Page 1: User Manual
VGA and Audio DVI Fiber Optic Extender Kit Cat-X AV Extender (Multi-mode LC type) ET-DF0101-TG500 ET-DF0101-RG500 User Manual ◄ V1.0 ► www.databay.com.tw www.green-box.com.tw... - Page 2 Manual Contents Manual Content Product Description System Requirements Installation Troubleshooting, Maintenance, Technical Support Product Specifications Warranty Information Regulatory Statements Pictorials Figure 1 -- ET-DF0101-MG500 Transmitter and Receiver Figure 2 -- +5V AC/DC power adaptor (100~240V, 1A) Figure 3 -- Installation of Optical DVI extender - 1 -...
- Page 3 Optical DVI Extender user’s manual Thank you for your purchase of the DataBay Optical DVI (Digital Visual Interface) Extender. You now have a high quality and durable device to extend high resolution content with the highest quality to 500 meters. This manual contains will assist you in installing and operating the product.
- Page 4 System Requirements for Setup Hardware requirements You have to have a DVI graphic controller or card having a DVI port in your PC, SUN or Mac systems. It should support the maximum graphic resolution feature of displays to be connected. No special requirements memory size, CPU speed and chipsets, if you’ve already properly installed your DVI graphic controllers or cards.
- Page 5 Installation Important: Please use the installation procedure below. Improper, or no operation may result if the start-up sequence is not correctly followed. Multimode Fiber (4LC) Figure 3 Installation of Optical DVI extender Installation Step Step 1 Carefully unpack the contents of the shipping group. Step 2 Connect each duplex LC fiber cable one by one as indicated number.
- Page 6 Ensure that the TX, RX and power modules are stored or used in a benign environment free from liquid or dirt contamination. There are no user serviceable parts. Refer all service and repair issues to DataBay. Technical Support and Service For commercial or general product support, contact your reseller.
-
Page 7: Product Specifications
Product Specifications Specification PARAMETER SPECIFICATION Remark 300M @ WUXGA 62.5/125 MMF 4-LC Max length 500M @ WUXGA 50/125 MMF 4-LC 1920 × 1200 Single link Max resoultion 1.65 Gbps per channel Max DVI bandwidth Pseudo DDC Customers optional EDID support HDCP compliant 5VDC Operating voltage... - Page 8 GREEN-BOX TECHNOLOGY CO., LTD. 2F, No.198, Chung Yuan Rd., Chung-Li Ind. Zone, Chung-Li 320, Taiwan Tel: +886-3-435-8189 Fax: +886-3-462-5477 E-Mail：Sales@databay.com.tw - 7 -...
