN connectors of the LCD display and the other end of an audio cable to the AUDIO OUT connectors of the video player (DVR/VCR/VCD).

  • Page 30: Using Hdmi Video Input

    MAKING CONNECTIONS 2.4.3 Using HDMI Video Input Connect one end of an HDMI cable to the HDMI1 IN/ HDMI2 IN connector of the LCD display and the other end of an HDMI cable to the HDMI out connector of the video player (DVR/VCR/VCD). RJ-45 HDMI IN DisplayPort...

  • Page 31: Connecting An External Audio Device

    MAKING CONNECTIONS 2.5.2 Connecting an External Audio Device Connect one end of an audio cable to the AUDIO OUT connector of the LCD display and the other end of an audio cable to the AUDIO IN connector of the audio device. AUDIO OUT AUDIO IN Audio Device...

  • Page 32: Connecting Multiple Displays In A Daisy-Chain Configuration

    MAKING CONNECTIONS 2.6 Connecting Multiple Displays in a Daisy-chain Configuration You can interconnect multiple displays to create a daisy-chain configuration for applications such as a video wall. Caution: To avoid unnecessary strain on the bezel, it is highly recommended to keep a minimum space of 0.5mm in which a business card is able to slip between all displays on all sides.

  • Page 33: Analog Video Connection

    MAKING CONNECTIONS 2.6.3 Analog Video Connection Connect the DVI OUT / VGA OUT connector of DISPLAY 1 to the VGA IN connector of DISPLAY 2. DISPLAY 1 DISPLAY 2 [VGA] [VGA IN] [DVI/VGA OUT] [VGA IN] 2.7 IR Connection Connect the IR sensor cable to the IR IN connector of the LCD display. IR Sensor Cable IR IN IR OUT...

  • Page 34: Ir Pass-Through Connection

    MAKING CONNECTIONS 2.8 IR Pass-Through Connection To control a Video-Wall set up by multiple displays using the remote control of the DVD player, do the following: Connect the IR sensor cable to the IR IN connector port of the LCD display. Connect one end of the IR cable to the IR OUT connector of the LCD display.

  • Page 35: Connecting To Wired Network

    MAKING CONNECTIONS 2.9 Connecting to Wired Network If you connect this LCD display to a home network, you can play photos, music, and videos from your computer. INTERNET ROUTER [RJ-45] [RJ-45] To setup the network: Switch on the router and switch on its DHCP setting. Connect the router to the LCD display with an Ethernet cable.

  • Page 36: Chapter 3: Using The Lcd Display

    CHAPTER 3: USING THE LCD DISPLAY 3.1 Turning on the Power POWER button POWER Plug the power cord to a power Note: VIDEO AUDIO SMART SOURCE SOURCE outlet or power supply. ♦ The LCD display still consumes Press the button to turn the power as long as the power cord is connected to the power LCD display on.

  • Page 37: Adjusting The Volume

    POWER USING THE LCD DISPLAY VIDEO AUDIO SMART SOURCE SOURCE 3.3 Adjusting the Volume ON/OFF INPUT CHANGE CONTRAST BRIGHTNESS Note: DISPLAY MENU ♦ After pressing the VOL UP (p) or VOL DOWN (q) button, the volume menu is displayed on AUTO EXIT ADJUST...

  • Page 38: Choosing Your Preferred Picture Settings

    USING THE LCD DISPLAY 3.5 Choosing Your Preferred Picture Settings Note: The available preset picture modes include: POWER ♦ STANDARD: Used for normal images (default setting). VIDEO AUDIO SMART SOURCE SOURCE ♦ HIGH BRIGHT: Used for moving image such as Video. SMART button ♦...

  • Page 39: Chapter 4: On Screen Display Menu

    CHAPTER 4: ON SCREEN DISPLAY MENU 4.1 Using the OSD Menu Operation Menu Navigation Control Panel Remote Control Press the MENU Press the MENU Display the main menu screen. button. button. PICTURE BRIGHTNESS CONTRAST SHARPNESS BLACK LEVEL TINT COLOR COLOR TEMPERATURE 10000K USER COLOR GAMMA SELECTION...
  • Page 40 ON SCREEN DISPLAY MENU Operation Menu Navigation Control Panel Remote Control Exit the submenu. Press the MENU Press the EXIT button to return to button to return to the previous menu. the previous menu. Close the OSD window. Press the MENU Press the MENU button repeatedly.

