Page 1 Your Lexus dealer will provide quality maintenance and any other assistance you may require. If there is not a Lexus dealer near you, or you need emergency assistance for any reason, please call the following number: U.S.
Page 2 SRS airbag and seat belt pretensioner removed effect they may have on, your Lexus vehicle. and disposed of by a qualified service shop or by your Lexus dealer before you scrap your vehicle.
Page 3: Table Of Contents
The vehicle’s equipment is divided into the 7 groups listed Regular and periodic inspection and maintenance of your below. Use of the equipment is explained, including any points Lexus will help to keep your vehicle in its best condition. you should pay particular attention to. 1. Keys and doors SECTION 6 –...
Page 4 Lexus and its equipment. Your Lexus Owner ’s Manual provides you with a considerable amount of information. To use this information most effectively, please take the time to familiarize yourself with the contents and use of the manual.
Page 5 PICTORIAL INDEX INSTRUMENT PANEL PE038...
Page 6 PICTORIAL INDEX Page Page Automatic transmission selector lever ..Door lock switch and power window switches ....... . . 28, 42 Ashtray .
Page 7 PICTORIAL INDEX INSTRUMENT CLUSTER (Vehicles sold in U. S. A.) (Type A) PE022...
Page 8 PICTORIAL INDEX Page Page Vehicle skid control system off Engine coolant temperature gauge ... . indicator light ....... Tachometer .
Page 9 PICTORIAL INDEX INSTRUMENT CLUSTER (Vehicles sold in Canada) (Type A) PE023...
Page 10 PICTORIAL INDEX Page Page Vehicle skid control system off Engine coolant temperature gauge ... . indicator light ....... Tachometer .
Page 11 PICTORIAL INDEX INSTRUMENT CLUSTER (Vehicles sold in U. S. A.) (Type B) PE024...
Page 12 PICTORIAL INDEX Page Page Traction control system off Engine coolant temperature gauge ... . indicator/warning light ..... . . Tachometer .
Page 13 PICTORIAL INDEX INSTRUMENT CLUSTER (Vehicles sold in Canada) (Type B) PE025 xiii...
Page 14 PICTORIAL INDEX Page Page Traction control system off Engine coolant temperature gauge ... . indicator/warning light ..... . . Tachometer .
Page 15 PICTORIAL INDEX SEAT AND STEERING WHEEL Page Tilt steering adjustment lever ......Driving position memory switch .
Page 16 PICTORIAL INDEX EXTERIOR VIEW Page Rear window defogger ..Trunk lid ..... . Tire and wheel .
Page 17 PICTORIAL INDEX xvii...
Page 18 BASIC OPERATION QUICK REFERENCE Driver’s seat ........Steering wheel .
Page 19: Driver's Seat
BASIC OPERATION – QUICK REFERENCE 1. DRIVER’S SEAT 2. STEERING WHEEL D TILT STEERING WHEEL Seat position BE024 Seat cushion angle To tilt the steering wheel up or down to the desired angle: Seat cushion height 1. Pull the lever up while holding the steering wheel. 2.
Page 20: Automatic Transmission
BASIC OPERATION – QUICK REFERENCE 3. AUTOMATIC TRANSMISSION Overdrive switch Lock release button (To prevent misshifting) Parking, engine starting and key For selecting either a three–speed or removal position four–speed transmission Reverse position Neutral position “O/D OFF” indicator Normal driving (with overdrive on) light on the instrument position cluster...
Page 21: Headlight And Turn Signal Switch
BASIC OPERATION – QUICK REFERENCE 4. HEADLIGHT AND TURN SIGNAL High beam SWITCH BE005 D HEADLIGHT SWITCH Headlight flasher With the ignition OFF Parking, tail, license plate, D TURN SIGNAL SWITCH side marker and instrument BE004 panel lights turn on. Headlights also turn on.
Page 22: Wiper Switch
BASIC OPERATION – QUICK REFERENCE 5. WIPER SWITCH Washer on Intermittent operation Low speed operation BE007 High speed operation...
Page 23 BASIC OPERATION – QUICK REFERENCE...
Page 24: Keys
SECTION – INSTRUMENTS AND CONTROLS Keys and doors Keys ......... . Engine immobiliser system .
Page 25: Keys And Doors
If you should lose your keys or if you need additional Sub key (gray) – The sub key will not open the keys, duplicates can be made by a Lexus dealer using trunk, glove box and armrest door in the rear the key number.
Page 26 KEYS AND DOORS 11L003a Since a transponder chip is not built in this flat key, NOTICE you cannot start the engine with this key. Use this key to release the lock in case you accidentally lock D Do not let the key case become bent as the key your keys inside the vehicle or trunk.
Page 27 KEYS AND DOORS 11E021 When using a key containing a transponder chip, observe the following precautions: D When starting the engine, do not use the key with a key ring resting on the key grip and do not press the key ring against the key grip. Otherwise the engine may not start, or may stop soon after it starts.
Page 28 KEYS AND DOORS 11E022 D When starting the engine, do not use the key with other transponder keys around (including keys of other vehicles) and do not press other key plates against the key grip. Otherwise the engine may not start, or may stop soon after it starts.
Page 29: Engine Immobiliser System
KEYS AND DOORS 11E035 ENGINE IMMOBILISER SYSTEM D Do not bend the key grip. D Do not cover the key grip with any material that cuts off electromagnetic waves. D Do not knock the key hard against other objects. D Do not leave the key exposed to high temperatures for a long period, such as on the dashboard and hood under the direct sunlight.
Page 30 (2) this device must enables the engine to start. accept any interference received, including For your Lexus dealer to make you a new key with interference that may cause undesired built–in transponder chip, your dealer will need your key operation.
Page 31: Wireless Remote Control
KEYS AND DOORS CAUTION Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. For vehicles sold in Canada This device complies with RSS–210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) this device must accept any interference, including interference that may...
Page 32 1 meter (3 ft.) from your Lexus. If you lose the wireless key, contact your Lexus dealer as soon as possible to avoid the possibility of theft, or an accident. (See “If you lose your keys or lock yourself out”...
Page 33 KEYS AND DOORS dropping it. Locking/Unlocking the doors D Avoid putting it in water. When you push the “LOCK” button on the key briefly, all the doors can be locked from outside the vehicle. At this time, one beep sounds and the parking lights and tail lights flash once.
Page 34 KEYS AND DOORS At this time, two beeps sound and the parking lights and tail lights flash twice. Together with the activation of unlocking, the interior light comes on for 15 seconds if the interior light switch is in “DOOR” position. However, this function does not work when the ignition key is in the “ON”...
Page 35 KEYS AND DOORS 11E031 " 1 Louder 2 Off When you push any button on the key, the vehicle sounds one beep when the doors are locked by remote control, and sounds two beeps when the doors are unlocked. You can adjust the beep loudness with the knob under the instrument panel.
Page 36 KEYS AND DOORS Unlocking the trunk lid 11E046 When you keep the button pushed for about 1 Sounding an alarm second, you can unlock the trunk lid. One beep sounds. This function does not work when the ignition key is in the “ON”...
Page 37 KEYS AND DOORS When you push the “PANIC” button for about 2 to 3 For vehicles sold in U.S.A. seconds, an alarm sounds to deter any person trying to break into or damage your vehicle. This device complies with Part 15 of the FCC If you want to stop the alarm, push any button.
Page 38 KEYS AND DOORS the user is encouraged to try to correct the D Increase the separation between the interference by one or more of the following measures: equipment and receiver. D Reorient or relocate the receiving antenna. D Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Page 39 KEYS AND DOORS Replacing the battery When you replace the battery, prepare a lithium battery CR1616 and a special screwdriver. CAUTION Special care should be taken that small children do not swallow the removed battery or components. NOTICE When replacing the battery, be careful not to lose the components, screws and O–ring.
Page 40 KEYS AND DOORS 11E026 2. Remove the module from the key frame. 11E027 3. Remove the 2 screws to take out the lid of the module. 4. Take out the discharged battery and put a new battery with the positive side up.
Page 41: Doors
KEYS AND DOORS DOORS NOTICE D Make sure the positive side and negative side Locking with key of the battery should be faced correctly. D Be careful not to bend the electrode of the battery insertion and that dust or oils do not adhere to the inside of the module.
Page 42 KEYS AND DOORS 11E028 " 1 Lock 2 Unlock Turn the key towards the front of the vehicle to lock and towards the back to unlock. The doors lock and unlock simultaneously with either front door. In the driver’s door lock, turning the key once will unlock the driver’s door and twice in succession will unlock all doors simultaneously.
Page 43 KEYS AND DOORS Locking with inside lock button 11E004 " 1 Lock 2 Unlock Push in the lock button to lock and unlock the door. When locked, the door cannot be opened with either the outside or inside door handle. Closing the door with the lock button pushed in will also lock the door.
Page 44 KEYS AND DOORS CAUTION Before driving, make sure the doors are closed and locked, especially when small children are in the vehicle. Along with the proper use of seat belts, locking the doors helps prevent the driver and passengers from being thrown out from the vehicle during an accident.
Page 45 KEYS AND DOORS Locking with power door lock switch 11E032 " 1 Lock 2 Unlock To lock all the doors simultaneously, push the power door lock switch on the front side. Pushing on the rear side will unlock them. The same switch is also equipped on the front passenger’s side.
Page 46 KEYS AND DOORS Locking with rear door child–protector 11E029 " 1 Lock 2 Unlock Whenever small children are in the vehicle, lock the rear door so that it does not open from the inside. To do this, move the lever to the lock position as shown on the label next to the lever.
Page 47 KEYS AND DOORS...
Page 48 SECTION – INSTRUMENTS AND CONTROLS Switches Headlight switch ....... Headlight dimmer and turn signal switch .
Page 49: Switches
SWITCHES To turn the lights on, twist the knob on the end of the When the headlight switch is turned to the first or second lever. clickstop, the brightness of the instrument cluster will be reduced slightly unless the instrument panel light control FIRST CLICKSTOP: Only the parking, tail, license knob is turned fully on.
Page 50 SWITCHES The automatic light control sensor is on top of the Daytime Running Light System driver’s side instrument panel. The headlights turn on at reduced intensity when the Do not place anything on the instrument panel, and/or do parking brake is released with the engine started, even not affix anything on the windshield to block this sensor.
Page 51: Headlight Dimmer And Turn Signal Switch
TURN SIGNAL SWITCH your headlights do not dazzle other road users. If this system fails, the warning light in the instrument cluster comes on. If this occurs, have your vehicle checked by Lexus dealer. 12E003–1...
Page 52 SWITCHES For high beam, push the lever forward. Pull it back for low beam. For the headlight flasher, pull it further back. A blue light in the instrument cluster indicates high beam or headlight flasher is on. The headlight flasher works even when the headlight switch is off.
Page 53: Fog Light Switch
SWITCHES For signaling turns, move the lever up or down in the FOG LIGHT SWITCH conventional manner. The ignition key must be in the “ON” position. The turn signal is self–cancelling after a turn, but after a lane change, you may have to cancel it by hand. You can also signal a lane change by moving the turn signal lever partway and holding it there.
Page 54 SWITCHES 12E006 " 1 Interval adjuster 2 Washer on Also, the wipers will automatically operate a couple of times after the washer squirts even with the lever in the To turn the wipers on, move the lever down until you “OFF”...
Page 55 SWITCHES Shifting the windshield wiper position 12E053 " 1 Rest position 2 Retracted position The wiper blades retract under the hood when the wipers are turned off. If retraction is obstructed by snow etc., at the bottom of the windshield, the wipers should be shifted from the retracted position to the rest position above the hood level.
Page 56 SWITCHES 12E054 * More than 10 cm (3.9 in.) To shift the windshield wipers from retracted to rest position, hold the connection of the wiper arm and wiper blade and pull it upward along the windshield glass with the force of about 98 N (10 kgf, 22 lbf.). NOTICE To prevent the wiper blades from being deformed, be sure to hold the connection of the wiper arm...
Page 57 SWITCHES 12E055 To return the windshield wipers to retracted position, push the connection of the wiper arm and wiper blade downward. NOTICE To prevent the wiper blades from being deformed, be sure to hold the connection of the wiper arm and wiper blade securely.
Page 58: Rear Window And Outside Rear View Mirror Defogger Switch
SWITCHES REAR WINDOW AND OUTSIDE REAR VIEW MIRROR DEFOGGER SWITCH 12E043 To turn the electric rear window and outside rear view mirror defogger on, push the switch. The ignition key must be in the “ON” position. The thin heater wires on the inside of the rear window and the heater panels in the outside rear view mirrors will quickly clear the surface.
Page 59: Power Window Switches
SWITCHES CAUTION Since the mirror surfaces can get hot, keep your hands off them when the rear window and outside rear view mirror defogger switch is on. If further defrosting or defogging is desired, simply POWER WINDOW SWITCHES actuate the switch again. When the surface has cleared, push the switch once again to turn the defogger off.
Page 60 SWITCHES " 1 For driver’s window 2 For front passenger’s window 3 For left rear window 4 For right rear window To raise or lower the windows, use the switch on each door. The passengers’ windows can also be controlled by the switches on the driver’s door. The power windows work when the ignition key is in the “ON”...
Page 61 SWITCHES Operating the driver’s and front Operating the rear passengers’ switches passenger’s switch To lower the window, push the switch down. Pull it up to raise the window. The window moves as long To lower the window, push the switch halfway down. as the switch is operated.
Page 62 SWITCHES Operating the driver’s and front passenger’s windows from outside the vehicle The windows can be operated using an ignition key. 12E041 Insert the ignition key into the key hole on either front door. To close the windows: Turn the key in the locking direction and hold it.
Page 63 SWITCHES Jam protection function During automatic raising operation, key off raising operation or raising operation using the ignition key from the outside, the window stops and is lowered if something gets caught between the window and window frame. If the window receives a strong impact, this function may work even if nothing is caught.
Page 64 SWITCHES D When small children are in the vehicle, never let them use the power window switches without supervision. Use the window lock switch to prevent them from making unexpected use of the switches. D Never leave small children alone in the vehicle, especially with the ignition key still inserted.
Page 65: Emergency Flasher Switch
SWITCHES EMERGENCY FLASHER SWITCH 12E040...
Page 66: Seat Heater Switches
SWITCHES To turn on the emergency flashers, push the switch. SEAT HEATER SWITCHES All the turn signal lights will flash. The emergency flashers will work with the engine running or off and with or without the ignition key. Turn on the emergency flashers to warn other drivers if you must stop your vehicle where it might be a traffic hazard.
Page 67 SWITCHES " 1 For driver’s seat 2 For front passenger’s seat 3 High heating temperature 4 Low heating temperature To turn on the seat heater, push the switch to “HI” (high temperature) or “LO” (low temperature). Pushing lightly on the opposite side will turn it off. The ignition key must be in the “ON”...
