Page 2: Table Of Contents
TABLE OF CONTENTS SAFETY INFORMATION ..................... 1 REGULATORY INFORMATION ................... 3 CE Declaration of Conformity..................... 3 Polish Center for Testing and Certification Notice ..............4 Electric, Magnetic and Electromagnetic Fields (“EMF”) ............. 5 North Europe (Nordic Countries) Information ................6 End-of-Life Disposal ........................ - Page 3 TABLE OF CONTENTS 3.6. IR Pass-through Connection ................... 22 3.7. Wire-connecting to Network .................... 22 CHAPTER 4: OPERATION ....................23 4.1. Watch the Connected Video Source ................23 4.2. Change Picture Format ....................23 4.3. Choose your Preferred Picture Settings ................. 23 4.4.
-
Page 4: Safety Information
SAFETY INFORMATION Safety precautions and maintenance WARNING: Use of controls, adjustments or procedures other than those specified in this documentation may result in exposure to shock, electrical hazards and/or mechanical hazards. Read and follow these instructions when connecting and using your display: Operation: •... - Page 5 SAFETY INFORMATION WARNING: Severe “burn-in” or “after-image” or “ghost image” symptoms will not disappear and cannot be repaired. This is also not covered under the terms of your warranty. Service: • The casing cover should be opened only by qualified service personnel. •...
-
Page 6: Regulatory Information
REGULATORY INFORMATION CE Declaration of Conformity This device complies with the requirements set out in the Council Directive on the Approximation of the Laws of the Member States relating to Electromagnetic Compatibility (2014/30/EU), Low- voltage Directive (2014/35/EU) and RoHS directive (2011/65/EU). This product has been tested and found to comply with the harmonized standards for Information Technology Equipment, these harmonized standards published under Directives of Official Journal of the European Union. -
Page 7: Polish Center For Testing And Certification Notice
REGULATORY INFORMATION Polish Center for Testing and Certification Notice The equipment should draw power from a socket with an attached protection circuit (a three-prong socket). All equipment that works together (computer, display, printer, and so on) should have the same power supply source. The phasing conductor of the room’s electrical installation should have a reserve short-circuit protection device in the form of a fuse with a nominal value no larger than 16 amperes (A). -
Page 8: Electric, Magnetic And Electromagnetic Fields ("Emf")
REGULATORY INFORMATION Electric, Magnetic and Electromagnetic Fields (“EMF”) 1. We manufacture and sell many products targeted at consumers, which, like any electronic apparatus, in general have the ability to emit and receive electromagnetic signals. 2. One of our leading Business Principles is to take all necessary health and safety measures for our products, to comply with all applicable legal requirements and to stay well within the EMF standards applicable at the time of producing the products. -
Page 9: North Europe (Nordic Countries) Information
REGULATORY INFORMATION 設備名稱： 液晶彩色顯示器，型號（型式）：PM-65P 限用物質及其化學符號 單元 鉛 汞 鎘 六價鉻 多溴聯苯 多溴二苯醚 (Pb) (Hg) (Cd) (PBB) (PBDE) 塑料外框 ○ ○ ○ ○ ○ ○ 後殼 ○ ○ ○ ○ ○ ○ LCD panel － ○ ○ ○ ○ ○ 電路板組件... -
Page 10: Waste Electrical And Electronie Equipment-Weee
REGULATORY INFORMATION Waste Electrical and Electronie Equipment-WEEE ttention users in European Union private households This marking on the product or on its packaging illustrates that, under European Directive 2002/96/EG governing used electrical and electronic appliances, this product may not be disposed of with normal household waste. You are responsible for disposal of this equipment through a designated waste electrical and electronic equipment collection. -
Page 11: Chapter 1: Unpacking And Installation
CHAPTER 1: UNPACKING AND INSTALLATION Ukraine RoHS Обладнання відповідає вимогам Технічного регламенту щодо обмеження використання деяких небезпечних речовин в електричному та електронному обладнанні, затвердженого постановою Кабінету Міністрів України від 3 грудня 2008 № 1057 1.1. Unpacking • This product is packed in a carton, together with the standard accessories. •... -
Page 12: Mounting On A Wall
For use only with UL Listed Wall Mount Bracket with minimum weight/load: 24.8 kg. 6. Portrait is not allowed 1.4.1. VESA Grid PM-65P 400(H) x 400(V) mm Caution: To prevent the display from falling: • For wall or ceiling installation, we recommend installing the display with metal brackets which are commercially available. - Page 13 UNPACKING AND INSTALLATION • To lessen the probability of injury and damage resulting from fall of the display in case of earthquake or other natural disaster, be sure to consult the bracket manufacturer for installation location. Ventilation Requirements for enclosure locating To allow heat to disperse, leave space between surrounding objects as shown in the diagram below.