  • Page 41: Osd Menu Tree

    ON SCREEN DISPLAY MENU 4.2 OSD Menu Tree PICTURE BRIGHTNESS CONTRAST SHARPNESS BLACK LEVEL TINT COLOR COLOR TEMPERATURE 10000K USER COLOR GAMMA SELECTION NATIVE NOISE REDUCTION FILM MODE PICTURE RESET :SEL :NEXT :RETURN :EXIT MENU EXIT MENU Main Menu Submenu Remarks 1.
  • Page 42 ON SCREEN DISPLAY MENU Main Menu Submenu Remarks 4. PIP • PIP MODE See page 44. • PIP SIZE • PIP AUDIO • PIP H POSITION • PIP V POSITION • SUB INPUT • PIP RESET 5. CONFIGURATION1 • OFF TIMER See page 46.

  • Page 43: Chapter 5: Adjusting The Lcd Display

    CHAPTER 5: ADJUSTING THE LCD DISPLAY 5.1 Picture Settings 1 Press the MENU button on the control panel or remote control to call out the OSD window. PICTURE BRIGHTNESS CONTRAST 2 Select PICTURE, then press the INPUT button on SHARPNESS BLACK LEVEL TINT the control panel or the SET button on the remote...
  • Page 44 ADJUSTING THE LCD DISPLAY Item Function Operation Range Adjust the black level of the screen Press the button on the control image. Low brightness setting 0 to 100 panel or remote control to adjust makes black colour darker. the value. Note: The default value is 50.

  • Page 45: Screen Settings

    ADJUSTING THE LCD DISPLAY Item Function Operation Range Adjust the noise reduction to help remove noise from images. This Press the button on the control NOISE helps produce clearer and crisper panel or remote control to select an REDUCTION MIDDLE images.
  • Page 46 ADJUSTING THE LCD DISPLAY Item Function Operation Range Press the button on the control H POSITION Move the image to the right or left. 0 to 100 panel or remote control to adjust the position. Press the button on the control V POSITION Move the image up or down.

  • Page 47: Audio Settings

    ADJUSTING THE LCD DISPLAY Item Function Operation Range Press the p/q button on the Reset all settings in the SCREEN SCREEN control panel or remote control to RESET menu to the factory preset values. select an option. 5.3 Audio Settings 1 Press the MENU button on the control panel or remote control to call out the OSD window.

  • Page 48: Pip Settings

    ADJUSTING THE LCD DISPLAY 5.4 PIP Settings 1 Press the MENU button on the control panel or remote control to call out the OSD window. PIP MODE PIP SIZE SMALL 2 Select PIP, then press the INPUT button on the PIP AUDIO MAIN AUDIO PIP H POSITION...
  • Page 49 ADJUSTING THE LCD DISPLAY Note: ♦ The PIP function is available only for certain signal source combinations as shown in the table below. The availability of the PIP function will also depend on the resolution of the input signal being used. Main Picture Card HDMI...

  • Page 50: Configuration1 Settings

    ADJUSTING THE LCD DISPLAY 5.5 Configuration1 Settings 1 Press the MENU button on the control panel or remote control to call out the OSD window. CONFIGURATION1 OFF TIMER SCHEDULE 2 Select CONFIGURATION1, then press the INPUT DATE AND TIME LOGO CONFIGURATION1 RESET button on the control panel or the SET button on the remote control.
  • Page 51 ADJUSTING THE LCD DISPLAY Item Function Operation Range INPUT-SOURCE selection: Press the p/q button on the control panel or remote control to to select an input source. If no input source is selected, the input source will remain the same as last selected. DATE schedule: Press the button on the control panel or remote control to select which day in a week this schedule item will be taken effect, and then...

  • Page 52: Configuration2 Settings

    ADJUSTING THE LCD DISPLAY Item Function Operation Range Reset all settings in the Press the p/q button on the CONFIGURATION1 CONFIGURATION1 menu to the control panel or remote control to RESET factory preset values. select an option. 5.6 Configuration2 Settings 1 Press the MENU button on the control panel or remote control to call out the OSD window.
  • Page 53 ADJUSTING THE LCD DISPLAY Item Function Operation Range MENU Press the button on the View the information about your MONITOR EXIT control panel or the button display, including MODEL NAME and on the remote control to return to INFORMATION SERIAL. the previous menu.
  • Page 54 ADJUSTING THE LCD DISPLAY Item Function Operation Range Example2: 5 x 5 screen matrix (25 displays) H MONITORS = 5 displays V MONITORS = 5 displays H monitors Position • H MONITORS: Adjust displays Press the button on the on the horizontal side. 1 to 15 control panel or remote control to select an option.
  • Page 55 ADJUSTING THE LCD DISPLAY Item Function Operation Range Select the delayed time until the 2 SEC. power-on mode is activated after 4 SEC. the power is turned on manually or 6 SEC. Press the button on the automatically. This setting is useful 8 SEC.