Page 68 SWITCHES CAUTION Occupants must use caution when operating the seat heater because they may experience minor burns even at low temperatures. Use extra caution for; D Babies, small children, elderly persons, sick persons or handicapped persons D Persons who have delicate skin D Persons who are exhausted D Persons who have taken alcohol or drugs which induce sleep (sleeping drug, cold remedy, etc.).
Page 69 SWITCHES NOTICE D Do not put unevenly weighted objects on the seat and do not stick sharp objects (needles, nails, etc.) into the seat. D When cleaning the seats, do not use organic substances (paint thinner, benzine, alcohol, gasoline, etc.). They may damage the heater and seat surface.
Page 70 SWITCHES...
Page 71 SECTION – INSTRUMENTS AND CONTROLS Gauges, meters and service reminder indicators Fuel gauge ........Engine coolant temperature gauge .
Page 72: Gauges, Meters And Service Reminder Indicators
Fill the fuel tank immediately. The indicator lamp goes off after driving several times. If the indicator lamp does not go off, contact your Lexus dealer as soon as possible. See the inner back cover for fuel capacity and...
Page 73: Engine Coolant Temperature Gauge
GAUGES, METERS AND SERVICE REMINDER INDICATORS ENGINE COOLANT TEMPERATURE GAUGE 13E018 " Normal range The gauge indicates the engine coolant temperature when the ignition switch is on. The engine operating temperature will vary with changes in weather and engine load. If the needle points to the red zone or higher, stop your vehicle and allow the engine to cool.
Page 74 GAUGES, METERS AND SERVICE REMINDER INDICATORS Your vehicle may overheat during severe operating conditions, such as: D Driving up a long hill on a hot day. D Reducing speed or stopping after high speed driving. D Idling for a long period with the air conditioning on in stop–and–go traffic.
Page 75: Tachometer
GAUGES, METERS AND SERVICE REMINDER INDICATORS TACHOMETER 13E019 The tachometer indicates engine speed in ODOMETER AND TRIP METER thousands of rpm (revolutions per minute). Use it while driving to prevent engine over–revving. Driving with the engine running too fast causes excessive engine wear and poor fuel economy.
Page 76 GAUGES, METERS AND SERVICE REMINDER INDICATORS 13E021...
Page 77: Service Reminder Indicators And Warning Buzzers
GAUGES, METERS AND SERVICE REMINDER INDICATORS " “ODO/TRIP” knob SERVICE REMINDER INDICATORS AND WARNING This meter displays the odometer and two trip meters. To change the mode indication, push the BUZZERS “ODO/TRIP” knob briefly. Each time you push the knob, the mode changes in order from the odometer to trip meter A to trip meter B, then back to the odometer.
Page 78 GAUGES, METERS AND SERVICE REMINDER INDICATORS If parking brake Add engine oil. is off, stop immediately and contact Lexus Take vehicle to dealer. Lexus dealer. Fasten seat belt. Take vehicle to Lexus dealer. (Indicator and buzzer) Close all doors. Take vehicle to Lexus dealer immediately.
Page 79 If the light does not turn off even after the parking brake is released while the engine is running, immediately stop your vehicle at a safe place and contact your Lexus dealer. In this case, the brakes may not work properly and your stopping distance will become longer.
Page 80 If either of the following conditions occurs, this indicates a malfunction somewhere in the parts monitored by the Do not continue driving if the engine drive belt is warning light system. Contact your Lexus dealer as broken or loose. soon as possible to service the vehicle.
Page 81 If it flickers or stays on while you are driving, pull off the the engine oil level” on page 410.) road to a safe place and stop the engine immediately. Call a Lexus dealer or qualified repair shop for While driving on steep inclines or rough roads which assistance.
Page 82 These lights warn that there is a problem somewhere in monitored by the warning light system. Contact the vehicle skid control system, traction control system your Lexus dealer as soon as possible to service the and brake assist system. vehicle.
Page 83 If either of the following conditions occurs, this indicates a malfunction somewhere in the parts monitored by the D The light comes on while driving without pushing warning light system. Contact your Lexus dealer as “TRAC OFF” switch. soon as possible to service the vehicle: D The light flashes.
Page 84 This light warns that when there is a problem on. It goes off after 6 seconds. somewhere in the automatic headlight leveling system. If it comes on, have your vehicle checked by your Lexus dealer. 4. Turn the ignition key to “ON”. (p) Key Reminder Buzzer...
Page 85 The following service reminder indicators go off after a few seconds. w069 5. Turn the ignition key to “START”. The following service reminder indicators should come If any service reminder indicator or warning buzzer does not function, have it checked by your Lexus dealer as...
Page 86: Instrument Panel Light Control
GAUGES, METERS AND SERVICE REMINDER INDICATORS INSTRUMENT PANEL LIGHT CONTROL 13E005 To adjust the brightness of the instrument panel lights, turn the knob.
Page 87 GAUGES, METERS AND SERVICE REMINDER INDICATORS...
Page 88 SECTION – INSTRUMENTS AND CONTROLS Interior equipment Vanity mirrors ....... . . Interior light .
Page 89: Interior Equipment
INTERIOR EQUIPMENT 14E001–1 " Sun visor with garage door opener...
Page 90 INTERIOR EQUIPMENT 14E047 " Sun visor without garage door opener Sun visors To use the vanity mirrors, swing the sun visor down and open the cover. The vanity lights come on when you open the cover. 14E062...
Page 91 INTERIOR EQUIPMENT To block out glare from the front , swing the sun visor down. To block out glare from the side, remove the sun visor from the hook and swing it to the side. To block out glare coming obliquely from behind you, pull out an extension plate from the inside of the sun visor.
Page 92: Interior Light
INTERIOR EQUIPMENT INTERIOR LIGHT NOTICE Take care not to swing back the sun visor without pushing back the extension plate so as not to damage the extension plate.
Page 93 INTERIOR EQUIPMENT 14E003...
Page 94: Personal Light
INTERIOR EQUIPMENT To turn on the interior light, slide the switch. With the switch in the “DOOR” position, the light comes on when any of the doors are opened. After all the doors are closed, the light remains on for about 15 seconds and then goes out.
Page 95 INTERIOR EQUIPMENT " Vehicles without moon roof To turn on the personal light, push the switch. To turn it off, push the switch again.
Page 96: Ignition Switch Light
INTERIOR EQUIPMENT 14E052 " Vehicles with moon roof IGNITION SWITCH LIGHT To turn on the personal light, push the switch. To turn it off, push the switch again. 14E054...
Page 97 INTERIOR EQUIPMENT For easy access to the ignition switch, the ignition switch light comes on when any of the doors are opened. The light remains on for about 15 seconds and goes out after all the doors are closed. However, the light goes out immediately when all the doors are locked or the ignition key is in the “ACC”...
Page 98: Clock
INTERIOR EQUIPMENT CLOCK 14E006a The digital clock indicates the time with the ignition CIGARETTE LIGHTER AND key at the “ACC” or “ON” position. To reset the ASHTRAY hour, press the “H” button. To reset the minutes, press the “M” button. To adjust the time to the nearest hour, press the “:00”...
Page 99 When finished with your cigarette, thoroughly extinguish it in the ashtray to prevent other cigarette butts from catching fire. After using the ashtray, push it back in completely. To remove the ashtray, just pull it up. Use a Lexus genuine cigarette lighter or equivalent for replacement.
Page 100 INTERIOR EQUIPMENT 14E008–4 " Rear ashtray 1 Snuffer bridge To use the ashtray, pull on the lid. When finished with your cigarette, thoroughly extinguish it in the ashtray to prevent other cigarette butts from catching fire. After using the ashtray, close the lid completely.
Page 101: Power Outlet
INTERIOR EQUIPMENT POWER OUTLET 14E016...
Page 102: Glove Box
INTERIOR EQUIPMENT The power outlet is designed for power supply for GLOVE BOX car accessories. The ignition key must be in the “ACC” or “ON” position for the power outlet to be used. NOTICE To prevent the fuse from being blown, do not use the electricity over the total vehicle capacity of 12V/120W.
Page 103 INTERIOR EQUIPMENT 14E061 " 1 Unlock 2 Open 3 Lock To open the glove box door, pull the lever. To lock the glove box door, insert the master key and turn it clockwise. With the tail lights on, the glove box light will come on when the glove box door is open.
Page 104: Rear Console Box
INTERIOR EQUIPMENT REAR CONSOLE BOX 14E059 " 1 Upper tray 2 Console box To access the upper tray, push the lock release button and raise the lid. To access the console box, pull up the lock release lever and raise the lid. CAUTION To reduce the chance of injury in case of an accident or a sudden stop, always keep the rear console box closed...
Page 105: Garage Door Opener
INTERIOR EQUIPMENT GARAGE DOOR OPENER The garage door opener (HomeLink Universal Transceiver) is manufactured under license from HomeLink and can be programmed to operate garage doors, gates, entry doors, door locks, home lighting systems, and security systems, etc. (a) Programming the HomeLink 14E065 "...
Page 106 INTERIOR EQUIPMENT If the garage door does not operate, identify if your The battery side of the hand–held transmitter must be pointed away from the HomeLink during the garage transmitter is of the “Rolling Code” type. Press programming process. and hold the programmed HomeLink button.
Page 107 INTERIOR EQUIPMENT seconds until step 5 is complete. 3. Press and release the vehicle’s programmed HomeLink button twice. The garage door may open. 5. When the indicator light on the HomeLink changes If the door does open, the programming process is from a slow to a rapid flash after 20 seconds, you can complete.
Page 108 HomeLink memory. To program other devices such as home security systems, home door locks or lighting, contact your authorized Lexus dealer for assistance. Reprogramming a button Individual HomeLink buttons cannot be erased, however, to reprogram a single button, follow the procedure “Programming the HomeLink...
Page 109 INTERIOR EQUIPMENT CAUTION When programming the HomeLink Universal Transceiver, you may be operating a garage door or other device. Make sure people and objects are out of the way of the garage door or other device to prevent potential harm or damage. Do not use this HomeLink Universal Transceiver with any garage door opener that lacks the safety...
Page 110: Cup Holder
INTERIOR EQUIPMENT CUP HOLDER FCC ID: CB2V94800 CANADA: 1763 102 264 This device complies with FCC Rules Part 15. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference that may be received, including interference that may cause undesired operation.
Page 111 INTERIOR EQUIPMENT 14E011–2 " Rear cup holder To use the rear cup holder, pull the cup holder portion of the console box. The cup holder is designed for holding cups or drink–cans securely. CAUTION Do not place anything else other than cups or drink–cans on the cup holder, as such items may be thrown about in the compartment and possibly injure people in the vehicle during sudden braking or in an...
Page 112: Overhead Console Box
INTERIOR EQUIPMENT OVERHEAD CONSOLE BOX 14E051 To use the box, open it as shown above. CAUTION To reduce the chance of injury in case of an accident or a sudden stop, always keep the overhead console box closed while driving. As this box is designed for holding eyeglasses, do not place any object heavier than approximately 60 g (0.13 lb.) in it.
Page 113: Auxiliary Box
INTERIOR EQUIPMENT AUXILIARY BOX NOTICE In hot weather, inside of the vehicle becomes very hot. Do not leave anything flammable or deformable such as a lighter, the glasses, etc. inside. 14E028–1 To use the box, pull on the handle. CAUTION To reduce the chance of injury in case of an accident or a sudden stop, always keep the auxiliary box closed while driving.
Page 114: Floor Mat
INTERIOR EQUIPMENT FLOOR MAT 14E013–1 Use a floor mat of the correct size. If the floor carpet and floor mat have a hole, then it is designed for use with a locking clip. Fix the floor mat with locking clip into the hole in the floor carpet.
Page 115 INTERIOR EQUIPMENT 14E014–1 CAUTION Make sure the floor mat is properly placed on the floor carpet. If the floor mat slips and interferes with the movement of the pedals during driving, it may cause an accident.
Page 116: Luggage Stowage Precautions
INTERIOR EQUIPMENT LUGGAGE STOWAGE PRECAUTIONS When stowing luggage or cargo in the vehicle, observe the following: Put luggage or cargo in the trunk when at all possible. Be sure all items are secured in place. Be careful to keep the vehicle level. Placing the weight as far forward as possible helps maintain vehicle balance.
Page 117 INTERIOR EQUIPMENT NOTICE Do not load the vehicle beyond the vehicle capacity weight specified on the tire pressure label.
Page 118 SECTION – INSTRUMENTS AND CONTROLS Exterior equipment Hood ........Trunk lid .
Page 119: Exterior Equipment
EXTERIOR EQUIPMENT HOOD 15E016 1. To open the hood, pull the hood lock release lever under the instrument panel. The hood will spring up slightly. 15E023 2. Insert your fingers under the hood, push up the auxiliary catch lever and lift the hood.
Page 120 EXTERIOR EQUIPMENT Before closing the hood, check to see that you have not forgotten any tools, rags, etc. Then lower the hood and make sure it locks. CAUTION Before driving, be sure that the hood is securely locked. Otherwise, the hood may open unexpectedly while driving and an accident may occur.
Page 121: Trunk Lid
EXTERIOR EQUIPMENT TRUNK LID 15E024 To unlock the trunk lid, insert the master key and turn it clockwise. To close the trunk lid, lower it and press down on it. After closing the trunk lid, try pulling it up to make sure it is securely closed.
Page 122 EXTERIOR EQUIPMENT Trunk lid opener 15E004 To open the trunk lid while sitting in the driver’s seat, push the switch with the main switch on.
Page 123 EXTERIOR EQUIPMENT 15E005–2 " 1 Main switch 2 Operative 3 Inoperative If you do not want to activate the trunk lid opener system, turn off the main switch in the glove box. To turn it on, push in the main switch. To protect things put in the trunk when you have your vehicle parked, turn off the trunk lid opener system and lock the glove box.
Page 124 EXTERIOR EQUIPMENT Internal trunk release handle 15E031 If a person is locked in the trunk, pull down the phosphorescent handle (illuminated for a while) on the inside of trunk lid in case of emergency to open the trunk lid. The handle illuminating time depends on the intensity of the light thrown on the handle.
Page 125: Fuel Tank Cap
EXTERIOR EQUIPMENT FUEL TANK CAP 15E026 This indicates that the fuel filler door is on the left side of your vehicle.
Page 126 EXTERIOR EQUIPMENT 15E006 1. To open the fuel filler door, push the switch. When refueling, turn off the engine.
Page 127 If the cap is not tightened securely, the malfunction indicator lamp comes on. Make sure the cap is tightened securely. The indicator lamp goes off after driving several times. If the indicator lamp does not go off, contact your Lexus dealer as soon as possible.
Page 128: Moon Roof
CAUTION D Make sure the cap is tightened securely to prevent fuel spillage in case of an accident. D Use only a genuine Lexus fuel tank cap for replacement. It is designed to regulate fuel tank pressure. In case the opener is not actuated 15E008–1...
Page 129 EXTERIOR EQUIPMENT 15E021 " 1 Open 2 Close To slide open the tilted–up moon roof: Push the switch on the “SLIDE OPEN” side to tilt down To slide open the moon roof, push the switch on the the moon roof. After releasing the switch, push the “SLIDE OPEN”...
Page 130 EXTERIOR EQUIPMENT 15E022 " 1 Lower 2 Tilt up Operating the moon roof from outside the vehicle To tilt up the rear end of the moon roof, push the switch on the “TILT UP” side or on the “SLIDE The moon roof can be closed or opened using an ignition OPEN”...
Page 131 EXTERIOR EQUIPMENT Jam protection function During closing operation, the moon roof stops and is open if something gets caught into the roof opening. If the moon roof receives a strong impact, this function may work even if nothing is caught. CAUTION To avoid serious personal injury, you must do the following.
