Ellington E-PD52ABZ5C4 Installation Manual

Ceiling fan elevating style

Hide thumbs

Table of Contents

Quick Links

Federal regulations require all ceiling

fans with light kits manufactured or

imported after January 1, 2009, to limit

total wattage consumed by the light kit

to 190W. Therefore, this fan is equipped

with a wattage limiting device.

Installation Guide

For Models:

E-PD52ABZ5C4

E-PD52BP5C4

E-PD52WW5C4

E124404

net weight of fan: 17.64 lb. (8kg)

READ THESE INSTRUCTIONS AND

SAVE THEM FOR FUTURE USE

Need help?

Do you have a question about the E-PD52ABZ5C4 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ellington E-PD52ABZ5C4

Page 1: Table Of Contents
January 1, 2009, to limit total wattage consumed by the light kit to 190W. Therefore, this fan is equipped with a wattage limiting device. Installation Guide For Models: E-PD52ABZ5C4 Table of Contents: E-PD52BP5C4 Safety Tips. pg. 1 E-PD52WW5C4 Unpacking Your Fan. pg. 2 Parts Inventory.
Page 2: Safety Tips
SAFETY TIPS. WARNING: To reduce the risk of electrical shock, turn off the electricity to the fan at the main fuse box or circuit panel before you begin the fan installation or before servicing the fan or installing accessories. Read all instructions and safety information carefully before installing your fan and save these instructions. CAUTION: To avoid personal injury, the use of gloves may be necessary while handling fan parts with sharp edges.
Page 3: Unpacking Your Fan
1. Unpacking Your Fan. Carefully open the packaging. Remove items from Styrofoam inserts. Remove motor housing and place on carpet or Styrofoam to avoid damage to finish. Do not discard fan carton or Styrofoam inserts should this fan need to be returned for repairs.
Page 4: Installation Preparation
3. Installation Preparation. blade edge inches To prevent personal injury and damage, ensure that 7 feet (76cm) the hanging location allows the blades a clearance of (2.13m) 7ft. (2.13m) from the floor and 30in. (76cm) from any wall or obstruction. This fan is suitable for room sizes up to 400 square 12ft.
Page 5: Fan Assembly (With Downrod)
5. Fan Assembly (with downrod). If you wish to extend the hanging length of set screw hole your fan, you must remove the hanging ball set screw from the 4in. downrod provided to use with an stop pin extended downrod (sold separately). [If you wish to use the 4in.
Page 6: Fan Assembly. Pgs
5. Fan Assembly (with downrod). (cont. ) With the hanging bracket secured to the outlet box and able to support the fan, you are now ready to hang your fan. Grab the fan firmly with two hands. Slide downrod through opening in hanging bracket tab hanging bracket and let hanging ball rest on the hanging ball slot...
Page 8: Wiring
7. Wiring. CAUTION: Be sure outlet box is properly grounded and that a ground wire (GREEN or Bare) is present. white supply wire Make sure all electrical connections comply with ground (green or bare) Local Codes or Ordinances and the National black supply wire Electrical Code.
Page 9: Blade Assembly
9. Blade Assembly. Time Saver: Washers for blade screws can be set on each blade screw prior to installing blades. motor housing Locate 15 blade attachment screws and washers in one of the hardware packs. Hold blade arm up to blade and align holes. Insert 3 blade attachment screws (along with washers) with blade attachment fingers first and then tighten screws securely...
Page 11: Testing Your Fan
10. Light Kit Assembly (Optional). (cont.) motor housing Connect WHITE wire from switch housing to WHITE wire from light kit fitter. Connect BLACK wire from switch housing to BLACK wire from light kit fitter. When making the connections, use wire connectors that were previously removed.
Page 12: Troubleshooting
Troubleshooting. Warranty. ELLINGTON LIFETIME LIMITED WARRANTY: ELLINGTON/LITEX INDUSTRIES, LTD. warrants this fan to the original household purchaser for indoor use under the following provisions: 1-YEAR WARRANTY: ELLINGTON/LITEX INDUSTRIES, LTD. will replace or repair any fan which has faulty performance Problem: Fan fails to operate.