  • Page 56: Configuration3 Settings

    ADJUSTING THE LCD DISPLAY 5.7 Configuration3 Settings 1 Press the MENU button on the control panel or remote control to call out the OSD window. CONFIGURATION3 POWER SAVE HEAT STATUS 2 Select CONFIGURATION3, then press the INPUT SCREEN SAVER SIDE BORDER COLOR CONFIGURATION3 RESET button on the control panel or the SET button on the remote control.
  • Page 57 ADJUSTING THE LCD DISPLAY Item Function Operation Range • COOLING FAN: Set the cooling fan operation. » ON: Turn on the cooling fan all the time. » AUTO: Turn on/off the cooling fan according to the LCD display temperature. Note: ♦...

  • Page 58: Advanced Option Settings

    ADJUSTING THE LCD DISPLAY 5.8 Advanced Option Settings 1 Press the MENU button on the control panel or remote control to call out the OSD window. ADVANCED OPTION INPUT CHANGE NORMAL TERMINAL SETTING 2 Select ADVANCED OPTION, then press the INPUT SCAN CONVERSION COLOR SYSTEM SCAN MODE...
  • Page 59 ADJUSTING THE LCD DISPLAY Item Function Operation Range Enable/Disable the IP (Interlace to Press the button on the Progressive) conversion function. SCAN PROGRESSIVE control panel or remote control INTERLACE CONVERSION Note: The default value is to select an option. PROGRESSIVE. Select the Color System depending on AUTO your input video format.
  • Page 60 ADJUSTING THE LCD DISPLAY Item Function Operation Range • DHCP CLIENT: Enable/Disable the DHCP function. If the setting is set to ON, the IP ADDRESS, Press the button on the SUBNET MASK, and DEFAULT control panel or remote control GATEWAY parameters will be to select an option.

  • Page 61: Chapter 6: Appendix

    CHAPTER 6: APPENDIX 6.1 Warning Messages Warning Messages Cause Solution The resolution or the refresh rate of • Change the resolution the graphics card of the computer or the refresh rate of the INPUT NOT SUPPORTED!! is set too high. graphics card.

  • Page 62: Supported Resolution

    APPENDIX 6.2 Supported Resolution VGA Resolution: Active Resolution Standard Refresh Rate Pixel Rate Aspect Ratio Stand for Mode Resolution H Pixels V Lines 60 Hz 25.175 MHz 72 Hz 31.5 MHz Video Graphic Array 75 Hz 31.5 MHz Wide Video Graphic WVGA 70 Hz 33.75 MHz...

  • Page 63: Cleaning

    APPENDIX • If a vertical and horizontal frequency-select mode exists, select 60Hz (vertical) and 31.5KHz (horizontal). In some cases, abnormal signals (such as stripes) might appear on the screen when the PC power is turned off (or if the PC is disconnected). If so, press the [INPUT] button to enter the video mode. Also, make sure that the PC is connected.

  • Page 64: Troubleshooting

    APPENDIX 6.4 Troubleshooting Symptom Possible Cause Remedy No picture is displayed • The main power switch on 1 Plug in the power cord. the back of the display is not 2 Make sure the power switch is switched on. switched on. •...

  • Page 65: Transporting The Lcd Display

    APPENDIX 6.5 Transporting the LCD Display To transport the LCD display for repair or shipment, place the display in its original packaging carton. 1 Put all the accessories in the box (if necessary). 2 Place the lower foam cushion inside the lower box (a). 3 Place the LCD display down in the lower box (a).

  • Page 66: Chapter 7: Specifications

    CHAPTER 7: SPECIFICATIONS 7.1 Display Specifications Display PN-46D Screen Size (Active Area) 46” (116.8 cm) LCD Aspect Ratio 16:9 Number of Pixels 1920 (H) x 1080 (V) Pixel Pitch 0.53025 (H) x 0.53025 (V) [mm] Displayable Colors 16.7M colors Brightness (Typical)
  • Page 67 SPECIFICATIONS General PN-46D Power Supply AC 100 - 240V, 50 - 60Hz Power Consumption (Max) (With OPS) 260 W Power Consumption (Without OPS) 120 W Power Consumption (Standby & Off) <0.5W (RS232 in active) Dimensions (With Stand) [W x H x D] 1023.98 x 629.41 x 400.0 mm...

  • Page 68: Display Dimensions

    SPECIFICATIONS 7.2 Display Dimensions 7.2.1 PN-46D Dimensions 0.95±0.5 244.75±0.5 246.65±0.5 125.7 480.94±1.0 482.84±1.0 311.99 311.99 83.85 1023.98 47±1.0 3.4±0.5 512.94 511.04 8*(M6XL10) 1.5±0.3 482.84±1.0 480.94±1.0 246.65±0.5 244.75±0.5 0.95±0.5 Company Address: 5F-1, No. 3-1, Park Street, Nangang District, Taipei, 11503, Taiwan.
