Pictorial index

For safety

1

and security

Instrument cluster

2

Operation of each

3

component

Driving

4

Lexus Display

5

Audio system

Interior features

6

Maintenance

7

and care

When trouble

8

arises

Vehicle

9

specifications

For owners

10

Index

ES300h_OM_OM33B71U_(U)

Search by illustration

Make sure to read through them

How to read the gauges and meters, the variety of

warning lights and indicators, etc.

Opening and closing the doors and windows,

adjustment before driving, etc.

Operations and advice which are necessary for driving

Operating the Lexus Display Audio system

Usage of the interior features, etc.

Caring for your vehicle and maintenance procedures

What to do in case of malfunction or emergency

Vehicle specifications, customizable features, etc.

Reporting safety defects for U.S. owners, and seat belt

and SRS airbag instructions for Canadian owners

Search by symptom

Search alphabetically

Table of Contents

Advertisement

Table of Contents

Troubleshooting

Need help?

Need help?

Do you have a question about the ES300h and is the answer not in the manual?

Questions and answers

Summary of Contents for Lexus ES300h

Page 1 Driving Operations and advice which are necessary for driving Lexus Display Operating the Lexus Display Audio system Audio system Interior features Usage of the interior features, etc. Maintenance Caring for your vehicle and maintenance procedures...
Page 2: Table Of Contents
TABLE OF CONTENTS For your information........8 Operation of each Reading this manual........14 component How to search ..........15 3-1. Key information Pictorial index..........16 Keys ..........104 For safety and security 3-2. Opening, closing and locking the doors and trunk Doors..........108 1-1.
Page 3 4-5. Using the driving support Driving systems Lexus Safety System+ ....194 4-1. Before driving (Pre-Collision System) ..201 Driving the vehicle ......154 LDA (Lane Departure Alert Cargo and luggage....160 with steering control)....213 Vehicle load limits......163 Dynamic radar Trailer towing .........164 cruise control......
Page 4 TABLE OF CONTENTS 5-6. Using an external device Lexus Display Audio system Listening to an iPod....326 Using USB memory 5-1. Basic Operations device ..........330 Lexus Display Audio Using the AUX port ....334 System ......... 286 ® 5-7. Connecting Bluetooth Steering wheel audio ®...
Page 5 Weather information ....375 • Clock ........406 Voice command system... 376 • Power outlets......406 Mobile Assistant......380 • Armrest........407 LEXUS Enform Remote ..382 • Rear sunshade/rear door sunshades .......408 Interior features • Coat hooks......410 • Assist grips ......410 Garage door opener ....411 6-1.
Page 6 TABLE OF CONTENTS Maintenance and care When trouble arises 7-1. Maintenance and care 8-1. Essential information Cleaning and protecting Emergency flashers ....492 the vehicle exterior ....428 If your vehicle has to be Cleaning and protecting stopped in an emergency..493 the vehicle interior....431 8-2.
Page 7 What to do if... (Troubleshooting)........ 578 Alphabetical index ........582 For vehicles with navigation system, refer to the “NAVIGATION SYSTEM OWNER’S MANUAL” for information regarding the equipment listed below. • Navigation system • Lexus parking assist monitor • Audio/video system • Lexus Enform ES300h_OM_OM33B71U_(U)
Page 8: For Your Information
Lexus vehicle. This vehicle should not be modified with non-genuine Lexus products. Modification with non-genuine Lexus products could affect its performance, safety or durability, and may even violate governmental regulations.
Page 9 Seat belt pretensioner system ● Be sure to check with your Lexus dealer for precautionary measures or special instruc- tions regarding installation of a mobile two-way radio system. High voltage parts and cables on the hybrid vehicles emit approximately the same amount of electromagnetic waves as the conventional gasoline powered vehicles or home electronic appliances despite of their electromagnetic shielding.
Page 10 ● land only) If your Lexus has Safety Connect or Lexus Enform and if you have subscribed to those services, please refer to the Safety Connect / Lexus Enform Telematics Subscription Service Agreement for information on data collected and its usage.
Page 11: Event Data Recorder
EDR. Disclosure of the EDR data ● Lexus will not disclose the data recorded in an EDR to a third party except when: • An agreement from the vehicle’ s owner (or the lessee for a leased vehicle) is obtained •...
Page 12 Scrapping of your Lexus The SRS airbag and seat belt pretensioner devices in your Lexus contain explosive chemicals. If the vehicle is scrapped with the airbags and seat belt pretensioners not deployed, this may cause an accident such as fire. Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Lexus dealer before you scrap your vehicle.
Page 13 ES300h_OM_OM33B71U_(U)
Page 14: Reading This Manual
Reading this manual WARNING: Explains something that, if not obeyed, could cause death or serious injury to people. NOTICE: Explains something that, if not obeyed, could cause damage to or a mal- function in the vehicle or its equipment. Indicates operating or working procedures. Follow the steps in numerical order.
Page 15: How To Search
How to search Searching by name ■ • Alphabetical index....P. 582 Searching by installation position ■ • Pictorial index ......P. 16 Searching by symptom or sound ■ • What to do if... (Troubleshooting)....P. 578 Searching by title ■ • Table of contents......P. 2 ES300h_OM_OM33B71U_(U)
Page 16: Pictorial Index
Pictorial index Pictorial index ■ Exterior Doors ..............P. 108 Locking/unlocking .
Page 17 Pictorial index Windshield wipers ........... .P. 186 Precautions against winter season .
Page 18: Instrument Panel
Pictorial index ■ Instrument panel Power switch............P. 166 Starting the hybrid system/changing the modes.
Page 19 Pictorial index Multi-information display ..........P. 91 Display .
Page 20 Pictorial index ■ Switches Outside rear view mirror switches ........P. 142 Instrument panel light control switches.
Page 21 Pictorial index Driving position memory switches ....... . . P. 130 Door lock switch.
Page 22 Pictorial index Audio remote control switches ........P. 293 Talk switch .
Page 23 Remote Touch Lexus Display Audio controller ........P. 288 : For vehicles with navigation system, refer to “NAVIGATION SYSTEM OWNER’S MANUAL”.
Page 24 Pictorial index ■ Interior SRS airbags ............P. 37 Floor mats.
Page 25 Pictorial index Inside rear view mirror ..........P. 140 Sun visors .
Page 26 Pictorial index ES300h_OM_OM33B71U_(U)
Page 27: For Safety And Security
For safety and security 1-1. For safe use Before driving.........28 For safe driving.......30 Seat belts .......... 32 SRS airbags ........37 Front passenger occupant classification system....46 Safety information for children........52 Child restraint systems ....53 Installing child restraints..... 57 Exhaust gas precautions....
Page 28: 1-1. For Safe Use
1-1. For safe use Before driving Floor mat Use only floor mats designed specifically for vehicles of the same model and model year as your vehicle. Fix them securely in place onto the carpet. Insert the retaining hooks (clips) into the floor mat eyelets.
Page 29 ■ Do not use floor mats designed for other models or different model year vehicles, ● even if they are Lexus Genuine floor mats. Only use floor mats designed for the driver’ s seating position. ● Always install the floor mat securely using the retaining hooks (clips) provided.
Page 30: For Safe Driving
1-1. For safe use For safe driving For safe driving, adjust the seat and mirror to an appropriate position before driving. Correct driving posture Adjust the angle of the seatback so that you are sitting straight up and so that you do not have to lean forward to steer.
Page 31 1-1. For safe use WARNING Observe the following precautions. Failure to do so may result in death or serious injury. Do not adjust the position of the driver’ s seat while driving. ● Doing so could cause the driver to lose control of the vehicle. Do not place a cushion between the driver or passenger and the seatback.
Page 32: Seat Belts
1-1. For safe use Seat belts Make sure that all occupants are wearing their seat belts before driving the vehicle. Correct use of the seat belts Extend the shoulder belt so that it ● comes fully over the shoulder, but does not come into contact with the neck or slide off the shoulder.
Page 33 1-1. For safe use Seat belt pretensioners (front and outboard rear seats) The pretensioners help the seat belts to quickly restrain the occupants by retracting the seat belts when the vehi- cle is subjected to certain types of severe frontal collision or a vehicle roll- over.
Page 34 Each seat belt should be used by one person only. Do not use a seat belt for more ● than one person at once, including children. Lexus recommends that children be seated in the rear seat and always use a seat belt ● and/or an appropriate child restraint system.
Page 35 If the pretensioner has activated, the SRS warning light will come on. In that case, the ● seat belt cannot be used again and must be replaced at your Lexus dealer. Adjustable shoulder anchor ■...
Page 36 1-1. For safe use NOTICE When using a seat belt extender ■ When releasing the seat belt, press on the buckle release button on the extender, not on the seat belt. This helps prevent damage to the vehicle interior and the extender itself. ES300h_OM_OM33B71U_(U)
Page 37: Srs Airbags
1-1. For safe use SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. ◆...
Page 38 1-1. For safe use SRS curtain shield airbags Can help protect primarily the head of occupants in the outer seats ● Can prevent the occupants from being thrown from the vehicle in the ● event of vehicle rollover SRS airbag system components Front passenger occupant classifi- Side impact sensors (front) cation system (ECU and sensors)
Page 39 1-1. For safe use Your vehicle is equipped with ADVANCED AIRBAGS designed based on the US motor vehicle safety standards (FMVSS208). The airbag sensor assembly (ECU) controls airbag deployment based on information obtained from the sen- sors etc. shown in the system components diagram above. This information includes crash severity and occupant information.
Page 40 An infant or child who is too small to use a seat belt should be properly secured using a child restraint system. Lexus strongly recom- mends that all infants and children be placed in the rear seats of the vehicle and prop- erly restrained.
Page 41 1-1. For safe use WARNING SRS airbag precautions ■ Do not lean against the door, the roof side rail ● or the front, side and rear pillars. Do not allow anyone to kneel on the passen- ● ger seats toward the door or put their head or hands outside the vehicle.
Page 42 The airbag itself may also be hot. The windshield may crack. ● For Lexus Enform Safety Connect subscribers, if the SRS airbags deploy or in the event ● of a severe rear-end collision, the system is designed to send an emergency call to the response center, notifying them of the vehicle’...
Page 43 1-1. For safe use SRS airbag deployment conditions (SRS front airbags) ■ The SRS front airbags will deploy in the event of an impact that exceeds the set thresh- ● old level (the level of force corresponding to an approximately 12 - 18 mph [20 - 30 km/h] frontal collision with a fixed wall that does not move or deform).
Page 44 1-1. For safe use Types of collisions that may not deploy the SRS airbags (SRS front airbags) ■ The SRS front airbags do not generally inflate if the vehicle is involved in a side or rear collision, if it rolls over, or if it is involved in a low-speed frontal collision. But, whenever a collision of any type causes sufficient forward deceleration of the vehicle, deployment of the SRS front airbags may occur.
Page 45 1-1. For safe use When to contact your Lexus dealer ■ In the following cases, the vehicle will require inspection and/or repair. Contact your Lexus dealer as soon as possible. Any of the SRS airbags have been inflated. ● The front of the vehicle is damaged or ●...
Page 46: Front Passenger Occupant Classification System
1-1. For safe use Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classification sys- tem. This system detects the conditions of the front passenger seat and acti- vates or deactivates the devices for the front passenger. Seat belt reminder light SRS warning light “AIR BAG OFF”...
Page 47 1-1. For safe use Condition and operation in the front passenger occupant classification system Adult ■ “AIR BAG ON” and “AIR BAG OFF” “AIR BAG ON” indicator lights Indicator/ SRS warning light warning light Seat belt reminder light or flashing Front passenger airbag Side airbag on the front passenger seat...
Page 48 1-1. For safe use Child restraint system with infant ■ “AIR BAG ON” and “AIR BAG OFF” “AIR BAG OFF” indicator lights Indicator/ SRS warning light warning light Seat belt reminder light or flashing Front passenger airbag Deactivated Side airbag on the front passenger seat Activated Curtain shield airbag...
Page 49 1-1. For safe use There is a malfunction in the system ■ “AIR BAG ON” and “AIR BAG OFF” “AIR BAG OFF” indicator lights Indicator/ SRS warning light warning light Seat belt reminder light Front passenger airbag Deactivated Side airbag on the front passenger seat Activated Curtain shield airbag...
Page 50 1-1. For safe use WARNING Front passenger occupant classification system precautions ■ Observe the following precautions regarding the front passenger occupant classifica- tion system. Failure to do so may cause death or serious injury. Wear the seat belt properly. ● Make sure the front passenger’...
Page 51 ● SRS warning light may come on to indicate a malfunction of the front passenger occupant classification system. In this case, contact your Lexus dealer immediately. Child restraint systems installed on the rear seat should not contact the front seat- ●...
Page 52: Safety Information For Children
1-1. For safe use Safety information for children Observe the following precautions when children are in the vehicle. Use a child restraint system appropriate for the child, until the child becomes large enough to properly wear the vehicle’s seat belt. It is recommended that children sit in the rear seats to avoid accidental con- ●...
Page 53: Child Restraint Systems
1-1. For safe use Child restraint systems A child restraint system for a small child or baby must itself be properly restrained on the seat with the LATCH anchors or the lap portion of the lap/ shoulder belt. The laws of all 50 states of the U.S.A. and Canada now require the use of child restraint systems.
Page 54 1-1. For safe use Types of child restraints Child restraint systems are classified into the following 3 types according to the age and size of the child: Rear facing  Infant seat/convert- Forward facing  Convertible   ible seat seat Booster seat ...
Page 55 In an accident, the child can be crushed against the windshield, or between you and the vehicle’ s interior. Lexus strongly urges the use of a proper child restraint system that conforms to the ● size of the child, installed on the rear seat. According to accident statistics, the child is safer when properly restrained in the rear seat than in the front seat.
Page 56 1-1. For safe use WARNING When children are in the vehicle ■ Do not allow children to play with the seat belt. If the seat belt becomes twisted around a child’ s neck, it may lead to choking or other serious injuries that could result in death. If this occurs and the child cannot be released from the seat belt, scissors should be used to cut the belt.
Page 57: Installing Child Restraints
1-1. For safe use Installing child restraints Follow the child restraint system manufacturer’s instructions. Firmly secure child restraints to the seats using the LATCH anchors or a seat belt. Attach the top tether strap when installing a child restraint. The lap/shoulder belt can be used if your child restraint system is not compati- ble with the LATCH (Lower Anchors and Tethers for Children) system.
Page 58 1-1. For safe use Installation with LATCH system Lower the head restraint in place at the lowest position. Widen the gap between the seat cushion and seatback slightly. Type A  Latch the hooks of the lower straps onto the LATCH anchors. If the child restraint has a top tether strap, the top tether strap should be latched onto the top tether strap anchor.
Page 59 1-1. For safe use Type B  Latch the buckles onto the LATCH anchors. If the child restraint has a top tether strap, the top tether strap should be latched onto the top tether strap anchor. For owners in Canada: The symbol on a child restraint sys- tem indicates the presence of a lower connector system.
Page 60 1-1. For safe use Installing child restraints using a seat belt (child restraint lock function belt) Rear-facing  Infant seat/convertible seat ■ Place the child restraint system on the rear seat facing the rear of the vehicle. Run the seat belt through the child restraint system and insert the plate into the buckle.
Page 61 1-1. For safe use Forward-facing Convertible seat ■ Lower the head restraint in place at the lowest position. Place the child restraint system on the seat facing the front of the vehicle. Run the seat belt through the child restraint system and insert the plate into the buckle.
Page 62 1-1. For safe use While pushing the child restraint system into the rear seat, allow the shoulder belt to retract until the child restraint system is securely in place. After the shoulder belt has retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
Page 63 1-1. For safe use Removing a child restraint installed with a seat belt Push the buckle release button and fully retract the seat belt. Child restraint systems with a top tether strap Lower the head restraint in place at the lowest position. Secure the child restraint system using the seat belt or LATCH anchors.
Page 64 1-1. For safe use Laws and regulations pertaining to anchorages ■ The LATCH system conforms to FMVSS225 or CMVSS210.2. Child restraint systems conforming to FMVSS213 or CMVSS213 specifications can be used. This vehicle is designed to conform to the SAE J1819. WARNING When installing a booster seat ■...
Page 65 1-1. For safe use WARNING When installing a child restraint system ■ When a booster seat is installed, always ensure that the shoulder belt is positioned ● across the center of the child’ s shoulder. The belt should be kept away from the child’ s neck, but not so that it could fall off the child’...
Page 66: Exhaust Gas Precautions
● If you smell exhaust gases in the vehicle even when the trunk lid is closed, open the ● windows and have the vehicle inspected at your Lexus dealer as soon as possible. When parking ■ If the vehicle is in a poorly ventilated area or a closed area, such as a garage, stop the ●...
Page 67: Hybrid System Features
1-2. Hybrid system Hybrid system features Your vehicle is a hybrid vehicle. It has characteristics different from conven- tional vehicles. Be sure you are closely familiar with the characteristics of your vehicle, and operate it with care. The hybrid system combines the use of a gasoline engine and an electric motor (traction motor) according to driving conditions, improving fuel effi- ciency and reducing exhaust emissions.
Page 68 1-2. Hybrid system ◆ When stopped/during start off The gasoline engine stops when the vehicle is stopped. During start off, the electric motor (traction motor) drives the vehicle. At slow speeds or when traveling down a gentle slope, the engine is stopped and the electric motor (traction motor) is used.
Page 69 After the 12-volt battery has discharged or when the terminal has been removed and ■ installed during exchange, etc. The gasoline engine may not stop even if the vehicle is being driven by the hybrid battery (traction battery). If this continues for a few days, contact your Lexus dealer. ES300h_OM_OM33B71U_(U)
Page 70 If “Proximity Notification System Malfunction” is displayed on the multi-information ■ display The system may be malfunctioning. Have the vehicle inspected by your Lexus dealer. Maintenance, repair, recycling, and disposal ■ Contact your Lexus dealer regarding maintenance, repair, recycling and disposal. Do not dispose of the vehicle yourself.
Page 71: Hybrid System Precautions
1-2. Hybrid system Hybrid system precautions Take care when handling the hybrid system, as it is a high voltage system (about 650 V at maximum) as well as contains parts that become extremely hot when the hybrid system is operating. Obey the warning labels attached to the vehicle.
Page 72 If the emergency shut off system activates, your vehicle will not restart. To restart the hybrid system, contact your Lexus dealer. Hybrid warning message A message is automatically displayed when a malfunction occurs in the hybrid system or an improper operation is attempted.
Page 73 ■ connected The hybrid system may not start. In this case, try to start the system again. If the “READY” indicator does not come on, contact your Lexus dealer. Running out of fuel ■ When the vehicle has run out of fuel and the hybrid system cannot be started, refuel the vehicle with at least enough gasoline to make the low fuel level warning light (P.
Page 74 In the event that your vehicle must be disposed of, the hybrid battery must be disposed of by your Lexus dealer or a qualified service shop. If the hybrid bat- tery is not disposed of properly, it may cause electric shock that can result in death or serious injury.
Page 75 (traction battery). Do not carry large amounts of water such as water cooler bottles in the vehicle. If ● water spills onto the hybrid battery (traction battery), the battery may be damaged. Have the vehicle inspected by your Lexus dealer. ES300h_OM_OM33B71U_(U)
Page 76: 1-3. Theft Deterrent System
1-3. Theft deterrent system Immobilizer system The vehicle’s keys have built-in transponder chips that prevent the hybrid sys- tem from starting if a key has not been previously registered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehicle. This system is designed to help prevent vehicle theft but does not guarantee absolute security against all vehicle thefts.
Page 77 1-3. Theft deterrent system Certifications for the immobilizer system ■ For vehicles sold in the U.S.A., Hawaii, NATO Germany, Guam and Puerto Rico  For vehicles sold in Canada  WARNING Certifications for the immobilizer system ■ Changes or modifications not expressly approved by the party responsible for compli- ance could void the user’...
Page 78: Alarm
1-3. Theft deterrent system Alarm The alarm The alarm uses light and sound to give an alert when an intrusion is detected. The alarm is triggered in the following situations when the alarm is set: A locked door or trunk is unlocked or opened in any way other than using the ●...
