Page 3: Table Of Contents
Table of Contents ● FCC Information ● Safety Precautions 1. General Features 2. Set Up 3. Controls and Indicators 4. On Screen Display... -
Page 4: Fcc Information
FCC INFORMATION This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 5: Safety Precautions
SAFETY PRECAUTIONS 1. Do not modify the three-prong grounding type monitor power plug in any way. 2. Operate this unit only from the type of power source indicated on the label. 3. Do not block or cover ventilation openings on the back or bottom of the monitor cabinet. 4. -
Page 6: General Features
1. GENERAL FEATURES This is a high performance TFT LCD monitor with up to 1280X1024 SXGA resolutions. The LCD monitor has been designed for use with both PC and Video, complying with the power management regulations of VESA DPMS, supported by Plug &... -
Page 7: Set Up
2. SET UP Read this chapter for important safety information and how to set up and connect the display to your computer or camera. ˙Check the accessories in the box. There is power cord, power adapter user's manual, audio cable and D-Sub cable. ˙Make sure the surface for placing the LCD monitor is stable and level. -
Page 8: Controls And Indicators
3. CONTROLS AND INDICATORS 3.1 FRONT PANEL A. CHANNEL SELECT INPUT / AUTO-ADJ / EXIT BUTTON ˙Press the button to display the input signal. ˙Press the button for 2 second to do auto adjust function. ˙Press the button to exit OSD menu. B. - Page 9 3.2 I/O CONNECTORS A. AUDIO input B. CVBS output C. CVBS input D. DVI-I (PC) input E. DC 12V input...
-
Page 10: On Screen Display
4. ON SCREEN DISPLAY (OSD) VOLUME：Press button to select the function and then press buttons to adjust the volume value，press button to exit the OSD. KEY LOCK：Press MENU button + CHANNEL button + POWER button Simultaneously for 2.5 sec to enter to key Lock function. (Note: Always Press MENU Key first) (In no signal mode the Key Lock function is invalid) KEY UNLOCK：Press MENU... - Page 11 AUTO ADJUST：On VGA mode Press button for 2 sec to enter to Auto Adjust function. PC mode OSD： MAIN ADJUST, COLOR ADJUST, IMAGE ADJUST, INFORMATION, SETUP MENU, RECALL, EXIT MAIN MENU: Press MENU button to enter to MAIN MENU. Press MENU to confirm the selection.
- Page 12 MAIN ADJUST: 1. Press MENU button to enter the selection 2. Press button to adjust the value. 3. Press to leave the selection BRIGHTNESS：Adjust the brightness value. CONTRAST：Adjust the contrast value. VOLUME：Adjust the volume value. EXIT：Leave the selection.
- Page 13 COLOR ADJUST：Select the color temperature for the CIE coordinate 9300˚k or 6500˚k or USER COLOR Mode. 1. Press MENU button to enter the selection. 2. Press button to select the color temperature. 3. Press to leave the selection. 6500/9300/USER COLOR：Adjust the color temperature. RED：Adjust the RED value for user mode.
- Page 14 IMAGE ADJUST： 1. Press MENU button to enter the selection. 2. Press button to adjust the value. 3. Press button to leave the selection. AUTO ADJUST：Auto adjust the H.Position，V.Position，Phase and Clock. H. POSITION：Adjust the horizontal position value. V. POSITION：Adjust the vertical position value. PHASE：Adjust the phase value.
- Page 15 INFORMATION： Display the VGA timing and F.W version information. SETUP MENU： 1. Press MENU button to enter the selection. 2. Press button to select the function. 3. Press button to leave the selection.
- Page 16 LANGUAGE：Select language VIVID MODE：Select Vivid Mode (0:Normal,1:Text,2:Photo,3:Movie) GREEN MODE：Adjust Green Mode (Off or 5 min~10 min) Off – No function. On – Screen will reduce back light to 80% within (5Min to 10Min) Screen will back to normal when any button is pressed. ANTI-BURN-IN：Adjust ANTI-BURN-IN(On or Off) Off –...
- Page 17 OSD H. POSITION：Adjust the OSD horizontal position value. OSD V. POSITION：Adjust the OSD vertical position value. OSD TIMEOUT：Adjust the OSD display time. EXIT：Leave the selection RECALL：BRIGHTNESS, CONTRAST, VOLUME, VIVID MODE, OSD Horizontal/Vertical, OSD TIMEOUT, GREEN MODE, ANTI-BURN-IN return to default Value. Video mode OSD: MAIN ADJUST, COLOR ADJUST, SCAN SETTING, INFORMATION, SETUP MENU, RECALL, EXIT...
- Page 18 MAIN ADJUST: 1. Press MENU button to enter the selection 2. Press button to adjust the value. 3. Press CH button to leave the selection BRIGHTNESS：Adjust the brightness value. CONTRAST：Adjust the contrast value. SHARPNESS：Adjust the sharpness value. SATURATION：Adjust the saturation value. TINT：Adjust the tint value (NTSC only).
- Page 19 SCAN SETTING: 1. Press MENU button to enter the selection. 2. Press buttons to select the function. 3. Press button to leave the function. OVERSCAN / UNDERSCAN：Adjust scan mode. Exit：Leave the selection INFORMATION： Display the Video timing and F.W version information， RECALL：BRIGHTNESS, CONTRAST, SHARPNESS, SATURATION, TINT, VOLUME, VIVID MODE, OSD Horizontal/Vertical, OSD TIMEOUT, GREEN MODE, ANTI-BURN-IN return to default Value.
- Page 20 MODEL SC-17 SC-19 DESCRIPTION Panel type 17” TFT color LCD panel 19” TFT color LCD panel Viewable size 337.92(H) x 270.336(V) mm 376.32(H) x 301.06(V) mm Dot pitch 0.264 mm 0.294 mm Resolution 1280 x 1024 1280 x 1024 Display color 16.7M 16.7M Power input...
- Page 24 3121-1175G02 Rev.A0...