Page 132 EXTERIOR EQUIPMENT D Never leave small children alone in the vehicle, especially with the ignition key still inserted. They could use the moon roof switches and get trapped in the roof opening. Unattended children can be involved in serious accidents. D Never sit on top of the vehicle around the roof opening.
Page 133 EXTERIOR EQUIPMENT...
Page 134: Front Seats
SECTION – INSTRUMENTS AND CONTROLS Comfort adjustment Front seats ........Trunk storage extension .
Page 135: Comfort Adjustment
D Do not modify or replace the seats or upholstery of the front seats with the side airbags. Such changes may disable the system or cause the side airbags to inflate accidentally, resulting in death or serious injury. Consult your Lexus dealer if you insist on modifications of this kind.
Page 136 COMFORT ADJUSTMENT Seat adjustment precautions Adjust the driver’s seat so that the foot pedals, steering wheel and instrument panel controls are within easy reach of the driver. CAUTION D Do not adjust the seat while the vehicle is moving as the seat may unexpectedly move and cause the driver to lose control of the vehicle.
Page 137 COMFORT ADJUSTMENT 16E153a...
Page 138 COMFORT ADJUSTMENT " 1 Seat position control switch, seat cushion Adjusting seat position angle and height control switch 2 Seatback angle control switch 3 Lumbar support control switch 16E154a Move the control switch in the desired direction. Releasing the switch will stop the seat in that position. Do not place anything under the seat.
Page 139 COMFORT ADJUSTMENT Adjusting seatback angle 16E155a Move the control switch in the desired direction. Releasing the switch will stop the seatback in that position. CAUTION To reduce the risk of sliding under the lap belt during a collision, avoid reclining the seatback any more than needed.
Page 140 COMFORT ADJUSTMENT Adjusting seat cushion angle and height 16E156a Move the control switch in the desired direction. Releasing the switch will stop the seat cushion in that position.
Page 141: Trunk Storage Extension
COMFORT ADJUSTMENT Adjusting lumbar support (driver’s seat only) 16E142 Push the control switch on either side. TRUNK STORAGE EXTENSION The amount of lumbar support will change as long as the switch is pushed. 16E196...
Page 142 COMFORT ADJUSTMENT " 1 Unlock 2 Lock 3 Open Pull down the center armrest in the rear seat. Pull the lever of the armrest door and open the armrest door. Access to the trunk can be prevented by locking the armrest door with the master key.
Page 143: Head Restraints
COMFORT ADJUSTMENT HEAD RESTRAINTS Front seats 16E007 To raise the head restraint, pull it up. To lower it, press the lock release button and push the head restraint down. To move the head restraint forward or rearward, pull or push on the top. The head restraint is most effective when it is close to your head.
Page 144 COMFORT ADJUSTMENT CAUTION D Adjust the center of the head restraint so that it is closest to the top of your ears. D After adjusting the head restraint, make sure it is locked in position. D Do not drive with the head restraints removed.
Page 145 COMFORT ADJUSTMENT Rear seats 16E222 To raise the head restraint, pull it up. To lower it, press the lock release button and push the head restraint down. To move the head restraint forward or rearward, pull or push on the top. The head restraint is most effective when it is close to your head.
Page 146: Tilt Steering Wheell
COMFORT ADJUSTMENT TILT STEERING WHEEL 16E009 To change the steering wheel angle, hold the steering wheel, pull up the lock release lever, tilt the steering wheel to the desired angle and release the lever. When the steering wheel is in a low position, it will spring up as you release the lock release lever.
Page 147: Outside Rear View Mirrors
COMFORT ADJUSTMENT OUTSIDE REAR VIEW MIRRORS 16E197 Adjust the mirror so that you can just see the side of When you push the rear window and outside rear view your vehicle in the mirror. mirror defogger switch, the heater panels in the outside rear view mirrors will quickly clear the mirror surface.
Page 148 COMFORT ADJUSTMENT CAUTION D Do not adjust the mirror while the vehicle is moving. It may cause the driver to mishandle the vehicle and an accident may occur resulting in death or serious injuries. D Since the mirror surfaces can get hot, keep your hands off them when the rear window and outside rear view mirror defogger switch is on.
Page 149 COMFORT ADJUSTMENT Power rear view mirror control 16E011 " 1 Control switch 2 Master switch To adjust the power rear view mirror, first place the master switch at “L” (left) or “R” (right), and push the control switch on the desired side. The power rear view mirror can be adjusted when the key is in the “ACC”...
Page 150 COMFORT ADJUSTMENT Folding rear view mirrors 16E198 To fold the rear view mirror, push backward. The rear view mirrors can be folded backward for parking in restricted areas. CAUTION Do not drive with the mirrors folded backward. Both the driver and passenger side rear view mirrors must be extended and properly adjusted before driving.
Page 151: Inside Rear View Mirror
COMFORT ADJUSTMENT INSIDE REAR VIEW MIRROR 16E178...
Page 152 COMFORT ADJUSTMENT Adjust the mirror so that you can just see the rear of When the outside air temperature is low, it may take a your vehicle in the mirror. little longer for the mirror to darken in response to the detection of headlights.
Page 153: Seat Belts
Seat belt precautions Lexus strongly urges that the driver and passengers in the vehicle be properly restrained at all times with the seat belts provided. Failure to do so could increase the chance of injury and/or the severity of injury in accidents.
Page 154 COMFORT ADJUSTMENT Injured person. Lexus recommends the use of a seat belt. Depending on the injury, first check with your doctor for specific recommendations.
Page 155 COMFORT ADJUSTMENT CAUTION Persons should ride in their seats properly wearing their seat belts whenever the vehicle is moving. Otherwise, they are much more likely to suffer serious bodily injury or death in the event of sudden braking or a collision. When using the seat belts, observe the following: D Use the belt for only one person at a time.
Page 156 COMFORT ADJUSTMENT D Replace the belt assembly (including bolts) if it has been used in a severe impact. The entire assembly should be replaced even if damage is not obvious.
Page 157 COMFORT ADJUSTMENT Fastening front and rear seat belts 16E014a Adjust the seat as needed and sit up straight and When a passenger’s shoulder belt is completely well back in the seat. To fasten your belt, pull it out extended and is then retracted even slightly, the belt is of the retractor and insert the tab into the buckle.
Page 158 D If the seat belt does not function normally, immediately contact your Lexus dealer. Do not use the seat until the seat belt is fixed. It cannot protect an adult occupant or your child from injury.
Page 159 COMFORT ADJUSTMENT Adjust the position of the lap and shoulder belts. Position the lap belt as low as possible on your hips – not on your waist. Adjust it to a snug fit by pulling the shoulder portion upward through the latch plate. CAUTION D Both high–positioned lap belts and loose–fitting belts could cause serious injuries due to sliding...
Page 160 COMFORT ADJUSTMENT " Front seat belts only Adjust the shoulder anchor position to your size. To raise the anchor position, push the anchor up. To lower the anchor position, support the anchor while you push the lock release button then slide the anchor down. After the adjustment, make sure the anchor is locked in position.
Page 161 Lexus dealer free of charge. as it retracts. Please contact your local Lexus dealer so that the dealer can order the proper required length for the extender. Bring the heaviest coat you expect to wear for proper measurement and selection of length.
Page 162 COMFORT ADJUSTMENT To connect the extender to the seat belt, insert the tab into the seat belt buckle so that the “PRESS” signs on the buckle release buttons of the extender and the seat belt are both facing outward as shown. You will hear a click when the tab locks into the buckle.
Page 163 D If the seat belt does not function normally, immediately contact your Lexus dealer. Do not use the seat until the seat belt is fixed. It cannot protect an adult occupant or your child from injury.
Page 164 COMFORT ADJUSTMENT Front seat belt pretensioners 16E228 The driver and front passenger ’s seat belt pretensioners are designed to be activated in response to a severe frontal impact. When the airbag sensor detects the shock of a severe frontal impact, the front seat belts are quickly drawn back in by the retractors so that the belts snugly restrain the front seat occupants.
Page 165 COMFORT ADJUSTMENT 16E179 This indicator comes on when the ignition key is turned to the “ACC” or “ON” position. It goes off after about 6 seconds. This means the front seat belt pretensioners are operating properly. This warning light system monitors the airbag sensor assembly, front airbag sensors, side airbag sensors, front seat belt pretensioner assemblies, inflators, warning light, interconnecting wiring and power sources.
Page 166 COMFORT ADJUSTMENT 16E229 " 1 Front seat belt pretensioner assemblies 2 SRS warning light 3 Airbag sensor assembly 4 Front airbag sensors The front seat belt pretensioner system mainly consists of the above components, and their locations are shown in the illustration. The front seat belt pretensioners are controlled by the airbag sensor assembly.
Page 167 Do not perform any of the following changes without consulting your Lexus dealer. Such D Repair made on or near the front fenders, front changes can interfere with proper operation of the end structure or console front seat belt pretensioners in some cases.
Page 168 If any of the following conditions occurs, this indicates a malfunction of the airbags or pretensioners. Contact your Lexus dealer as soon as possible to service the vehicle. D The light does not come on when the ignition key is turned to the “ACC”...
Page 169: Srs Airbags
COMFORT ADJUSTMENT 16E230 In the following cases, contact your Lexus dealer as SRS AIRBAGS soon as possible: The SRS (Supplemental Restraint System) airbags D The front part of the vehicle (shaded in the illustration) are designed to provide further protection for the...
Page 170 COMFORT ADJUSTMENT " SRS front airbags In response to a severe frontal impact, the SRS front airbags work together with the seat belts to help reduce injury by inflating. The SRS front airbags help to reduce injuries mainly to the driver’s or front passenger’s head or chest caused by directly hitting the steering wheel or dashboard.
Page 171 CAUTION The driver or front passenger too close to the steering wheel or dashboard during airbag deployment can be killed or seriously injured. Lexus strongly recommends that: D The driver sit as far back as possible from the steering wheel while still maintaining control of the vehicle.
Page 172 COMFORT ADJUSTMENT " SRS side airbags In response to a severe side impact, the SRS side airbags work together with the seat belts to help reduce injury by inflating. The SRS side airbags help to reduce injuries mainly to the driver’s or front passenger’s chest.
Page 173 COMFORT ADJUSTMENT CAUTION SRS side airbags inflate with considerable force. To avoid potential death or serious injury when they inflate, the driver and front passenger must: D Wear their seat belts properly. D Remain properly seated with their back upright and against the seat at all times.
Page 174 COMFORT ADJUSTMENT 16E023 The SRS front airbag system is designed to activate However, this threshold velocity will be considerably in response to a severe frontal impact within the higher if the vehicle strikes an object, such as a parked shaded area between the arrows in the illustration. vehicle or sign pole, which can move or deform on impact, or if it is involved in an underride collision (e.g.
Page 175 COMFORT ADJUSTMENT 16E134–1 " 1 Collision from the rear 2 Vehicle rollover The SRS front airbags are not designed to inflate if the vehicle is involved in a rear collision, if it rolls over, or if it is involved in a low–speed frontal collision.
Page 176 COMFORT ADJUSTMENT 16E135 " 1 Collision from the side at an angle 2 Collision from the side to the vehicle body other than the passenger compartment The SRS side airbag system may not activate if the vehicle is subjected to a collision from the side at certain angles, or a collision to the side of the vehicle body...
Page 177 COMFORT ADJUSTMENT 16E171 " 1 Collision from the front 2 Collision from the rear 3 Vehicle rollover The SRS side airbags are not designed to inflate if the vehicle is involved in a front or rear collision, if it rolls over, or if it is involved in a low–speed side collision.
Page 178 COMFORT ADJUSTMENT 16E159 " 1 Hitting a curb, edge of pavement or hard material 2 Falling into or jumping over a deep hole 3 Landing hard or vehicle falling The SRS front airbags may deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration.
Page 179 COMFORT ADJUSTMENT 16E232 " 1 Side airbag modules (airbag and inflator) 2 Airbag module for front passenger (airbag and inflator) 3 Side airbag sensors 4 Airbag module for driver (airbag and inflator) 5 SRS warning light 6 Airbag sensor assembly 7 Front airbag sensors The SRS airbag system consists mainly of the above components, and their locations are shown in the...
Page 180 COMFORT ADJUSTMENT In a severe frontal impact, the sensors detect deceleration and the system triggers the front airbag inflators. In a severe side impact, the side airbag sensor triggers the side airbag inflator. Then a chemical reaction in the inflators quickly fills the airbags with non–toxic gas to help restrain the forward or lateral motion of the occupants.
Page 181 Lexus strongly recommends that all infants and children be placed in the rear seat of the vehicle and properly restrained. The rear seat is the safest for infants and children.
Page 182 COMFORT ADJUSTMENT 16E177 D Never put a rear–facing child restraint system on the front passenger seat because the force of the rapid inflation of the front passenger airbag can cause death or serious injury to the child.
Page 183 COMFORT ADJUSTMENT 16L146 " Move seat fully back D A forward–facing child restraint system should be allowed to be put on the front passenger seat only when it is unavoidable. Always move the seat as far back as possible, because the force of the deploying front passenger airbag could cause death or serious injury to the child.
Page 184 COMFORT ADJUSTMENT 16E028 D Do not sit on the edge of the seat or lean over the dashboard when the vehicle is in use. The front airbags inflate with considerable speed and force; you may be killed or seriously injured. Sit up straight and well back in the seat, and always use your seat belt properly.
Page 185 COMFORT ADJUSTMENT 16E126 D Do not lean against the front door when the vehicle is in use. The side airbag inflates with considerable speed and force; you may be killed or seriously injured. D Do not apply excessive weight to the outer side of the front seats on vehicles with side airbags.
Page 186 COMFORT ADJUSTMENT 16E029 D Do not allow a child to stand up, or to kneel on the front passenger seat. The front airbag inflates with considerable speed and force; the child may be killed or seriously injured. D Do not hold a child on your lap or in your arms. Use a child restraint system in the rear seat.
Page 187 COMFORT ADJUSTMENT 16E030 D Do not put objects or your pets on or in front of the dashboard or steering wheel pad that houses the front airbag system. They might restrict inflation or cause death or serious injury as they are projected rearward by the force of the deploying airbags.
Page 188 COMFORT ADJUSTMENT 16E127 D Do not attach a cup holder or any other device or object on or around the door. When the side airbag inflates, the cup holder or any other device or object will be thrown with great force, or the side airbag may not activate correctly, resulting in death or serious injury.