Page 79 1-3. Theft deterrent system System maintenance ■ The vehicle has a maintenance-free type alarm system. Items to check before locking the vehicle ■ To prevent unexpected triggering of the alarm and vehicle theft, make sure of the follow- ing: Nobody is in the vehicle. ●...
Page 80 1-3. Theft deterrent system ES300h_OM_OM33B71U_(U)
Page 81: Instrument Cluster
Instrument cluster Instrument cluster Warning lights and indicators......82 Gauges and meters .....86 Multi-information display ... 91 Energy monitor/ consumption screen ....96 ES300h_OM_OM33B71U_(U)
Page 82: Warning Lights And Indicators
2. Instrument cluster Warning lights and indicators The warning lights and indicators on the instrument cluster and center panel inform the driver of the status of the vehicle’s various systems. For the purpose of explanation, the following illustration displays all warning lights and indicators illuminated.
Page 83 They will turn off after the hybrid system is on, or after a few seconds. There may be a malfunction in a system if a light does not come on, or turn off. Have the vehicle inspected by your Lexus dealer. : The light flashes to indicate a malfunction.
Page 84 2. Instrument cluster Indicators The indicators inform the driver of the operating state of the vehicle’ s various sys- tems. “LDA” (Lane Departure Turn signal indicator Alert with steering control) (P. 176) indicator (P. 213) (if equipped) Headlight indicator Intuitive parking assist (P.
Page 85 There may be a malfunction in a system if a light does not come on, or turn off. Have the vehicle inspected by your Lexus dealer. : The light flashes to indicate that the system is operating.
Page 86: Gauges And Meters
2. Instrument cluster Gauges and meters The units used on the speedometer may differ depending on the target region. Engine coolant temperature gauge Displays the engine coolant temperature Tachometer/Hybrid System Indicator Tachometer: Displays the engine speed in revolutions per minute. Hybrid System Indicator: Displays hybrid system output or regeneration level.
Page 87 2. Instrument cluster Odometer, trip meter and maintenance required information display Odometer: Displays the total distance the vehicle has been driven Trip meter: Displays the distance the vehicle has been driven since the meter was last reset. Trip meters “A” and “B” can be used to record and display different distances indepen- dently.
Page 88 2. Instrument cluster The meters and display illuminate when ■ The power switch is in ON mode. Instrument panel brightness adjustment ■ The instrument panel brightness levels when the tail lights are on and off can be adjusted individually. However, when the surroundings are bright (daytime, etc.), turning on the tail lights will not change the instrument panel brightness.
Page 89 • When the vehicle is parked in direct sunlight When “--” or “E” is displayed, the system may be malfunctioning. ● Take your vehicle to your Lexus dealer. Pop-up display ■ In some situations, a pop-up display will be temporarily displayed on the multi-informa- tion display or the odometer/trip meter/maintenance required information screen.
Page 90 2. Instrument cluster NOTICE To prevent damage to the engine and its components ■ Do not let the indicator needle of the tachometer enter the red zone, which indicates ● the maximum engine speed. The engine may be overheating if the engine coolant temperature gauge is in the red ●...
Page 91: Multi-Information Display
2. Instrument cluster Multi-information display Display contents The multi-information display presents the driver with a variety of vehicle data. Displays the following information when an icon is selected. (P. 92) Drive information Select to display various drive data. (P. 92) Navigation system-linked dis- play (if equipped) Select to display the following navigation system-linked information.
Page 92 2. Instrument cluster Operating the meter control switches The multi-information display is oper- ated using the meter control switches. Select an item/change pages Enter/Set Return to the previous screen Press: Displays the screen registered to When no screen has been registered, the drive information screen will be displayed. Press and hold: Registers the currently displayed screen to (P.
Page 93 2. Instrument cluster Average speed (after reset /after start) ■ Displays the average vehicle speed since the function was reset and the hybrid system was started, respectively Elapsed time (after reset /after start) ■ Displays the elapsed time since the function was reset and the hybrid system was started, respectively Distance (range/after start) ■...
Page 94 2. Instrument cluster Settings display The settings of the following items can be changed, refer to P. 555 For functions that can be enabled or disabled, the function switches between on and off each time is pressed. (Lane Departure Alert with steering control) (if ●...
Page 95 2. Instrument cluster System check display ■ After turning the power switch to ON mode, opening image is displayed while system operation is checked. When the system check is complete, the normal screen will return. Suspension of the settings display ■...
Page 96: Energy Monitor/ Consumption Screen
2. Instrument cluster Energy monitor/consumption screen You can view the status of your hybrid system on the multi-information display and the navigation system screen or Lexus Display Audio system screen. Navigation system screen or Lexus Display Audio system screen Multi-information display...
Page 97 Lexus Display Audio screen  Press the “MENU” button on the Lexus Display Audio controller, then select “Info” on the “Menu” screen, and then select “Fuel Consumption”. If the “Energy Monitor” screen does not appear, move the controller to the right and select “Energy”.
Page 98 2. Instrument cluster Navigation system screen or Multi-information display Lexus Display Audio screen When the vehicle is charging the hybrid battery (traction bat- tery) When there is no energy flow Full Full Hybrid battery (trac- tion battery) status These images are examples only.
Page 99 2. Instrument cluster Fuel consumption Trip information ■ Navigation system screen  Press the “MENU” button on the Remote Touch, then select “Info” on the “Menu” screen, and then select “Fuel Consumption”. If the “Trip Information” screen does not appear, select “Trip Information”. Resetting the consumption data Fuel consumption in the past 15 minutes...
Page 100 Lexus Display Audio screen  Press the “MENU” button on the Lexus Display Audio controller, then select “Info” on the “Menu” screen, and then select “Fuel Consumption”. If the “Trip Information” screen does not appear, move the controller to the right and select “Trip Information”.
Page 101 Lexus Display Audio screen  Press the “MENU” button on the Lexus Display Audio controller, then select “Info” on the “Menu” screen, and then select “Fuel Consumption”. If the “Past Record” screen does not appear, move the controller to the right and select “Past Record”.
Page 102  Update the average fuel consumption by selecting “Update” to measure the current fuel consumption again. Vehicles with Lexus Display Audio system  Update the average fuel consumption by moving the controller to the left and select “Update” to measure the current fuel consumption again.
Page 103: Operation Of Each Component
Operation of each component 3-1. Key information Keys ..........104 3-2. Opening, closing and locking the doors and trunk Doors ..........108 Trunk...........114 Smart access system with push-button start ....121 3-3. Adjusting the seats Front seats........129 Driving position memory..130 Head restraints ......135 3-4.
Page 104: 3-1. Key Information
Wireless remote control Locks the doors (P. 108) Unlocks the doors (P. 108) Opens the windows and moon roof (P. 108) Opens the trunk (P. 114) Sounds the alarm (P. 105) : This setting must be customized at your Lexus dealer. ES300h_OM_OM33B71U_(U)
Page 105 If you lose your mechanical keys ■ New genuine mechanical keys can be made by your Lexus dealer using the other mechanical key and the key number stamped on your key number plate. Keep the plate in a safe place such as your wallet, not in the vehicle.
Page 106 ■ P. 475 Confirmation of the registered key number ■ The number of keys already registered to the vehicle can be confirmed. Ask your Lexus dealer for details. If a wrong key is used ■ The key cylinder rotates freely to isolate inside mechanism.
Page 107 In case of a smart access system with push-button start malfunction or other key- ■ related problems Take your vehicle with all the electronic keys provided with your vehicle to your Lexus dealer. When an electronic key is lost ■...
Page 108: 3-2. Opening, Closing And Locking The Doors And Trunk
Pressing the button unlocks the driver’ s door. Pressing the button again within 5 seconds unlocks the other doors. Press and hold to open the windows and moon roof : This setting must be customized at your Lexus dealer. ES300h_OM_OM33B71U_(U)
Page 109 3-2. Opening, closing and locking the doors and trunk Operation signals ■ A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: Once; Unlocked: Twice) Windows and moon roof: A buzzer sounds to indicate that the windows and moon roof are opening. Security feature ■...
Page 110 3-2. Opening, closing and locking the doors and trunk Unlocking and locking the doors from the inside ◆ Door lock switch Locks all the doors Unlocks all the doors ◆ Inside lock buttons Locks the door Unlocks the door The front doors can be opened by pulling the inside handle even if the lock buttons are in the lock position.
Page 111 3-2. Opening, closing and locking the doors and trunk Rear door child-protector lock The door cannot be opened from inside the vehicle when the lock is set. Unlock Lock These locks can be set to prevent chil- dren from opening the rear doors. Push down on each rear door switch to lock both rear doors.
Page 112 3-2. Opening, closing and locking the doors and trunk Switching the door unlock function ■ It is possible to set which doors the entry function unlocks using the wireless remote con- trol. Turn the power switch off. When the indicator light on the key surface is not on, press and hold for approximately 5 seconds while pressing and holding The setting changes each time an operation is performed, as shown below.
Page 113 3-2. Opening, closing and locking the doors and trunk WARNING To prevent an accident ■ Observe the following precautions while driving the vehicle. Failure to do so may result in a door opening and an occupant throwing out of the vehi- cle, resulting in death or serious injury.
Page 114: Trunk
3-2. Opening, closing and locking the doors and trunk Trunk The trunk can be opened using the trunk opener, entry function or wireless remote control. If the vehicle is equipped with a power trunk opener and closer, the trunk can be closed using the trunk closer.
Page 115 3-2. Opening, closing and locking the doors and trunk Trunk closer switch (vehicles with power trunk opener and closer) Pressing the switch closes the trunk lid automatically. (A buzzer sounds.) Pressing the switch while the trunk lid is closing opens the trunk lid again. When closing the trunk Using the trunk grip, lower the trunk without applying force to the side and...
Page 116 3-2. Opening, closing and locking the doors and trunk Trunk light ■ The trunk light turns on when the trunk is opened. Trunk easy closer (vehicles with power trunk opener and closer) ■ In the event that the trunk lid is left slightly open, the trunk easy closer will automatically close it to the fully closed position.
Page 117 3-2. Opening, closing and locking the doors and trunk Using the mechanical key ■ The trunk can be also opened using the mechanical key. (P. 521) When leaving a key to the vehicle with a parking attendant ■ P. 105 If the smart access system with push-button start or the wireless remote control does ■...
Page 118 Do not attach any accessories other than genuine Lexus parts to the trunk lid. Such ● additional weight on the trunk lid may cause the lid to suddenly shut again after it is opened.
Page 119 • When the 12-volt battery voltage suddenly drops, such as when the power switch is turned to ON mode or the hybrid system is started during automatic operation Do not attach any accessories other than genuine Lexus parts to the trunk lid. The ●...
Page 120 3-2. Opening, closing and locking the doors and trunk NOTICE To prevent trunk easy closer malfunctions (vehicles with power trunk opener and ■ closer) Do not apply force to the trunk lid while the trunk easy closer is operating. To prevent damage to the power trunk opener and closer (vehicles with power trunk ■...
Page 121: Smart Access System With Push-Button Start
3-2. Opening, closing and locking the doors and trunk Smart access system with push-button start The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. The driver should always carry the electronic key. Locks and unlocks the doors (P.
Page 122 3-2. Opening, closing and locking the doors and trunk Alarms and warning indicators ■ An alarm sounds and warning message displays shown on the multi-information display are used to protect against unexpected accidents or theft of the vehicle resulting from erroneous operation.
Page 123 3-2. Opening, closing and locking the doors and trunk Electronic Key Battery-Saving Function ■ When battery-saving mode is set, battery depletion is minimized by stopping the elec- tronic key from receiving radio waves. Press twice while pressing and holding . Confirm that the electronic key indica- tor flashes 4 times.
Page 124 3-2. Opening, closing and locking the doors and trunk Note for the entry function ■ Even when the electronic key is within the effective range (detection areas), the system ● may not operate properly in the following cases: • The electronic key is too close to the window or outside door handle, near the ground, or in a high place when the doors are locked or unlocked.
Page 125 3-2. Opening, closing and locking the doors and trunk When the vehicle is not driven for extended periods ■ To prevent theft of the vehicle, do not leave the electronic key within 6 ft. (2 m) of the ● vehicle. The smart access system with push-button start can be deactivated in advance.
Page 126 3-2. Opening, closing and locking the doors and trunk Certification for the smart access system with push-button start ■ For vehicles sold in the U.S.A., Hawaii, NATO Germany, Guam and Puerto Rico  ES300h_OM_OM33B71U_(U)
Page 127 3-2. Opening, closing and locking the doors and trunk For vehicles sold in Canada  ES300h_OM_OM33B71U_(U)
Page 128 The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Lexus dealer for details, such as the frequency of radio waves and timing of the emitted radio waves. Then, consult your doctor to see if you should disable the entry function.
Page 129: Adjusting The Seats
3-3. Adjusting the seats Front seats Adjustment procedure Seat position adjustment switch Vertical height adjustment switch Seatback angle adjustment switch Lumbar support adjustment switch Seat cushion (front) angle adjust- Seat cushion length adjustment ment switch switch (if equipped for driver’ s side) Power easy access system ■...
Page 130: Driving Position Memory
3-3. Adjusting the seats  Driving position memory This feature automatically adjusts the front seats, steering wheel (power adjustment type) and outside rear view mirrors to make entering and exiting the vehicle easier or to suit your preferences. Power easy access system The seat and steering wheel are automatically adjusted to allow the driver to enter and exit the vehicle easily.
Page 131 3-3. Adjusting the seats Driving position memory Your preferred driving position (the position of the driver’ s seat, steering wheel and outside rear view mirrors) can be recorded and recalled by pressing a but- ton. Three different driving positions can be recorded into memory. Recording procedure ■...
Page 132 3-3. Adjusting the seats To stop the position recall operation part-way through ■ Perform any of the following: Press the “SET” button. ● Press button “1”, “2” or “3”. ● Operate any of the seat adjustment switches (only cancels seat position recall). ●...
Page 133 3-3. Adjusting the seats While pressing the recalled but- ton, press and hold the door lock switch (either lock or unlock) until the buzzer sounds. If the button could not be registered, the buzzer sounds continuously for approximately 3 seconds. Recall procedure ■...
Page 134 3-3. Adjusting the seats WARNING Seat adjustment caution ■ Take care during seat adjustment so that the seat does not strike the rear passenger or squeeze your body against the steering wheel. ES300h_OM_OM33B71U_(U)
Page 135: Head Restraints
3-3. Adjusting the seats Head restraints Head restraints are provided for all seats. Front seats ◆ Vertical adjustment Pull the head restraints up. Down Push the head restraint down while pressing the lock release button. Lock release button ◆ Horizontal adjustment The position of the head restraint can be adjusted forward in 4 stages.
Page 136 3-3. Adjusting the seats Rear seats Outboard Center   Lock release button Lock release button Pull the head restraints up. Down Push the head restraint down while pressing the lock release button. Removing the head restraints ■ Pull the head restraint up while pressing the lock release button.
Page 137 3-3. Adjusting the seats Installing the head restraints ■ Front seats  Align the head restraint with the installation holes and push it down to the lock position. Press and hold the lock release button when lowering the head restraint. Lock release button Rear seats ...
Page 138: 3-4. Adjusting The Steering Wheel And Mirrors
3-4. Adjusting the steering wheel and mirrors Steering wheel Adjustment procedure Manual adjustment type  Hold the steering wheel and pull the lever down. Adjust to the ideal position by mov- ing the steering wheel horizontally and vertically. After adjustment, pull the lever up to secure the steering wheel.
Page 139 3-4. Adjusting the steering wheel and mirrors Horn To sound the horn, press on or close to mark. The power adjustment type steering wheel can be adjusted when ■ The power switch is in ACCESSORY or ON mode : If the driver’ s seat belt is fastened, the steering wheel can be adjusted regardless of power switch mode.
Page 140: Inside Rear View Mirror
3-4. Adjusting the steering wheel and mirrors Inside rear view mirror The rear view mirror’s position can be adjusted to enable sufficient confirma- tion of the rear view. Adjusting the height of rear view mirror The height of the rear view mirror can be adjusted to suit your driving posture. Adjust the height of the rear view mir- ror by moving it up and down.
Page 141 3-4. Adjusting the steering wheel and mirrors To prevent sensor error ■ To ensure that the sensors operate properly, do not touch or cover them. WARNING Do not adjust the position of the mirror while driving. Doing so may lead to mishandling of the vehicle and cause an accident, resulting in death or serious injury.
Page 142: Outside Rear View Mirrors
3-4. Adjusting the steering wheel and mirrors Outside rear view mirrors Adjustment procedure To select a mirror to adjust, press the switch. Left Right To adjust the mirror, press the switch. Right Down Left Folding the mirrors Push the mirror back in the direction of the vehicle’...
Page 143 3-4. Adjusting the steering wheel and mirrors Linked mirror function when reversing When the mirror select switch is in the L or R position, the outside rear view mir- rors will automatically angle downwards when the vehicle is reversing in order to give a better view of the ground.
Page 144 3-4. Adjusting the steering wheel and mirrors WARNING Important points while driving ■ Observe the following precautions while driving. Failure to do so may result in loss of control of the vehicle and cause an accident, result- ing in death or serious injury. Do not adjust the mirrors while driving.
Page 145: Opening, Closing The Windows And Moon Roof
3-5. Opening, closing the windows and moon roof Power windows Opening and closing procedures The power windows can be opened and closed using the switches. Operating the switch moves the windows as follows: Closing One-touch closing Opening One-touch opening : To stop the window partway, operate the switch in the opposite direction.
Page 146 The power windows can be opened using the wireless remote control. (P. 108) ● : These settings must be customized at your Lexus dealer. When the 12-volt battery is disconnected ■ The window lock switch is disabled. If necessary, press the window lock switch after reconnecting the 12-volt battery.
Page 147 3-5. Opening, closing the windows and moon roof WARNING Observe the following precautions. Failure to do so may result in death or serious injury. Closing the windows ■ The driver is responsible for all the power window operations, including the operation ●...
Page 148: Moon Roof
3-5. Opening, closing the windows and moon roof Moon roof Use the overhead switches to open and close the moon roof and tilt it up and down. Opening and closing Opens the moon roof The moon roof stops slightly before the fully open position to reduce wind noise.
Page 149 The moon roof can be opened and closed using the mechanical key. (P. 521) ● The moon roof can be opened using the wireless remote control. (P. 108) ● : These settings must be customized at your Lexus dealer. ES300h_OM_OM33B71U_(U)
Page 150 Check to make sure that the moon roof is completely closed and then release the switch. If the moon roof does not fully close even after performing the above procedure cor- rectly, have the vehicle inspected by your Lexus dealer. Moon roof open warning buzzer ■...
Page 151 3-5. Opening, closing the windows and moon roof WARNING Observe the following precautions. Failure to do so may cause death or serious injury. Opening the moon roof ■ Do not allow any passengers to put their hands or heads outside the vehicle while it is ●...
Page 152 3-5. Opening, closing the windows and moon roof ES300h_OM_OM33B71U_(U)
Page 153: Driving
Opening the fuel tank cap ..190 EV drive mode .......171 4-5. Using the driving support Hybrid transmission ....173 systems Turn signal lever ......176 Lexus Safety System+ ....194 Parking brake.........177 (Pre-Collision System)... 201 LDA (Lane Departure Alert with steering control) ..... 213 Dynamic radar cruise control......
Page 154: 4-1. Before Driving
4-1. Before driving Driving the vehicle The following procedures should be observed to ensure safe driving: Starting the hybrid system P. 166 Driving With the brake pedal depressed, shift the shift lever to D. (P. 173) Release the parking brake. (P. 177) Gradually release the brake pedal and gently depress the accelerator pedal to accelerate the vehicle.
