Summary of Contents for AGneovo PF-55H
-
Page 3: Table Of Contents
Table of contents Safety warnings and precautions ............ 4 Product Description ................7 Parts and functions ................8 Input/Output Terminals ................ 8 Rear side buttons ................8 OSD Menu ..................9 OSD Main Menu .................. 9 Function Menu: Color ................9 Function Menu: Image setting ............. -
Page 4: Safety Warnings And Precautions
Safety warnings and precautions WEEE Information for users applicable in European Union countries. The symbol on the product or its packaging signifies that this product has to be disposed separately from ordinary household wastes at its end of life. Please kindly be aware that this is your responsibility to dispose electronic equipment at recycling centers so as to help conserve natural resources. - Page 5 Safety warnings and precautions Please read these instructions before using the product, and retain for future reference. Please comply with standard operating methods stipulated for this product. Please ensure that the voltage provided at the site of use is compatible with the products voltage requirements.
- Page 6 Safety warnings and precautions Please do not place the Please do not place the display in close proximity to display under direct sunlight or water, such as bathing pools strong lighting. Excessive heat or swimming pools, and do not from sunlight may damage the place the display at areas that display, while direct exposure may be exposed to water...
-
Page 7: Product Description
Product Description Package Contents When unpacking, check if the following items are included in the package. If any of them is missing or damaged, contact your dealer. Kiosk Display Power Cord HDMI Cable User’s Manual... -
Page 8: Parts And Functions
Parts and functions Input/Output Terminals Rearside buttons Press this button to turn the display on or off Green: ON Red: OFF AUTO 1. When the OSD menu screen is not activated, press this button to automatically switch to another input source. AUTO 2. -
Page 9: Osd Menu
OSD Menu OSD Main Menu Press the [MENU] button to call out the OSD window. Press the [V+] or [V-] buttons to select the desired option. To exit, press the [AUTO] button. Function Menu: Color Press the [MENU] button to select Color. - Page 10 OSD Menu Under Color menu, the available menu options are: 1. Contrast 2. Brightness 3. Color Adjust 4. Color Temp (color temperature) Select Contrast / Brightness and press the [MENU] button, then use [V+] or [V-] buttons to adjust the values.
-
Page 11: Function Menu: Image Setting
OSD Menu Color Temp is used to adjust color temperature according to the user's requirements. When the Color Temp setting is set to User mode, you may implement display color adjustments in Color Adjust. To exit, press the [AUTO] button. Function Menu: Image setting ... -
Page 12: Function Menu: Osd Menu
OSD Menu Under Image Setting menu, the available menu options are: 1. Clock: adjusting the clock 2. Phase: adjusting the phase 3. Sharpness: adjusting sharpness 4. H. Position: moves the display up and down 5. V. Position: moves the display left and right ... -
Page 13: Function Menu: Signal Source
OSD Menu Under OSD Menu menu, the available menu options are: 1. OSD H. POS: moves the OSD menu position up and down 2. OSD V. POS: moves the OSD menu position left and right 3. OSD Timer: selects the OSD interface dwelling time 4. -
Page 14: Function Menu: Audio
OSD Menu Under Signal Source menu, you can switch to the desired input signal source. The available option are: 1. D-SUB 2. DVI 3. HDMI 4. Auto Search: automatically detect the available signal source To exit, press the [AUTO] button. Function Menu: Audio ... -
Page 15: Function Menu: Special
OSD Menu Under Audio menu, the available menu options are: 1. Volume: adjusts the volume 2. Mute: temporarily turns off all volume 3. Auto Select: automatically selects the audio source To exit, press the [AUTO] button. Function Menu: Special ... - Page 16 OSD Menu Under Special menu, the available menu options are: 1. Aspect Ratio: No support. 2. Reset: resets all parameters to the factory default settings 3. Auto: automatic adjustments 4. Monitor ID: sets the name of the device To exit, press the [AUTO] button...
-
Page 17: Installation Notes
Installation Notes... - Page 18 Installation Notes Space for IPC Remark: B1: M3 screw x 7L B2: M4 screw x 7L B3: M4 screw x 8.4L B4: M4 screw x 9.4L Space: 550 x 376 x 50 mm...
-
Page 19: Troubleshooting
Troubleshooting Problem Solution 1. Check if the HDMI cable between PC/Media player Shift in displayed and the display is properly plugged in. Replace the picture HDMI cable if it appears to be damaged 1. Enter the graphics card adjustment menu (click the Adjusting the right button of the mouse on any location on the resolution... - Page 20 Troubleshooting Problem Solution 1. Check if the volume is set to 0. No sound (When 2. Check if the audio is set to OFF. using HDMI cable) 3. Ensure the HDMI supports audio output. If so, select video under DVI source. If still not support, select PC (audio connection is required).
-
Page 21: Product Dimensions
Product Dimensions PF-55H Speaker (10W) Caster... -
Page 22: Specification
Specification Model PF-55H LCD Size 55 inch Light Source Active Area (mm) 1209.6(H) x 680.4(V) Resolution FHD 1080 x 1920 (pixels) Pixel Pitch 0.63(H) x 0.63 (V) mm Aspect Ratio 16:9 Brightness (typ)/(min) 700nits Panel Contrast Ratio (typ.) 4000 : 1 ( typ ) Response Time (ms) 6.5 ms (G to G) - Page 23 Specification AC Outlet (inside) Power 100~240V / 5.3A Dimension 1975 x 815x 67/ 651(D) mm (H x W x D mm) Stand:815 x 651mm (Top view) Border width (U/R/L) 65 / 67.3 / 67.3 mm Net weight 105 kg Packing weight 115 kg OSD Control 5 KEY KEYPAD...