Page 189 Consult steering wheel, dashboard near the front your Lexus dealer if you insist on modifications passenger airbag or front seats of this kind. Failure to follow these instructions can result in...
Page 190 If either of the following conditions occurs, this indicates a malfunction of the airbags. Contact your Lexus dealer as soon as possible to service the vehicle. D When the ignition key is turned to the “ACC” or “ON”...
Page 191 COMFORT ADJUSTMENT 16E218...
Page 192: Child Restraint
COMFORT ADJUSTMENT In the following cases, contact your Lexus dealer as CHILD RESTRAINT soon as possible: D Any of the SRS airbags have been inflated. Child restraint precautions D The front part of the vehicle and portion of the doors...
Page 193 D Lexus strongly urges use of a proper child restraint which conforms to the size of the child, and is put on the rear seat. According to accident statistics, the child is safer when properly restrained in the rear seat than in the front seat.
Page 194 COMFORT ADJUSTMENT D Never put a rear–facing child restraint system on the front seat. In the event of an accident, the force of the rapid inflation of the airbag can cause death or serious injury if a rear–facing child restraint system is put on the front seat.
Page 195 COMFORT ADJUSTMENT Child restraint system A child restraint system for a small child or baby must itself be properly restrained on the seat with the lap portion of the lap/shoulder belt. You must carefully consult the manufacturer’s instructions which accompany the child restraint system. To provide proper restraint, use a child restraint system following the manufacturer’s instructions about the appropriate age and size of the child for the restraint...
Page 196 COMFORT ADJUSTMENT CAUTION D Never put a rear–facing child restraint system on the front seat. In the event of an accident, the force of the rapid inflation of the airbag can cause death or serious injury if a rear–facing child restraint system is put on the front seat.
Page 197 COMFORT ADJUSTMENT When not using the child restraint system, keep it Types of child restraint system secured with the seat belt or place it in the trunk or Child restraint systems are classified into the following somewhere other than in the passenger compartment. 3 types depending on the child’s age and size.
Page 198 COMFORT ADJUSTMENT (B) Convertible seat 16E182 (C) Booster seat 16E183...
Page 199 COMFORT ADJUSTMENT INSTALLATION WITH 3–POINT TYPE SEAT BELT (A) Infant seat installation 16E181 An infant seat is used in rear–facing position only.
Page 200 COMFORT ADJUSTMENT 16E177 CAUTION Never put a rear–facing child restraint system on the front passenger seat because the force of the rapid inflation of the front passenger airbag can cause death or serious injury to the child.
Page 201 COMFORT ADJUSTMENT 16E253 D If your driving seat position is not satisfactory, install the child restraint system at another position. 16E185...
Page 202 COMFORT ADJUSTMENT 1. Run the lap and shoulder belt through or around the infant seat following the instructions provided by its manufacturer and inserting the tab into the buckle taking care not to twist the belt. Keep the lap portion of the belt tight.
Page 203 D If the seat belt does not function normally, immediately contact your Lexus dealer. Do not use the seat until the seat belt is fixed. It cannot protect your child from injury.
Page 204 COMFORT ADJUSTMENT 16E187 3. While pressing the infant seat firmly against the seat cushion and seatback, let the shoulder belt retract as far as it will go to hold the infant seat securely.
Page 205 COMFORT ADJUSTMENT 16E188 CAUTION Push and pull the child restraint system in different directions to be sure it is secure. Follow all the installation instructions provided by its manufacturer. 16E110a...
Page 206 COMFORT ADJUSTMENT 4. To remove the infant seat, press the buckle–release (B) Convertible seat installation button and allow the belt to retract completely. The belt will move freely again and be ready to work for an adult or older child passenger. 16E189 A convertible seat is used in forward–facing or rear–facing position depending on the age and size of...
Page 207 COMFORT ADJUSTMENT 16E101-1 CAUTION D Never put a rear–facing child restraint system on the front passenger seat because the force of the rapid inflation of the front passenger airbag can cause death or serious injury to the child.
Page 208 COMFORT ADJUSTMENT 16L146 " Move seat fully back D A forward–facing child restraint system should be allowed to be put on the front passenger seat only when it is unavoidable. Always move the seat as far back as possible, because the force of the deploying front passenger airbag could cause death or serious injury to the child.
Page 209 COMFORT ADJUSTMENT 16E254 D If your driving seat position is not satisfactory, install the child restraint system at another position. 16E190...
Page 210 COMFORT ADJUSTMENT 1. Run the lap and shoulder belt through or around the convertible seat following the instructions provided by its manufacturer and inserting the tab into the buckle taking care not to twist the belt. Keep the lap portion of the belt tight.
Page 211 D If the seat belt does not function normally, immediately contact your Lexus dealer. Do not use the seat until the seat belt is fixed. It cannot protect your child from injury.
Page 212 COMFORT ADJUSTMENT 16E192 3. While pressing the convertible seat firmly against the seat cushion and seatback, let the shoulder belt retract as far as it will go to hold the convertible seat securely.
Page 213 COMFORT ADJUSTMENT 16E193 CAUTION Push and pull the child restraint system in different directions to be sure it is secure. Follow all the installation instructions provided by its manufacturer. 16E115c...
Page 214 COMFORT ADJUSTMENT 4. To remove the convertible seat, press the (C) Booster seat installation buckle–release button and allow the belt to retract completely. The belt will move freely again and be ready to work for an adult or older child passenger. 16E194 A booster seat is used in forward–facing position only.
Page 215 COMFORT ADJUSTMENT 16L152 " Move seat fully back...
Page 216 COMFORT ADJUSTMENT CAUTION D A forward–facing child restraint system should be allowed to be put on the front passenger seat only when it is unavoidable. Always move the seat as far back as possible, because the force of the deploying front passenger airbag could cause death or serious injury to the child.
Page 217 D If the seat belt does not function normally, immediately contact your Lexus dealer. Do not use the seat until the seat belt is fixed. It cannot protect your child from injury.
Page 218 COMFORT ADJUSTMENT 16E117c 2. To remove the child restraint system, press the Using a top strap buckle–release button and allow the belt to retract. 16E219 Follow the procedure below for a child restraint system that requires the use of a top strap.
Page 219 COMFORT ADJUSTMENT 16E248 " Anchor bracket Use the anchor bracket on the package tray behind the rear seat to attach the top strap. Anchor brackets are installed for each rear seating position.
Page 220 COMFORT ADJUSTMENT 16E211 Fix the child restraint system with the seat belt. Latch the hook onto the anchor bracket and tighten the top strap. For instructions to install the child restraint system, see “Child restraint system” on page 178. CAUTION Make sure the top strap is securely latched, and check that the child restraint system is securely by pushing and pulling it in different directions.
Page 221: Driving Position Memory System
COMFORT ADJUSTMENT DRIVING POSITION MEMORY SYSTEM The micro computer can memorize the positions of the driver’s seat and outside rear view mirrors. Two different driving position profiles can be entered into the computer’s memory. Recording a driving position in the computer’s memory can only be done when the ignition key is in the “ON”...
Page 222 COMFORT ADJUSTMENT 1. Adjust the driver’s seat and outside rear view By repeating these two steps and pressing the mirrors to the desired position. remaining button, the driving position for another driver can be recorded. 2. While pushing the “SET” button, push button “1” or “2”...
Page 223 COMFORT ADJUSTMENT Activating a memorized position 16E048 When you push button “1” or “2”, the driving position will be automatically adjusted to the position recorded for that button.
Page 224 COMFORT ADJUSTMENT Conditions for memorized position activation D Ignition key “ON” and selector lever in “P” position All parts of the memorized positions can be activated. However, if the brake pedal is being depressed, the seat position will not change. D Key not in ignition switch and within 30 seconds of opening driver’s door.
Page 225 COMFORT ADJUSTMENT CAUTION D Do not start the vehicle while the adjustments are being made. D Take care not to select the wrong button, or the seat could strike the rear passenger or hit your body against the steering wheel. If this happens, you can stop the movement by pressing another driving position memory switch, or depressing the brake pedal.
Page 226 COMFORT ADJUSTMENT...
Page 227 SECTION – INSTRUMENTS AND CONTROLS Theft deterrent Theft deterrent system ......Theft prevention labels ......
Page 228: Theft Deterrent
THEFT DETERRENT THEFT DETERRENT SYSTEM To deter theft of the vehicle, this system is designed to give an alarm if any of the doors, trunk or hood is forcibly unlocked or the battery terminal is disconnected and then reconnected while the vehicle is locked.
Page 229 If the system does not work properly, have it checked by If any door is unlocked and the ignition key is not in the your Lexus dealer. ignition switch during the alarm sounding, the door is automatically locked.
Page 230 THEFT DETERRENT NOTICE Disconnecting the battery may result in the erasure of information you have set in the computer memory. After reconnecting the battery, check that the memorized data has been retained. If it has been erased, input it into the computer once more.
Page 231 THEFT DETERRENT THEFT PREVENTION LABELS (U.S.A. ONLY) 17E002...
Page 232 THEFT DETERRENT Your new vehicle carries theft prevention labels which are approximately 56 mm (2.20 in.) by 16 mm (0.63 in.). The purpose of these labels is to reduce the incidence of vehicle thefts by facilitating the tracing and recovery of parts from stolen vehicles.
Page 233 SECTION – AIR CONDITIONING AND AUDIO Air conditioning Automatic air conditioning controls ....
Page 234 AIR CONDITIONING AUTOMATIC AIR CONDITIONING CONTROLS "The automatic air conditioning automatically NOTICE maintains the set temperature. To prevent the battery from being discharged, do In the automatic operation mode, the air conditioning not leave the air conditioning on longer than selects the most suitable fan speed, air flow, air intake necessary when the engine is not running.
Page 235 AIR CONDITIONING Air intake control button " Air flow selection Temperature display (in degrees Fahrenheit or Centigrade) Fan speed display Air flow display Front windshield button Air conditioning on–off button Air flow control button Fan speed control button OFF button Automatic control button Temperature control and outside temperature knob...
Page 236 AIR CONDITIONING 20E002–1...
Page 237 AIR CONDITIONING (a) Climate control SETTING OPERATION – automatic control 20E094 1. Push the “AUTO” button. An indicator light will illuminate to show that the automatic operation mode has been selected. Air flow quantity, switching of the diffusers, on–off of the air conditioning and switching of the air intake between RECIRCULATED AIR and OUTSIDE AIR are automatically adjusted.
Page 238 AIR CONDITIONING 20E095 2. Turn the “TEMP” knob until the desired SETTING OPERATION – manual control temperature is displayed. If manual air flow selection is desired – The “TEMP” knob is used to set the desired passenger compartment temperature. The temperature of air delivered to the passenger compartment will be controlled automatically according to the setting.
Page 239 AIR CONDITIONING 20E096 The outlets from which air is delivered can be selected If quick heating or cooling is desired – manually by pushing the button. The function of each Turn the “TEMP” knob until “MAX. HOT” or “MAX. mode is as follows: COLD”...
Page 240 AIR CONDITIONING 20E097 " 1 Fan speed at low 2 Fan speed at high If manual switching of air intake is desired – The fan speed can be set to your desired speed by pushing the appropriate side of fan speed control button. The higher the fan speed is, the more air is delivered.
Page 241 AIR CONDITIONING 20E098...
Page 242 “A/C” button blinks even when the “A/C” button is system will take fresh outside air into the vehicle. pushed again, have the compressor checked by your nearest Lexus dealer. If quick circulation of cooled air is desired, push the air intake control button for RECIRCULATED AIR. The Displaying the outside temperature –...
Page 243 AIR CONDITIONING (b) Windshield defogging and defrosting 20E099...
Page 244 AIR CONDITIONING To remove interior fog on the windshield – Pushing the “FRONT WINDSHIELD” button turns on the defroster–linked air conditioning. At this time, the “A/C” Push the “FRONT WINDSHIELD” button. button indicator comes on regardless of whether or not To remove frost or exterior fog on the windshield –...
Page 245 AIR CONDITIONING D If following another vehicle on a dusty road, or driving (c) Operating tips in windy and dusty conditions, it is recommended that D To help cool down the interior after parking in the hot the air intake control button be temporarily pressed in sun, drive for the first few minutes with the windows to the RECIRCULATED AIR mode, which will close open.
Page 246 AIR CONDITIONING Air conditioning Fan speed – To the desired fan speed Temperature – Towards WARM (to the right) For best results, set controls to: Air intake – OUTSIDE AIR For automatic operation – Air flow – FLOOR Air conditioning – OFF Push in the “AUTO”...
Page 247 AIR CONDITIONING If you want to return the setting to RECIRCULATED AIR For manual operation – mode, push the air intake control button once again. Fan speed – To the desired fan speed Pushing the “FRONT WINDSHIELD” button turns on the Temperature –...
Page 248 AIR CONDITIONING For manual operation – Fan speed – To the desired fan speed Temperature – Towards WARM (to the right) Air intake – OUTSIDE AIR Air flow – WINDSHIELD When pushing the “FRONT WINDSHIELD” button, the air intake selects OUTSIDE AIR automatically. This is to clean up the front view more quickly.
Page 249 AIR CONDITIONING Side vents 20E009 If air flow control is not satisfactory, check the side (d) Checking and replacing the air vents. The side vents may be opened or closed as conditioning filter shown. 20E207...
Page 250 AIR CONDITIONING On some models, the air conditioning filters are behind the central instrument panel. The air conditioning filter may clog after long use. The filter may need to be replaced if the air flow of the air conditioner and heater experiences extreme reductions in operating efficiency, or if the windows become to fog up easily.
Page 251 AIR CONDITIONING 1. Turn over the floor carpet carefully until the filter cover appears. Pull open the cover while compressing the cover clips. 20E209 2. Pull on the lower tab and remove the lower filter from the filter outlet. 20E210...
Page 252 AIR CONDITIONING 3. Remove the upper filter by pulling down on its tab then pulling it out. 4. Inspect the filter on the surface facing the front of the vehicle. If it is the just moderately dusty, it may be cleaned by blowing compressed air from the reverse surface.
Page 253 AIR CONDITIONING NOTICE Do not drive with the air conditioning filter removed, or the efficiency of the air conditioning may be lost.
Page 254 SECTION – AIR CONDITIONING AND AUDIO Audio Audio system ....... . . 238...
Page 255 AUDIO AUDIO SYSTEM Quick reference for your audio system...
Page 256 AUDIO 20E100 " The “CD” button works only when your Lexus is equipped with an automatic changer. Audio system made in Nakamichi has a “NAKAMICHI” logo on the panel.
Page 257 AUDIO Turning the system on and adjusting volume Display of functions in CD mode (See page 241 for details.) : Disc selection Stopping and ejecting a cassette tape (See page 260 for details.) (See page 250 for details.) Reversing Function buttons (See page 264 for details.) "": 1 –...