Page 155 Your vehicle has a drum-in-disc type parking brake system. This type of brake system needs bedding-down of the brake shoes periodically or whenever the parking brake shoes and/or drum are replaced. Have your Lexus dealer perform the bedding down operation.
Page 156 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. When starting the vehicle ■ Always keep your foot on the brake pedal while stopped with the “READY” indicator is illuminated. This prevents the vehicle from creeping. When driving the vehicle ■...
Page 157 If you hear a squealing or scraping noise (brake pad wear limit indicators) ■ Have the brake pads checked and replaced by your Lexus dealer as soon as possible. Rotor damage may result if the pads are not replaced when needed.
Page 158 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. When the vehicle is parked ■ Do not leave glasses, cigarette lighters, spray cans, or soft drink cans in the vehicle ●...
Page 159 Engine damage caused by water immersion ● In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Lexus dealer check the following: Brake function ● Changes in quantity and quality of oil and fluid used for the engine, hybrid transmis- ●...
Page 160: Cargo And Luggage
Consult this manual to determine how this reduces the avail- able cargo and luggage load capacity of your vehicle. (P. 163) Lexus does not recommend towing a trailer with your vehicle. Your vehicle is not designed for trailer towing.
Page 161 4-1. Before driving Calculation formula for your vehicle Cargo capacity Total load capacity (vehicle capacity weight) (P. 534) When 2 people with the combined weight of A lb. (kg) are riding in your vehicle, which has a total load capacity (vehicle capacity weight) of B lb. (kg), the avail- able amount of cargo and luggage load capacity will be C lb.
Page 162 • On the front passenger or rear seats (when stacking items) • On the package tray • On the instrument panel • On the dashboard • In front of the navigation system screen or Lexus Display Audio system screen Secure all items in the occupant compartment. ● Capacity and distribution ■...
Page 163: Vehicle Load Limits
Seating capacity means the maximum number of occupants whose estimated average weight is 150 lb. (68 kg) per person. ◆ Towing capacity Lexus does not recommend towing a trailer with your vehicle. ◆ Cargo capacity Cargo capacity may increase or decrease depending on the weight and the number of occupants.
Page 164: Trailer Towing
4-1. Before driving Trailer towing Lexus does not recommend towing a trailer with your vehicle. Lexus also does not recommend the installation of a tow hitch or the use of a tow hitch carrier for a wheelchair, scooter, bicycle, etc. Your vehicle is not designed for trailer towing or for the use of tow hitch mounted carriers.
Page 165: Dinghy Towing
4-1. Before driving Dinghy towing Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground) behind a motor home. NOTICE To avoid serious damage to your vehicle ■ Do not tow your vehicle with the four wheels on the ground. ES300h_OM_OM33B71U_(U)
Page 166: 4-2. Driving Procedures
4-2. Driving procedures Power (ignition) switch Performing the following operations when carrying the electronic key on your person starts the hybrid system or changes power switch modes. Starting the hybrid system Check that the parking brake is set. Check that the shift lever is in P. Firmly depress the brake pedal.
Page 167 4-2. Driving procedures Stopping the hybrid system Stop the vehicle completely. Shift the shift lever to P. Set the parking brake. (P. 177) Press the power switch. Release the brake pedal and check that “POWER ON” on the multi-informa- tion display is off. Changing power switch modes Modes can be changed by pressing the power switch with brake pedal released.
Page 168 ■ The immobilizer system may not have been deactivated. (P. 76) ● Contact your Lexus dealer. Check that the shift lever is securely set in P. The hybrid system may not start if the shift ● lever is displaced out of P. “Shift to P position to Start” will be displayed on the multi- information display.
Page 169 When “Check Access System with Elec. Key” is displayed on the multi-information dis- ■ play The system may be malfunctioning. Have the vehicle inspected by your Lexus dealer immediately. If the “READY” indicator does not come on ■...
Page 170 ACCESSORY mode. If the vehicle is left in ACCESSORY mode, 12-volt battery discharge may occur. When starting the hybrid system ■ If the hybrid system becomes difficult to start, have your vehicle checked by your Lexus dealer immediately. Symptoms indicating a malfunction with the power switch ■...
Page 171: Ev Drive Mode
4-2. Driving procedures EV drive mode In EV drive mode, electric power is supplied by the hybrid battery (traction battery), and only the electric motor (traction motor) is used to drive the vehi- cle. This mode allows you to drive in residential areas early in the morning and late at night, or in indoor parking lots etc.
Page 172 4-2. Driving procedures Switching to EV drive mode when the gasoline engine is cold ■ If the hybrid system is started while the gasoline engine is cold, the gasoline engine will start automatically in order to warm up. In this case, you will become unable to switch to EV drive mode.
Page 173: Hybrid Transmission
4-2. Driving procedures Hybrid transmission Shifting the shift lever While the power switch is in ON mode, move the shift lever with the brake pedal depressed. When shifting the shift lever between P and D, make sure that the vehicle is com- pletely stopped.
Page 174 4-2. Driving procedures Selecting shift ranges in the S position To enter S mode, shift the shift lever to S. Shift ranges can then be selected by operating the shift lever, allowing you to drive in the shift range of your choosing. Upshifting Downshifting The selected shift range, from 1 to 6, will...
Page 175 If the S indicator does not come on even after shifting the shift lever to S ■ This may indicate a malfunction in the hybrid transmission system. Have the vehicle inspected by your Lexus dealer immediately. (In this situation, the transmission will operate in the same manner as when the shift lever is in D.) If the shift lever cannot be shifted from P ■...
Page 176: Turn Signal Lever
4-2. Driving procedures Turn signal lever Operating instructions Right turn Lane change to the right (move the lever partway and then release it) The right hand signals will flash 3 times. Lane change to the left (move the lever partway and then release it) The left hand signals will flash 3 times.
Page 177: Parking Brake
4-2. Driving procedures Parking brake To set the parking brake, fully depress the parking brake pedal with your left foot while depressing the brake pedal U.S.A. Canada with your right foot. (Depressing the pedal again releases the parking brake.) Parking brake engaged warning buzzer ■...
Page 178: 4-3. Operating The Lights And Wipers
4-3. Operating the lights and wipers Headlight switch The headlights can be operated manually or automatically. Operating instructions Turning the end of the lever turns on the lights as follows: The side marker, parking, day- time running (P. 179), tail, license plate and instrument U.S.A.
Page 179 4-3. Operating the lights and wipers Turning on the high beam headlights With the headlights on, push the lever away from you to turn on the high beams. Pull the lever toward you to the center position to turn the high beams off. Pull the lever toward you and release it to flash the high beams once.
Page 180 If “Headlight System Malfunction Visit Your Dealer” is displayed on the multi-informa- ■ tion display The system may be malfunctioning. Have the vehicle inspected by your Lexus dealer. Customization ■ Settings (e.g. light sensor sensitivity) can be changed.
Page 181: Automatic High Beam
4-3. Operating the lights and wipers  Automatic High Beam The Automatic High Beam uses an in-vehicle camera sensor to assess the brightness of streetlights, the lights of vehicles ahead, etc., and automatically turns the high beam on or off as necessary. WARNING Limitations of the Automatic High Beam ■...
Page 182 4-3. Operating the lights and wipers Turning the high beam on/off manually Switching to low beam ■ Pull the lever to the original position. The Automatic High Beam indicator will turn off. Push the lever away from you to acti- vate the Automatic High Beam sys- tem again.
Page 183 4-3. Operating the lights and wipers Camera sensor detection information ■ The high beam may not be automatically turned off in the following situations: ● • When oncoming vehicles suddenly appear from a curve • When the vehicle is cut in front of by another vehicle •...
Page 184 4-3. Operating the lights and wipers Temporarily lowering sensor sensitivity ■ The sensitivity of the sensor can be temporarily lowered. Turn the power switch off while the following conditions are met. • The headlight switch is in • The headlight switch lever is in high beam position. •...
Page 185: Fog Light Switch
4-3. Operating the lights and wipers Fog light switch The fog lights enhance visibility in difficult driving conditions, such as in rain and fog. (U.S.A.) (Canada) Turns the fog lights off Turns the fog lights on Fog lights can be used when ■...
Page 186: Windshield Wipers And Washer
4-3. Operating the lights and wipers Windshield wipers and washer Operating the wiper lever The wiper operation is selected by moving the lever as follows. Intermittent windshield wipers with interval adjuster  Temporary operation Intermittent operation Low speed operation High speed operation Wiper intervals can be adjusted when intermittent operation is selected.
Page 187 4-3. Operating the lights and wipers Rain-sensing windshield wipers  Temporary operation Rain-sensing wiper operation (AUTO) Low speed operation High speed operation When AUTO is selected, the wipers will operate automatically when the sensor detects falling rain. The system automat- ically adjusts wiper timing in accordance with rain volume and vehicle speed.
Page 188 4-3. Operating the lights and wipers Raindrop sensor (vehicles with rain-sensing windshield wipers) ■ The raindrop sensor judges the amount of ● raindrops. An optical sensor is adopted. It may not oper- ate properly when sunlight from the rising or setting of the sun intermittently strikes the windshield, or if bugs etc.
Page 189 Damage to the washer fluid pump may be caused if the lever is pulled toward you and held continually. When a nozzle becomes blocked ■ In this case, contact your Lexus dealer. Do not try to clear it with a pin or other object. The nozzle will be damaged. When standing the windshield wipers up ■...
Page 190: 4-4. Refueling
4-4. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap: Before refueling the vehicle Turn the power switch off and ensure that all the doors and windows are ● closed. Confirm the type of fuel. ●...
Page 191 4-4. Refueling NOTICE Refueling ■ Do not spill fuel during refueling. Doing so may damage the vehicle, such as causing the emission control system to operate abnormally or damaging fuel system components or the vehicle’ s painted sur- face. ES300h_OM_OM33B71U_(U)
Page 192 4-4. Refueling Opening the fuel tank cap Press the opener switch to open the fuel filler door. Turn the fuel tank cap slowly to open and hang it on the back of the fuel filler door. When the fuel filler door cannot be opened by pressing the inside switch ■...
Page 193 When replacing the fuel tank cap ■ Do not use anything but a genuine Lexus fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury. ES300h_OM_OM33B71U_(U)
Page 194: 4-5. Using The Driving Support Systems
Lexus Safety System+ ■ The Lexus Safety System+ is designed to operate under the assumption that the driver will drive safely, and is designed to help reduce the impact to the occupants and the vehicle in the case of a collision or assist the driver in normal driving conditions.
Page 195 Data usage ● Lexus may use the data recorded in this computer to diagnose malfunctions, conduct research and development, and improve quality. Lexus will not disclose the recorded data to a third party except: • With the consent of the vehicle owner or with the consent of the lessee if the vehicle is leased •...
Page 196 4-5. Using the driving support systems Sensors Two types of sensors, located behind the front grille and windshield, detect infor- mation necessary to operate the drive assist systems. Radar sensor Camera sensor ES300h_OM_OM33B71U_(U)
Page 197 Do not subject the radar sensor or surrounding area to a strong impact. ● If the radar sensor, front grille, or front bumper has been subjected to a strong impact, have the vehicle inspected by your Lexus dealer. Do not disassemble the radar sensor. ●...
Page 198 ● of the camera sensor by the windshield wipers, replace the wiper rubber or wiper blade. If the wiper inserts or wiper blades need to be replaced, contact your Lexus dealer. Do not attach window tinting to the windshield. ●...
Page 199 4-5. Using the driving support systems Certification ■ For vehicles sold in the U.S.A., Hawaii, Guam, Saipan, Puerto Rico and NATO Ger-  many For vehicles sold in Canada  ES300h_OM_OM33B71U_(U)
Page 200 4-5. Using the driving support systems ES300h_OM_OM33B71U_(U)
Page 201: (Pre-Collision System)
(P. 204) : Depending on the region in which the vehicle was sold, the pedestrian detection function may not be available. Contact your Lexus dealer for details. : Depending on the region in which the vehicle was sold, the pre-collision braking function (automatic braking function) may not be available.
Page 202 4-5. Using the driving support systems ◆ Pre-collision braking When the system determines that the possibility of a frontal collision is high, the system warns the driver. If the system determines that the possibility of a collision is extremely high, the brakes are automatically applied to help avoid the collision or reduce the collision speed.
Page 203 4-5. Using the driving support systems WARNING When to disable the pre-collision system ■ In the following situations, disable the system, as it may not operate properly, possibly ● leading to an accident resulting in death or serious injury: • When the vehicle is being towed •...
Page 204 4-5. Using the driving support systems Changing settings of the pre-collision system Enabling/disabling the pre-collision system ■ The pre-collision system can be enabled/disabled on (P. 91) of the multi-information display. The system is automatically enabled each time the power switch is turned to ON mode.
Page 205 4-5. Using the driving support systems Operational conditions ■ For vehicles sold in regions where the pedestrian detection function and pre-collision  braking function are available The pre-collision system is enabled and the system determines that the possibility of a frontal collision with a vehicle or pedestrian is high.
Page 206 4-5. Using the driving support systems For vehicles sold in regions where the pedestrian detection function is not available  and the pre-collision braking function is available The pre-collision system is enabled and the system determines that the possibility of a frontal collision with a vehicle is high.
Page 207 4-5. Using the driving support systems Pedestrian detection function ■ The pre-collision system detects pedestrians based on the size, profile, and motion of a detected object. However, a pedestrian may not be detected depending on the surrounding brightness and the motion, posture, and angle of the detected object, preventing the system from operating properly.
Page 208 4-5. Using the driving support systems • When driving on a road where relative location to vehicle ahead in an adjacent lane may change, such as on a winding road • When a preceding vehicle suddenly decelerates • If the front of the vehicle is raised or lowered, such as when the road surface is uneven or undulating •...
Page 209 4-5. Using the driving support systems • When passing under an object (billboard, etc.) at the top of an uphill road • When rapidly closing on an electric toll gate barrier, parking area barrier, or other barrier that opens and closes •...
Page 210 4-5. Using the driving support systems Situations in which the system may not operate properly ■ In some situations such as the following, a vehicle may not be detected by the radar ● sensor and camera sensor, preventing the system from operating properly: •...
Page 211 4-5. Using the driving support systems • After the hybrid system has started the vehicle has not been driven for a certain amount of time • While making a left/right turn and for a few seconds after making a left/right turn •...
Page 212 If the PCS warning light continues to flash or the warning message does not disappear, ● the system may be malfunctioning. Have the vehicle inspected by your Lexus dealer immediately. If VSC is disabled ■...
Page 213: Lda (Lane Departure Alert With Steering Control)
4-5. Using the driving support systems  LDA (Lane Departure Alert with steering control) Summary of functions When driving on highways and freeways with white or yellow lines, this function alerts the driver when the vehicle might depart from its lane and provides assis- tance by operating the steering wheel to keep the vehicle in its lane.
Page 214 4-5. Using the driving support systems ◆ Steering control function When the system determines that the vehicle might depart from its lane, the system provides assistance as necessary by operating the steer- ing wheel in small amounts for a short period of time to keep the vehicle in its lane.
Page 215 ● tact your Lexus dealer. Do not install or place anything on the hood or grille. Also, do not install a grille guard ● (bull bars, kangaroo bar, etc.). If your windshield needs repairs, contact your Lexus dealer. ● ES300h_OM_OM33B71U_(U)
Page 216 4-5. Using the driving support systems Turning LDA system on Press the LDA switch to turn the LDA system on. The LDA indicator illuminates and a message is displayed on the multi-infor- mation display. Press the LDA switch again to turn the LDA system off.
Page 217 4-5. Using the driving support systems Indications on multi-information display LDA indicator The illumination condition of the indicator informs the driver of the system operation status. Illuminated in white: LDA system is operating. Illuminated in green: Steering wheel assistance of the steer- ing control function is operating.
Page 218 4-5. Using the driving support systems Operation conditions of each function ■ Lane departure alert function ● This function operates when all of the following conditions are met. • LDA is turned on. • Vehicle speed is approximately 32 mph (50 km/h) or more. •...
Page 219 4-5. Using the driving support systems White (yellow) lines are only on one side of road ■ The LDA system will not operate for the side on which white (yellow) lines could not be recognized. Conditions in which functions may not operate properly ■...
Page 220 Warning message Details/Actions “Lane Departure The system may not be operating properly. Alert  Have the vehicle inspected at your Lexus Malfunction dealer. Visit Your Dealer” Dirt, rain, condensation, ice, snow, etc., are present on the windshield in front of the cam- “Forward Camera...
Page 221 4-5. Using the driving support systems Customization ■ The following settings can be changed. Function Setting details Adjust alert sensitivity Lane departure alert Adjust alert type Steering control function Turn steering wheel assistance on and off Turn function on and off Vehicle sway warning Adjust alert sensitivity For how to change settings, refer to P.
Page 222: Dynamic Radar Cruise Control
4-5. Using the driving support systems  Dynamic radar cruise control Summary of functions In vehicle-to-vehicle distance control mode, the vehicle automatically acceler- ates and decelerates to match the speed changes of the preceding vehicle even if the accelerator pedal is not depressed. In constant speed control mode, the vehicle runs at a fixed speed.
Page 223 4-5. Using the driving support systems WARNING Before using dynamic radar cruise control ■ Driving safely is the sole responsibility of the driver. Do not rely solely on the system, and drive safely by always paying careful attention to your surroundings. The dynamic radar cruise control provides driving assistance to reduce the driver’...
Page 224 4-5. Using the driving support systems WARNING Situations unsuitable for dynamic radar cruise control ■ Do not use dynamic radar cruise control in any of the following situations. Doing so may result in inappropriate speed control and could cause an accident result- ing in death or serious injury.
Page 225 4-5. Using the driving support systems Driving in vehicle-to-vehicle distance control mode This mode employs a radar sensor to detect the presence of vehicles up to approximately 400 ft. (120 m) ahead, determines the current vehicle-to-vehicle following distance, and operates to maintain a suitable following distance from the vehicle ahead.
Page 226 4-5. Using the driving support systems Setting the vehicle speed (vehicle-to-vehicle distance control mode) Press the “ON/OFF” button to acti- vate the cruise control. Radar cruise control indicator will come on and a message will be displayed on the multi-information display. Press the button again to deactivate the cruise control.
Page 227 4-5. Using the driving support systems Adjusting the set speed To change the set speed, operate the lever until the desired set speed is dis- played. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direction. Large adjustment: Hold the lever up or down to change the speed, and release when the desired speed is reached.
Page 228 4-5. Using the driving support systems Changing the vehicle-to-vehicle distance (vehicle-to-vehicle distance control mode) Pressing the button changes the vehi- Preceding cle-to-vehicle distance as follows: vehicle mark Long Medium Short The vehicle-to-vehicle distance is set automatically to long mode when the power switch is turned to ON mode.
Page 229 4-5. Using the driving support systems Canceling and resuming the speed control Pulling the lever toward you cancels the speed control. The speed setting is also canceled when the brake pedal is depressed. Pushing the lever up resumes the cruise control and returns vehicle speed to the set speed.
Page 230 4-5. Using the driving support systems Selecting constant speed control mode When constant speed control mode is selected, your vehicle will maintain a set speed without controlling the vehicle-to-vehicle distance. Select this mode only when vehicle-to-vehicle distance control mode does not function correctly due to dirt, etc.
Page 231 Pre-collision braking is activated. ● If vehicle-to-vehicle distance control mode is automatically canceled for any other rea- son, there may be a malfunction in the system. Contact your Lexus dealer. Automatic cancelation of constant speed control mode ■ Constant speed control mode is automatically canceled in the following situations: Actual vehicle speed is more than approximately 10 mph (16 km/h) below the set vehi- ●...
