Summary of Contents for AGneovo FM-27
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Information---------------------------------------------------------------2 Important Safety Instruction---------------------------------------------------3 Special Notice ------------------------------------------------------------------- 3 Connection------------------------------------------------------------------------4 Stand Assembly Instruction---------------------------------------------------4 Front Panel Controls------------------------------------------------------------5 Operate Explanation------------------------------------------------------------5 OSD Control---------------------------------------------------------------------- 5 OSD Menu------------------------------------------------------------------------ 6 Specification-----------------------------------------------------------------------7 Display Mode--------------------------------------------------------------------- 7... -
Page 3: Safety Information
Safety Information CE Declaration of Conformity We declare under our responsibility that the product is in conformity with the following standards: • EN60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013 (Safety requirement of Information Technology Equipment). • EN55022:2010 (Radio Disturbance requirement of Information Technology Equipment). • EN55024:2010 (Immunity requirement of Information Technology Equipment). •... -
Page 4: Important Safety Instruction
Important Safety Instruction 1. Read these instructions thoroughly and keep this user manual for future use. 2. Do not use the product near water. Never spill liquid of any kind of the products. Clean LED monitor when power off. Never clean it with liquid cleanness or liquefier. Better use clean wet cloth carefully. -
Page 5: Connection
Connection 1. Turn off computer and unplug power cord. 2. To connect signal cable with 15pin into VGA connector on the back of monitor, and to be sure to tighten switches on both ends of signal cable. 3. To plug PC and monitor adapter to the nearest socket. 4. -
Page 6: Front Panel Controls
Front Panel Controls Press it to open the OSD MENU, to MENU select MENU options when the OSD MENU is displayed. Hot key to adjust Contrast when the ◄ OSD is off. Adjust value up selection button Hot key to adjust Brightness when the ►... -
Page 7: Osd Menu
OSD Menu Primary Secondary Description Directory Directory Contrast Adjust the contrast of the image Color Brightness Adjust the brightness of the screen Color Temp Set up the color Temp. to be 9300K 6500K 5500K USER red, green, blue to adjust red/green/blue Auto Adjust Set up to adjust clock, phase and position automatically (VGA only) Color Adjust... -
Page 8: Specification
Specification FM-24 FM-27 Panel Size 23.6” 27” Max resolution 1920 x 1080 / Full HD 1920 x 1080 / Full HD Display Color 16.7M 16.7M Pixel Pitch 0.2715mm(H) x 0.2715mm(V) 0.3114mm(H) x 0.3114mm(V) Brightness 250cd/m (typical) 250cd/m (typical) Contrast Ratio...
