Summary of Contents for AGneovo DS-55

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Important Safety Instructions ..............1 1.1 Safety precautions and maintenance…………………….…....1 1.2 Use…………………………………………………………..…..……...4 1.3 Installation Notes……………………………………………..…..…...7 Package Content ..................9 2.1 Unpacking………………………………………………….…………..9 2.2 Accessories……………………………….…………….………..…..10 2.3 Overview……………………………………………………..……….11 Setting Up the Display ................13 3.1 Step 1 : Putting the dual-sided display upside …………..………13 3.2 Step 2 : Remove the three I/O covers on the sides ……………..14 3.3 Step 3 : Remove the downside cover …………………..…….…..15 3.4 Step 4 : Link power box to dual side display …………..………...16...
  • Page 3: Important Safety Instructions

    Important Safety Instructions 1.1 Safety precautions and maintenance WARNING: Use of control, adjustments or procedures other than those specified in this documentation may result in exposure to shock, electrical hazards and/or mechanical hazards. Read and follow these instructions when connecting and using your display: Operation: •...
  • Page 4 Important Safety Instructions Maintenance: • To protect your display from possible damage, do not put excessive pressure on the display. • Unplug the display if you are not going to use it for an extensive period of time. • Unplug the display if you need to clean it with a slightly damp cloth. The screen may be wiped with a dry cloth when the power is off.
  • Page 5 Important Safety Instructions Read and follow these instructions when connecting and using your display: • Unplug the display if you are not going to use it for an extensive period of time. • Unplug the display if you need to clean it with a slightly damp cloth. The screen may be wiped with a dry cloth when the power is off.
  • Page 6: Use

    Important Safety Instructions 1.2 Use • Don’t turn the ventilation hole of Power Box upside down. As shown in the picture below. The ventilation hole of power box The ventilation hole of power box It is prohibited to It is prohibited to turn the place tilt ventilation hole of Power Box upside down.
  • Page 7 Important Safety Instructions • When you install the display, please don’t use the “bottom side” I/O hole and open the I/O cover . As shown in the picture below. The “bottom side” I/O cover can’t be opened.
  • Page 8 Important Safety Instructions Remote Controller Precautions: • This product requires remote switch (ON/OFF) from Front Side ; the Back Side only has OSD function operated by remote controller. Front Side (450 nits) Back Side (450 nits) The Front Side have a product label. Disconnect devices: •...
  • Page 9: Installation Notes

    Important Safety Instructions Installation Notes There have 8 use holes on the side of the display set (M4x15mm)
  • Page 10 Important Safety Instructions Please make sure you have a solid installation. As shown in the picture. You can install the display set by screws x 8 (M4x15mm)
  • Page 11: Package Content

    This product is packed in a carton, together with the standard accessories. • Due to the size and weight of this display it is recommended for two people to move it. • After opening the carton, ensure that the contents are complete and in good condition. DS-55 DUAL SET...
  • Page 12: Accessories

    Package Content 2.2 Accessories PC Box x1 Dual Side Display x1 with 24V&12V line) Remote Controller x1 Power Cord x1 (Battery : CR 2025 3V)
  • Page 13: Overview

    Package Content 2.3 Over View Top View Diagonal View Front View Side View...
  • Page 14 Package Content 1. Display (Dual-sided) 2. Display Set 3. Remote control sensor (Dual-sided) 4. Use hole x 8 (single side have 4) 5. I/O cover x 3...
  • Page 15: Setting Up The Display

    Setting Up The Display 3.1 Step 1 : Putting the dual-sided display upside While the display put upside , the screw will be seen on the left.
  • Page 16: Step 2 : Remove The Three I/O Covers On The Sides

    Setting Up The Display 3.2 Step 2 : Remove the three I/O covers on the sides Remove I/O cover screws x 3 (M3x6mm)
  • Page 17: Step 3 : Remove The Downside Cover

    Setting Up The Display 3.3 Step 3 : Remove the downside cover Tear down the downside cover. screws x 10 (M3x6mm)
  • Page 18: Step 4 : Link Power Box To Dual Side Display

    Setting Up The Display 3.4 Step 4 : Connect Power Box to Dual Side Display 24V*1 Red line 12V*1 (10 pin) Yellow line (8 pin) Power Box Dual Side Display...
  • Page 19 Setting Up The Display Connect the 12V (8 pin) power line Connect the 24V (10 pin) power line 12V*1 24V*1 Yellow line Red line (8 pin) (10 pin)
  • Page 20: Step 5 : Connect By Hdmi Connector

    Setting Up The Display 3.5 Step 5 : Connect by HDMI connector Plug two HDMI cables into the cabinet. And ensure that all cable plugs are firmly fitted to the equipment jacks. HDMI HDMI Front Side (450 nits) Back Side (450 nits)
  • Page 21: Step 6 : Reinstall The Downside Cover And I/O Covers

    Setting Up The Display 3.6 Step 6 : Reinstall the downside cover and I/O covers Reinstall the downside cover. screws x 10 (M6x30mm) Reinstall the other two I/O covers which are not used.
  • Page 22: Step 7 : Connect The Power Cord

    Setting Up The Display Step 7 : Connect the power cord Power Box AC in / switch Plug in the power cable and turn on the AC power switch.
  • Page 23: Step 8 : Using The Remote Control

    Setting Up The Display 3.8 Step 8 : Using the Remote Control Descriptions Power Power on/Power off Menu Into OSD module Menu Up Menu Down Exit Menu/Exit selection...
  • Page 24: Osd Setting Menu

    Setting Up The Display 3.9 OSD Setting Menu Press “MENU” into the OSD Setting Menu, and then press “UP” or “DOWN” to select the item, at last press “EXIT” to leave menu : Press MENU to select one of the following, and then press “UP” or Luminance “DOWN”...
  • Page 25 Setting Up The Display Press “MENU” into the OSD Setting Menu, and then press “UP” or “DOWN” to select the item, at last press “EXIT” to leave menu : Press MENU to select one of the following, and then press “UP” or Color “DOWN”...
  • Page 26 Setting Up The Display Press “MENU” into the OSD Setting Menu, and then press “UP” or “DOWN” to select the item, at last press “EXIT” to leave menu : Press MENU to select one of the following, and then press “UP” or Settings “DOWN”...
  • Page 27 Setting Up The Display Press “MENU” into the OSD Setting Menu, and then press “UP” or “DOWN” to select the item, at last press “EXIT” to leave menu : Press MENU to select one of the following, and then press “UP” or Setup “DOWN”...
  • Page 28: Trouble Shooting

    Trouble shooting Symptom Possible Cause Remedy 1. The power cord is disconnected. 1. Plug in the power cord. 2. The main power switch on the back 2. Make sure the power No picture is of the display is not switched on. switch is switched on.
  • Page 29: Specifications

    Specifications Model name DS-55 Screen size 55 inch (diagonal) Resolution 1920 x1080 (Pixel) Display Area 1209.6(H) x 680.4(V) LCD Display 55” Contrast Ratio 3000:1 Brightness 450 nits / 450 nits 178° (H); 178° (V) View angle Color Gamut 72 (%)
  • Page 30: Product Dimensions

    Product Dimensions A,B,C: I/O covers Company Address: 5F-1, No. 3-1, Park Street, Nangang District, Taipei, 11503, Taiwan.