Page 232 4-5. Using the driving support systems When the sensor may not be correctly detecting the vehicle ahead ■ In the case of the following and depending on the conditions, operate the brake pedal when deceleration of the system is insufficient or operate the accelerator pedal when acceleration is required.
Page 233 4-5. Using the driving support systems Conditions under which the vehicle-to-vehicle distance control mode may not function ■ correctly In the case of the following conditions, operate the brake pedal (or accelerator pedal, depending on the situation) as necessary. As the sensor may not be able to correctly detect vehicles ahead, the system may not operate properly.
Page 234: Cruise Control
4-5. Using the driving support systems  Cruise control Summary of functions Use the cruise control to maintain a set speed without depressing the accelera- tor pedal. Set speed Indicators Cruise control switch Setting the vehicle speed Press the “ON/OFF” button to acti- vate the cruise control.
Page 235 4-5. Using the driving support systems Adjusting the set speed To change the set speed, operate the lever until the desired set speed is obtained. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direction. Large adjustment: Hold the lever in the desired direction.
Page 236 If the cruise control speed cannot be set or if the cruise control cancels immediately after being activated, there may be a malfunction in the cruise control system. Have the vehi- cle inspected by your Lexus dealer. WARNING To avoid operating the cruise control by mistake ■...
Page 237: Intuitive Parking Assist
The distance from your vehicle to nearby obstacles when parallel parking or maneuvering into a garage is measured by the sensors and communicated via the multi-information display, navigation system screen or Lexus Display Audio system screen and a buzzer. Always check the surrounding area when using this system.
Page 238 Display When the sensors detect an obstacle, a graphic is shown on the multi-informa- tion display and navigation system screen or Lexus Display Audio system screen depending on the position and distance to the obstacle. Multi-information display ■...
Page 239 4-5. Using the driving support systems Navigation system screen or Lexus Display Audio system screen ■ When the Lexus parking assist mon- itor (if equipped) is not displayed A graphic is automatically displayed when an obstacle is detected. The screen can be set so that the graphic is not displayed.
Page 240 1.0 ft. (30 cm) 1.0 ft. (30 cm) 1.1 ft. (35 cm) (continuous) (blinking continuous : The images may differ from that shown in the illustrations. (P. 238) : Multi-information display : Lexus Display Audio or navigation system screen ES300h_OM_OM33B71U_(U)
Page 241 4-5. Using the driving support systems Buzzer operation and distance to an obstacle ■ A buzzer sounds when the sensors are operating. The buzzer beeps faster as the vehicle approaches an obstacle. When the ● vehicle comes within the following distance of the obstacle, the buzzer sounds continuously: •...
Page 242 You can change the buzzer sounds volume and the screen operating conditions. Lexus Display Audio system  Press the “MENU” button on the Lexus Display Audio controller, and then select “Setup” on the screen. Select “Vehicle”, and then select “LEXUS Park Assist” on the screen.
Page 243 • The area directly under the bumpers is not detected. • If obstacles draw too close to the sensor. • A non-genuine Lexus suspension (lowered suspension etc.) is installed. • People may not be detected if they are wearing certain types of clothing.
Page 244 If “Parking Assist Malfunction” is displayed on the multi-information display ■ Depending on the malfunction of the sensor, the device may not be working normally. Have the vehicle inspected by your Lexus dealer. Certification ■ For vehicles sold in the U.S.A.
Page 245 ■ In the following situations, the system may not function correctly due to a sensor mal- function etc. Have the vehicle checked by your Lexus dealer. The intuitive parking assist operation display flashes, and a beep sounds when no ●...
Page 246: Lexus Parking Assist Monitor
4-5. Using the driving support systems  Lexus parking assist monitor The parking assist monitor assists the driver by displaying an image of the view behind the vehicle while backing up, for example while parking. Owners of models equipped with a navigation system should refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”.
Page 247 4-5. Using the driving support systems Using the Lexus parking assist monitor Screen display ■ The parking assist monitor screen will be displayed if the shift position is shifted to R while the power switch is in ON mode. Intuitive parking assist display (if...
Page 248 When the shift position is in any position other than R, the display mode can be changed in the following procedure. Press the “MENU” button on the Lexus Display Audio controller, and then select “Setup” on the screen. Select “Vehicle”, and then select “Back Camera Guide Line Setting” on the screen.
Page 249 4-5. Using the driving support systems Estimated course line display mode Screen description ■ Vehicle width guide line The line indicates a guide path when the vehicle is being backed straight up. The displayed width is wider than the actual vehicle width. The line aligns with the estimated course lines when the steering wheel is straight.
Page 250 4-5. Using the driving support systems Parking operation ■ When parking in a space which is in the reverse direction to the space described in the procedure below, the steering directions will be reversed. Shift the shift position to R position. Turn the steering wheel so that the estimated course lines are within the parking space, and...
Page 251 4-5. Using the driving support systems Once the vehicle width guide lines and the parking space lines are parallel, straighten the steering wheel and back up slowly until the vehicle has com- pletely entered the parking space. Stop the vehicle in an appropriate place, and finish parking. Parking assist guide line display mode Screen description ■...
Page 252 4-5. Using the driving support systems Parking operation ■ When parking in a space which is in the reverse direction to the space described in the procedure below, the steering directions will be reversed. Shift the shift position to R position. Back up until the parking assist guide line meets the edge of the left-hand dividing line of the park-...
Page 253 4-5. Using the driving support systems Lexus parking assist monitor precautions Area displayed on screen ■ The parking assist monitor displays an image of the view from the bumper of the rear area of the vehi- cle. The image on the rear view monitor system screen can be adjusted.
Page 254 4-5. Using the driving support systems Lexus parking assist monitor camera ■ The camera for the parking assist monitor is located above the license plate. Using the camera ● If dirt or foreign matter (such as water droplets, snow, mud etc.) is adhering to the camera, it cannot transmit a clear image.
Page 255 4-5. Using the driving support systems When the ground behind the vehicle slopes up sharply ● The distance guide lines will appear to be closer to the vehicle than the actual distance. Because of this, objects will appear to be farther away than they actually are.
Page 256 4-5. Using the driving support systems When any part of the vehicle sags ● When any part of the vehicle sags due to the number of passengers or the distribution of the load, there is a margin of error between the guide lines on the screen and the actual distance/course on the road.
Page 257 4-5. Using the driving support systems Distance guidelines ● Visually check the surroundings and the area behind the vehicle. On the screen, it appears that a truck is parking at point . How- ever, in reality if you back up to point , you will hit the truck.
Page 258 • Foreign matter (mud etc.) is adhering to improved.) the camera The image on the Lexus parking assist • There are scratches on the camera monitor system screen can be adjusted. • Sunlight or headlights are shining (P.
Page 259 4-5. Using the driving support systems Likely cause Solution  The guide lines are very far out of alignment Have the vehicle inspected by your Lexus The camera position is out of alignment. dealer. • The vehicle is tilted (there is a heavy...
Page 260 4-5. Using the driving support systems WARNING When using the Lexus parking assist monitor system ■ The parking assist monitor is a supplemental device intended to assist the driver when backing up. When backing up, be sure to check visually behind and all around the vehi- cle before proceeding.
Page 261 Do not expose the camera to strong impact as this could cause a malfunction. ● If this happens, have the vehicle inspected by your Lexus dealer as soon as possible. ES300h_OM_OM33B71U_(U)
Page 262: Driving Mode Select Switch
4-5. Using the driving support systems Driving mode select switch The driving modes can be selected to suit driving condition. Normal mode For normal driving. Press the switch to change the driving mode to normal mode when selected to Eco mode or sport mode.
Page 263 4-5. Using the driving support systems Operation of the air conditioning system in Eco drive mode ■ Eco drive mode controls the heating/cooling operations and fan speed of the air condi- tioning system to enhance fuel efficiency (P. 391). To improve air conditioning perfor- mance, adjust the fan speed or turn off Eco drive mode.
Page 264: Summary Of Blind Spot Monitor
4-5. Using the driving support systems  BSM (Blind Spot Monitor) Summary of the Blind Spot Monitor The Blind Spot Monitor is a system that has 2 functions; The Blind Spot Monitor function ● Assists the driver in making the decision when changing lanes The Rear Cross Traffic Alert function ●...
Page 265 When “Blind Spot Monitor System Malfunction Visit Your Dealer” is shown on the ■ multi-information display There may be a sensor malfunction or voltage abnormality. Have the vehicle inspected at a Lexus dealer. Certification for the Blind Spot Monitor system ■ For vehicles sold in the U.S.A.
Page 266 If the sensor or surrounding area is subject to a strong impact, always have the area inspected by your Lexus dealer. Do not disassemble the sensor.
Page 267: Blind Spot Monitor Function
4-5. Using the driving support systems The Blind Spot Monitor function The Blind Spot Monitor function uses radar sensors to detect vehicles that are traveling in an adjacent lane in the area that is not reflected in the outside rear view mirror (the blind spot), and advises the driver of the vehicles existence via the outside rear view mirror indicator.
Page 268 4-5. Using the driving support systems The Blind Spot Monitor function is operational when ■ The BSM main switch is set to on ● Vehicle speed is greater than approximately 10 mph (16 km/h). ● The Blind Spot Monitor function will detect a vehicle when ■...
Page 269: Rear Cross Traffic Alert Function
4-5. Using the driving support systems The Rear Cross Traffic Alert function The Rear Cross Traffic Alert functions when your vehicle is in reverse. It can detect other vehicles approaching from the right or left rear of the vehicle. It uses radar sensors to alert the driver of the other vehicle’...
Page 270 4-5. Using the driving support systems The Rear Cross Traffic Alert function detection areas The areas that vehicles can be detected in are outlined below. To give the driver a more consistent time to react, the buzzer can alert for faster vehicles from farther away.
Page 271 4-5. Using the driving support systems Conditions under which the Rear Cross Traffic Alert function will not detect a vehicle ■ The Rear Cross Traffic Alert function is not designed to detect the following types of vehicles and/or objects. Small motorcycles, bicycles, pedestrians etc. ●...
Page 272: Driving Assist Systems
4-5. Using the driving support systems Driving assist systems To help enhance driving safety and performance, the following systems oper- ate automatically in response to various driving situations. Be aware, however, that these systems are supplementary and should not be relied upon too heavily when operating the vehicle.
Page 273 4-5. Using the driving support systems ◆ EPS (Electric Power Steering) Employs an electric motor to reduce the amount of effort needed to turn the steering wheel When the TRAC/VSC/ABS systems are operating The slip indicator light will flash while the TRAC/VSC/ABS systems are operating.
Page 274 When the message is displayed on the multi-information display showing that TRAC ■ has been disabled even if the VSC OFF switch has not been pressed TRAC cannot be operated. Contact your Lexus dealer. When the 12-volt battery is disconnected ■...
Page 275 4-5. Using the driving support systems ECB operating sound ■ ECB operating sound may be heard in the following cases, but it does not indicate that a malfunction has occurred. Operating sound heard from the engine compartment when the brake pedal is oper- ●...
Page 276 4-5. Using the driving support systems WARNING The ABS does not operate effectively when ■ The limits of tire gripping performance have been exceeded (such as excessively ● worn tires on a snow covered road). The vehicle hydroplanes while driving at high speed on wet or slick roads. ●...
Page 277 The ABS, TRAC and VSC systems will not function correctly if different size tires are installed on the vehicle. Contact your Lexus dealer for further information when replacing tires or wheels. Handling of tires and the suspension ■...
Page 278: 4-6. Driving Tips
4-6. Driving tips Hybrid vehicle driving tips For economical and ecological driving, pay attention to the following points: ◆ Using Eco drive mode When using Eco drive mode, the torque corresponding to the accelerator pedal depression amount can be generated more smoothly than it is in normal conditions.
Page 279 4-6. Driving tips ◆ Delays Repeated acceleration and deceleration, as well as long waits at traffic lights, will lead to bad fuel economy. Check traffic reports before leaving and avoid delays as much as possible. When driving in a traffic jam, gently release the brake pedal to allow the vehicle to move forward slightly while avoiding over- use of the accelerator pedal.
Page 280: Winter Driving Tips
4-6. Driving tips Winter driving tips Carry out the necessary preparations and inspections before driving the vehi- cle in winter. Always drive the vehicle in a manner appropriate to the prevail- ing weather conditions. Preparation for winter Use fluids that are appropriate to the prevailing outside temperatures. ●...
Page 281 4-6. Driving tips When parking the vehicle Park the vehicle and move the shift lever to P without setting the parking brake. The parking brake may freeze up, preventing it from being released. If necessary, block the wheels to prevent inadvertent sliding or creeping. Selecting tire chains Use the correct tire chain size when mounting the tire chains.
Page 282 4-6. Driving tips Shifting the windshield wiper position If heavy snow or icy condition is expected, shift the rest position manually. Grip the hook section of the wiper arm firmly when shifting the wiper position. To rest position ■ Raise the wiper in line with the wind- shield until it locks.
Page 283 NOTICE Repairing or replacing snow tires ■ Request repairs or replacement of snow tires from Lexus dealers or legitimate tire retailers. This is because the removal and attachment of snow tires affects the operation of the tire pressure warning valves and transmitters.
Page 284: Lexus Display Audio
Lexus Display Audio system 5-1. Basic Operations Lexus Display Audio System .........286 Steering wheel audio switches........293 USB/AUX ports ......294 5-2. Setup Setup menu ........296 General settings......297 Voice settings ....... 301 Display settings......302 5-3. Using the audio system Selecting the audio source ..........304...
Page 285 ® Displaying a Bluetooth ® Bluetooth ........366 device details ......341 5-12. Other function ® Detailed Bluetooth “Information” screen....371 settings.........342 USB photo ........373 Weather information ....375 Voice command system ...376 Mobile Assistant......380 LEXUS Enform Remote ..382 ES300h_OM_OM33B71U_(U)
Page 286: 5-1. Basic Operations
5-1. Basic Operations  Lexus Display Audio System Use the following buttons to start listening to the audio system. Lexus Display Audio operation buttons Eject a disc. Disc slot Except radio and A/V mode: Pause or resume playing a track.
Page 287 5-1. Basic Operations “Menu” screen ■ To display the “Menu” screen, press the “MENU” button on the controller unit. Button Function “Radio” Display the radio top screen (P. 312) “Media” Display the media top screen (P. 319, 326, 330, 334, 343) “Climate”...
Page 288 5-1. Basic Operations Lexus Display Audio controller By using the Lexus Display Audio controller, you can control the audio system, hands-free system, etc. Display the “Source” screen or audio top screen (P. 304) Display the “Menu” screen (P. 287) Back button Display the previous screen Turn or move the controller to select a function and number.
Page 289 5-1. Basic Operations Using the Lexus Display Audio controller ■ Select: Turn or move the control- ler. Enter: Push the controller. Basic screen operation ■ When a list is displayed, use the appropriate button to scroll through the list. Indicator turns on when you can select the list by turning the con- troller.
Page 290 5-1. Basic Operations Inputting letters and numbers Input mode ■ Letters and numbers are inputted via the screen. Turn the controller to select the desired character and press the controller to input the character. When this indicator is shown, you can change input fields by moving the controller forward.
Page 291 When this indicator is shown, you can change to input mode by moving the controller backward. When using the screen ■ Under extremely cold conditions, the Lexus Display Audio controller may react slowly. ● If the screen is cold, the display may be dark, or the system may seem to be operating ●...
Page 292 To prevent Lexus Display Audio controller malfunction ■ Do not allow the Lexus Display Audio controller to come into contact with food, liq- ● uid, stickers or lit cigarettes as doing so may cause it to change color, emit a strange odor or stop functioning.
Page 293: Steering Wheel Audio Switches
5-1. Basic Operations Steering wheel audio switches Some audio features can be controlled using the switches on the steering wheel. Operation may differ depending on the type of audio system or navigation system. For details, refer to the manual provided with the audio system or nav- igation system.
Page 294: Usb/Aux Ports
Connect an iPod, USB memory device or portable audio player to the USB/ AUX port as indicated below. Select “iPod”, “USB”, “AUX” or “A/V” on the audio source selection screen and the device can be operated via Lexus Display Audio system.
Page 295 5-1. Basic Operations Using a 4-pole AUX cable To view a video on an iPod video or VTR, it is necessary to use a 4-pole AUX cable to connect the portable audio device. When connecting a portable audio device to the AUX port, use a 4-pole AUX cable with a plug that matches the exact layout shown in the illustration.
Page 296: 5-2. Setup
5-2. Setup Setup menu The Lexus Display Audio system can be adjusted to the desired settings. Display “Setup” screen “Setup” screen: “MENU” button “Setup” Change the settings for operation sounds, screen animation, etc. (P. 297) Adjust the settings for voice guid- ance volume and voice recognition prompts.
Page 297: General Settings
(P. 298) Set the animation effect on/off. Delete personal data (P. 300) Update program versions. For details, contact your Lexus dealer. Update gracenote database versions. For details, contact your Lexus dealer. Display the open source license. ES300h_OM_OM33B71U_(U)
Page 298 5-2. Setup Customizing images Go to “Customize Images”: “MENU” button  “Setup”  “General”  “Customize Images” Select “Set Images” and then select the desired image. Set as startup image. Set as screen off image. Set as startup image and screen off image.
Page 299 5-2. Setup USB memory ■ When saving the images to a USB memory device, name the folder that the images are saved to “Image”. Compatible device formats ● The following device format can be used: • USB communication format: USB2.0 FS (480 Mbps) •...
Page 300 5-2. Setup Deleting personal data “MENU” button  “Setup”  “General”  “Delete Personal Data” Select “Delete”. Check carefully beforehand, as data cannot be retrieved once deleted. The following personal data will be deleted or changed to its default settings. •...
Page 301: Voice Settings
5-2. Setup Voice settings You can adjust the guidance volume setting. Go to “Voice Settings”: “MENU” button  “Setup”  “Voice” Adjust the voice guidance volume setting. Set the voice recognition prompts on/off. Return to the default settings ■ Move the controller to the left and select “Default”. ES300h_OM_OM33B71U_(U)
Page 302: Display Settings
5-2. Setup Display settings Settings are available for adjusting the contrast and brightness of the screen. The display can also be turned off. Screen for display settings Go to “Display”: “MENU” button  “Display” Turn off screen. Adjust screen quality. Adjust screen quality of the rear view monitor camera.
Page 303 5-2. Setup Adjusting the screen quality Select “General” or “Camera” on the “Display” screen or select “Display” on each audio menu screen. (P. 309) Adjust the display as desired by turning the controller clockwise (+) or coun- terclockwise (-). To select “Contrast”, “Brightness”, “Color” or “Tone”, move the controller to the left. (“Colour”...
Page 304: 5-3. Using The Audio System
5-3. Using the audio system Selecting the audio source Switching between audio sources such as radio and CD are explained in this section. Changing audio source Press the “AUDIO” button to display the “Source” screen. If the “Source” screen is not displayed, press the button again. Select the desired audio source.
Page 305: Optimal Use Of The Audio System
5-3. Using the audio system Optimal use of the audio system On the “Sound Settings” screen, sound quality (Treble/Mid/Bass), volume balance and DSP settings can be adjusted. How to adjust the sound settings and sound quality Audio menu screen. (P. 309) Select “Sound Settings”.
Page 306: Audio Settings
5-3. Using the audio system Audio settings Screen for audio settings Go to “Audio Settings”: “MENU” button  “Setup”  “Audio” Change radio settings (P. 306) Change iPod settings (P. 307) Change A/V settings (P. 307) Change the cover art settings (P.
