- Page 1 USER'S MANUAL LOCAL AIR CONDITIONER AMC-11AN, AMC-14AN...
-
Page 2: Introduction / Technical Data
INTRODUCTION / TECHNICAL DATA Congratulations on purchasing portable type air conditioner. Your air-conditioner has been developed and manufactured in accordance with standards of state of the art technology. Please read the operating instructions carefully before connecting your unit to the power supply in order to prevent damage from improper use. -
Page 3: Scope Of Delivery
SCOPE OF DELIVERY 1 x unit 1 x bracket air hose 1 x operating instructions 1 x remote control 1 x sir outlet grid 1 x drainage hose 50 cm 1 x air hose 150 cm 1 x coarse filter top, 1 coarse filter 2 x sealing plug 1 x air hose connector bottom... -
Page 4: Name Of The Components
NAME OF THE COMPONENTS Operating panel Control lamp Air outlet grid Air hose connection piece Air hose Upper condensation water outlet with rubber plug 7. Cool inlet 8. Cool Air filter 9. Hot inlet 10. Hot air filter 11. Drain pipe IMPORTANT INSTRUCTIONS 1. -
Page 5: Operating Panel
OPERATING PANEL DESCRIPTION OF FUNCTIONS 1. [POWER] Press this switch to switch on or off 2. [FUNC] Press this switch to select between the functions “Cooling”, „Heating“ or „Dehumidity“ 3. [TEMP+] Press this switch in the cooling function in order to set the required room temperature by 1°C respectively up to a maximum temperature of 30°C. - Page 6 7. [TIMER] Programmable time switch with start and residual time Starting time: This function is used to switch on the unit automatically when the time entered has expired. Proceed as follows: i) Press [TIMER] switch in Stand-by (this unit is connected but not in operation), to enter the required number of hours after which the unit is to start.
- Page 7 COOLING It is recommended to start the unit early on hot days, thus avoiding heating up of the room. This unit has a self-evaporation function for condensation water, so that it is normally not necessary to empty the water tank in cooling mode. The drainage hose need not be connected. Please make sure that the outlet is closed with the rubber cap during operation.
- Page 8 Set the function to “COOLING”. The settable temperature range is between 17 and 30 degrees. This can be set using the temperature control. The air with high oxygen content cooled by the unit is fed into the room via the air hose. This can be executed e.g.
- Page 9 HEATING IN OUTDOOR OPERATION The unit is outside the room tio be heated. Outdoor operation is ideal for the transition period in which outside temperatures do no fall below 7 degrees. (If the outside temperature should however fall below 7 degrees Connect the air hose and the air outlet grid to the unit as continuously, we recommend indoor operation).
-
Page 10: Error Messages
CLEANING AND MAINTENANCE MAINTENANCE PLEASE REMOVE THE POWER PLUG FROM THE SOCKET BEFORE CLEANING THE UNIT. COARSE FILTER The air filters on the side of the unit can be simply removed by pulling the frame sidewards. When cleaning, use a vacuum cleaner with brush or wash the filters under running, warm water and dry them with a soft cloth! Please clean the coarse filters before initial use, and regularly when in use. - Page 11 You achieve the most effective and economical cooling Unit does not cool comfort if you already cool the room to be cooled when correctly the room temperature is not yet heated up. Air conditioners operate more effectively if the temperature is to be maintained.
-
Page 12: Wiring Diagram
WIRING DIAGRAM ENERGY LABEL... -
Page 13: Technical Parameters
Weight with package 30,7 Name and address of the manufacturer Manufacturer: SINCLAIR CORPORATION Ltd., 1-4 Argyll St., London, UK or of its authorised representative. Representative: NEPA spol. s r.o., Purkyňova 45, Brno 612 00, ČR Contact details for obtaining more information www.sinclair-eu.com / klimatizace@nepa.cz... - Page 14 Weight with package 32,8 Name and address of the manufacturer Manufacturer: SINCLAIR CORPORATION Ltd., 1-4 Argyll St., London, UK or of its authorised representative. Representative: NEPA spol. s r.o., Purkyňova 45, Brno 612 00, ČR Contact details for obtaining more information www.sinclair-eu.com / klimatizace@nepa.cz...
- Page 15 In case of quality problem or other please contact your local supplier or authorized service center. Emergency number: 112 PRODUCER Producer: SINCLAIR CORPORATION Ltd., 1-4 Argyll St., London W1F 7LD, UK, www.sinclair-eu.com This product was manufactured in China (Made in China).
