Page 1: User Manual
VGA and Audio CAT-5 AV Extender AVE-M180T AVE-M180R User Manual ◄ V1.1 ► www.DataBay.com.tw www.green-box.com.tw... -
Page 2: Table Of Contents
Contents 1. Product Introduction................4 2. Product Features................4 3. Panel Descriptions ................5 4. Installation and Operation...............7 4.1 AVE-M180T Single-Port Transmitter Installation .......7 4.2 Receiver AVE-M180R installation and UTP Connection ....8 5. Specifications................. 11 6. Remarks..................12 7. Notice .................... 12... - Page 3 VGA and Audio CAT-5 AV Extender Certifications This equipment has been tested and found to comply with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference (2) This device must accept any interference received, including interference that may cause undesired operation.
-
Page 4: Product Introduction
VGA and Audio CAT-5 AV Extender 1. Product Introduction AVE-M180 is the smallest AV Extender in the industry; the main body is as big as a VGA connector and able to transmit VGA + Audio by a single Cat5e cable up to 180m. With its simplified design, you can install the extender very easily and save space. -
Page 5: Panel Descriptions
VGA and Audio CAT-5 AV Extender 3. Panel Descriptions AVE-M180T Single-Port AV Transmitter Power Indicator RJ-45 System Link Audio Output To USB Power(DC 5V) VGA Output 5 / 12... - Page 6 VGA and Audio CAT-5 AV Extender AVE-M180R Single-Port AV Receiver Power Indicator RJ-45 System Link Video Control Power Jack Audio Input VGA Input 6 / 12...
-
Page 7: Installation And Operation
VGA and Audio CAT-5 AV Extender 4. Installation and Operation 4.1 AVE-M180T Single-Port Transmitter Installation: Connecting Transmitter: Take AVE-180T and connect the interface to computer’s VGA, Audio and USB port. The Transmitter will take the DC5V power from computer’s USB port. -
Page 8: Receiver Ave-M180R Installation And Utp Connection
VGA and Audio CAT-5 AV Extender 4.2 Receiver AVE-M180R installation and UTP Connection: Power Up: Plug power adapter to the Receiver and connect to monitor and speaker. The LED above RJ-45 port should blink to indicate the unconnected status of AV signal. You can also use a short VGA cable (in the package) to connect in between Receiver and monitor and place the receiver in other place. - Page 9 VGA and Audio CAT-5 AV Extender (3)Connect UTP Cable: Installation Diagram of Receiver AVE-M180R Plug two ends of UTP cable to Transmitter and Receiver’s RJ45 SYSTEM LINK ports, the Receiver’s connected monitor and speaker should work now and the LEDs above RJ-45 port should remain ON. You can adjust the “FOCUS”...
- Page 10 VGA and Audio CAT-5 AV Extender c. When using LCD or same type monitor, there might have some image offset or blinking, please adjust the position, clock or phase of the LCD monitor, or simply press Auto Adjust / Tune to have a better image solution.
-
Page 11: Specifications
VGA and Audio CAT-5 AV Extender 5. Specifications AV Transmitter AV Receiver Model Name AVE-M180T AVE –M180R Model No. VGA x 1 RJ45 x1 AV Output Audio x 1 VGA x 1 RJ45 x1 AV Input Audio x 1 Stereo... -
Page 12: Remarks
VGA and Audio CAT-5 AV Extender 6. Remarks Before operating this system, please read operation manual carefully. II. Please use correct power adapter and use high quality cable for optimum broadcasting. III. To prevent potential power damage, please don’t use 2 -wire extension cord and ensure AC outlets at relative devices on the same electronic phase and have correct grounding.