Page 307 5-3. Using the audio system Changing iPod settings To change iPod settings, select “iPod Settings” on the “Audio Settings” screen or iPod menu screen. (P. 309) Change the screen size (video mode) Change the cover art settings (P. 308) Adjust the screen quality (video mode) (P.
Page 308 5-3. Using the audio system Changing the cover art settings To change the cover art settings, select “Cover Art Settings” on the “Audio Set- tings” screen, CD or MP3/WMA/AAC disc menu screen. (P. 309) Select to set the cover art display of the DISC mode on/off.
Page 309: Audio Menu Screen Operation
5-3. Using the audio system Audio menu screen operation You can change the settings and control functions for each audio source. Audio menu screen To display the audio menu screen, move the controller to the left while on an audio top screen. AM, FM radio or XM Satellite Radio ...
Page 310 5-3. Using the audio system ® CD, MP3/WMA/AAC disc, iPod, USB or Bluetooth  Play or pause a track/file Select a track/file Select a folder/album (MP3/WMA/ AAC disc or USB) Select and hold: Fast-forward or rewind a track/file Select a repeat mode. (P. 311) Select a random/shuffle play mode.
Page 311 5-3. Using the audio system Repeat play Mode Action Target audio source File/track repeat All media Folder repeat MP3/WMA/AAC disc, USB ® Album repeat USB, Bluetooth Random/shuffle playback Mode Action Target audio source Random/shuffle play of the disc/ All media folder/album Random play of all folders MP3/WMA/AAC disc, USB...
Page 312: 5-4. Using The Radio
5-4. Using the radio Radio operation Select “AM”, “FM” or “SAT” on the audio source selection screen to begin lis- tening to the radio. Radio top screen Pressing the “RADIO” button displays the radio top screen from any screen of the selected source.
Page 313 5-4. Using the radio Selecting an HD Radio channel When “HD Radio” is set to “On”, available stations with HD Radio channels are marked with “HD)”. In AM or FM mode, select a station marked with “HD)”. Turn the “TUNE•SCROLL” knob to select an HD Radio channel. HD Radio channels can also be selected by selecting “Multicast”...
Page 314 For more information, and a guide to available radio stations and programming, refer to www.hdradio.com. “HD Radio features included in Lexus radios: Digital Sound - HD Radio broadcasts deliver crystal-clear, digital audio quality to listeners.
Page 315 5-4. Using the radio HD Radio™ Technology troubleshooting guide ■ Experience Cause Action Mismatch of time align- The radio stations analog ment- a user may hear a None, radio broadcast and digital volume are not short period of program- issue. A user can contact properly aligned or the sta- ming replayed or an echo, the radio station.
Page 316 5-4. Using the radio Reception sensitivity ■ Maintaining perfect radio reception at all times is difficult due to the continually chang- ● ing position of the antenna, differences in signal strength and surrounding objects, such as trains, transmitters, etc. The radio antenna is mounted inside the rear window. To maintain clear radio reception, ●...
Page 317 5-4. Using the radio XM Radio Services — Legal Disclaimers and Warnings ■ Fees and Taxes — Subscription fee, taxes, one time activation fee, and other fees may ● apply. Subscription fee is consumer only. All fees and programming subject to change. Subscriptions subject to Customer Agreement available at www.siriusxm.com (U.S.A.) or www.xmradio.ca (Canada) XM service only available in the 48 contiguous United States and Canada...
Page 318 SAT Check Antenna There is a short-circuit in the antenna or the surrounding antenna cable. See a Lexus certified dealer. You have not subscribed to XM Satellite Radio. The radio is being updated with the latest encryption code. Contact XM Satellite Radio for subscription information.
Page 319: Cd Player Operation
5-5. Playing an audio CD and MP3/WMA/AAC discs CD player operation Insert a disc, press the “MEDIA” button or select “DISC” on the “Source” screen with a disc inserted to begin listening to a CD. CD top screen Pressing the “MEDIA” button displays the CD top screen from any screen of the selected source.
Page 320 5-5. Playing an audio CD and MP3/WMA/AAC discs Error messages ■ If the following error messages appear on the screen, refer to the table and take the appropriate measures. If the problem is not rectified, take the vehicle to your Lexus dealer. Message Cause Correction procedures •...
Page 321 5-5. Playing an audio CD and MP3/WMA/AAC discs MP3, WMA and AAC files ■ MP3 (MPEG Audio LAYER3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size by using MP3 com- pression. WMA (Windows Media Audio) is a Microsoft audio compression format.
Page 322 5-5. Playing an audio CD and MP3/WMA/AAC discs Compatible media ● Media that can be used for MP3, WMA and AAC playback are CD-Rs and CD-RWs. Playback in some instances may not be possible if the CD-R or CD-RW is not final- ized.
Page 323 5-5. Playing an audio CD and MP3/WMA/AAC discs MP3, WMA and AAC playback ● When a disc containing MP3, WMA or AAC files is inserted, all files on the disc are first checked. Once the file check is finished, the first MP3, WMA or AAC file is played.
Page 324 5-5. Playing an audio CD and MP3/WMA/AAC discs ES300h_OM_OM33B71U_(U)
Page 325 5-5. Playing an audio CD and MP3/WMA/AAC discs NOTICE Discs and adapters that cannot be used ■ Do not use the following types of discs. Also, do not use 3 in. (8 cm) disc adapters, DualDiscs or printable discs. Doing so may damage the player and/or disc insert/eject function. Discs that have a diameter that is not 4.7 in.
Page 326: 5-6. Using An External Device
5-6. Using an external device Listening to an iPod Connecting an iPod enables you to enjoy music from the vehicle speakers. Press the “MEDIA” button or select “iPod” on the audio source selection screen. Connecting an iPod P. 294 iPod top screen Pressing the “MEDIA”...
Page 327 5-6. Using an external device About iPod ■ “Made for iPod” and “Made for iPhone” mean that an electronic accessory has been ● designed to connect specifically to an iPod, or iPhone, respectively, and has been certi- fied by the developer to meet Apple performance standards. Apple is not responsible for the operation of this device or its compliance with safety ●...
Page 328 Owner’ s Manual. Error messages ■ If the following error messages appear on the screen, refer to the table and take the appropriate measures. If the problem is not rectified, take the vehicle to your Lexus dealer. Message Cause/Correction procedures “Connection error.”...
Page 329 5-6. Using an external device Compatible models ■ ® ® ® ® ® The following iPod , iPod nano , iPod classic , iPod touch and iPhone devices can be used with this system. Made for ● • iPod touch (5th generation) •...
Page 330: Using Usb Memory Device
5-6. Using an external device Using USB memory device Connecting a USB memory device enables you to enjoy music from the vehi- cle speakers. Select “USB1” or “USB2” on the audio source selection screen. Connecting a USB memory device P. 294 USB top screen Pressing the “MEDIA”...
Page 331 Error messages for USB memory ■ If the following error messages appear on the screen, refer to the table and take the appropriate measures. If the problem is not rectified, take the vehicle to your Lexus dealer. Message Cause/Correction procedures This indicates a problem with the USB memory “Connection error.”...
Page 332 5-6. Using an external device MP3, WMA and AAC files ● MP3 (MPEG Audio LAYER 3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size using MP3 com- pression. WMA (Windows Media Audio) is a Microsoft audio compression format. This format compresses audio data to a size smaller than that of the MP3 format.
Page 333 5-6. Using an external device ID3, WMA and AAC tags ● ID3 tags can be added to MP3 files, making it possible to record the track title, artist name, etc. The system is compatible with ID3 Ver. 1.0, 1.1, and Ver. 2.2, 2.3 ID3 tags. (The number of characters is based on ID3 Ver.
Page 334: Using The Aux Port
5-6. Using an external device Using the AUX port To use the AUX port, connect a portable player, press the “MEDIA” button or select “AUX” or “A/V” on the “Source” screen. Connecting a portable player P. 294 Top screen Pressing the “MEDIA” button displays the top screen from any screen of the selected source.
Page 335: Connecting Bluetooth
Steps for using Bluetooth devices ® The following can be performed using Bluetooth wireless communication: A portable audio player can be operated and listened to via the Lexus ■ Display Audio system Hands-free phone calls can be made via a cellular phone ■...
Page 336 ® 5-7. Connecting Bluetooth “Bluetooth Setup” screen Setup”: “MENU” button  “Setup”  “Bluetooth Go to “Bluetooth ” : Bluetooth is a registered trademark of Bluetooth SIG, Inc. When displaying “Bluetooth Setup” screen from the “Bluetooth Audio” screen ■ Display the “Bluetooth Audio”...
Page 337: Registering A Bluetooth ® Device
® 5-7. Connecting Bluetooth ® Registering a Bluetooth device ® Bluetooth compatible phones (HFP) and portable audio players (AVP) can ® be registered simultaneously. You can register up to 5 Bluetooth devices. ® How to register a Bluetooth device ® Turn the Bluetooth connection setting of your device set to on.
Page 338: Selecting A Bluetooth ® Device
® 5-7. Connecting Bluetooth Selecting a Bluetooth ® device ® If multiple Bluetooth devices are registered, follow the procedure below to ® select the Bluetooth device to be used. You may only use one device at a time. ® How to select a Bluetooth device Setup”: “MENU”...
Page 339: Connecting A Bluetooth Audio Player
® 5-7. Connecting Bluetooth ® Connecting a Bluetooth audio player There are 2 portable audio player connection settings available: connecting from the vehicle and connecting from the portable player. Connecting method is set to “Vehicle” When the portable audio player is in standby for a connection, it will be automat- ically connected whenever the power switch is in either ACCESSORY or ON mode.
Page 340: Connecting A Bluetooth ® Phone
® 5-7. Connecting Bluetooth ® Connecting a Bluetooth phone There are two connecting methods available: automatic and manual. Auto connection When you register a phone, auto connection will be activated. Always set it to ® this mode and leave the Bluetooth phone in a place where a connection can be established.
Page 341: Displaying A Bluetooth ® Device Details
® 5-7. Connecting Bluetooth ® Displaying a Bluetooth device details You can confirm and change the registered device details. ® Bluetooth device registration status Setup”: “MENU” button  “Setup”  “Bluetooth Go to “Bluetooth ” Select the desired device and then select “Device Info”. Change the name of the device Change the connection method “Vehicle”: Connect the audio system...
Page 342: Detailed Bluetooth Settings
® 5-7. Connecting Bluetooth ® Detailed Bluetooth settings ® You can confirm and change the detailed Bluetooth settings. ® How to check and change detailed Bluetooth settings Setup”: “MENU” button  “Setup”  “Bluetooth Go to “Bluetooth ” Move the controller to the left and then select “System Settings”. ®...
Page 343: Bluetooth ® Audio
® 5-8. Bluetooth Audio ® Listening to Bluetooth Audio ® The Bluetooth audio system enables the user to enjoy music played on a por- table player from the vehicle speakers via wireless communication. ® When a Bluetooth device cannot be connected, check the connection status on the “Bluetooth Audio”...
Page 344 ® 5-8. Bluetooth Audio ® Bluetooth audio top screen ® Pressing the “MEDIA” button displays the Bluetooth audio top screen from any screen of the selected source. Menu screen ■ P. 309 Selecting a song ■ Press the “” or “” button or turn the “TUNE•SCROLL” knob to select the desired song number.
Page 345: Bluetooth ® Phone
® 5-9. Bluetooth Phone ® Using a Bluetooth Phone The hands-free system is a function that allows you to use your cellular phone without touching it. ® ® This system supports Bluetooth . Bluetooth is a wireless data system that allows the cellular phone to wirelessly connect to the hands-free system and make/receive calls.
Page 346 ® 5-9. Bluetooth Phone ◆ Telephone switch (P. 356) ◆ Microphone The vehicle’ s built-in microphone is used when talking on the phone. The person you are speaking to can be heard from the front speakers. ® To use the hands-free system, you must register your Bluetooth phone in the system.
Page 347: Making A Call
® 5-9. Bluetooth Phone Making a call ® Once a Bluetooth phone is registered, you can make a call using the follow- ing procedure: Dialing Go to “Dial Pad”: “MENU” button  “Phone”  “Dial Pad” Input a phone number. (P. 290) Press the off-hook switch on the steering wheel or select Dialing from the phonebook You can dial a number from the phonebook data imported from your cellular...
Page 348 ® 5-9. Bluetooth Phone When the phonebook is empty ® You can transfer the phone numbers in a Bluetooth phone to the system. Operation methods differ between PBAP (Phone Book Access Profile) compat- ® ible and PBAP incompatible Bluetooth phones. If the cellular phone does not support either PBAP or OPP (Object Push Profile) service, you cannot transfer contacts.
Page 349 ® 5-9. Bluetooth Phone Dialing from history You can make a call using the call history. Go to “Call History”: “MENU” button  “Phone”  “Call History” Select the desired entry from the list. Press the off-hook switch on the steering wheel or select Call history list ■...
Page 350: Receiving A Call
® 5-9. Bluetooth Phone Receiving a call When a call is received, the following screen is displayed together with a sound. To answer the phone Press the off-hook switch on the steer- ing wheel or select To refuse a call Press the on-hook switch on the steering wheel or select International calls ■...
Page 351: Speaking On The Phone
® 5-9. Bluetooth Phone Speaking on the phone The following screen is displayed when speaking on the phone. To adjust the transmit volume Select “Transmit Volume”. To restore default volume, move the controller to the left on the “Transmit Volume” screen and then select “Default”. To adjust in call volume Move the controller to the left and then select “In-call Volume”.
Page 352 ® 5-9. Bluetooth Phone Inputting tones When using phone services such as an answering service or a bank, you can store phone numbers and code numbers in the contacts using “p” or “w” symbols (eg. 056133 w 0123p#1). Contact including a phone number only ...
Page 353: Call Waiting
® 5-9. Bluetooth Phone Call waiting When a call is interrupted by a third party while talking, an incoming call mes- sage will be displayed. To talk with the other party: Press the off-hook switch on the steer- ing wheel or select To refuse the call: Press the on-hook switch on the steer- ing wheel or select...
Page 354: Using A Bluetooth ® Phone Message
® 5-9. Bluetooth Phone ® Using a Bluetooth phone message Once a MAP-profile compatible Bluetooth phone is registered, you can check the E-mail/SMS/MMS and reply to a message using the following pro- cedures: Checking messages Go to message screen: “MENU” button  “Phone”  “Messages” Select a message.
Page 355 ® 5-9. Bluetooth Phone Replying to a message Move the controller to the left while on the message screen. Select “Quick Message” to display the “Quick Message” screen. Select the desired message and then select “Send”. Editing a quick message ■...
Page 356: Using The Steering Wheel Switches
® 5-9. Bluetooth Phone Using the steering wheel switches The steering wheel switches can be used to operate a connected cellular phone. Operating a telephone using the steering wheel switches Volume switch During an incoming call: Adjusts the ring tone volume During speaking on the phone: Adjusts in call volume The voice guidance volume cannot be...
Page 357: Bluetooth ® Phone
® 5-9. Bluetooth Phone ® Bluetooth phone settings You can adjust the hands-free system to your desired settings. “Phone/Message Settings” screen Go to “Phone/Message Settings”: “MENU” button  “Setup”  “Phone” ® Register and connect a Bluetooth device. (P. 336) Adjust the call volume and message readout volume.
Page 358: Settings
® 5-9. Bluetooth Phone Sound settings Go to “Sound Settings”: “MENU” button  “Setup”  “Phone”  “Sound Settings” Change the ring tone type Adjust the ring tone volume Adjust the message readout volume Change the incoming SMS/MMS tone type Adjust the incoming SMS/MMS tone volume Change the incoming e-mail tone...
Page 359: Phonebook
5-10. Phonebook Contact settings Individual phonebooks can be registered for a maximum of 5 phones in total. The data for 2500 contacts (up to 4 numbers per contact) can be registered in each phonebook. “Contact/Call History Settings” screen Go to “Contact/Call History Settings”: “MENU” button  “Setup”  “Phone” ...
Page 360 5-10. Phonebook Transferring a phone number ® You can transfer the phone numbers in your Bluetooth phone to the system. Operation methods differ between PBAP compatible and PBAP incompatible ® Bluetooth phones. If your cellular phone does not support either PBAP or OPP services, you cannot transfer contacts.
Page 361 5-10. Phonebook Removing favorites Go to “Remove Favorite”: “MENU” button  “Setup”  “Phone”  “Con- tact/Call History Settings”  “Remove Favorite” Select the desired contacts. You can select all contacts by selecting “Select All”. Move the controller to the left and select “Remove”. Deleting the contacts data Go to “Delete Contacts”: “MENU”...
Page 362: Messaging Setting
5-10. Phonebook Messaging setting Go to “Messaging Settings”: “MENU” button  “Setup”  “Phone”  “Mes- saging Settings” Set the message forwarding from cellular phones on/off Set the automatic message read out function on/off Set the new SMS/MMS notification display on/off Set the new e-mail notification dis- play on/off Set the signature function on/off...
Page 363: Bluetooth
® The connected device may not be a compatible Bluetooth cellular phone.  For a list of specific devices which operation has been confirmed on this system, check with your Lexus dealer or the following website: http://www.lexus.com/MobileLink ® The Bluetooth version of the connected cellular phone may be older than the speci- fied version.
Page 364 The profile version of the connected cellular phone may not be compatible with trans- ferring phonebook data.  For a list of specific devices which operation has been confirmed on this system, check with your Lexus dealer or the following website: http://www.lexus.com/MobileLink Automatic phonebook transfer function on this system is set to off.
Page 365 ® 5-11. Bluetooth In other situations  Even though all conceivable measures have been taken, the symptom status does not change. The cellular phone is not close enough to this system.  Bring the cellular phone closer to this system. The cellular phone is the most likely cause of the symptom.
Page 366: Bluetooth
® 5-11. Bluetooth ® Bluetooth ® When using the Bluetooth audio system ■ In the following situations, the system may not function. ● • If the portable audio player is turned off • If the portable audio player is not connected •...
Page 367 ® 5-11. Bluetooth Battery charge/signal status ■ This display may not correspond exactly with the portable audio player or cellular ● phone itself. This system does not have a charging function. ● The portable audio player or cellular phone battery will be depleted quickly when the ●...
Page 368 ® 5-11. Bluetooth Compatible models ■ ® The Bluetooth audio system supports portable audio players with the following specifi- cations ® Bluetooth specifications: ● Ver. 2.0 or higher (Recommended: Ver. 3.0 +EDR or higher) Profiles: ● • A2DP (Advanced Audio Distribution Profile) Ver. 1.0, or higher (Recommended: Ver.
Page 369 ® 5-11. Bluetooth Certification ■ For vehicles sold in the U.S.A., Hawaii, Guam and Puerto Rico  For vehicles sold in Canada  ES300h_OM_OM33B71U_(U)
Page 370 ® 5-11. Bluetooth WARNING While driving ■ Do not operate the portable audio player, cellular phone or connect a device to the ® Bluetooth system. Caution regarding interference with electronic devices ■ ® Your audio unit is fitted with Bluetooth antennas.
Page 371: Other Function
5-12. Other function “Information” screen Display “Information” screen Go to “Information”: “MENU” button  “Info” Display the fuel consumption. (P. 99) Display the Traffic Map picture. Display the “USB Photo” screen. (P. 373) Display the weather information. (P. 375) Available when in a traffic supported HD Radio coverage area Traffic information map Go to “Traffic Map”: “MENU”...
Page 372 5-12. Other function Certification for U.S. owners ■ ES300h_OM_OM33B71U_(U)
Page 373: Usb Photo
5-12. Other function USB photo Connecting a USB memory device enables you to enjoy photos on the Lexus Display Audio display. USB photo screen Go to “USB Photo”: “MENU” button  “Info”  “USB1 Photo” or “USB2 Photo” Connecting a USB memory device P.
Page 374 5-12. Other function USB memory functions ■ P. 331 USB memory ■ Compatible devices ● USB memory device that can be used for JPEG display. Compatible device formats ● The following device format can be used: • USB communication format: USB2.0 FS (480 Mbps) •...
Page 375: Weather Information
5-12. Other function Weather information Weather information for the selected city is displayed. Available when in weather supported HD Radio coverage area How to check the weather information Go to “Weather”: “MENU” button  “Info”  “Weather” Select the desired city/location. Current location of your car Select of the recently checked location list...
Page 376: Voice Command System
5-12. Other function Voice command system The voice command system enables the audio and hands-free systems to be operated using voice commands. Operations of the voice command system can be performed by selecting the menu corresponding to each function on the right part of the screen. Even if any menu is selected, commands displayed on all menus can be operated.
Page 377 5-12. Other function Microphone ■ P. 346 When using the microphone ■ It is unnecessary to speak directly into the microphone when giving a command. ● Wait for the confirmation beep before speaking a command. ● Voice commands may not be recognized if: ●...
Page 378 5-12. Other function Casual speech recognition Due to natural language speech recognition technology, this system enables rec- ognition of a command when spoken naturally. However, the system cannot rec- ognize every variation of each command. In some situations, it is possible to omit the command for the procedure and directly state the desired operation.
Page 379 5-12. Other function Phone  Command Action Places a call to the phone number of the latest outgo- “Redial” ing call Places a call to the phone number of latest incoming “Call Back” call “Show Recent Calls” Displays the call history screen “Dial <phone number>”...
Page 380: Mobile Assistant