-
Page 14: Chapter 2: Parts And Functions
CHAPTER 2: PARTS AND FUNCTIONS 2.1. Control Panel MUTE INPUT MENU [ ] Power button Remote control sensor and power status Use this button to turn the display on or put indicator the display to standby. • Receives command signals from the remote control. -
Page 15: Input/Output Terminals
PARTS AND FUNCTIONS 2.2. Input/Output Terminals 11 12 AC IN SPEAKER SWITCH AC power input from the wall outlet. Internal speaker on/off switch. MAIN POWER SWITCH AUDIO IN Switch the main power on/off. Audio input from external AV device (RCA). RS232C IN / RS232C OUT AUDIO OUT... -
Page 16: Remote Control
PARTS AND FUNCTIONS 2.3. Remote Control [POWER] button Turn the display on or put the display to standby. 2.3.1 General functions [PLAY] buttons Control playback of media files. ] SOURCE button Choose input source. Press button to choose from Network HDMI 1 HDMI , or... -
Page 17: Id Remote Control
PARTS AND FUNCTIONS 2.3.2 ID Remote Control Press [ID] button. The red LED blinks twice. 1. Press [ID SET] button for more than 1 second You can set the remote control ID when you to enter the ID Mode. The red LED lights up. want to use this remote control on one of Press the [ID SET] button again will exit the ID Mode. -
Page 18: Inserting The Batteries In The Remote Control
PARTS AND FUNCTIONS 2.3.3 Inserting the batteries in the remote control The remote control is powered by two 1.5V AAA batteries. To install or replace batteries: 1. Press and then slide the cover to open it. 2. Align the batteries according to the (+) and (–) indications inside the battery compartment. -
Page 19: Chapter 3: Connecting External Equipment
CHAPTER 3: CONNECTING EXTERNAL EQUIPMENT 3.1 Connecting External Equipment (DVD/VCR/VCD) 3.1.1 Using COMPONENT video input Audio Out COMPONENT Out (YPbPr) DVD / VCR / VCD [AUDIO IN] [COMPONENT IN] (YPbPr) 3.1.2 Using Video Source input Y/CVBS Out DVD / VCR / VCD [AUDIO IN] [Y/CVBS IN]... -
Page 20: Using Hdmi Video Input
CONNECTING EXTERNAL EQUIPMENT 3.1.3 Using HDMI video input DVD / VCR / VCD HDMI Out [HDMI IN] 3.2 Connecting a PC 3.2.1 Using VGA input VGA Out D-Sub 15 pin Audio Out [VGA IN] [VGA AUDIO IN]... -
Page 21: Using Dvi Input
CONNECTING EXTERNAL EQUIPMENT 3.2.2 Using DVI input DVI Out Audio Out [DVI IN] [VGA AUDIO IN] 3.2.3 Using HDMI input HDMI Out [HDMI IN] 3.2.4 Using DisplayPort input DisplayPort Out [DisplayPort IN]... -
Page 22: Connecting Audio Equipment
CONNECTING EXTERNAL EQUIPMENT 3.3 Connecting Audio Equipment 3.3.1 Connecting external speakers External speakers 3.3.2 Connecting an external audio device Audio In Stereo Amplifier [AUDIO OUT] 3.4 Connecting Multiple Displays in a Daisy-chain Configuration You can interconnect multiple displays to create a daisy-chain configuration for applications such as a video wall. -
Page 23: Digital Video Connection
CONNECTING EXTERNAL EQUIPMENT DISPLAY 1 DISPLAY 2 [RS-232C] [RS-232C IN] [RS-232C OUT] [RS-232C IN] 3.4.2 Digital video connection Connect the [DVI OUT / VGA OUT] connector of DISPLAY 1 to the [DVI IN] connector of DISPLAY DISPLAY 1 DISPLAY 2 [DVI] [DVI IN] [DVI/VGA OUT]... -
Page 24: Analog Video Connection
CONNECTING EXTERNAL EQUIPMENT Connect the [DVI OUT ] connector of DISPLAY 1 to the [DVI IN] connector of DISPLAY 2. DVD / VCR / VCD DISPLAY 1 DISPLAY 2 [HDMI] [DVI IN] [DVI OUT] [DVI IN] 3.4.3 Analog video connection Connect the [DVI OUT / VGA OUT] connector of DISPLAY 1 to the [VGA IN] connector of DISPLAY DISPLAY 1 DISPLAY 2... -
Page 25: Ir Pass-Through Connection
CONNECTING EXTERNAL EQUIPMENT 3.6 IR Pass-through Connection [IR OUT] DVD / VCR / VCD [IR IN] (DVD / VCR / VCD) Remote Control 3.7 Wire-connecting to Network If you connect this display to a home network, you can play photos, music and videos from your computer. -