Page 258 Using your audio system: some basics (See page 263 for details.) This section describes some of the basic features of the Lexus audio system. Some information may not pertain to your system. Your audio system works when the ignition key is in the “ACC”...
Page 259 AUDIO Push “AM”, “FM1/2”, “TAPE” or “CD” to turn on that mode. The selected mode turns on directly. Push these buttons if you want to switch from one mode to another. If the tape or disc is not set, the cassette player or compact disc player does not turn on.
Page 260 AUDIO In the “TAPE” or “CD” mode, the applicable functions are shown in the lowest part of the display. Push the switch just below to turn on each function. (b) Tone and balance How good an audio program sounds to you is largely determined by the mix of the treble, mid–range, and bass levels.
Page 261 “FADER” knob: Use this knob to adjust the sound reception of radio. For the installation of the balance between the front and rear speakers. window tint, consult with your Lexus dealer. After adjustment, push the knob back into its retracted (e) Your cassette player position.
Page 262 AUDIO (f) Your automatic changer 20E016–2 If your Lexus is equipped with an automatic changer, it can play selected discs or continuously play all the discs set in the magazine. When you set discs into the magazine, make sure they face the correct way.
Page 263 AUDIO Radio operation (a) Listening to the radio 20E104 Push these buttons to choose either an AM or FM station. “AM”, “FM1” or “FM2” appears on the display.
Page 264 AUDIO 20E205 Push this button on the upper side to step up the (b) Presetting a station station band or on the lower side to step down. Your radio automatically changes to stereo reception when a stereo broadcast is received. “ST” appears on the display.
Page 265 (c) Selecting a station 2. Push one of the station selector buttons (1–6) and Your Lexus has an electronic tuning radio (ETR). Tune hold it until a beep is heard. This sets the station to in the desired station using one of the following methods.
Page 266 AUDIO 20E139 Preset tuning: Push the button (1–6) for the station you want briefly. The button number (1–6) and station frequency appear on the display. Manual tuning: Push the “TUNE SEEK” button briefly. Each time you push the button, the radio will step up or down to another frequency.
Page 267 AUDIO 20E125 To scan all the frequencies: Push the “SCAN” button. Cassette tape player operation “SCAN” appears on the display. The radio will find the (a) Playing a cassette tape next station up the band, stay there for a few seconds, and then scan again.
Page 268 AUDIO When you insert a cassette tape, the exposed tape should be to the right. The player will automatically start when you insert a cassette tape. At this time, “TAPE” appears on the display. If a metal or chrome equivalent cassette tape is put in the cassette player, the player will automatically adapt to it and “METAL”...
Page 269 AUDIO (b) Manual program selection If a cassette is already in the slot, push the “TAPE” button. Dolby Noise Reduction* feature: If you are listening to a tape that was recorded with Dolby* B or C Noise Reduction, push the button by the double–D symbol until the appropriate symbol appears on the display.
Page 270 AUDIO 20E109 A " “Program” button: Push the “ ” button to select (c) Automatic program selection the other side of a cassette tape. The display indicates which side is currently selected (“Y” indicates top side, “B” indicates bottom side). “Rewind”...
Page 271 AUDIO 20E175 “RPT” button: The repeat feature automatically replays the current program. Push the “RPT” button while the program is playing. When the program ends, it will automatically be rewound and replayed. Push the button again to turn off the repeat feature.
Page 272 AUDIO 20E215 “Automatic program selection” button: The automatic program selection feature allows you to program your cassette player to skip forward or backward to locate the song you want to hear. You can skip up to nine programs at a time. Push this button on the upper side to skip forward.
Page 273 AUDIO Push this button on the lower side to skip backward. Compact disc player operation Push the button until “REW” and the number you want The compact disc player is an optional accessory that to skip appear on the display. your vehicle is pre–wired to accept.
Page 274 AUDIO 20E028 1. Pull the lever and open the glove box door. 20E119 2. Push this button to eject the magazine.
Page 275 AUDIO 20L021 3. Pull out the tray while pushing the lock release button. 20L022 4. Put a disc on the tray with its label face down and push the tray back into the magazine. If the label faces up, the disc cannot be played. In this case, “ERR”...
Page 276 AUDIO 20E032–2 5. Insert the magazine into the player as indicated by the arrow head on the magazine and close the glove box door. When the magazine is set completely, the system will be in a “Load” cycle for approximately 20 seconds while the system searches for discs in the magazine.
Page 277 AUDIO (b) Playing a compact disc 20E112 Push the “CD” button if the magazine is already (c) Selecting a desired disc loaded in the player. “CD” appears on the display. The discs set in the magazine are played continuously, starting with disc number 1. The disc number of the disc currently being played, the track number and the time from the beginning of the program appear on the display.
Page 278 AUDIO 20E177 Push the “DISC” button to select the disc number. (d) Searching for a desired track Push the button several times until the desired disc number appears on the display. When you release the button, the player will start playing the selected disc from the first track.
Page 279 AUDIO Push the “SCAN” button briefly. (e) Searching for a desired disc “SCAN” will appear on the display. The compact disc player will play the next track for 10 seconds, then scan again. To select a track, push the “SCAN” button a second time.
Page 280 AUDIO 20E179 Push the “SCAN” button until you hear a beep. (f) Selecting a desired track With “D.SCAN” on the display, the program at the beginning of each disc will be played for 10 seconds. To continue listening to the program of your choice, push the “SCAN”...
Page 281 AUDIO 20E180 “TRACK” button: Use for direct access to a desired (g) Other compact disc player functions track. Push either side of the “TRACK” button several times until the desired track number appears on the display. As you release the button, the player will start playing the selected track from the beginning.
Page 282 To cancel it, push Remove the magazine from the player to cool it. the button once again. If the player still does not operate, take it to your Lexus When a track is skipped or the system is inoperative, dealer.
Page 283 AUDIO Radio reception Car audio system operating hints Usually, the problem with radio reception does not mean there is a problem with your radio – it is just the normal NOTICE result of conditions outside the vehicle. To ensure the correct audio system operation: For example, nearby buildings and terrain can interfere D Be careful not to spill beverages over the audio with FM reception.
Page 284 AUDIO Station swapping – If the FM signal you are listening to Use high–quality cassettes: is interrupted or weakened, and there is another strong D Low–quality cassette tapes can cause many station nearby on the FM band, your radio may tune in problems, including poor sound, inconsistent playing the second station until the original signal can be picked speed, and constant auto–reversing.
Page 285 AUDIO Caring for your compact disc player and discs 20L037 D Use only compact discs labeled as shown. CD–R (CD–Recordable), CD–RW (CD–Re–writable) and personal computer use CD–ROMs may not be playable on your compact disc player. D Your compact disc player is intended for use with 12 cm (4.7 in.) discs only.
Page 286 AUDIO ss22072...
Page 287 AUDIO Your automatic changer cannot play special shaped or low–quality compact discs such as those shown here. Do not use them as the changer could be damaged. 20L038 " Correct " Wrong D Handle compact discs carefully, especially when you set them into the magazine.
Page 288 AUDIO 20L039 To clean a compact disc: Wipe it with a soft, lint–free cloth that has been dampened with water. Wipe in a straight line from the center to the edge of the disc (not in a circle). Do not use a conventional record cleaner or anti–static device.
Page 289 AUDIO...
Page 290: Three-Way Catalytic Converter
SECTION – STARTING AND DRIVING Starting and driving Three–way catalytic converter ....Engine exhaust caution ......Before starting the engine .
Page 291 STARTING AND DRIVING 31E085 The three–way catalytic converters are emission control devices installed in the exhaust system. It looks somewhat like a muffler, but its purpose is to reduce pollutants in the exhaust gas. CAUTION D Keep people and combustible materials away from the exhaust pipe while the engine is running.
Page 292 D If the engine becomes difficult to start or stalls frequently, take your vehicle in for a check–up as soon as possible. Remember, your Lexus dealer knows your vehicle and its three–way catalytic converter system best.
Page 293: Engine Exhaust Caution
ENGINE EXHAUST CAUTION D To ensure that the three–way catalytic converter and the entire emission control system operate properly, your vehicle must receive the periodic inspections required by the Lexus Maintenance Schedule. scheduled maintenance information, refer to “Owner’s Manual Supplement/Maintenance Schedule”.
Page 294 STARTING AND DRIVING CAUTION D Avoid inhaling the engine exhaust. It contains carbon monoxide, which is a colorless and odorless gas. It can cause unconsciousness or even death. D Make sure the exhaust system has no holes or loose connections. The system should be checked from time to time.
Page 295: Before Starting The Engine
STARTING AND DRIVING BEFORE STARTING THE D To allow proper operation of your vehicle’s ventilation system, keep the inlet grilles in front ENGINE of the windshield clear of snow, leaves, or other obstructions. 1. Check the area around the vehicle before entering it. D If you smell exhaust fumes in the vehicle, drive 2.
Page 296: Ignition Switch With Steering Lock
STARTING AND DRIVING IGNITION SWITCH WITH STEERING LOCK 31E069...
Page 297 STARTING AND DRIVING If you leave the key in the “ACC” or “LOCK” position and “START” – Starter motor on. The key will return to the “ON” position when released. open the driver’s door, a buzzer will remind you to remove the key.
Page 298: Parking Brake
STARTING AND DRIVING “LOCK” – Engine is off and the steering wheel is PARKING BRAKE locked. The ignition key can be removed only at this position. You must push in the key to turn it from “ACC” to the “LOCK” position. The selector lever must be put in the “P”...
Page 299 STARTING AND DRIVING To set: Hold the regular brake pedal down with your right foot. Push down the parking brake pedal with your left foot. To release: Hold the regular brake pedal down with your right foot and push the parking brake pedal with your left foot.
Page 300: How To Start The Engine
STARTING AND DRIVING HOW TO START THE ENGINE If the weather is below freezing, let the engine warm up for a few minutes before driving. Do not leave the vehicle while the engine is warming up. Before cranking If the engine stalls ... 1.
Page 301: Automatic Transmission
STARTING AND DRIVING AUTOMATIC TRANSMISSION Your automatic transmission has a shift lock system to minimize the possibility of incorrect operation. This means you can only shift out of “P” position when the brake pedal is depressed (with the ignition switch in “ON” position and the lock release button depressed).
Page 302 STARTING AND DRIVING Overdrive switch Correct use of the automatic transmission is explained in the following parts. For selecting either a three–speed or four–speed transmission. (a) Overdrive switch (b) Normal driving When the cruise control is being used, even if you downshift the transmission by turning off the (c) Using engine braking overdrive switch, engine braking will not be...
Page 303 STARTING AND DRIVING (a) Overdrive switch 31E082 You can select either third gear (with overdrive off) or fourth gear (with overdrive on) by pushing this switch. To turn the overdrive off, push the switch. The “O/D OFF” indicator light should come on. To turn the overdrive on again, push the switch again.
Page 304 STARTING AND DRIVING (b) Normal driving 31E006 " 1 “P” (Park) position 2 “N” (Neutral) position 1. Start the engine as instructed in “How to start the engine” on page 283. The transmission must be in “P” or “N”. The engine will not start in “R”, “2”, “L”...
Page 305 STARTING AND DRIVING 31E008 " 1 Brake pedal 2 “D” (Drive) position 2. With your foot holding down the brake pedal, shift the selector lever to “D”. CAUTION Never put your foot on the accelerator pedal while shifting.
Page 306 STARTING AND DRIVING 3. Release the parking brake and brake pedal. When the lever is in the “D” position, the automatic Depress the accelerator pedal slowly for smooth transmission system will select the most suitable gear starting. for the running conditions such as hill climbing, hard towing, etc.
Page 307 STARTING AND DRIVING (c) Using engine braking 31E009–2...
Page 308 STARTING AND DRIVING Shift into the “L” position. The transmission will To use the braking power of the engine, downshift the transmission in the way described below: downshift to first gear when the vehicle speed is lower than 55 km/h (34 mph) and maximum engine Push the overdrive switch.
Page 309 STARTING AND DRIVING (d) Using the “2” and “L” positions The “2” and “L” positions are used for strong engine braking as described previously. With the selector lever in “2” or “L”, you can start the vehicle in motion as with the lever in “D”. With the selector lever in “2”, the vehicle will start in first gear and automatically shift to second gear.
Page 310 STARTING AND DRIVING (e) Backing up 31E010 " 1 Brake pedal 2 “R” (Reverse) position 1. Bring the vehicle to a complete stop. 2. With the brake pedal held down with your foot, shift the selector lever to the “R” position. NOTICE Never shift into reverse while the vehicle is moving.
Page 311 STARTING AND DRIVING (f) Parking 31E011–1 " 1 Brake pedal 2 Parking brake pedal 3 “P” (Park) position 1. Bring the vehicle to a complete stop. 2. Depress the parking brake fully to securely apply the parking brake. 3. With the brake pedal held down with your foot, shift the selector lever to the “P”...
Page 312 STARTING AND DRIVING (g) Good driving practice D If the transmission repeatedly shifts up and down between the third and overdrive gears when climbing a gentle slope, the overdrive should be turned off. Be sure to turn the switch on immediately after climbing the slope.
Page 313 STARTING AND DRIVING (i) If you cannot shift the selector lever NOTICE out of “P” position If you rock your vehicle, observe the following If you cannot shift the selector lever from “P” position precautions prevent damage even though the brake pedal is depressed, use the shift transmission and other parts.
Page 314: Cruise Control
STARTING AND DRIVING CRUISE CONTROL The cruise control allows you to cruise the vehicle at a desired speed over 40 km/h (25 mph) with your foot off the accelerator pedal. Your cruising speed can be maintained although a slight speed change may occur when driving up or down a gradient, within the limits of engine performance.
Page 315 STARTING AND DRIVING Turning on the system 31L013 To operate the cruise control, push the main switch. This turns the system on. The indicator light in the instrument cluster shows that you can now set your desired cruising speed. Another push on the switch will turn the system completely off.
Page 316 When you release the accelerator pedal, the vehicle will return to the speed set prior to the If the preset speed automatically cancels out for other acceleration. than these reasons, have your vehicle checked by your Lexus dealer at the earliest opportunity.