5-12. Other function Mobile Assistant The Mobile Assistant feature on this system allows the activation of Apple’s ® Siri Eyes Free mode via the steering wheel switches. To operate the Mobile Assistant, a compatible cellular phone must be registered and connected to ®...
Page 381 5-12. Other function Microphone ■ It is not necessary to speak directly into the microphone when using the Mobile Assistant. Wait for the listening beeps before using the Mobile Assistant. ● The Mobile Assistant may not recognize commands in the following situations: ●...
Page 382: Lexus Enform Remote
● operating Lexus Enform Remote. In some states, use of Lexus Enform Remote may violate state or local laws. Before using Lexus Enform Remote, check your state and local laws. Any malfunction of the Lexus should be repaired by your Lexus dealer.
Page 383: Interior Features
• Vanity mirrors ......405 • Clock ........406 • Power outlets ......406 • Armrest........407 • Rear sunshade/rear door sunshades....... 408 • Coat hooks......410 • Assist grips....... 410 Garage door opener....411 Compass ........418 LEXUS Enform Safety Connect........422 ES300h_OM_OM33B71U_(U)
Page 384: Automatic Air Conditioning System
Air outlets and fan speed are automatically adjusted according to the temper- ature setting. Vehicles with Lexus Display Audio system: Press the “MENU” button on the Lexus Display Audio controller, then select “Climate” to display the air condi- tioning operation screen.
Page 385 : Air flows to the feet : Air flows to the feet and the windshield defogger operates Adjust the right-hand side temperature setting Move the Lexus Display Audio controller left/right to select the desired item When is selected: Move the controller forward/backward or turn it left/right for adjusting.
Page 386 6-1. Using the air conditioning system and defogger Vehicles with navigation system  Adjust the left-hand side tempera- ture setting Adjust the fan speed setting Select the air flow mode : Air flows to the upper body : Air flows to the upper body and feet : Air flows to the feet : Air flows to the feet and the windshield defogger operates...
Page 387 Option control screen ■ Select on the climate screen to display the option control screen. The functions can be switched on and off. Vehicles with Lexus Display Vehicles with navigation system   Audio system Select to set cooling and dehumidification function on/off Adjusting the temperature for driver and passenger seats separately (“DUAL”...
Page 388: Other Functions
6-1. Using the air conditioning system and defogger Adjusting the temperature for driver and passenger seats separately ■ (“DUAL” mode) To turn on the “DUAL” mode, perform any of the following procedures: Press the “DUAL” button. ● Select “DUAL” on the option control screen. ●...
Page 389: Air Outlets
6-1. Using the air conditioning system and defogger Micro dust and pollen filter ■ Pollen is removed from the air and the air flows to the upper part of the body. Select on the option control screen. When the micro dust and pollen filter is on, is displayed on the air condition- ing control screen.
Page 390 The system may not operate correctly if more than one electronic key is in the vicinity or if the smart access system is used to unlock a passenger door. Settings for the electronic key and the corresponding door can be changed. Contact your Lexus dealer. Using automatic mode ■...
Page 391 6-1. Using the air conditioning system and defogger Fogging up of the windows ■ The windows will easily fog up when the humidity in the vehicle is high. Selecting “A/C” ● on the option control screen will dehumidify the air from the outlets and defog the windshield effectively.
Page 392 6-1. Using the air conditioning system and defogger Ventilation and air conditioning odors ■ To let fresh air in, set the air conditioning system to the outside air mode. ● During use, various odors from inside and outside the vehicle may enter into and accu- ●...
Page 393 6-1. Using the air conditioning system and defogger NOTICE Humidity sensor ■ In order to detect fog on the windshield, a sen- sor which monitors the temperature of the windshield, the surround humidity, etc. is installed. (P. 391) Follow these points to avoid damaging the sen- sor: Do not disassemble the sensor ●...
Page 394: Heated Steering Wheel/ Seat Heaters/Seat Ventilators
6-1. Using the air conditioning system and defogger   Heated steering wheel /seat heaters  seat ventilators Heated steering wheel and seat heaters heat the side grips of the steering wheel and seats, respectively. Seat ventilators maintain good airflow by blow- ing air from the seats.
Page 395 6-1. Using the air conditioning system and defogger Heated steering wheel Turns the heated steering wheel on/off The indicator light comes on when the heated steering wheel is operating. The heated steering wheel can be used when the power switch is in ON mode. ●...
Page 396: 6-2. Using The Interior Lights
6-2. Using the interior lights Interior lights list Outer foot lights Rear personal lights (P. 397) Shift lever light Door courtesy lights Interior lights (P. 397) Ornament lights (if equipped) Front personal lights (P. 397) Footwell lights When the instrument panel light control switch is turned to minimum and the tail lights are on, the ornament lights and the footwell lights will turn off.
Page 397: Interior Lights
6-2. Using the interior lights Interior lights Turns the light on/off (touch the light) The rear interior light also turns on/off. Turns the door position on/off The front and rear interior lights turn on/ off when a door is opened/closed. Personal lights Front ■...
Page 398 6-2. Using the interior lights Illuminated entry system: The lights automatically turn on/off according to power switch ● mode, the presence of the electronic key, whether the doors are locked/unlocked, and whether the doors are opened/closed. If the following lights remain on when the power switch is turned off the lights will go off ●...
Page 399: Using The Storage Features
6-3. Using the storage features List of storage features Cup holders (P. 401) Console box (P. 400) Glove box (P. 400) Auxiliary box (P. 402) WARNING Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause ●...
Page 400: Glove Box
6-3. Using the storage features Glove box Open (press the button) Unlock with the mechanical key Lock with the mechanical key The glove box light turns on when the tail lights are on. ● The trunk opener main switch is located in the glove box. (P. 115) ●...
Page 401: Cup Holders
6-3. Using the storage features Cup holders Driver’s side ■ To open, move the cup holder lid until it locks. To close, press and release the cup holder lid. Front passenger’s side ■ To open, press down and release the cup holder lid.
Page 402: Auxiliary Box
6-3. Using the storage features WARNING Do not place anything other than cups or beverage cans in the cup holders. ● Other items may be thrown out of the holders in the event of an accident or sudden braking, causing injury. If possible, cover hot drinks to prevent burns. Front passenger’...
Page 403: Trunk Features
6-3. Using the storage features Trunk features Cargo hooks Raise the hooks when needed. The cargo hooks are provided for securing loose items. WARNING To avoid injury, always return the cargo hooks to their stowed positions when not in use. Grocery bag hooks ES300h_OM_OM33B71U_(U)
Page 404 6-3. Using the storage features Luggage mat Pull the lever upwards when lifting the luggage mat up. The lever can be hooked on the edge of the trunk. NOTICE When closing the trunk door, do not leave the luggage mat lever hooked on the edge of the trunk.
Page 405: Using The Other Interior Features
6-4. Using the other interior features Other interior features Sun visors To set the visor in the forward posi- tion, flip it down. To set the visor in the side position, flip down, unhook, and swing it to the side. To use the side extender, place the visor in the side position, then slide it backward.
Page 406: Clock
6-4. Using the other interior features Clock The clock can be adjusted. Pressing and holding will move the clock hands backward. Pressing and holding will move the clock hands forward. Power outlets The power outlets can be used for 12V accessories that run on less than 10A. Front ■...
Page 407: Armrest
6-4. Using the other interior features NOTICE To avoid damaging the power outlets, close the power outlet lids when the power out- ● lets are not in use. Foreign objects or liquids that enter the power outlets may cause a short circuit. To prevent blown fuse, do not use an accessory that uses more than 12V 10A.
Page 408: Rear Sunshade/Rear Door Sunshades
6-4. Using the other interior features Rear sunshade (if equipped)/rear door sunshades (if equipped) Rear sunshade ■ The rear sunshade can be raised and lowered by operating the button shown below. Raise/lower Rear door sunshades ■ Pull the tab of the rear door sun- shade and hook the sunshade on the anchors.
Page 409 6-4. Using the other interior features The rear sunshade can be used when the power switch is in ON mode. ● The rear sunshade can be operated for approximately 1 minute even after the power ● switch is turned to ACCESSORY mode or turned off. Reverse operation feature: To ensure adequate rear visibility, the rear sunshade auto- ●...
Page 410: Coat Hooks
6-4. Using the other interior features Coat hooks The coat hooks are provided with the rear assist grips. WARNING Do not hang coat hangers or other hard or sharp objects on the hook. If the SRS cur- tain shield airbags deploy, these items may become projectiles, causing death or seri- ous injury.
Page 411: Garage Door Opener
6-4. Using the other interior features Garage door opener The garage door opener can be programmed to operate garage doors, gates, entry doors, door locks, home lighting systems, security systems, and other devices. ® Programming HomeLink ® The HomeLink wireless control system in your vehicle has 3 buttons which can be programmed to operate 3 different devices.
Page 412 6-4. Using the other interior features ® Programming HomeLink ■ ® Press and release the HomeLink button you want to program and check ® that the HomeLink indicator light flashes (orange). Perform within 60 seconds of , or the indicator light will stop flashing and programming will not be able to be completed.
Page 413 6-4. Using the other interior features If the garage door or other device does not operate, proceed to “Pro- ● gramming a rolling code system”. Repeat the steps above to program another device for any of the remaining ® HomeLink buttons.
Page 414 6-4. Using the other interior features Enabling 2-way communication with a garage door (only available for com- ■ patible devices) When enabled, 2-way communication allows you to check the status of the opening and closing of a garage door through indicators in your vehicle. 2-way communication is only available if the garage door opener motor used is a compatible device.
Page 415 6-4. Using the other interior features Garage door operation indicators The status of the opening and closing of a garage door is shown by the indica- tors. Opening Closing This function is only available if the garage door opener motor used is a compatible device.
Page 416 6-4. Using the other interior features ® Codes stored in the HomeLink memory ■ The registered codes are not erased even if the battery cable is disconnected. ● ® If learning failed when registering a different code to a HomeLink button that already ●...
Page 417 6-4. Using the other interior features WARNING When programming a garage door or other remote control device ■ The garage door or other device may operate, so ensure people and objects are out of danger to prevent potential harm. Conforming to federal safety standards ■...
Page 418: Compass
6-4. Using the other interior features  Compass The compass on the inside rear view mirror indicates the direction in which the vehicle is heading. Operation To turn the compass on or off, press and hold the switch for 3 second. Displays and directions Display Direction...
Page 419 6-4. Using the other interior features Calibrating the compass The direction display deviates from the true direction determined by the earth’ s magnetic field. The amount of deviation varies according to the geographic posi- tion of the vehicle. If you cross over a map boundaries shown in illustration, the compass will deviate. To obtain higher precision or perfect calibration, refer to the following.
Page 420 6-4. Using the other interior features Circling calibration ■ Stop the vehicle in a place where it is safe to drive in a circle. Press and hold the switch for 9 seconds. “C” appears on the compass display. Drive the vehicle at 5 mph (8 km/h) or less in a circle until a direction is displayed.
Page 421 6-4. Using the other interior features NOTICE To avoid the compass malfunctions ■ Do not place magnets or any metal objects near the inside rear view mirror. Doing this may cause the compass sensor to malfunction. To ensure normal operation of the compass ■...
Page 422: Lexus Enform Safety Connect
Telematics Subscription Service Agreement and its Terms and Conditions, as in effect and amended from time to time, a current copy of which is available at Lexus.com. All use of the Safety Connect service is subject to such then- applicable Terms and Conditions.
Page 423 After you have signed the Telematics Subscription Service Agreement and are enrolled, you can begin receiving services. A variety of subscription terms is available for purchase. Contact your Lexus dealer, call 1-800-25-LEXUS (1-800-255-3987) or push the “SOS” button in your vehicle for further subscription details.
Page 424 If your vehicle is stolen, Safety Connect can work with local authorities to assist them in locating and recovering the vehicle. After filing a police report, call the Safety Connect response center at 1-800-25-LEXUS (1-800-255- 3987) and follow the prompts for Safety Connect to initiate this service.
Page 425 For a description of the Roadside Assistance services and their limitations, please see the Safety Connect Terms and Conditions, which are available at Lexus.com. Safety information for Safety Connect Important! Read this information before using Safety Connect.
Page 426 6-4. Using the other interior features Certification for Lexus Enform (for vehicles sold in the U. S. A.) ■ FCC ID: N7NGTM2 FCC WARNING: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65.
Page 427: Maintenance And Care Cleaning And Protecting
Maintenance and care 7-1. Maintenance and care Cleaning and protecting the vehicle exterior....428 Cleaning and protecting the vehicle interior....431 7-2. Maintenance Maintenance requirements......434 General maintenance....437 Emission inspection and maintenance (I/M) programs ........440 7-3. Do-it-yourself maintenance Do-it-yourself service precautions........441 Hood ..........443 Positioning a floor jack.....
Page 428: Cleaning And Protecting The Vehicle Exterior
7-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condi- tion: Working from top to bottom, liberally apply water to the vehicle body, wheel ● wells and underside of the vehicle to remove any dirt and dust. Wash the vehicle body using a sponge or soft cloth, such as a chamois.
Page 429 Precaution regarding the Blind Spot Monitor (if equipped) ■ If the paint of the rear bumper is chipped or scratched, the system may malfunction. If this occurs, consult your Lexus dealer. ES300h_OM_OM33B71U_(U)
Page 430 7-1. Maintenance and care NOTICE To prevent paint deterioration and corrosion on the body and components (aluminum ■ wheels etc.) Wash the vehicle immediately in the following cases: ● • After driving near the sea coast • After driving on salted roads •...
Page 431: Cleaning And Protecting The Vehicle Interior
7-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle’s interior and keep it in top condition: Protecting the vehicle interior Remove dirt and dust using a vacuum cleaner. Wipe dirty surfaces with a cloth dampened with lukewarm water.
Page 432 7-1. Maintenance and care Caring for leather areas ■ Lexus recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’ s interior. Shampooing the carpets ■ There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
Page 433 Water may also cause the body to rust. When cleaning the inside of the windshield (vehicles with Lexus Safety System+) ■ Do not allow glass cleaner to contact the lens. Also, do not touch the lens. (P. 196) Cleaning the inside of the rear window ■...
Page 434: 434 7-2. Maintenance Maintenance Requirements
You can perform some maintenance procedures by yourself. Please be aware that do-it-yourself maintenance may affect warranty coverage. The use of Lexus repair manuals is recommended. For details about warranty coverage, refer to the separate “Owner’ s Guide”, “War- ranty and Service Guide”, “Owner’ s Manual Supplement” or “Warranty Booklet”.
Page 435: Maintenance
It is recommended that genuine Lexus parts be used for repairs to ensure performance of each system. If non-Lexus parts are used in replacement or if a repair shop other than a Lexus dealer performs repairs, confirm the warranty coverage.
Page 436 7-2. Maintenance WARNING If your vehicle is not properly maintained ■ Improper maintenance could result in serious damage to the vehicle and possible death or serious injury. Handling of the 12-volt battery ■ Engine exhaust, some of its constituents, and a wide variety of automobile compo- ●...
Page 437: General Maintenance
Listed below are the general maintenance items that should be performed at the intervals specified in the “Warranty and Service Guide” or “Owner’s Manual Supplement”. It is recommended that any problem you notice should be brought to the attention of your Lexus dealer or qualified service shop for advice. Engine compartment...
Page 438: Vehicle Interior
7-2. Maintenance Vehicle interior Items Check points • The accelerator pedal should move smoothly (with- Accelerator pedal out uneven pedal effort or catching). Hybrid transmission “Park” • When parked on a slope and the shift lever is in P, is mechanism the vehicle securely stopped? •...
Page 439: Vehicle Exterior
7-2. Maintenance Vehicle exterior Items Check points Doors/trunk • Do the doors/trunk operate smoothly? Engine hood • Does the engine hood lock system work properly? • There should not be any signs of fluid leakage after Fluid leaks the vehicle has been parked. •...
Page 440: Emission Inspection And Maintenance (I/M) Programs
The error code in the OBD system will not be cleared unless the vehicle is driven 40 or more times. If your vehicle does not pass the I/M test Contact your Lexus dealer to prepare the vehicle for re-testing. ES300h_OM_OM33B71U_(U)
Page 441: Do-It-Yourself Maintenance
7-3. Do-it-yourself maintenance Do-it-yourself service precautions If you perform maintenance by yourself, be sure to follow the correct proce- dure as given in these sections. Items Parts and tools • Grease 12-volt battery con- dition (P. 455) • Conventional wrench (for terminal clamp bolts) •...
Page 442 7-3. Do-it-yourself maintenance WARNING The engine compartment contains many components and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury, observe the following precautions. When working on the engine compartment ■ Make sure that the indicator on the power switch and the “READY” indicator are ●...
Page 443: Hood
7-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood lock release lever. The hood will pop up slightly. Pull up the auxiliary catch lever and lift the hood. WARNING Pre-driving check ■...
Page 444: Positioning A Floor Jack
7-3. Do-it-yourself maintenance Positioning a floor jack When using a floor jack, follow the instructions in the manual provided with the jack and perform the operation safely. When raising your vehicle with a floor jack, position the jack correctly. Improper placement may damage your vehicle or cause injury. ◆...
Page 445: Engine Compartment
7-3. Do-it-yourself maintenance Engine compartment Washer fluid tank (P. 454) Engine coolant reservoir (P. 451) Fuse boxes (P. 477) Brake fluid reservoir (P. 453) Power control unit coolant reservoir (P. 451) Power control unit coolant radiator (P. 452) Engine oil level dipstick (P.
Page 446 7-3. Do-it-yourself maintenance Engine compartment cover Removing the engine compartment cover ■ Installing the clips ■ Push up center portion Insert Press NOTICE Checking the engine compartment cover after installation ■ Make sure that the cover is securely installed in its original position. ES300h_OM_OM33B71U_(U)
Page 447 7-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. Checking the engine oil ■ Park the vehicle on level ground. After warming up the engine and turning off the hybrid system, wait more than 5 minutes for the oil to drain back into the bottom of the engine.
Page 448 7-3. Do-it-yourself maintenance Adding engine oil ■ If the oil level is below or near the low level mark, add engine oil of the same type as that already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
Page 449 7-3. Do-it-yourself maintenance Engine oil consumption ■ A certain amount of engine oil will be consumed while driving. In the following situations, oil consumption may increase, and engine oil may need to be refilled in between oil maintenance intervals. When the engine is new, for example directly after purchasing the vehicle or after ●...
Page 450 ● used oil and filters in household trash, in sewers or onto the ground. Call your Lexus dealer, service station or auto parts store for information concerning recycling or disposal. Do not leave used engine oil within the reach of children.
Page 451 Visually check the radiator, hoses, engine coolant reservoir cap, power control unit cool- ant reservoir cap, drain cock and water pump. If you cannot find a leak, have your Lexus dealer test the cap and check for leaks in the cooling system.
Page 452 Check the radiator and condenser and clear away any foreign objects. If either of the above parts is extremely dirty or you are not sure of their condi- tion, have your vehicle inspected by your Lexus dealer. WARNING When the hybrid system is hot ■...
Page 453 7-3. Do-it-yourself maintenance Brake fluid Checking fluid level ■ The brake fluid level should be between the “MAX” and “MIN” lines on the tank. Adding fluid ■ Make sure to check the fluid type and prepare the necessary item. Fluid type FMVSS No.116 DOT 3 or SAE J1703 brake fluid Items Clean funnel...
Page 454 7-3. Do-it-yourself maintenance Washer fluid If any washer does not work or the warning message appears on the multi- information display, the washer tank may be empty. Add washer fluid. WARNING When adding washer fluid ■ Do not add washer fluid when the hybrid system is hot or operating as washer fluid contains alcohol and may catch fire if spilled on the engine etc.
Page 455: 12-Volt Battery