Page 26: Chapter 4: Operation
CHAPTER 4: OPERATION NOTE: The control button described in this section is mainly on the remote control unless specified otherwise. 4.1 Watch the Connected Video Source 1. Press button. ] SOURCE 2. Press button to choose a device, then press button. -
Page 27: Play Multimedia Files Via Local Area Network
OPERATION • {Game}: Ideal settings for games. • {News}: Ideal settings for spoken audio, such as the news. 4.5 Play multimedia files via Local Area Network To play files via Local Area Network, you will need: • A wired home network, connected with a Universal Plug and Play (uPnP) router. •... -
Page 28: How To Use Dlna-Dmr From Pc
OPERATION Play files from display 1. Press SOURCE button, choose network and press [ ] button. Network HDMI 1 HDMI 2 Display Port Card OPS DVI-D YPbPr 2. Now, you can see all the PC’s connected to the same router on the screen. Choose the right one. - Page 29 OPERATION 3. Set the name of your display. Picture View network settings Sound Network configuration Tiling Static IP configuration General settings Digital Media Render... Network settings Network name testabc Cancel Done Clear 4. Press SOURCE button, choose and press button. network 5.
-
Page 30: Play Multimedia Files From Usb Device
OPERATION 4.6 Play multimedia files from USB device 1. Connect your USB device to the USB port on the display. 2. Press [ ] SOURCE button, choose USB, and press [ ] button. Network HDMI 1 HDMI 2 Display Port Card OPS DVI-D YPbPr... -
Page 31: Playing Movie Files
OPERATION 4.7.2 Playing movie files 1. Choose Movie in the top bar. Movie 2. Choose a video, and press [ ] button. • To play all the videos in a folder, choose one video file. Then, press [ ] to Play All. •... -
Page 32: Chapter 5: Change Your Settings
CHAPTER 5: CHANGE YOUR SETTINGS Using the remote control: 1. Press [ ] HOME button to display the OSD menu. 2. Press [ ] [ ] [ ] or [ ] button to choose Picture, sound, Tiling, General Settings or Network settings. -
Page 33: Settings
CHANGE YOUR SETTINGS 5.1 Settings 5.1.1 Picture Picture Picture style Sound Restore style Tiling Backlight General settings Colour Network settings Sharpness Noise reduction MPEG artifact reducti... Digital Crystal Clear Advanced Game or computer Foramat and edges Picture style Choose a predefined picture setting. Restore style Restore the last-selected predefined picture setting. -
Page 34: Sound
CHANGE YOUR SETTINGS Advanced Access advanced settings such as gamma, tint, video contrast and so on. • {Gamma}: Adjust the non-linear setting for picture luminance and contrast. • {Tint}: Change the colour balance. • {Custom tint}: Customise colour balance setting. Only available if {Tint} {Custom} is chosen. -
Page 35: Tiling
CHANGE YOUR SETTINGS Surround mode Enhance your audio experience. Audio out Adjust audio output volume. Advanced Access advanced settings to enhance your audio experience. • {Auto volume leveling}: Enable the reduction of sudden volume changes. • {Speaker settings}: Turn on or off the internal speakers. •... -
Page 36: General Settings
CHANGE YOUR SETTINGS Example: 2 x 2 screen matrix (4 displays) H monitors = 2 displays V monitors = 2 displays H monitors Position Example: 5 x 5 screen matrix (25 displays) H monitors = 5 displays V monitors = 5 displays H monitors Position Frame comp. - Page 37 CHANGE YOUR SETTINGS Menu language Choose language used for OSD menus. Monitor ID Adjust the ID number for controlling the display via the RS232C connection. Each display must have a unique ID number when multiple sets of this display are connected. Monitor ID number range is between 1 to 255.
