Page 1: User Manual
HDMI over Single CAT-5 Extender Kit with IR ET-HK0101-TC ET-HK0101-RC User Manual ◄ V1.0 ► www.databay.com.tw www.green-box.com.tw... -
Page 2: Safety And Notice
The ET-HK0101-MC HDMI 1.3 over Single CAT5 Extender has been tested for conformity to safety regulations and requirements, and has been certified for international use. However, like all electronic equipments, the ET-HK0101-TC should be used with care. Please read and follow the safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit. - Page 3 The ET-HK0101-MC includes two units: transmitting (ET-HK0101-TC) and receiving (ET-HK0101-TC) units. The transmitting unit is used to capture the input HDMI/DVI signals and carry the signals through one RJ-45 connector into one cost effective CAT-5/5e/6 LAN cable.
- Page 4 Features State-of-the-art Silicon Image (founder of HDMI) chipset embedded for upmost compatibility and reliability HDMI 1.3 compliant Extend the transmission length up to 60m (200ft) from the HDMI sources under HD resolution (1080i or 720p at 24-bit color depth) Extend the transmission length up to 40m (130ft) from the HDMI sources under Full HD resolution (1080p at 24-bit color depth) Extend the transmission length up to 20m (65ft) from the HDMI sources under Full HD resolution (1080p at 36-bit color depth)
-
Page 5: Specifications & Package Contents
Power supply 5V 2A DC Power consumption 1 Watt [max] Operation temperature 0~40°C [32~104°F] Storage temperature -20~60°C [-4~140°F] Relative humidity 20~90% RH [no condensation] 1x ET-HK0101-TC [TX & RX] Package Contents 1x 5V power adapter 1x User Manual 5 / 10... -
Page 6: Panel Descriptions
Panel Descriptions ET-HK0101-TC Front View HDMI IN: Connects to a HDMI source with a HDMI Male-Male cable here MODE: 0 = [Video] – supports up to HDMI 1.3 output. [Audio] – supports up to 7.1ch output 1 = [Video] – supports up to HDMI 1.3 output. [Audio] – locks to stereo audio output 2 = [Video] –... - Page 7 Mode 5 Mode 6 which will erase the EDID just learned and restore the default EDID. ET-HK0101-TC Rear View +5V DC: Connect to 5V DC power supply. HDMI Signal OUT: Plug in a CAT-5/5e/6 LAN cable that needs to be linked to the RJ-45 connector of the receiving unit ET-HK0101-TC.
- Page 8 – weakest. It is recommended to switch from 7 to 0 to find the optimal visual experience. ET-HK0101-TC Rear View HDMI Signal IN: Plug in a CAT-5/5e/6 cable that needs to be linked to the RJ-45 connector of the transmitting unit ET-HK0101-TC.
-
Page 9: Hardware Installation
1. Turn on ET-HK0101-TC. 2. Turn the Mode of ET-HK0101-TC to 7. 3. Connect the HDMI display to the “HDMI IN” of ET-HK0101-TC with a HDMI cable. The LED on the RJ-45 connector of ET-HK0101-TC will dim and light again, which indicates the EDID learning procedure is complete. - Page 10 Notice Notice 1. If the DVI or HDMI device requires the EDID information, please use EDID Reader/Writer to retrieve and provide DVI/HDMI EDID information. 2. All HDMI over CAT5 transmission distances are measured using Belden CAT5e 125MHz LAN cable and ASTRODESIGN Video Signal Generator VG-859C. 3.