7-3. Do-it-yourself maintenance 12-volt battery Location The 12-volt battery is located on the right-hand side of trunk. Removing the 12-volt battery cover Remove the 12-volt battery cover. Installing the 12-volt battery cover Install the cover Lift the tab to secure to the trunk liner ES300h_OM_OM33B71U_(U)
Page 456 Make sure to turn off the power switch before disconnect the 12- volt battery. Take extra care when connecting the 12-volt battery if the power switch mode prior to discharge is unknown. If the system will not start even after multiple attempts at all methods above, contact your Lexus dealer. ES300h_OM_OM33B71U_(U)
Page 457 When replacing the 12-volt battery ■ Use a 12-volt battery designed for this vehicle. Failure to do so may cause gas (hydro- gen) to enter the passenger compartment, causing a fire or explosion. For replacement of the 12-volt battery, contact your Lexus dealer. ES300h_OM_OM33B71U_(U)
Page 458 7-3. Do-it-yourself maintenance NOTICE When recharging the 12-volt battery ■ Never recharge the 12-volt battery while the hybrid system is operating. Also, be sure all accessories are turned off. ES300h_OM_OM33B71U_(U)
Page 459: Tires
Tire rotation Rotate the tires in the order shown. To equalize tire wear and extend tire life, Lexus recommends that tire rotation is carried out at the same interval as tire inspection. Do not fail to initialize the tire pressure Front warning system after tire rotation.
Page 460 Have tire pressure warning valve and transmitter ID codes registered by your Lexus dealer. (P. 461) ◆ Initializing the tire pressure warning system The tire pressure warning system must be initialized in the following circum- ■...
Page 461 The tire pressure warning valve and transmitter is equipped with a unique ID code. When replacing a tire pressure warning valve and transmitter, it is nec- essary to register the ID code. Have the ID code registered by your Lexus dealer.
Page 462 A tire goes flat repeatedly or cannot be properly repaired due to the size or location of ● a cut or other damage If you are not sure, consult with your Lexus dealer. Replacing tires and wheels ■ If the ID code of the tire pressure warning valve and transmitter is not registered, the tire pressure warning system will not work properly.
Page 463 In the following cases, the tire pressure warning system may not operate properly. ● • If non-genuine Lexus wheels are used. • A tire has been replaced with a tire that is not an OE (Original Equipment) tire. • A tire has been replaced with a tire that is not of the specified size.
Page 464 If repeated attempts to record tire inflation pressure settings are unsuccessful, have the vehicle inspected by your Lexus dealer. When operating the tire pressure warning reset switch, the tire pressure warning light ●...
Page 465 7-3. Do-it-yourself maintenance For vehicles sold in Canada  Transmitter ● NOTE: Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interfer- ence that may cause undesired operation of the device. Initiator ●...
Page 466 Make sure to install four tires that are of the specified size, and that all four tires are of ● the same size, same brand, and same tread pattern. Do not use tire sizes other than those recommended by Lexus. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
Page 467 When a tire is repaired with liquid sealants, the tire pressure warning valve and trans- mitter may not operate properly. If a liquid sealant is used, contact your Lexus dealer or other qualified service shop as soon as possible. After use of liquid sealant, make sure to replace the tire pressure warning valve and transmitter when repairing or replacing the tire.
Page 468: Tire Inflation Pressure
7-3. Do-it-yourself maintenance Tire inflation pressure Tire inflation pressure The recommended cold tire inflation pressure and tire size are displayed on the tire and loading information label. (P. 541) ES300h_OM_OM33B71U_(U)
Page 469 Reduced fuel economy ● Reduced driving comfort and poor handling ● Reduced tire life due to wear ● Reduced safety ● Damage to the drive train ● If a tire needs frequent inflating, have it checked by your Lexus dealer. ES300h_OM_OM33B71U_(U)
Page 470 7-3. Do-it-yourself maintenance Instructions for checking tire inflation pressure ■ When checking tire inflation pressure, observe the following: Check only when the tires are cold. ● If your vehicle has been parked for at least 3 hours or has not been driven for more than 1 mile or 1.5 km, you will get an accurate cold tire inflation pressure reading.
Page 471: Wheels
● Bent wheels that have been straightened ● Aluminum wheel precautions Use only Lexus wheel nuts and wrenches designed for use with your alumi- ● num wheels. When rotating, repairing or changing your tires, check that the wheel nuts are ●...
Page 472 Because tire repair or replacement may affect the tire pressure warning valves and ● transmitters, make sure to have tires serviced by your Lexus dealer or other qualified service shop. In addition, make sure to purchase your tire pressure warning valves and transmitters at your Lexus dealer.
Page 473: Air Conditioning Filter
7-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be changed regularly to maintain air condi- tioning efficiency. Removal method Turn the power switch off. Open the glove box. Lift and remove the partition. Remove the glove box cover. Remove the filter cover.
Page 474 7-3. Do-it-yourself maintenance Slide and pull out the filter. Replace it with a new one. The “UP” marks shown on the filter should be pointing up. Changing interval ■ Inspect and replace the air conditioning filter according to the maintenance schedule. In dusty areas or areas with heavy traffic flow, early replacement may be required.
Page 475: Electronic Key Battery
7-3. Do-it-yourself maintenance Electronic key battery Replace the battery with a new one if it is depleted. You will need the following items: Flathead screwdriver ● Small flathead screwdriver ● Lithium battery CR2032 ● Replacing the battery Take out the mechanical key. Remove the cover.
Page 476 7-3. Do-it-yourself maintenance Use a CR2032 lithium battery ■ Batteries can be purchased at your Lexus dealer, local electrical appliance shops or ● camera stores. Replace only with the same or equivalent type recommended by the manufacturer. ● Dispose of used batteries according to local laws.
Page 477: Checking And Replacing Fuses
7-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as necessary. Turn the power switch off. Open the Fuse box cover. Engine compartment (right side) Engine compartment (left side) ...
Page 478 Type A and B: Replace the blown fuse with a new fuse of an appropriate amperage rating. The amperage rating can be found on the fuse box lid. Type C: Contact your Lexus dealer. Type A Type B  ...
Page 479 If the lights do not turn on even after the fuse has been replaced, a bulb may need ● replacement. (P. 480) If the replaced fuse blows again, have the vehicle inspected by your Lexus dealer. ● If there is an overload in a circuit ■...
Page 480: Light Bulbs
You may replace the following bulbs by yourself. The difficulty level of replace- ment varies depending on the bulb. If necessary bulb replacement seems diffi- cult to perform, contact your Lexus dealer. For more information about replacing other light bulbs, contact your Lexus dealer. Preparing for light bulb replacement Check the wattage of the light bulb to be replaced.
Page 481 7-3. Do-it-yourself maintenance Rear ■ Back-up light Rear turn signal light ES300h_OM_OM33B71U_(U)
Page 482 7-3. Do-it-yourself maintenance Replacing light bulbs Headlight high beam (halogen bulb) ■ Turn the cover counterclockwise and remove it. Unplug the connector while pull- ing the lock release. Turn the bulb base counterclock- wise. ES300h_OM_OM33B71U_(U)
Page 483 7-3. Do-it-yourself maintenance Set the new light bulb. Align the 3 tabs on the light bulb with the mounting, and insert. Turn it clockwise to set. Set the connector. Shake the bulb base gently to check that it is not loose, turn the headlight high beams on once and visually confirm that no light is leaking through the mounting.
Page 484 7-3. Do-it-yourself maintenance Front turn signal lights ■ To allow enough working space, turn the steering wheel to the opposite side of the bulb to be replaced. Remove the 3 fender liner clips and 1 screw. Turn the steering wheel to the left when replacing the right side light bulb, and turn the steering wheel to the right when replacing the...
Page 485 7-3. Do-it-yourself maintenance Turn the bulb base counterclock- wise. Remove the light bulb. When installing, reverse the steps listed. After installing the bulb base, reinstall the fender liner and install the clips and screw. ES300h_OM_OM33B71U_(U)
Page 486 7-3. Do-it-yourself maintenance Front side marker lights ■ Partly remove the fender liner. Perform the procedure for “Front turn signal lights” from step 1 to 2. (P. 484) Turn the bulb base counterclock- wise. Remove the light bulb. When installing, reverse the steps listed.
Page 487 7-3. Do-it-yourself maintenance Rear turn signal lights ■ Open the trunk lid and remove the cover. Turn the bulb base counterclock- wise. Remove the light bulb. When installing, reverse the steps listed. ES300h_OM_OM33B71U_(U)
Page 488 7-3. Do-it-yourself maintenance Back-up lights ■ Open the trunk lid. For the left side (vehicles with power trunk opener and closer only): Pry out each side of the trunk closer switch in turn by inserting a screwdriver into the base. To prevent damage, cover the tip of the screwdriver with a rag.
Page 489 7-3. Do-it-yourself maintenance Replacing the following bulbs ■ If any of the lights listed below has burnt out, have it replaced by your Lexus dealer. Headlight low beams ● Headlight high beams (LED type) ● Parking lights/daytime running lights ●...
Page 490 7-3. Do-it-yourself maintenance WARNING Replacing light bulbs ■ Turn off the lights. Do not attempt to replace the bulb immediately after turning off the ● lights. The bulbs become very hot and may cause burns. Do not touch the glass portion of the light bulb with bare hands. When it is unavoid- ●...
Page 491: When Trouble Arises
When trouble arises 8-1. Essential information Emergency flashers ....492 If your vehicle has to be stopped in an emergency..493 8-2. Steps to take in an emergency If your vehicle needs to be towed........ 494 If you think something is wrong....498 If a warning light turns on or a warning buzzer sounds..499 If a warning message...
Page 492: Emergency Flashers
8-1. Essential information Emergency flashers The emergency flashers are used to warn other drivers when the vehicle has to be stopped in the road due to a breakdown, etc. Press the switch. All the turn signal lights will flash. To turn them off, press the switch once again.
Page 493: If Your Vehicle Has To Be Stopped In An Emergency
8-1. Essential information If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the following procedure: Steadily step on the brake pedal with both feet and firmly depress it. Do not pump the brake pedal repeatedly as this will increase the effort required to slow the vehicle.
Page 494: 8-2. Steps To Take In An Emergency
If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Lexus dealer or commercial towing service, using a wheel-lift type truck or flat bed truck. Use a safety chain system for all towing, and abide by all state/provincial and local laws.
Page 495 8-2. Steps to take in an emergency Using a flat bed truck If your vehicle is transported by a flat bed truck, it should be tied down at the locations shown in the illustration. If you use chains or cables to tie down your vehicle, the angles shaded in black must be 45.
Page 496 8-2. Steps to take in an emergency Emergency towing procedure Take out the towing eyelet. (P. 509) Remove the eyelet cover using a flat- head screwdriver. To protect the bodywork, place a rag between the screwdriver and the vehi- cle body as shown in the illustration. Insert the towing eyelet into the hole and tighten partially by hand.
Page 497 8-2. Steps to take in an emergency While towing ■ If the hybrid system is off, the power assist for the brakes and steering will not function, making steering and braking more difficult. Wheel nut wrench ■ Wheel nut wrench is installed in trunk. (P. 509) WARNING Observe the following precautions.
Page 498: If You Think Something Is Wrong
8-2. Steps to take in an emergency If you think something is wrong If you notice any of the following symptoms, your vehicle probably needs adjustment or repair. Contact your Lexus dealer as soon as possible. Visible symptoms Fluid leaks under the vehicle.
Page 499: If A Warning Light Turns On Or A Warning Buzzer Sounds
(U.S.A.) • The brake system is malfunctioning  Immediately stop the vehicle in a safe place and contact your Lexus dealer. Continuing to drive the vehicle may be dangerous. (Canada) Brake system warning light (yellow indicator) Indicates a malfunction in: •...
Page 500 Warning light/Details/Actions Electric power steering system warning light (warning buzzer) Indicates a malfunction in the EPS (Electric Power Steering) sys-  Have the vehicle inspected by your Lexus dealer immediately. PCS warning light Indicates a malfunction in the pre-collision system...
Page 501 “AFS OFF” indicator Indicates a malfunction in the adaptive front-lighting system (Flashes)  Have the vehicle inspected by your Lexus dealer immediately. (If equipped) : Driver’ s and front passenger’ s seat belt warning buzzer: The driver’ s seat belt warning buzzer sounds to alert the driver that his or her seat belt is not fastened.
Page 502 If it is, tighten it securely. The light will go off after several driving trips. If the light does not go off even after several trips, contact your Lexus dealer as soon as possible. When the tire pressure warning light comes on ■...
Page 503 If both the ABS and the brake system warning lights remain on ■ Stop your vehicle in a safe place immediately and contact your Lexus dealer. The vehi- cle will become extremely unstable during braking, and the ABS system may fail, which could cause an accident resulting in death or serious injury.
Page 504 8-2. Steps to take in an emergency WARNING Maintenance of the tires ■ Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label (tire and load information label). (If your vehicle has tires of a different size than the size indicated on the vehicle placard or tire inflation pressure label [tire and load information label], you should determine the proper tire inflation pressure for those tires.)
Page 505: If A Warning Message Is Displayed
Messages and warnings The warning lights and warning buzzers operate as follows depending on the content of the message. If a message indicates the need for inspection by a dealer, have the vehicle inspected by your Lexus dealer immediately. System warning...
Page 506 The filter may be clogged, the air intake vent may be blocked or there may be a gap in duct. Have maintenance performed on the hybrid battery (traction battery) cooling component at your Lexus dealer. If “Hybrid Battery Low Shift Out of N to Recharge” is shown ■...
Page 507 Indicates that the engine oil should be changed. (After the engine oil is changed and the oil maintenance data has been reset.) Check and change the engine oil, and oil filter by your Lexus dealer. After changing the engine oil, the oil change system should be reset. (P. 449) If “Power Turned Off to Save Battery”...
Page 508: If You Have A Flat Tire
8-2. Steps to take in an emergency If you have a flat tire Your vehicle is equipped with a spare tire. The flat tire can be replaced with the spare tire. For details about tires: P. 459 WARNING If you have a flat tire ■...
Page 509 8-2. Steps to take in an emergency Location of the spare tire, jack and tools Jack handle Wheel nut wrench Towing eyelet Spare tire Jack Screwdriver ES300h_OM_OM33B71U_(U)
Page 510 8-2. Steps to take in an emergency WARNING Using the tire jack ■ Observe the following precautions. Improper use of the tire jack may cause the vehicle to suddenly fall off the jack, leading to death or serious injury. Do not use the tire jack for any purpose other than replacing tires or installing and ●...
Page 511 8-2. Steps to take in an emergency Taking out the spare tire Open the luggage mat. (P. 404) Remove the auxiliary boxes. Loosen the center fastener that secures the spare tire. WARNING When storing the spare tire ■ Be careful not to catch fingers or other body parts between the spare tire and the body of the vehicle.
Page 512 8-2. Steps to take in an emergency Replacing a flat tire Chock the tires. Flat tire Wheel chock positions Left-hand side Behind the rear right-hand side tire Front Right-hand side Behind the rear left-hand side tire Left-hand side In front of the front right-hand side tire Rear Right-hand side In front of the front left-hand side tire...
Page 513 8-2. Steps to take in an emergency Raise the vehicle until the tire is slightly raised off the ground. Remove all the wheel nuts and the tire. When resting the tire on the ground, place the tire so that the wheel design faces up to avoid scratching the wheel surface.
Page 514 • When installing a tire, only use wheel nuts that have been specifically designed for that wheel. • If there are any cracks or deformations in the bolt screws, nut threads or bolt holes of the wheel, have the vehicle inspected by your Lexus dealer. ES300h_OM_OM33B71U_(U)
Page 515 8-2. Steps to take in an emergency Installing the spare tire Remove any dirt or foreign matter from the wheel contact surface. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, causing the tire to come off.
Page 516 8-2. Steps to take in an emergency The compact spare tire ■ The compact spare tire is identified by the label “TEMPORARY USE ONLY” on the ● tire sidewall. Use the compact spare tire temporarily, and only in an emergency. Make sure to check the tire inflation pressure of the compact spare tire.
Page 517 When replacing the tires ■ When removing or fitting the wheels, tires or the tire pressure warning valve and trans- mitter, contact your Lexus dealer as the tire pressure warning valve and transmitter may be damaged if not handled correctly. ES300h_OM_OM33B71U_(U)
Page 518: If The Hybrid System Will Not Start
The 12-volt battery may be discharged. (P. 523) ● One or both of the 12-volt battery terminals may be disconnected. (P. 455) ● Contact your Lexus dealer if the problem cannot be repaired, or if repair procedures are unknown. ES300h_OM_OM33B71U_(U)
Page 519 Press and hold the power switch for about 15 seconds while depressing the brake pedal firmly. Even if the hybrid system can be started using the above steps, the system may be malfunctioning. Have the vehicle inspected by your Lexus dealer. ES300h_OM_OM33B71U_(U)
Page 520: If The Shift Lever Cannot Be Shifted From P
If the shift lever cannot be shifted with your foot on the brake pedal, there may be a problem with the shift lock system (a system to prevent accidental opera- tion of the shift lever). Have the vehicle inspected by your Lexus dealer imme- diately.
Page 521: If The Electronic Key Does Not Operate Properly
Turning the key once again within 5 seconds unlocks the other doors. Opens the windows and moon roof (turn and hold) : This setting must be customized at your Lexus dealer. Trunk ■ Turn the mechanical key clockwise to open.
Page 522 Firmly depress the brake pedal and check that is shown on the multi- information display. Press the power switch. In the event that the hybrid system still cannot be started, contact your Lexus dealer. Stopping the hybrid system ■ Shift the shift lever to P and press the power switch as you normally do when stopping the hybrid system.
Page 523: If The 12-Volt Battery Is Discharged
The following procedures may be used to start the hybrid system if the 12-volt battery is discharged. You can also call your Lexus dealer or a qualified repair shop. If you have a set of jumper (or booster) cables and a second vehicle with a 12-volt battery, you can jump start your vehicle by following the steps below.
Page 524 Lexus dealer. Once the hybrid system has started, remove the jumper cables in the exact reverse order from which they were connected. Once the hybrid system starts, have the vehicle inspected at your Lexus dealer as soon as possible. ES300h_OM_OM33B71U_(U)
Page 525 8-2. Steps to take in an emergency Starting the hybrid system when the 12-volt battery is discharged ■ The hybrid system cannot be started by push-starting. To prevent 12-volt battery discharge ■ Turn off the headlights and the audio system while the hybrid system is stopped. ●...
Page 526 After recharging the 12-volt battery ■ Have the 12-volt battery inspected at your Lexus dealer as soon as possible. If the 12-volt battery is deteriorating, continued use may cause the 12-volt battery to emit a malodorous gas, which may be detrimental to the health of passengers.
Page 527: If Your Vehicle Overheats
Radiator Cooling fans If a large amount of coolant leaks, immediately contact your Lexus dealer. The coolant level is satisfactory if it is between the “FULL” and “LOW” line on the reservoir. Reservoir “FULL”...
Page 528 If it is difficult to check these, turn the air conditioning system on and off repeatedly. (The fans may not operate in freezing temperatures.) If the fans are not operating: Stop the hybrid system immediately and contact your Lexus dealer. If the fans are operating: Have the vehicle inspected at the nearest Lexus dealer.
Page 529 Start the hybrid system and check for the multi-information display. If the message does not disappear: Stop the hybrid system and contact your Lexus dealer. If the message is not displayed: Have the vehicle inspected at the nearest Lexus dealer.
Page 530 8-2. Steps to take in an emergency WARNING When inspecting under the hood of your vehicle ■ Observe the following precautions. Failure to do so may result in serious injury such as burns. If steam is seen coming from under the hood, do not open the hood until the steam ●...
Page 531: If The Vehicle Becomes Stuck
8-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt or snow: Stop the hybrid system. Set the parking brake and shift the shift lever to P. Remove the mud, snow or sand from around the front wheels.
Page 532 8-2. Steps to take in an emergency NOTICE To avoid damaging the transmission and other components ■ Avoid spinning the front wheels and depressing the accelerator pedal more than nec- ● essary. If the vehicle remains stuck even after these procedures are performed, the vehicle ●...
Page 533: Vehicle Specifications
Vehicle specifications 9-1. Specifications Maintenance data (fuel, oil level, etc.)....534 Fuel information......543 Tire information......546 9-2. Customization Customizable features ....555 9-3. Initialization Items to initialize......566 ES300h_OM_OM33B71U_(U)
Page 534: 9-1. Specifications
