Page 1: User Manual
AV Extender Cat5 DVI-D + Audio DVIE- 1 0 1 T DVS- 1 02C Extender Family DVS- 1 04C DVS- 1 08C DVS- DR DVIE- 1 0 1 R DVS- AR User Manual... - Page 2 User Manual One-Port Transmitter: DVIE-101T 2/4/8-Port Transmitter: DVS-102C / DVS-104C / DVS-108C Short Range DVI-D Receiver: DVS-DR, Long Range DVI-D Receiver: DVIE-101R Audio Receiver: DVS-AR (C) 006 Green-Box Technology Co., Ltd., All Rights Reserved...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction Key Features Panel Description Installation and Operation Specification Order Information Remarks... -
Page 4: Introduction
User Manual Introduction The Cat5/5e/6 DVI-D + Audio Extender consist of a transmitter and a receiver. This pair can extend your DVI-D and audio signal over Cat5/5e/6 and 4-wire phone cable. If you are using short range receiver (DVS-DR) to receive the DVI-D signal, the extended distance is similar to standard DVI-D cable;... -
Page 5: Key Features
5. Audio type and distance: Stereo can be transmitted over 4-wire phone cable over 100 meters. (Audio function not included in DVIE-101T, so you will need to purchase a pair of DVS-AR to extend the audio source.) 6. Input for one DVI-D + audio, output for one DVI-D + audio connection and 1//4/8 sets of RJ-45 and RJ-11 connections to transmit DVI-D and audio signal using Cat5/5e/6 and 4-wire phone cable. - Page 6 User Manual 9. LED status to indicate the DVI activity 10. Stackable capacity to expand the AV broadcasting 11. Provides magnetic pad and attachable metal plate for single-port receiver to ease the installation DVIE-101T Transmitter DVS-10C Transmitter DVS-104C Transmitter DVS-108C Transmitter...
- Page 7 DVS-DR Short Range Receiver DVIE-101R Long Range Receiver DVS-AR Audio Receiver DVS-180AT DVI Integrated AV Cable 1.8M...
-
Page 8: Panel Description
User Manual Panel Description 1. DVIE-101T One-Port DVI-D Transmitter ❶ ❶ DVI-D Input (To PC’s DVI Port) ❷ Power Indicator (Orange LED) ❸ DDCB Activity (Green LED) ❹ RJ-45 DVI-D Output ❷ ❸ ❹ . DVS-10C -Port DVI-D + Audio Transmitter ❸... - Page 9 . DVS-104C 4-Port DVI-D + Audio Transmitter ❻ ❸ ❷ ❶ ❹ ❺ ❼ ❽ ❶ ❺ DDCB Activity DVI+Audio Intput ❷ ❻ Link of Local Monitor DVI+Audio Output ❸ ❼ Power Indicator RJ-45 DVI Output ❹ ❽ Power Jack RJ-11 Stereo Output 4.
- Page 10 User Manual 5. DVS-DR DVI-D Short Range Receiver ❶ ❶ DVI-D Input (To Monitor) ❷ RJ-45 DVI-D Intput ❷ 6. DVIE-101R DVI-D Long Range Receiver ❻ ❼ ❶ ❷❸ ❹ ❺ ❽ ❶ ❺ Auto EQ RJ-45 DVI-D Input ❷ ❻...
-
Page 11: Installation And Operation
(2) Install Single-Port Transmitter DVIE-101T: Please connect DVIE-101T to your PC or DVI player’s DVI output port (Your PC is still turned ON), the LED of DVIE-101T should all turn ON, the orange LED indicates the power ON status and the green LED indicates the DDCB activity of DVI port. - Page 12 User Manual (3) Install Short Range Receiver DVS-DR: Please connect DVS-DR to your DVI monitor’s DVI port directly. The DVI monitor can be PDP, LCD TV, projector or LCD. The supported DVI resolution and distance will be similar to regular DVI cable. If you are using long range receiver DVIE-101R, please refer to next section to install.
- Page 13 (5) Selection of Cat5/5e/6 cable: You may use most of current Cat5/5e/6 cables, and since the quality varies, we do encounter some cables not perform well, even it is expensive. Therefore, please test your current cables before you installing the devices on the site. For some environment need to prevent potential interference, the FTP type cable is recommended.
- Page 14 DVI Projector Monitor To Speaker Long Range Short Range Receiver DVS-AR Receiver DVIE-101T Cat5/5e/6 cable (RJ-45 568B/568B) DVS-AR Audio 4-Wire Photo Cable (RJ-11 Straight) Extended Connection of DVI-D with Audio 2. Install Multi-Port Transmitter: (1) The /4/8-port model will all act the same except they have different amount of outputs.
- Page 15 (5) Turn on your DVI output device and monitor to confirm the function of display. The “LINK” LED of the transmitter should turn orange to reflect the connection of a local DVI monitor and the “ACTIVE” LED should turn blue to indicate an activated DVI-D signal. (6) The transmitter has built in an EDID simulator, when you connect local DVI monitor, the transmitter will automatically record the EDID from DVI monitor.
- Page 16 User Manual (3) RJ-45 VIDEO with Long Range Receiver DVIE-101R: Please refer to previous section 1.(4) ~ (6) to install DVIE-101R and cable. If the video connection is HDMI type, you will need to use appropriate DVI-HDMI adaptor to connect. The supported DVI-D resolution and distance is similar to regular DVI cable, the estimated ranges are: 800x600@100m, 104x768@70m, 180x104@60m, 190x100@5m.
- Page 17 Stack More Transmitters to Have More Displays 1. If you would like to broadcast more monitors and speakers, you can connect another layer of same series Cat5/5e/6 DVI-D + Audio Transmitter. You can connect additional Transmitter from “VIDEO/ AUDIO IN” port or “RJ-45 VIDEO and RJ-11 AUDIO” ports: (1) From “VIDEO/AUDIO OUT”: Use one set of standard DVI/Audio cable, one end connect from the “VIDEO/AUDIO OUT”...
-
Page 18: Specification
User Manual Specification Function DVIE-101T DVS-10C DVS-104C DVS-108C Input DVI Male x 1 DVI Female x 1, Audio x 1 DVI Female x 1 DVI Female x 1 DVI Female x 1 Audio x 1 Audio x 1 Audio x 1... -
Page 19: Remarks
Remarks (1) Before operating this system, please read operation manual carefully. () Please use correct power adapter and use high quality cable for optimum broadcasting. () To prevent potential power damage, please don’t use -wire extension cord and ensure AC outlets at relative devices on the same electronic phase and have correct grounding.