- Page 38 CHANGE YOUR SETTINGS 1. There are 7 schedule can be set. Go to Status and choose On. Schedule 1 Status Schedule 2 Source Schedule 3 On time Schedule 4 Off time Schedule 5 Repeat modes Schedule 6 Playlist setting Schedule 7 2.
- Page 39 CHANGE YOUR SETTINGS 4. Set Off time. Schedule 1 Status Schedule 2 Source Schedule 3 On time Schedule 4 Off time Schedule 5 Repeat modes Off time Schedule 6 Playlist setting 14 : 00 Schedule 7 Cancel Done 5. Go to Repeat modes and choose. Schedule 1 Status No repeat...
- Page 40 CHANGE YOUR SETTINGS 7. To save the playlist, press [ ] and choose Save list. 0004/0004 Photo \media\photo [..] Photo Sort Movie.avi Media Type Photo1.jpg Recursive Parser Photo2.jpg Save list Photo3.jpg Options Exit NOTE: • Each Playlist supports up to 30 files. •...
- Page 41 CHANGE YOUR SETTINGS • {Lock all expect volume and power}: Disable all the keyboard function except the button: POWER NOTE: To disable the lock function from or - item, press buttons Local KB lock RC lock 1 9 9 8 the remote control.
-
Page 42: Network Settings
CHANGE YOUR SETTINGS NOTE: If the display is black screen or abnormal under DisplayPort source, please switch to 1.1a and turn AC off and on. Network control port Choose the RS232 control form Card OPS or embedded RS232. Factory settings Reset all your customized settings to the factory defaults. -
Page 43: Chapter 6: Usb Device Compatibility
CHAPTER 6: USB DEVICE COMPATIBILITY 6.1 USB device compatibility USB Video Subtitle Formats (for language subtitles, etc.) File Video Maximum Max.Frame Rate Max.Bit Rate Container Audio codec Extensions codec resolution (fps) (Mbps) .mpg MPEG-1(L1&L2), MPEG-1 1920x1080 25p,30p,50i,60i mpeg MPEG-2 1920x1080 25p,30p,50i,60i MPEG-1,2,2.5 L3, .vob... -
Page 44: Chapter 7: Input Mode
CHAPTER 7: INPUT MODE VGA Resolution: Active Resolution Standard Refresh Rate Pixel Rate Aspect Ratio Stand for Mode Resolution H Pixels V Lines 60 Hz 25.175 MHz 72 Hz 31.5 MHz Video Graphic Array 75 Hz 31.5 MHz Wide Video Graphic WVGA 70 Hz 33.75 MHz... - Page 45 INPUT MODE • When horizontal synchronous signals seem irregular in RGB mode, check PC power saving mode or cable connections. • The display settings table complies to the IBM/VESA standards, and based on the analog input. • The DVI support mode is regarded as same to the PC support mode. •...
-
Page 46: Chapter 8: Troubleshooting
CHAPTER 8: TROUBLESHOOTING 8.1 Troubleshooting Symptom Possible Cause Remedy No picture is displayed 1. The power cord is disconnected. 1. Plug in the power cord. 2. The main power switch on 2. Make sure the power switch is switched on. the back of the display is not switched on. -
Page 47: Chapter 9 Technical Specifications
CHAPTER 9 TECHNICAL SPECIFICATIONS Display PM-65P Screen Size (Active Area) 1428.48 (H)x 803.52 (V) [mm](64.5’’ diagonal) Aspect Ratio 16:9 Number of pixels 1920 (H) x 1080 (V) Pixel pitch 0.744 (H) x 0.744 (V) [mm] Displayable colors 16.7M colors Brightness (typical) - Page 48 TECHNICAL SPECIFICATIONS General PM-65P Power Input 100 - 240V~, 50 - 60Hz, 5.5A Power Output 100 - 240V~, 50 - 60Hz, 2.5A Power Consumption (Max) 313 W Power Consumption (typ.) 176 W Power Consumption (Standby & Off) <0.5 W (RS232 in active) Dimensions (Without Stand) [W x H x D] 1458.7 x 834.7 x 81.6 mm...