9-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions and weight Overall length 193.3 in. (4910 mm) Overall width 71.7 in. (1820 mm) Overall height 57.1 in. (1450 mm) Wheelbase 111.0 in. (2820 mm) Front 62.6 in. (1590 mm) Tread Rear 62.0 in.
Page 535 ■ The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Lexus. It is used in register- ing the ownership of your vehicle. This number is stamped on the top left of the instrument panel.
Page 536 9-1. Specifications Engine number ■ The engine number is stamped on the engine block as shown. Engine Model 2.5L 4-cylinder (2AR-FXE) Type 4-cylinder in line, 4-cycle, gasoline 3.54  3.86 in. (90.0  98.0 mm) Bore and stroke Displacement 152.2 cu.in. (2494 cm Valve clearance Automatic adjustment Fuel...
Page 537: Lubrication System
9-1. Specifications Hybrid battery (Traction battery) Type Nickel-metal hydride battery Voltage 7.2 V/module Capacity 6.5 Ah (3HR) Quantity 34 modules Overall voltage 244.8 V Lubrication system Oil capacity (Drain and refill  reference With filter 4.6 qt. (4.4 L, 3. 9 Imp.qt.) Without filter 4.2 qt.
Page 538 9-1. Specifications Engine oil selection ■ “Toyota Genuine Motor Oil” is used in your Lexus vehicle. Use Lexus approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Oil grade: ILSAC GF-5 multigrade engine oil Recommended viscosity: SAE 0W-20...
Page 539: Electrical System
9-1. Specifications Cooling system Gasoline 7.6 qt. (7.2 L, 6.3 Imp.qt.) engine Capacity Power 3.4 qt. (3.2 L, 2.8 Imp.qt.) control unit Use either of the following: • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol-based non-sili- Coolant type cate, non-amine, non-nitrite, and non-borate cool- ant with long-life hybrid organic acid technology Do not use plain water alone.
Page 540 3. 9 qt. (3.7 L, 3.3 Imp.qt.) Fluid type Toyota Genuine ATF WS : The fluid capacity is a reference quantity. If replacement is necessary, contact your Lexus dealer. NOTICE Transmission fluid type ■ Using transmission fluid other than “Toyota Genuine ATF WS” may cause deterioration in shift quality, locking up of your transmission accompanied by vibration, and ulti- mately damage the transmission of your vehicle.
Page 541 9-1. Specifications Tires and wheels Standard tire  Tire size P215/55R17 93V Front tire Tire inflation pressure 33 psi (230 kPa, 2.3 kgf/cm or bar) (Recommended cold tire 36 psi (250 kPa, 2.5 kgf/cm or bar) inflation pressure) Rear tire 33 psi (230 kPa, 2.3 kgf/cm or bar) 17 ...
Page 542 9-1. Specifications Light bulbs Light Bulbs Bulb No. Type Headlights high beam  (halogen bulbs) Front turn signal lights 7444NA 28/8 Front side marker lights Exterior Rear turn signal lights WY21W Back-up lights W16W Outer foot lights  Door courtesy lights ...
Page 543: Fuel Information
Recommendation of the use of gasoline containing detergent additives ■ Lexus recommends the use of gasoline that contains detergent additives to avoid the ● build-up of engine deposits. All gasoline sold in the U.S.A. contains minimum detergent additives to clean and/or ●...
Page 544 Some gasoline contains an octane enhancing additive called MMT (Methylcyclopenta- dienyl Manganese Tricarbonyl). Lexus does not recommend the use of gasoline that contains MMT. If fuel containing MMT is used, your emission control system may be adversely affected. The malfunction indicator lamp on the instrument cluster may come on. If this happens, contact your Lexus dealer for service.
Page 545 9-1. Specifications NOTICE Notice on fuel quality ■ Do not use improper fuels. If improper fuels are used, the engine will be damaged. ● Do not use leaded gasoline. ● Leaded gasoline can cause damage to your vehicle’ s three-way catalytic converters causing the emission control system to malfunction.
Page 546: Tire Information
9-1. Specifications Tire information Typical tire symbols Full-size tire  Compact spare tire  ES300h_OM_OM33B71U_(U)
Page 547 9-1. Specifications Tire size (P. 548) DOT and Tire Identification Number (TIN) (P. 547) Location of treadwear indicators (P. 459) Tire ply composition and materials Plies are layers of rubber-coated parallel cords. Cords are the strands which form the plies in a tire. Radial tires or bias-ply tires A radial tire has “RADIAL”...
Page 548 9-1. Specifications Tire size Typical tire size information ■ The illustration indicates typical tire size. Tire use (P = Passenger car, T = Temporary use) Section width (millimeters) Aspect ratio (tire height to section width) Tire construction code (R = Radial, D = Diagonal) Wheel diameter (inches) Load index (2 digits or 3 digits) Speed symbol (alphabet with one letter)
Page 549: Uniform Tire Quality Grading
National Highway Traffic Safety Administration of the U.S. Department of Trans- portation. It provides the purchasers and/or prospective purchasers of Lexus vehicles with information on uniform tire quality grading. Your Lexus dealer will help answer any questions you may have as you read this infor- mation. DOT quality grades ■...
Page 550 9-1. Specifications Traction AA, A, B, C ■ The traction grades, from highest to lowest, are AA, A, B and C, and they rep- resent the tire’ s ability to stop on wet pavement as measured under controlled conditions on specified government test surfaces of asphalt and concrete. A tire marked C may have poor traction performance.
Page 551 9-1. Specifications Glossary of tire terminology Tire related term Meaning Tire pressure when the vehicle has been parked for Cold tire inflation pressure three hours or more, or has not been driven more than 1 mile or 1.5 km under that condition Maximum inflation pres- The maximum cold inflated pressure to which a tire may sure...
Page 552 9-1. Specifications Tire related term Meaning Rim width Nominal distance between rim flanges Vehicle capacity weight The rated cargo and luggage load plus 150 lb. (68 kg) (Total load capacity) times the vehicle’ s designated seating capacity The load on an individual tire that is determined by dis- Vehicle maximum load on tributing to each axle its share of the maximum loaded the tire...
Page 553 9-1. Specifications Tire related term Meaning The parting of the innerliner from cord material in the Innerliner separation carcass (a) The sidewall that contains a whitewall, bears white lettering, or bears manufacturer, brand, and/or model name molding that is higher or deeper than the same molding on the other sidewall of the tire, Intended outboard sidewall (b) The outward facing sidewall of an asymmetrical tire...
Page 554 9-1. Specifications Tire related term Meaning A tire designed to operate at higher loads and at higher Reinforced tire inflation pressures than the corresponding standard tire The linear distance between the exteriors of the side- Section width walls of an inflated tire, excluding elevations due to labeling, decoration, or protective bands Sidewall That portion of a tire between the tread and bead...
Page 555: Customization
Your vehicle includes a variety of electronic features that can be personalized to your preferences. These preferences can be changed by using the meter control switches, by using Remote Touch, Lexus Display Audio controller, or at your Lexus dealer. Customizing vehicle features Changing by using the Remote Touch or Lexus Display Audio controller ■...
Page 556 Some function settings are changed simultaneously with other functions being customized. Contact your Lexus dealer for further details. Settings that can be changed using the Remote Touch or Lexus Display Audio controller Settings that can be changed using the meter control switches Settings that can be changed by your Lexus dealer Definition of symbols: O = Available, —...
Page 557 9-2. Customization Multi-information display (P. 91) ■ Default Customized Function setting setting French Language English – – Spanish miles (MPG Imperial) Units miles (MPG US) – – km (L/100 km) km (km/L) EV indicator – – Drive Desired status switch settings –...
Page 558 9-2. Customization : The default setting varies according to countries. : Some status screens cannot be registered (indicated on the multi-information display) : 2 of the following items: current fuel consumption, average fuel economy (after reset), average fuel economy (after refuel), average fuel economy (after start), average vehi- cle speed (after reset), average vehicle speed (after start), distance (driving range), distance (after start), elapsed time (after reset), elapsed time (after start), blank LDA (Lane Departure Alert with steering control) (if equipped) (P.
Page 559 9-2. Customization Door lock (P. 108, 521) ■ Customized Function Default setting setting On (Driver’ s Allows all doors to be door unlocked in Off (All doors unlocked by turning the one step, all unlocked in one — — mechanical key twice in the doors unlocked step) driver’...
Page 560 9-2. Customization Smart access system with push-button start and wireless remote control ■ (P. 108) Customized Function Default setting setting Adjust the volume of buzzer — sounds 1 to 7 Enable/disable the operation of the emergency flashers — when the vehicle is locked or unlocked Adjust the time elapsed before the automatic door...
Page 561 9-2. Customization Wireless remote control (P. 108) ■ Customized Function Default setting setting Wireless remote control — — On (Driver’ s Allows all doors to be door unlocked in Off (All doors unlocked by pressing one step, all unlocked in one —...
Page 562 9-2. Customization Power windows (P. 145) ■ Customized Function Default setting setting One-touch closing — — Moon roof (P. 148) ■ Customized Function Default setting setting Linked operation of compo- Slide only Tilt only — — nents when door key is used Linked operation of compo- nents when wireless remote Slide only...
Page 563 9-2. Customization Automatic light control system (P. 178) ■ Customized Function Default setting setting Adjust the sensitivity of the -2 to 2 — ambient light sensor Adjust the time elapsed before the headlights 30 seconds 60 seconds — automatically turn off 90 seconds Welcome light illumination —...
Page 564 9-2. Customization Illumination (P. 396) ■ Customized Function Default setting setting Interior lights illumination — — control Time elapsed before the inte- 15 seconds 7.5 seconds — rior lights turn off 30 seconds Operation after the power — — switch is turned off Operation when the doors —...
Page 565 (emergency flashers) settings. When customizing using Remote Touch or Lexus Display Audio controller ■ Stop the vehicle in a safe place, apply the parking brake, and shift the shift lever to P. Also, to prevent 12-volt battery discharge, leave the hybrid system operating while customiz- ing the features.
Page 566: 9-3. Initialization
9-3. Initialization Items to initialize The following items must be initialized for normal system operation after such cases as the 12-volt battery being reconnected, or maintenance being per- formed on the vehicle: Item When to initialize Reference Message indicating mainte- •...
Page 567: For Owners
For owners Reporting safety defects for U.S. owners........568 Seat belt instructions for Canadian owners (in French) ..........569 SRS airbag instructions for Canadian owners (in French) ..........570 ES300h_OM_OM33B71U_(U)
Page 568: Reporting Safety Defects For U.s. Owners
However, NHTSA cannot become involved in individual problems between you, your dealer, or Lexus Division of Toyota Motor Sales, U.S.A., Inc.
Page 569: Seat Belt Instructions For Canadian Owners (In French)
Seat belt instructions for Canadian owners (in French) The following is a French explanation of seat belt instructions extracted from the seat belt section in this manual. See the seat belt section for more detailed seat belt instructions in English. Utilisation adéquate des ceintures de sécurité...
Page 570: Srs Airbag Instructions For Canadian Owners (In French)
SRS airbag instructions for Canadian owners (in French) The following is a French explanation of SRS airbag instructions extracted from the SRS airbag section in this manual. See the SRS airbag section for more detailed SRS airbag instructions in English. ◆...
Page 571 ◆ Coussins gonflables SRS latéraux et en rideau Coussins gonflables SRS latéraux avant Peuvent aider à protéger le torse des occupants des sièges avant Coussins gonflables SRS latéraux arrière Peuvent aider à protéger le torse des occupants des sièges latéraux arrière Coussins gonflables SRS en rideau Peuvent aider à...
Page 572 Composants du système de coussins gonflables SRS Système de classification de l’occu- Coussins gonflables latéraux avant pant du siège du passager avant Lampe témoin SRS (ECU et capteurs) Coussin gonflable du conducteur Capteurs de choc latéral (portiè- Coussins gonflables latéraux res avant) arrière Coussins gonflables de protection...
Page 573 Votre véhicule est doté de COUSSINS GONFLABLES ÉVOLUÉS dont la con- ception s’appuie sur les normes de sécurité des véhicules à moteur américains (FMVSS208). Le module de capteur de coussin gonflable (ECU) contrôle le déploiement des coussins gonflables en fonction des informations obtenues des capteurs et d’autres éléments affichés dans le diagramme des composants du système ci-dessus.
Page 574 être correctement retenu à l’aide d’un dispositif de retenue pour enfants. Lexus recommande vivement de placer et d’attacher correctement tous les bébés et tous les enfants sur les sièges arrière du véhicule à...
Page 575 AVERTISSEMENT Précautions relatives aux coussins gonflables SRS ■ Ne vous appuyez pas sur la portière ou sur le ● brancard de pavillon, ni sur les montants avant, latéraux ou arrière. Ne laissez personne s’agenouiller face à la ● portière sur les sièges des passagers ni sortir la tête ou les mains à...
Page 576 ■ Ne mettez pas votre véhicule au rebut et n’effectuez aucune des modifications suivan- tes sans d’abord consulter votre concessionnaire Lexus. Les coussins gonflables SRS pourraient fonctionner de manière incorrecte ou se déployer (gonfler) accidentelle- ment, ce qui serait susceptible d’occasionner des blessures graves, voire mortelles.
Page 577: Index
What to do if... (Troubleshooting)........ 578 Alphabetical index.........582 For vehicles with navigation system, refer to the “NAVIGATION SYSTEM OWNER’S MANUAL” for information regarding the equipment listed below. • Navigation system • Lexus parking assist monitor • Audio/video system • Lexus Enform ES300h_OM_OM33B71U_(U)
Page 578 What to do if... (Troubleshooting) What to do if... (Troubleshooting) If you have a problem, check the following before contacting your Lexus dealer. The doors cannot be locked, unlocked, opened or closed You lose your keys If you lose your mechanical keys, new genuine mechanical keys can be made ●...
Page 579 What to do if... (Troubleshooting) If you think something is wrong The hybrid system does not start Did you press the power switch while firmly depressing the brake pedal? ● (P. 166) Is the shift lever in P? (P. 168) ●...
Page 580 What to do if... (Troubleshooting) The power switch is turned off automatically The auto power off function will be operated if the vehicle is left in ACCES- ● SORY or ON mode (the hybrid system is not operating) for a period of time. (P.
Page 581 What to do if... (Troubleshooting) When a problem has occurred If you have a flat tire Stop the vehicle in a safe place and replace the flat tire with the spare tire. ● (P. 508) The vehicle becomes stuck Try the procedure for when the vehicle becomes stuck in mud, dirt, or snow. ●...
Page 582: Alphabetical Index
Alphabetical index Alphabetical index Airbags Airbag operating conditions ..43 Air conditioning filter......473 Airbag precautions Automatic air conditioning for your child ........39 system ..........384 Airbag warning light ......499 Humidity sensor .........393 Correct driving posture....30 Micro dust and pollen Curtain shield airbag filter ............
Page 583 Alphabetical index Audio system ........286 Audio input..........294 Back-up lights AUX port..........294 Replacing light bulbs ...... 488 ® Bluetooth audio ......343 Wattage ..........542 CD player..........319 Battery (12-volt battery) ....455 iPod............326 If the 12-volt battery MP3/WMA disc ........ 319 is discharged ........523 Optimal use .........
Page 584 Alphabetical index Power window lock switch.....145 Care Power window precautions... 147 Aluminum wheels ......429 Rear door child-protectors....111 Exterior............428 Removed electronic Interior ............431 key battery precautions ....476 Seat belts..........432 Seat belt extender Cargo capacity........163 precautions .......... 35 Cargo hooks ..........403 Seat belt precautions......56 CD player ..........319...
Page 585 Alphabetical index Driver’s seat position memory..130 Daytime running light system....179 Driving position memory....131 Defogger Memory recall function ....132 Front windshield ........388 Power easy access system.... 130 Outside rear view mirrors....388 Driving Rear window ........388 Break-in tips.......... 155 Dimension ..........534 Correct driving posture....30 Dinghy towing..........165 Driving mode select switch..
Page 586 Alphabetical index Emergency, in case of Engine If a warning buzzer Accessory mode .........167 sounds..........499 Compartment ........445 If a warning light turns on....499 Hood............443 If a warning message How to start the hybrid is displayed ........505 system............166 If the 12-volt battery is Identification number.......536 discharged.........523...
Page 587 Alphabetical index Enhanced VSC ........272 Front side marker lights Light switch..........178 (Electronic Power Steering) Replacing light bulbs .......486 Function ..........273 Wattage ..........542 Warning light ........500 Front turn signal lights Event data recorder (EDR)....11 Replacing light bulbs .......484 Turn signal lever........176 Wattage ..........
Page 588 Alphabetical index Hybrid system..........67 Hands-free system Emergency shut off system ....72 (for cellular phone) ......345 Energy monitor/consumption Head restraints........135 screen ............. 96 Headlights EV drive mode ........171 Light switch ..........178 High voltage components....71 Replacing light Hybrid System Indicator....88 bulbs.........482, 489 Hybrid system precautions ....
Page 589 Alphabetical index I/M test .............440 Jack Identification Positioning a floor jack....444 Engine............. 536 Vehicle-equipped jack....509 Vehicle ........... 535 Jack handle ..........509 Ignition switch (power switch) ..166 Jam protection function Illuminated entry system....398 Moon roof..........149 Immobilizer system........76 Power trunk opener Indicators ............
Page 590 Display settings ........302 Setup menu...........296 Lexus Enform Maintenance Lexus Enform Remote ....382 Do-it-yourself maintenance ...441 Lexus Enform Safety Connect..422 General maintenance..... 437 Lexus Safety System+......194 Maintenance data......534 License plate lights Maintenance requirements..434 Light switch ..........178 Malfunction indicator lamp....499 Replacing light bulbs.......
Page 591 Alphabetical index Mirrors Inside rear view mirror..... 140 Odometer..........86 Outside rear view mirror defoggers..........388 Engine oil ..........537 Outside rear view mirrors....142 Opener Vanity mirrors........405 Hood............443 Mobile Assistant ........380 Trunk............114 Moon roof Ornament lights ........396 Door lock linked Outer foot lights moon roof operation.....
Page 592 Alphabetical index Power trunk opener and closer..114 Parking assist sensors Power windows (intuitive parking assist) ....237 Door lock linked Parking brake window operation ......146 Operation..........177 Jam protection function....145 Parking brake engaged Operation..........145 warning buzzer .........177 Window lock switch ......145 Parking lights Pre-Collision System (PCS) Light switch ..........
Page 593 Alphabetical index Rear turn signal lights Replacing light bulbs......487 Safety Connect ........422 Turn signal lever ........176 Seat belts Wattage..........542 Adjusting the seat belt......32 Rear view mirror Automatic Locking Retractor ..33 Inside rear view mirror..... 140 Child restraint system Outside rear view mirrors....142 installation ..........60 Rear window defoggers ....388 Cleaning and maintaining...
Page 594 Humidity sensor .........393 Entry functions ........108 Inside rear view mirror....... 141 Starting the hybrid system....166 Intuitive parking assist......237 Snow tires..........283 Lexus Safety System+....... 196 Spare tire ..........508 Radar sensor......... 196 Inflation pressure........541 Rain-sensing windshield Storage location........ 509 wipers............188 Spark plug ..........
Page 595 Alphabetical index Steering lock ........... 168 Switches Column lock release......169 Audio remote control Steering wheel switches ........... 293 Adjustment..........138 BSM (Blind spot monitor) Audio switches .........293 switch ........... 264 Heated steering wheel....395 Cruise control switch ...... 234 Power easy access system ....130 Door lock switch........
Page 596 Alphabetical index Rear sunshade switch.....408 Rear window and outside Tachometer ..........86 rear view mirror defoggers Tail lights switch...........388 Light switch..........178 Seat heater switches......395 Replacing light bulbs .......489 Seat ventilator switches ....395 Talk switch ..........356 “SOS” button........422 Telephone switches ......
Page 597 Alphabetical index Tires Trunk Chains............281 Internal trunk release lever ....116 Checking..........459 Jam protection function..... 116 If you have a flat tire ......508 Luggage security system....115 Inflation pressure......... 541 Power trunk opener and closer..114 Information ........... 546 Smart access system Replacing ..........508 with push-button start......114...
Page 598 Alphabetical index Vanity lights Warning buzzers Vanity lights ......... 405 Approach warning ......229 Wattage..........542 Seat belt reminder......500 Vanity mirrors........... 405 Warning lights .......... 83 Vehicle data recordings......10 ABS ............499 Vehicle identification number..535 Brake system ........499 Vehicle Stability Control Electric power steering ....
Page 599 Alphabetical index Weight Cargo capacity........163 Load limits..........163 Weight.............534 Welcome light illumination control............. 109 Wheels Replacing wheels.........471 Size............. 541 Window glasses........145 Window lock switch ......145 Windows Power windows........145 Rear window defogger....388 Windshield wiper de-icer ....389 Windshield wipers Intermittent windshield wipers with interval adjuster ..186 Position............282 Rain-sensing windshield...
Page 600 GAS STATION INFORMATION Auxiliary catch lever Trunk opener Fuel filler door P. 443 P. 114 P. 192 Hood lock release lever Fuel filler door opener Tire inflation pressure P. 443 P. 192 P. 541 Fuel tank capacity 17.0 gal. (64.35 L, 14.2 Imp.gal.) (Reference) Fuel type Unleaded gasoline only...