Page 317 STARTING AND DRIVING 3. Resetting to a faster speed 4. Resetting to a slower speed Press the control lever upward in the “RES/ACC” Press the control lever downward in the “SET/COAST” direction and hold it. Release the lever when the desired direction and hold it.
Page 318: Electronic Modulated Suspension
Contact your Lexus dealer. control switch. Select one of the 4 modes which is suited to the driving conditions with the control switch to provide good riding comfort and stability.
Page 319 STARTING AND DRIVING 31E013–1 " Slip indicator light When you turn the ignition switch on, this system always turns on. Leave the system on during ordinary driving so that it can operate when needed. When traction control is applied, the slip indicator light blinks.
Page 320 This means that the traction control malfunction somewhere in the parts monitored by the system is in the self–check mode, and does not indicate warning light system. Contact your Lexus dealer as malfunction. soon as possible to service the vehicle.
Page 321: Vehicle Skid Control System
STARTING AND DRIVING VEHICLE SKID CONTROL SYSTEM The vehicle skid control system helps provide comprehensive control of the systems such as an anti–lock brake system, brake assist system, traction control, engine control, etc. This system automatically controls the output of the brakes or engine to help prevent the vehicle from skidding when cornering on a slippery road surface or abrupt steering wheel operation occurs.
Page 322 STARTING AND DRIVING 31E081 You can turn off the vehicle skid control system by Vehicle skid control system failure pushing the “VSC OFF” switch. The “VSC OFF” warning indicator comes on. At this time, the traction control system also turns off. You cannot turn off either one of them.
Page 323 If either of the following conditions occurs, this indicates a malfunction somewhere in the parts monitored by the warning light system. Contact your Lexus dealer as soon as possible to service the vehicle: D The “VSC” warning light and/or “VSC OFF” indicator light do/does not come on after the ignition is turned to on.
Page 324 4 tires should be the same. If you use the tires other than specified, or different type or size, the vehicle skid control system may not function correctly. When replacing the tires or wheels, contact your Lexus dealer.
Page 325: Brake System
STARTING AND DRIVING BRAKE SYSTEM The tandem master cylinder brake system is a hydraulic system with two separate sub–systems. If either sub–system should fail, the other will still work. However, the pedal will be harder to press, and your stopping distance will be longer. Also, the brake system warning light may come on.
Page 326 STARTING AND DRIVING CAUTION D Do not pump the brake pedal if the engine stalls. Each push on the pedal uses up your reserved vacuum. D Even if the power assist is completely lost, the brakes will still work. But you will have to push the pedal hard, much harder than normal.
Page 327 STARTING AND DRIVING The anti–lock brake system becomes operative after the When the anti–lock brake system is activated, the vehicle has accelerated to a speed in excess of following conditions may occur. They do not approximately 10 km/h (6 mph). It stops operating when indicate a malfunction of the system: the vehicle decelerates to a speed below approximately D You may hear the anti–lock brake system operating...
Page 328 STARTING AND DRIVING CAUTION Do not overestimate the anti–lock brake system: Although the anti–lock brake system assists in providing vehicle control, it is still important to drive with all due care and maintain a moderate speed and safe distance from the vehicle in front of you, because there are limits to the vehicle stability and effectiveness of steering wheel operation even with the anti–lock brake system on.
Page 329 STARTING AND DRIVING Anti–lock brake system is not designed to shorten the stopping distance: Always drive at the moderate speed and maintain a safe distance from the vehicle in front of you. Compared with vehicles without an anti–lock brake system, your vehicle may require a longer stopping distance in the following cases: D Driving on rough, gravel or snow–covered roads.
Page 330 Contact a few seconds. Thereafter, if either of the systems your Lexus dealer as soon as possible to service the malfunctions, the light comes on again. vehicle.
Page 331 Have your Lexus dealer perform the bedding–down. Brake assist system (Vehicles with vehicle skid control system) When you slam the brakes on, the brake assist...
Page 332: Brake Pad Wear Limit Indicators
If you hear a squealing or scraping noise while driving, have the brake pads checked and replaced by your 1. Summer tires Lexus dealer as soon as possible. Expensive rotor damage can result if the pads are not replaced when Summer tires are high–speed capability tires best suited needed.
Page 333 STARTING AND DRIVING 2. All season tires All season tires are designed to provide better traction in snow and to be adequate for driving in most winter conditions, as well as for use all year round. All season tires, however, do not have adequate traction performance compared with snow tires in heavy or loose snow.
Page 334 STARTING AND DRIVING CAUTION D Do not mix summer and all season tires on your vehicle as this can cause dangerous handling characteristics, resulting in loss of control. D Do not use tires other than the manufacturer’s designated tires, and never mix tires or wheels of the sizes different from the originals.
Page 335 SECTION – STARTING AND DRIVING Driving tips Break–in period ....... Operation in foreign countries .
Page 336 Drive gently and avoid high speeds. You need not follow a break–in schedule with your new If you plan to drive your Lexus in another country ... Lexus. But following a few simple tips for the first 1600 First, comply with the vehicle registration laws.
Page 337 DRIVING TIPS CAUTION D Before driving off, make sure the parking brake is fully released and that the parking brake reminder light is off. D Do not rest your foot on the brake pedal while driving. It can cause dangerous overheating, needless wear, and poor fuel economy.
Page 338 Do not use alcohol type antifreeze or plain water alone. When it is extremely cold, we recommend to use 60% solution for your Lexus, to provide protection down to about –50_C (–58_F). Do not use more than 70% solution for better coolant performance.
Page 339 Keep ice and snow from accumulating under the may cause harder starting. If you are not sure about fenders. which oil to use, call your Lexus dealer – they will be pleased to help. Ice and snow built up under your fenders can make steering difficult.
Page 340 DRIVING TIPS Depending on where you are driving, we recommend you carry some emergency equipment. Some of the things you might put in the vehicle are tire chains, window scraper, bag of sand or salt, flares, small shovel, jumper cables, etc.
Page 341 DRIVING TIPS DINGHY TOWING 32E002 Your vehicle can be dinghy towed (with four wheels on the ground) from the front behind a motorhome. CAUTION Dinghy towing requires special equipment and accessories. Please refer to your service outlet of the motorhome manufacture recommended equipment.
Page 342 DRIVING TIPS 2. Shift the selector lever into the “N” position. 3. Turn the ignition switch to the “ACC” position. Make sure the audio is turned off and any item is not plugged into the power outlet. NOTICE To avoid the locking of the steering wheel, turn the ignition switch to the “ACC”...
Page 343 DRIVING TIPS 32E003 NOTICE Do not tow your vehicle from the rear. This may cause serious damage to your vehicle.
Page 344 Lexus warranties do not apply to damage or malfunction caused by towing a trailer for commercial purposes. Ask your local Lexus dealer for further details before towing.
Page 345 DRIVING TIPS 32E001–1 " Certification label CAUTION D The total trailer weight (trailer weight plus its cargo load) must not exceed 907 kg (2000 lb.). Exceeding this weight is dangerous.
Page 346 DRIVING TIPS D Trailer hitch assemblies have different weight capacities established by the hitch manufacturer. Even though the vehicle may be physically capable of towing a higher weight, the operator must determine the maximum weight rating of the particular hitch assembly and never exceed the maximum weight rating specified for the trailer hitch.
Page 347 DRIVING TIPS 32L002 " Total trailer weight " Tongue load D The trailer cargo load should be distributed so that the tongue load is 9 to 11 % of the total trailer weight, not exceeding the maximum of 90 kg (200 lb.). Tongue load x 100 = 9 to 11% Total trailer weight...
Page 348 DRIVING TIPS Hitches D If you wish to install a trailer hitch, your Lexus dealer should be consulted. D Use only a hitch which is recommended by Lexus dealer and conforms to the total trailer weight requirement. D Follow the directions supplied by the hitch manufacturer.
Page 349 DRIVING TIPS Brakes and safety chains D Lexus recommends trailers with brakes that conform to any applicable federal and state/provincial regulations. D A safety chain must always be used between the towing vehicle and the trailer. Leave sufficient slack in the chain for turns. The chain should...
Page 350 Break–in schedule for towing purposes. D Lexus recommends that you do not tow a trailer with a new vehicle or a vehicle with any new power train component (engine, transmission, differential, wheel bearing, etc.) for the first 800 km (500 miles) of...
Page 351 DRIVING TIPS D Before starting out, check the operation of the lights Trailer towing tips and all vehicle–trailer connections. After driving a When towing a trailer, your vehicle will handle short distance, stop and recheck the lights and differently than when not towing. The three main connections.
Page 352 DRIVING TIPS D Crosswinds and rough roads will adversely affect wheels will be closer than the vehicle wheels to the inside of the turn. Therefore, compensate for this by handling of your vehicle and trailer, causing sway. making a larger than normal turning radius with your Pay attention to the rear from time to time to prepare vehicle.
Page 353 DRIVING TIPS parking on a slope with a trailer, but if it cannot be 1. Apply the brakes and keep them applied. avoided, do so only after performing the following: 2. Have someone place wheel blocks under both the vehicle and trailer wheels. 3.
Page 354 DRIVING TIPS CAUTION D Do not exceed 72 km/h (45 mph) or the posted towing speed limit, whichever is lower. Because instability (swaying) of a towing vehicle–trailer combination usually increases as the speed increases, exceeding 72 km/h (45 mph) may cause loss of control. D Slow down and downshift before descending steep or long downhill grades.
Page 355 DRIVING TIPS HOW TO SAVE FUEL AND and you are not in traffic, it is better to turn off the engine and start again later. MAKE YOUR VEHICLE LAST D Avoid engine over–revving. Use a gear position LONGER suitable for the road on which you are traveling. Getting more kilometer/mileage from a liter/gallon of fuel is easy –...
Page 356 DRIVING TIPS D Avoid continuous speeding up and slowing D Keep your vehicle tuned–up and in top shape. A down. Stop–and–go driving wastes fuel. dirty air cleaner, improper valve clearance, dirty plugs, dirty oil and grease, brakes not adjusted, etc. D Avoid unnecessary stopping and braking.
Page 357 DRIVING TIPS CAUTION Never turn off the engine to coast down hills. Your power steering and brake booster will not function without the engine running. Also, the emission control system operates properly only when the engine is running.
Page 358 SECTION IN CASE OF AN EMERGENCY If your engine stalls while driving ....If your vehicle will not start ..... If your vehicle overheats .
Page 359: In Case Of An Emergency
IN CASE OF AN EMERGENCY IF YOUR ENGINE STALLS WHILE DRIVING If your engine stalls while driving... 1. Reduce your speed gradually, keeping a straight line. Move cautiously off the road to a safe place. 2. Turn on your emergency flashers. 3.
Page 360: If Your Vehicle Will Not Start
If they work, your key 1. The engine may be flooded because of repeated may be broken. Have the key checked at your Lexus cranking. See “(b) Starting a flooded engine” for further dealer. If none of your keys work, the system is possibly instructions.
Page 361 If you are unsure about how to follow this procedure, we strongly recommend that you seek help from your Lexus If the engine does not start after 30 seconds of cranking, dealer, Roadside Assistance or Customer Service release the key, wait a few minutes and try again.
Page 362 IN CASE OF AN EMERGENCY CAUTION D Batteries contain sulfuric acid which is poisonous and corrosive. Wear protective safety glasses when jump starting, and avoid spilling acid on your skin, clothing, or vehicle. D If you should accidentally get acid on yourself or in your eyes, remove any contaminated clothing and flush the affected area with water immediately.
Page 363 IN CASE OF AN EMERGENCY NOTICE The battery used for boosting must be 12 V. Do not jump start unless you are sure that the booster battery is correct. 40E053...
Page 364 IN CASE OF AN EMERGENCY " 5 Discharged battery 6 Booster battery JUMP STARTING PROCEDURE 1. If the booster battery is installed in another vehicle, make sure the vehicles are not touching. Turn off all unnecessary lights and accessories. 2. If required, remove all the vent plugs from the booster battery.
Page 365: If Your Vehicle Overheats
IN CASE OF AN EMERGENCY (black) cable to a solid, stationary, unpainted metallic point (e.g. cylinder head) away from the battery. Do not connect it to or near any part that moves when the engine is cranked. CAUTION When making the connections, to avoid serious injury, do not lean over the battery or accidentally let the jumper cables or clamps touch anything except the correct battery terminals or the ground.
Page 366 A: If steam is coming from your engine: Turn off the engine. Leave the hood closed until there is no sign of steam or coolant. Your engine could have been seriously damaged already. Call your Lexus dealer for assistance. CAUTION To help avoid personal injury, keep the hood closed until there is no steam.
Page 367: If You Have A Flat Tire
If the engine coolant temperature does not cool down, or your vehicle overheats again, have it checked as soon 3. Firmly set the parking brake and put the transmission as possible by your Lexus dealer. in “P”. 4. Have everyone get out of the vehicle on the side away from traffic.
Page 368 IN CASE OF AN EMERGENCY CAUTION When jacking, be sure to observe the following to reduce the possibility of personal injury: D Follow jacking instructions. D Do not put any part of your body under a vehicle supported by a jack. Personal injury may occur. D Do not start or run the engine while your vehicle is supported by the jack.
Page 369 IN CASE OF AN EMERGENCY D Make sure to set the jack properly in the jack point. Raising the vehicle with jack improperly positioned will damage the vehicle or may allow the vehicle to fall off the jack and cause personal injury. D Never get under the vehicle when the vehicle is supported by the jack alone.
Page 370 IN CASE OF AN EMERGENCY 40E002b " 1 Spare tire 2 Jack 3 Tool bag 4 Wrench 5 Jack handle 1. Get the jack, wrench and spare tire. To prepare yourself for an emergency, you should familiarize yourself with the use of the jack and each tool, and their storage locations.
Page 371 IN CASE OF AN EMERGENCY 40E040 " 1 Joint 2 When removing the jack, turn the joint by hand in the “contract” direction until the jack is free. 3 When storing, turn the joint by hand in the “expand” direction until the jack is firmly secured to prevent it from flying forward during a collision or sudden braking.
Page 372 IN CASE OF AN EMERGENCY 40E004–1 To remove the spare tire: Loosen the nut and remove it. Remove the spare tire cover. Loosen the bolt and remove it. When storing the spare tire, place it with the outer side of the wheel facing up. Then bolt the tire in place and install the spare tire cover to prevent the tire from flying forward during a collision or sudden braking.
