Page 1: User Manual
VGA and Audio Cat-X AV Extender AVE-301T AVE-301R AVE-304T AVE-308T AVE-316T AVE-304TR AVE-308TR User Manual ◄ V1.0 ► www.green-box.com.tw www.data-av.com... -
Page 2: Table Of Contents
3. System Devices & Function ..............5 4. Panel Descriptions ................6 5. Installation and Operation...............9 5.1 AVE-301T Single-Port Transmitter Installation: ......9 5.2 Receiver AVE-301R installation and UTP Connection ....10 5.3 AVE-300 Multi-Port Model: Installation and Operation..... 11 6. Specifications................. 14 7. - Page 3 RoHS. © 2009 by Green-Box Green-Box Technology Co. Ltd. reserves the right to make changes in the hardware, packaging, and any accompanying documentation without prior written notice. No part of this document may be reproduced or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission of Green-Box Technology Co.
-
Page 4: Product Introduction
VGA and Audio Cat-X AV Extender 1. Product Introduction AVE-300 series is a broadcast system to transmit Audio and Video signals over Cat5/5e/6 cable, it can reach the distance up to 300m and by stacking more system Transceivers, the whole system can extend AV signals up to 900m. You can use different cable kit to broadcast VGA, Component, Composite, or S-video from multimedia output devices. -
Page 5: System Devices & Function
VGA and Audio Cat-X AV Extender 3. System Devices & Function One-Port Transmitter AVE-301T: (1) Built in one set of AV inputs (2) Built in one set of AV outputs to monitor the AV signal broadcasted (3) Built in one RJ-45 port for system output which can be connected by... -
Page 6: Panel Descriptions
VGA and Audio Cat-X AV Extender 4. Panel Descriptions AVE-301T Single-Port AV Transmitter Power Indicator Power Jack VGA + Audio Output VGA + Audio + USB Power Input RJ-45 AV Output H & V Sync Activity Magnetic Pad AVE-301R Single-Port AV Receiver... - Page 7 VGA and Audio Cat-X AV Extender AVE-304T / AVE-308T / AVE-316T Multi-Port AV Transmitter AVE-304T AVE-308T AVE-316T VGA Activity Power Indicator Power Jack VGA + Audio Input VGA + Audio Output RJ-45 AV Output 7 / 16...
-
Page 8: Cable And Accessories
RJ-45 AV Input Power Jack VGA + Audio Output RJ-45 AV Output Cable and Accessories 3-in-1 AVU cable for AVE-301T VGA cable 1M & Audio cable 1.2M for AVE-304T, AVE-308T, AVE-316T PC cable kit for VGA Video + Audio 8 / 16... -
Page 9: Installation And Operation
TV cable kit to extend Component, Composite, and S-Video Extend VGA Video and Audio by PC Cable Kit 5.1 AVE-301T Single-Port Transmitter Installation: (1) Site Selection: In your first time installation, place Transmitter near the PC or AV devices (Audio and Video outputs); you can use magnetic pad to attach the unit on metal plane (Ex. -
Page 10: Receiver Ave-301R Installation And Utp Connection
VGA and Audio Cat-X AV Extender (3) Function Test: Turn on your AV device, the POWER LED should turn on green to indicate the Power On status and the LEDs above RJ-45 will blink before VGA signal is turned On and remain On after VGA signal is turned On. 5.2 Receiver AVE-301R installation and UTP Connection: (1) Site Selection: Please place Receiver in an appropriate place and have the UTP cable settled for later connection;... -
Page 11: Ave-300 Multi-Port Model: Installation And Operation
VGA and Audio Cat-X AV Extender Plug two ends of UTP cable to Transmitter and Receiver’s RJ45 SYSTEM LINK ports, the Receiver’s connected monitor and speaker should work now and the LEDs above RJ-45 port should remain ON. You can adjust the “FOCUS” and “GAIN”... - Page 12 VGA and Audio Cat-X AV Extender (3) Local Function Test: Power on your AV device, the “ACTIVE” LEDs of Transmitter will turn on orange to indicate the video activation, and you should ready to do AV broadcasting. Installation Diagram of System Transmitter (4) Receiver Installation: Please follow previous section for AVE-301R to install the system Receiver, please note that the maximum extended length of this section should not exceed 300 meters.
- Page 13 VGA and Audio Cat-X AV Extender (6) System Expansion through UTP: This series can stack into maximum three layers of UTP section to reach more AV outputs and depends on the display devices, you may reach a lower VGA solution than single layer. The suggested range of VGA broadcasting is 800x600@900m, 1280x1024@600m, and 2048x1536@300m.
-
Page 14: Specifications
RJ45 x8 RJ45 x16 AV x 1 RJ45 x1 AV Input Stereo Mono Audio AVU cable for AVE-301T, VGA and PC Cable Kit Audio cable for AVE-304T, AVE-308T, used to and AVE-316T Deliver VGA Video + Audio Video Gain and Focus... -
Page 15: Order Information
One Port AVE-300 AV Receiver AVE-301R AC7.5V Power Adaptor x 1, Rack-mount Kit x 1 PC Cable Kit for VGA and Audio For AVE-301T AVU cable x 1 AVE-304T, AVE-308T, AVE-316T VGA cable x 1 For AVE-304TR, AVE-308TR For AVE-301R... -
Page 16: Remarks
VGA and Audio Cat-X AV Extender 8. Remarks Before operating this system, please read operation manual carefully. II. Please use correct power adapter and use high quality cable for optimum broadcasting. III. To prevent potential power damage, please don’t use 2 -wire extension cord and ensure AC outlets at relative devices on the same electronic phase and have correct grounding.