Page 373 IN CASE OF AN EMERGENCY 40E041 3. Block the wheel diagonally opposite the flat tire to keep the vehicle from rolling when it is jacked up. When blocking the wheel, place a wheel block in front of the front wheels or behind the rear wheels.
Page 374 IN CASE OF AN EMERGENCY 40E006 4. Loosen all the wheel nuts. Always loosen the wheel nuts before raising the vehicle. Turn the wheel nuts counterclockwise to loosen them. To get maximum leverage, fit the wrench to the nut so that the handle is on the right side, as shown above.
Page 375 IN CASE OF AN EMERGENCY 40E007–1 5. Position the jack at the jack points as shown. Make sure the jack is positioned on a level and solid surface.
Page 376 IN CASE OF AN EMERGENCY 40E008–2 6. After making sure no one is in the vehicle, raise it high enough so that the spare tire can be installed. Allow for the fact that you need more ground clearance when putting on the spare tire than when removing the flat tire.
Page 377 IN CASE OF AN EMERGENCY CAUTION Never get under the vehicle when the vehicle is supported by the jack alone. 40E009–1 7. Remove the wheel nuts and remove the flat tire. Lift the flat tire straight off and put it aside.
Page 378 IN CASE OF AN EMERGENCY 40E010 Before putting on the wheel, remove any corrosion on the mounting surfaces with a wire brush or such. Installation of wheels without good metal–to–metal contact at the mounting surface can cause wheel nuts to loosen and eventually cause a wheel to come off while driving.
Page 379 IN CASE OF AN EMERGENCY 8. Reinstall all the wheel nuts finger tight. Align the holes in the wheel with the bolts. Then lift up the wheel and get at least the top bolt started through its hole. Wiggle the tire and press it back over the other bolts.
Page 380 IN CASE OF AN EMERGENCY 40E012 9. Lower the vehicle completely and tighten the wheel nuts. Turn the jack handle counterclockwise to lower the vehicle. Use only the wheel nut wrench to tighten the nuts. Do not use other tools or any additional leverage other than your hands, such as a hammer, pipe or your foot.
Page 381 IN CASE OF AN EMERGENCY CAUTION D When lowering the vehicle, make sure all portions of your body and all other persons around will not be injured as the vehicle is lowered to the ground. D As soon as possible after changing wheels, have the wheel nuts tightened by torque wrench at 103 N·m (10.5 kgf·m, 76 ft·lbf.).
Page 382 IN CASE OF AN EMERGENCY 10. After changing the wheel, check the air pressure of the replaced tire. Stow all the tools, jack and flat tire securely. If the pressure of the replaced tire is low, drive slowly to the nearest service station and fill to the correct pressure.
Page 383: If Your Vehicle Needs To Be Towed
If they are damaged, use a towing dolly. If towing is necessary, we recommend you to have it done by your Lexus dealer or a commercial tow truck service. In consultation with them, have your vehicle towed using either (a) or (b).
Page 384 IN CASE OF AN EMERGENCY (a) Towing with a wheel lift type truck D From front 40E018–2 D From rear Release the parking brake. NOTICE When lifting wheels, take care to ensure adequate ground clearance for towing at the opposite end of the raised vehicle.
Page 385 IN CASE OF AN EMERGENCY 40E019–1 Use a towing dolly under the front wheels. (b) Using a flat bed truck NOTICE Never vehicle with automatic transmission from the rear with front wheels on the ground, as this may cause serious damage to the transmission.
Page 386 IN CASE OF AN EMERGENCY 40E013 D Tie down points...
Page 387 IN CASE OF AN EMERGENCY 40E014 40E042 If your Lexus is transported by a flat bed, it should be tied down at locations A and B as shown above.
Page 388 IN CASE OF AN EMERGENCY 40E016 " Rear emergency towing eyelets NOTICE Do not use the rear emergency towing eyelets. D Tie down angle 40E017...
Page 389 IN CASE OF AN EMERGENCY If you use chains or wires to tie down your vehicle, (c) Towing with a sling type truck the angles shaded black must be at 45_. 40E020–1 (d) Emergency towing NOTICE Do not tow with a sling type truck, either from the front or rear.
Page 390 IN CASE OF AN EMERGENCY Towing in this manner may be done only on If towing is necessary, we recommend you to have it done by your Lexus dealer or a commercial tow hard–surfaced roads for a short distance and at low truck service.
Page 391 IN CASE OF AN EMERGENCY CAUTION Use extreme caution when towing the vehicle. Avoid sudden starts or erratic driving maneuvers which would place excessive stress on the emergency towing eyelet and towing cable or chain. The eyelet and towing cable or chain may break and cause serious injury or damage.
Page 392: If You Cannot Shift Automatic Transmission Selector Lever
IN CASE OF AN EMERGENCY IF YOU CANNOT SHIFT AUTOMATIC TRANSMISSION SELECTOR LEVER 40E044 If you cannot shift the selector lever out of “P” position to other positions even though the brake pedal is depressed, use the shift lock override button as follows: Turn the ignition key to “LOCK”.
Page 393 “P” position only while pushing the button. Shift into “N” position. Insert the cover. Start the engine. For your safety, keep the brake pedal depressed. Be sure to have the system checked by your Lexus dealer as soon as possible.
Page 394: If You Lose Your Keys Or Lock Yourself Out
IN CASE OF AN EMERGENCY IF YOU LOSE YOUR KEYS OR LOCK YOURSELF OUT You can purchase a new key at your Lexus dealer if you can give them the key number and master key, because your vehicle is equipped with the engine immobiliser system.
Page 395 IN CASE OF AN EMERGENCY...
Page 396 SECTION MAINTENANCE Maintenance requirements ..... General maintenance ......Does your vehicle need repairing? .
Page 397 REQUIREMENTS The scheduled maintenance items listed in the “Owner’s Manual Supplement/Maintenance Schedule” are those Your Lexus vehicle has been designed to have fewer required to be serviced at regular intervals. maintenance requirements with longer service intervals For details of your maintenance schedule, read the to save both your time and money.
Page 398 Section 6. about the operation of all the systems on your vehicle. If you are a skilled do–it–yourself mechanic, the Lexus You can be confident that your Lexus dealer’s service service manuals are recommended. Please be aware department performs the best job to meet the that do–it–yourself maintenance can affect your...
Page 399 Listed below are the general maintenance items that should be performed at the intervals specified. It is recommended that any problem you notice be brought to the attention of your Lexus dealer or qualified service shop for their advice. CAUTION Make these checks only where adequate ventilation can be obtained if you run the engine.
Page 400 MAINTENANCE Vehicle interior Accelerator pedal Check the pedal for smooth operation and uneven pedal Items listed below should be checked regularly, e.g. effort or catching. while performing periodic services, cleaning the vehicle, etc. Brake pedal Lights Check the pedal for smooth operation and the proper clearance and freeplay.
Page 401 “LOW” lines on the see–through reservoir when the engine is cold. See page 415 for additional information. Battery Your Lexus has a maintenance free battery. You do not have to add distilled water. For longer life of the battery, however, see page 451 for additional information.
Page 402 MAINTENANCE DOES YOUR VEHICLE NEED If you notice any of these clues, take your vehicle to your Lexus dealer as soon as possible. It probably needs REPAIRING? adjustment or repair. Be on the alert for changes in performance and sounds, and visual tip–offs that indicate service is needed.
Page 403 MAINTENANCE CAUTION Do not continue driving with the vehicle unchecked. It could result in serious vehicle damage and possibly personal injury.
Page 404 MAINTENANCE...
Page 405 SECTION – SERVICE PROCEDURES AND SPECIFICATIONS Introduction Vehicle identification ......Engine compartment overview ....Do–it–yourself service precautions .
Page 406 This number is on the left top of the instrument panel and can be seen through the windshield from outside. This is the primary identification number for your Lexus. It is used in registering the ownership of your vehicle. 32E001–1 The vehicle identification number (VIN) is also on the Certification Label.
Page 407 INTRODUCTION 61E011 The engine number is stamped on the engine block as shown.
Page 408 INTRODUCTION ENGINE COMPARTMENT OVERVIEW Engine oil filler cap Brake fluid reservoir Fuse box Battery Fuse box Engine oil level 61E020 dipstick Fuse box Washer fluid tank Engine coolant reservoir Power steering fluid reservoir...
Page 409 Performing do–it–yourself maintenance during the warranty period may affect your warranty coverage. Read the separate Lexus Warranty statement for details and suggestions. This section gives instructions only for those items that are relatively easy for an owner to perform. As explained in Section 5, there are still a number of items that must be performed by a qualified technician with special tools.
Page 410 INTRODUCTION CAUTION D When the engine is running, keep hands, clothing, and tools away from the moving fan and engine drive belt. (Removing rings, watches, and ties is advisable.) D Right after driving, the engine compartment – the engine, radiator, exhaust manifold and power steering fluid reservoir, etc.
Page 411 Here is a list of parts and tools you will need to perform D Remember that battery and ignition cables do–it–yourself maintenance. Remember all Lexus parts carry high currents or voltages. Be careful of are designed in metric sizes, so your tools must be accidentally causing a short circuit.
Page 412 D Funnel (only for adding fluid) Checking the cartridge type fuses Parts (if replacement is necessary): Checking power steering fluid D Genuine Lexus fuse or equivalent with same Parts (if level is low): amperage rating as original D Automatic transmission fluid DEXRON...
Page 413 INTRODUCTION POSITIONING THE JACK 61E030 " Front 61E031 " Rear When jacking up your vehicle with the jack, position the jack correctly as shown in the illustrations.
Page 414 INTRODUCTION CAUTION When jacking, be sure to observe the following to reduce the possibility of personal injury: D Follow jacking instructions. D Do not put any part of your body under the vehicle supported by the jack. Personal injury may occur. D Do not start or run the engine while your vehicle is supported by the jack.
Page 415 INTRODUCTION NOTICE Make sure to place the jack correctly, or your vehicle may be damaged.
Page 416 INTRODUCTION...
Page 417 SECTION – SERVICE PROCEDURES AND SPECIFICATIONS Engine Specifications ....... . Fuel .
Page 418 ENGINE SPECIFICATIONS – GENERAL Model 1MZ – FE Type 6 cylinder V type, 4 cycle, gasoline Bore and stroke 87.5 83 mm (3.44 3.27 in.) Displacement 2995 cm (182.8 cu. in.) Valve clearance (engine cold) Intake 0.15 – 0.25 mm (0.006 – 0.010 in.) Exhaust 0.25 –...
Page 419 ENGINE Oil capacity Drain and refill with filter 4.7 L (5.0 qt., 4.1 lmp. qt.) without filter 4.5 L (4.8 qt., 4.0 lmp. qt.) Oil grade API SJ, “Energy–Conserving” multigrade engine oil or ILSAC multigrade engine oil Recommended oil viscosity (SAE): –...
Page 420 ENGINE – IGNITION SYSTEM Spark plug – Make DENSO SK20R11 IFR6A11 – Gap 1.1 mm (0.043 in.) – ELECTRICAL SYSTEM Battery – Maintenance type battery Specific gravity reading at 20_C (68_F): 1.260 Fully charged 1.160 Half charged 1.060 Discharged Charging rates Quick charge 15A max.
Page 421 Your vehicle must use only unleaded gasoline. If you detect heavy knocking even when using the To help prevent gas station mixups, your Lexus has a recommended fuel, or if you hear steady knocking while smaller fuel tank opening. The special nozzle on pumps...
Page 422 Lexus allows the use of oxygenate blended gasoline where the oxygenate content is up to 10% ethanol or 15% MTBE. If you use gasohol in your Lexus, be sure that it has an octane rating no lower than 87. Lexus does not recommend the use of gasoline containing methanol.
Page 423 If you continue to have unacceptable driveability, try changing gasoline brands. If this does not rectify your Lexus does not recommend the use of gasoline that problem, then consult your Lexus dealer. contains MMT. If fuel containing MMT is used, your emission control system may be adversely affected.
Page 424 ENGINE FACTS ABOUT ENGINE OIL stems. CONSUMPTION The amount of engine oil consumed depends on the viscosity of the oil, the quality of the oil and the way the vehicle is driven. Functions of engine oil More oil is consumed under driving conditions such as Engine oil has the primary function of lubricating and high speeds and frequent acceleration and cooling the inside of the engine, and plays a major role...
Page 425 Therefore, it is essential that the oil level be checked regularly. Lexus recommends that the oil level be checked every time you refuel the vehicle. NOTICE Failure to check the oil level regularly could lead to serious engine trouble due to insufficient oil.
Page 426 D Dispose of used oil and used oil filters only in a safe and acceptable manner. Do not dispose of used oil and used oil filters in household trash, in sewers or onto the ground. Call your Lexus dealer or a service station for information concerning recycling or disposal.
Page 427 ENGINE CHECKING THE ENGINE OIL LEVEL 62E009 With the engine at operating temperature and turned off, check the oil level on the dipstick. 1. To get a true reading, the vehicle should be on a level spot. After turning off the engine, wait a few minutes for the oil to drain back into the bottom of the engine.
Page 428 ENGINE 62E002a " 1 Add oil 2 O.K. 3 Too full 4. Pull the dipstick out and look at the oil level on the end. If it is between the low level mark ( 4 ) and the full level mark ( 5 ), it is O.K.
Page 429 ENGINE 62E003–2...
Page 430 ENGINE If the oil level is below or only slightly above the low mark, add engine oil of the same type as already in the engine. Remove the oil filler cap and add engine oil a little at a time, checking the dipstick. The approximate quantity of oil needed to fill between the low level mark and the full level mark on the dipstick is indicated below for reference.
Page 431 ENGINE Engine oil selection Use API SJ, “Energy–Conserving” multigrade engine oil or ILSAC multigrade engine oil. Recommended viscosity (SAE): 62L005–1 Temperature range anticipated before next oil change SAE 5W–30 is the best choice for your vehicle, for good fuel economy, and good starting in cold weather.
Page 432 ENGINE Oil identification marks 62L006–1 " API Service Symbol " ILSAC Certification CHECKING THE ENGINE Mark COOLANT LEVEL Either or both API registered marks are added to some oil containers to help you select the oil you should use. D The API Service Symbol is located anywhere on the outside of the container.
Page 433 “FULL” and “LOW” lines on the If you can find no leak, have your Lexus dealer test the reservoir. If the level is low, add ethylene–glycol cap pressure and check for leaks in the cooling system.
Page 434 ENGINE CAUTION To prevent burning yourself, do not remove the radiator cap when the engine is hot.
Page 435 The total capacity of the cooling system is given on page 402. We recommend to use 50% solution for your Lexus, to provide protection down to about –35_C (–31_F). When it is extremely cold, to provide protection down to about –50_C (–58_F), 60% solution is recommended.
Page 436 ENGINE SPARK PLUGS 62E016 Your engine is fitted with iridium–tipped spark plugs. NOTICE Use only iridium–tipped spark plugs and do not adjust gaps for your engine performance and smooth drivability.
Page 437 SECTION – SERVICE PROCEDURES AND SPECIFICATIONS Chassis Specifications ....... . Checking brake fluid .
Page 438: Specifications
CHASSIS SPECIFICATIONS – AUTOMATIC TRANSAXLE Fluid capacity Drain and refill 3.5 L (3.7 qt., 3.1 lmp. qt.) Fluid type Automatic transmission fluid Type T–IV Change automatic transmission fluid only as NOTICE necessary. Generally, it is necessary to change automatic transmission fluid only if your vehicle is driven Using automatic transmission fluid other than under one of the Special Operating Conditions listed in Toyota Genuine ATF Type T–IV may cause...
Page 439 CHASSIS – BRAKES Pedal clearance 55 mm (2.2 in.) Min. * Pedal free play 1 – 6 mm (0.04 – 0.24 in.) Brake pad wear limit 1.0 mm (0.04 in.) Parking brake lining wear limit 1.0 mm (0.04 in.) Parking brake adjustment 3 –...
Page 440 CHASSIS – TIRES AND WHEELS Tire size Type A: P205/65R15 92V Type B: P205/60R16 91V Recommended cold tire inflation pressure Vehicle load up to 4 occupants 180 kPa (1.8 kgf/cm or bar, 26 psi) (Both front and rear) Vehicle loaded up to vehicle capacity weight 220 kPa (2.2 kgf/cm or bar, 32 psi) (Both front and Spare tire...
Page 441: Checking Brake Fluid
CHASSIS CHECKING BRAKE FLUID 63E001–1 " Vehicles equipped with vehicle skid control system 63E001...
Page 442 CHASSIS " Vehicles equipped with traction control system To check the fluid level, simply look at the see–through reservoir. The level should be between the “MAX” and “MIN” lines on the tank. It is normal for the brake fluid level to go down slightly as the brake pads wear.
Page 443: Checking Power Steering Fluid
CHASSIS CHECKING POWER STEERING NOTICE FLUID If you spill some of the fluid, be sure to wipe it off to prevent it from damaging the parts or paintwork.
Page 444 CHASSIS 63E009 Check the fluid level through the reservoir. If necessary, add automatic transmission fluid DEXRON II or III. If the vehicle has been driven around 80 km/h (50 mph) for 20 minutes (a little more in frigid temperatures), the fluid is hot (60_C –...
Page 445 CHASSIS 63E003–1 " 1 If hot O.K. 2 If hot add 3 If cold O.K. 4 If cold add Clean all dirt off the reservoir and look at the fluid level. If the fluid is cold, the level should be in the “COLD” range.
Page 446 CHASSIS CAUTION The reservoir may be hot so be careful not to burn yourself.
Page 447 CHASSIS NOTICE Avoid overfilling, or the power steering could be damaged.
Page 448: Checking Tire Pressure
If a tire needs frequent reduce tire life and make your vehicle less safe to drive. refilling, have it checked by your Lexus dealer. High tire pressure produces a harsh ride, handling problems, excessive wear at the center of the tire tread, and a greater possibility of tire damage from road hazards.
Page 449: Rotating Tires
CHASSIS least 3 hours and has not been driven for more than ROTATING TIRES 1.5 km or 1 mile since, you will get an accurate cold tire pressure reading. D Always use a tire pressure gauge. appearance of the tire can be misleading. Besides, tire pressures that are even just a few pounds off can degrade ride and handling.
Page 450: Checking And Replacing Tires
CHASSIS To equalize tire wear and help extend tire life, Lexus CHECKING AND REPLACING recommends that you rotate your tires according to TIRES the maintenance schedule. (For scheduled maintenance information, please refer to the When to replace your tires “Owner ’s Manual Supplement/Maintenance Schedule.) However, the most appropriate timing...
Page 451 “TWI” or “ ” marks molded on the sidewall of each tire. The tires on your Lexus have built–in tread wear indicators to help you know when the tires need replacement. When the tread depth wears to 1.6 mm (0.06 in.) or less, the indicators will appear.
Page 452 Transportation. It provides the purchasers and/or to the size or location of a cut or other damage, it should prospective purchasers of Lexus vehicles with be replaced. If you are not sure, consult with your Lexus information on uniform tire quality grading. dealer.
Page 453 CHASSIS controlled conditions on specified government test Warning: The traction grade assigned to this tire is surfaces of asphalt and concrete. A tire marked C may based on braking (straight ahead) traction tests and have poor traction performance. does not include cornering (turning) traction. Temperature A, B, C –...
Page 454: Installing Snow Tires And Chains
It can cause dangerous handling characteristics, on your Lexus. resulting in loss of control. If you need to change from Do not use tires other than stated above. Since your...
Page 455 CHASSIS CAUTION D Snow tires should be inflated to the same pressure as the original tires. D Never drive over 120 km/h (75 mph) with any type of snow tires. Tire chain selection Chain installation Regulations regarding the use of tire chains vary Install the chains on the front tires as tightly as according to location or type of road.
Page 456 CHASSIS CAUTION D Do not exceed 50 km/h (30 mph) or the chain manufacturer’s recommended speed limit, whichever is lower. D Drive carefully avoiding bumps, holes, and sharp turns, which may cause the vehicle to bounce. D Avoid sharp turns or locked–wheel braking, as use of chains may adversely affect vehicle handling.
Page 457: Replacing Wheels
Also, bent aluminum wheels. wheels which have been straightened may have hidden D Use only the Lexus wheel nuts and wrench designed structural damage and therefore should not be used. for your aluminum wheels.
Page 458: Suspension And Chassis
CHASSIS SUSPENSION AND CHASSIS CAUTION Do not modify the suspension/chassis with lift kits, spacers, springs, etc. It can cause dangerous handling characteristics, resulting in loss of control.
Page 459 CHASSIS...
Page 460 SECTION – SERVICE PROCEDURES AND SPECIFICATIONS Electrical components Specifications ....... . Checking battery condition .
Page 461: Electrical Components
ELECTRICAL COMPONENTS SPECIFICATIONS – FUSE LOCATIONS 64E043...
Page 462 ELECTRICAL COMPONENTS " 1 3 Engine compartment – FUSES 4 Driver’s side instrument panel 64E025a 1 Engine compartment 64E065 2 Engine compartment...
Page 463 ELECTRICAL COMPONENTS 64E066...
Page 464 ELECTRICAL COMPONENTS 3 Engine compartment 64E067 4 Driver’s side instrument panel...
Page 465 ELECTRICAL COMPONENTS FUSE AMPERE CIRCUIT Anti–lock brake system No circuit DRL NO.2 Daytime Running Light System ∗ 1 Left–hand headlight (low beam) H–LP H LP ∗ 2 LH(LWR) ∗ 1 Right–hand headlight (low H–LP H LP beam) beam) ∗ 2 RH(LWR) Charging system T–STK...
Page 466 ELECTRICAL COMPONENTS ∗ 1 : Vehicles with discharge headlight FUSE AMPERE CIRCUIT ∗ 2 : Vehicles without discharge headlight Starting system Telephone HEAD Left–hand headlight (high beam) LH(UPR) ALT–S Charging system HEAD Right–hand headlight (high beam) RH(UPR) Multiport fuel injection HORN Theft deterrent system Electronic cooling fan...
Page 467 ELECTRICAL COMPONENTS FUSE AMPERE CIRCUIT FUSE AMPERE CIRCUIT Windshield wipers and STARTER Starting system WIPER washer Door courtesy light, Theft deterrent system, Power MIRROR Outside rear view mirror DOOR door lock system, Trunk defogger –HEATER lid opener, Fuel filler door opener Cruise control system, Anti–lock brake system,...
Page 468: Checking Battery Condition
ELECTRICAL COMPONENTS CHECKING BATTERY CONDITION Precautions CAUTION BATTERY PRECAUTIONS The battery produces flammable and explosive hydrogen gas. D Do not cause a spark by contacting the battery terminals with tools. D Do not smoke or light a match near the battery. The electrolyte contains poisonous and corrosive sulfuric acid.
Page 469 ELECTRICAL COMPONENTS Checking battery exterior D If electrolyte gets on your skin, thoroughly wash the contacted area. If you feel a pain or burn, get medical attention immediately. D If electrolyte gets on your clothes, there is a possibility of its soaking through to your skin, so immediately take off the exposed clothing and follow the procedure above, if necessary.
Page 470 ELECTRICAL COMPONENTS " 1 Terminals 2 Hold–down clamp NOTICE Check the battery for corroded or loose D Make sure the engine and all accessories are connections, cracks, or loose hold–down clamps. turned off before performing maintenance. 1. If the battery is corroded, wash it off with a solution of D When checking the battery, remove the ground warm water and baking soda.
Page 471 Check the battery condition by the hydrometer color. BLUE – Good condition. WHITE – Charging necessary. Have the battery checked by your Lexus dealer. RED – Have the battery checked by your Lexus dealer. NOTICE Do not refill the battery with water.
Page 472: Battery Recharging Precautions
ELECTRICAL COMPONENTS BATTERY RECHARGING PRECAUTIONS During recharging, the battery is producing hydrogen gas. Therefore, before recharging: 1. If recharging with the battery installed on the vehicle, be sure to disconnect the ground cable. 2. Make sure the power switch on the recharger is off when connecting the charger cables to the battery and when disconnecting them.
Page 473 ELECTRICAL COMPONENTS 64E064 64E029–2 " Engine compartment 1 Pull–out tool 2 Spare fuses...
Page 474 ELECTRICAL COMPONENTS 64E013 " Driver’s side instrument panel 1. Turn the ignition switch off and remove the auxiliary box. Determine which fuse may be causing the problem. The auxiliary box shows the name of the circuit for each fuse.
Page 475 ELECTRICAL COMPONENTS 64L013 2. Make sure the inoperative component is turned off. Pull the suspected fuse straight out with the pull–out tool and check it. If it has blown, push a new fuse into the clips.
Page 476 If the new fuse immediately blows out, there is a problem to see, try replacing the suspected fuse with one of the with the electrical system. Have your Lexus dealer same value that you know is good. correct it as soon as possible.
Page 477 ELECTRICAL COMPONENTS CAUTION Never use a fuse with a higher amperage rating, or any other object, in place of a fuse. This may cause extensive damage and possibly a fire.
Page 478: Checking The Cartridge Type Fuses
ELECTRICAL COMPONENTS CHECKING THE CARTRIDGE TYPE FUSES 64E011–1 64E015–1 " Engine compartment...
Page 479 ELECTRICAL COMPONENTS 64E014 " Driver’s side instrument panel If the headlights or other electrical components do not work and the blade type fuses are O.K., check the cartridge type fuses. If any of the cartridge type fuses are blown, they must be replaced.
Page 480 CAUTION Always use a genuine Lexus fuse or equivalent for replacement. Never install an ordinary wire – even for a temporary fix. This may cause extensive damage and possibly a fire.
Page 481: Adding Washer Fluid
This product is available at your Lexus dealer and most auto parts stores. Follow the manufacturer’s directions for how much to mix with water. NOTICE Do not use engine antifreeze or any other substitute because it may damage your vehicle’s...
Page 482 ELECTRICAL COMPONENTS 64E086 " 1 Beam angle gauge (vertical movement) Adjusting the headlight aiming 2 Adjusting bolt A 3 Beam angle gauge (horizontal movement) 4 Adjusting bolt B Before checking the headlight aim: 1. Be sure that the body around the headlight is not deformed.
Page 483 ELECTRICAL COMPONENTS 64E077 " 1 Bubble 2 Acceptable range Vertical movement gauge: The bubble of the gauge should not deviate from the center of the gauge by more than two marks to either side of the gauge. If the bubble is out of the acceptable range of the beam angle gauge, adjust it using bolt A.
Page 484 If the arrow is out of the acceptable range of the beam angle gauge, adjust it using bolt B. If the error is over the value specified above, take the vehicle to your Lexus dealer to adjust the headlight aim. 64E079...
Page 485 ELECTRICAL COMPONENTS " 1 Beam angle gauge (horizontal movement) Adjusting the vertical aiming 2 Adjusting bolt A 3 Adjusting bolt B Before checking the headlight aim: 1. Be sure that the body around the headlight is not deformed. 2. Park the vehicle on a level spot. 3.
Page 486: Replacing Light Bulbs
If it is necessary to replace a one mark to either side of the gauge. bulb, take your vehicle to your Lexus dealer as soon as possible. Use bulbs with the bulb numbers and wattage If the mark is out of the acceptable range of the gauge, ratings given in the table.
Page 487 However, if there is a large drop of water on the inside of the lens, or if there is water pooled inside the light, contact your Lexus dealer. 64E047...
Page 488 ELECTRICAL COMPONENTS Light Bulbs Bulb No. Headlights (high beam) 9005 Headlights (low beam) Discharge bulb Halogen bulb Front turn signal/parking 1157NA 27/8 lights Fog lights 64E048...
Page 489 ELECTRICAL COMPONENTS Light Bulbs Bulb No. Rear turn signal lights ––– High mounted stoplight ––– Rear side marker lights ––– Stop/tail lights ––– 21/5 Tail lights ––– License plate lights ––– Back–up lights –––...
Page 490 ELECTRICAL COMPONENTS 64E060 Light Bulbs Bulb No. Interior light ––– Personal light ––– Door courtesy lights ––– Glove box light ––– Vanity lights –––...
Page 491 ELECTRICAL COMPONENTS 64E049 Light Bulbs Bulb No.
Page 492 ELECTRICAL COMPONENTS Trunk light A: HB3 halogen bulbs B: D2R discharge bulbs C: H7 halogen bulbs H3 halogen bulbs E: Single bulbs F: Wedge base bulbs G: Double bulbs...
Page 493 SECTION – SERVICE PROCEDURES AND SPECIFICATIONS Body Specifications ....... . 477 Protecting your vehicle from corrosion .
Page 494: Body
BODY SPECIFICATIONS – DIMENSIONS AND WEIGHT Overall length 4830 mm (190.2 in.) Overall width 1790 mm (70.5 in.) Overall height 1395 mm (54.9 in.)* Wheelbase 2670 mm (105.1 in.) Tread – Front 1545 mm (60.8 in.) – Rear 1520 mm (59.8 in.) Vehicle capacity weight (occupants + luggage) 410 kg (900 lb.) *: Unladen vehicle...
Page 495: Protecting Your Vehicle From Corrosion
BODY PROTECTING YOUR VEHICLE exposed to high temperature. FROM CORROSION Proper care of your Lexus can help ensure long–term corrosion prevention. The most common causes of corrosion to your vehicle are: D The accumulation of road salt, dirt and moisture in hard–to–reach areas under the vehicle.
Page 496 BODY To help prevent corrosion on your Lexus, follow Check the interior of your vehicle. Water and dirt can these guidelines: accumulate under the floor mats and could cause corrosion. Occasionally check under the mats to make Keep your vehicle clean by regular washing. In sure the area is dry.
Page 497: Washing And Waxing
BODY WASHING AND WAXING Hand–washing your Lexus Work in the shade and wait until the vehicle body is Washing your Lexus not hot to the touch. Keep your vehicle clean by regular washing. 1. Rinse off loose dirt with a hose. Remove any mud or...
Page 498 BODY Plastic wheel ornaments: The plastic wheel ornaments are damaged easily by organic substances. If any organic substances splashes an ornament, be sure to wash it off with water and check if the ornament is damaged. CAUTION Do not attach the heavily damaged plastic wheel ornament.
Page 499: Cleaning The Interior
Waxing your Lexus CLEANING THE INTERIOR Polishing and waxing is recommended to maintain the original beauty of your Lexus’ finish. Once a month or if the vehicle surface does not repel water well, apply wax. 1. Always wash and dry the vehicle before you begin waxing, even if you are using a combined cleaner and wax.
Page 500 BODY Leather Interior NOTICE The selected leather is used in your Lexus. Due to a leather product, some parts of leather may be rough, uneven or scratched originally. To keep good appearance, we recommend you to clean it periodically twice a year.
Page 501 BODY Synthetic Leather Areas (Dash) D Dirt or sand adhered to the leather may damage the treated surface and cause it to wear earlier. The synthetic leather areas may be easily cleaned Remove dirt or sand using a vacuum cleaner. with a mild soap or detergent and water.
Page 502 It may contain the ingredients mentioned above. Immediately clean any spill using the method mentioned above. If you have any questions about the cleaning of your Lexus, your local Lexus dealer will be pleased to answer them.
Page 503 National Highway Traffic Safety Administration (NHTSA) in addition to notifying Toyota Motor Sales, U.S.A., Inc. (Toll–free: 1–800–25–LEXUS). If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
Page 504 GAS STATION INFORMATION D Fuel selection: D Automatic transaxle: Select Octane Rating 87 (Research Octane Number 91) or Fluid type – Automatic transmission fluid Type T–IV higher. For improved vehicle performance, the use of See page 421 for detailed information. premium unleaded gasoline with an Octane Rating 91 D Tire information: (Research Octane Number 96) or higher is recommended.

Lexus ES-300 2001 Manual

How to Use this Manual

Basic Operation

1 Section -

2 Section -

3 Section -

4 Section -

5 Section -

6 Section -

1 Section -

Section

3 Section -

Quick Links

Chapters

Related Manuals for Lexus ES-300 2001

Summary of Contents for Lexus ES-300 2001

Table of Contents
