- Page 1 HDMI over CAT-5 Extender Kit with IR Control Path ET-HD0101TC ET-HD0101RC User Manual ◄ V1.0 ► www.databay.com.tw www.green-box.com.tw...
-
Page 2: Safety And Notice
Safety and Notice The ET-HD0101-MC HDMI 1.3 over CAT5 Extender with IR Pass-through has been tested for conformance to safety regulations and requirements, and has been certified for international use. However, like all electronic equipments, the ET-HD0101-TC should be used with care. Please read and follow the safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit. - Page 3 Introduction The ET-HD0101-MC HDMI over CAT5 Extender with IR Pass-through boosts up your HDMI transmission distance up to 60m (200ft) in HDTV 720p / 1080i format. With two low cost Cat-5/5e/6 LAN cables, users can readily extend HDTV sources from DVD players, Blu-ray Disc player, PS3, PC, and any other kinds of sources compliant with TMDS to remote HDMI displays such as HDTV, LCD PC monitors, or projectors.
- Page 4 Features HDMI 1.3c compliant Extends the transmission distance up to 60m (200ft) from the sources under 1080i or 720p Extends the transmission distance up to 40m (130ft) from the sources under 1080p Provides independent DDC channel, fully HDCP compliant Minimizes the cable skew by adjustable 8-level equalization rotary control switch Embedded IR pass-through from RX to TX Pure unaltered uncompressed 7.1ch digital HDMI over LAN cable transmission Wall mounting housing design for easy and robust installation...
-
Page 5: Specifications & Package Contents
Specifications & Package Contents Model Name ET-HD0101-MC Technical ET-HD0101-TC ET-HD0101-TC Role of usage Transmitter [TX] Receiver [RX] HDMI compliance HDMI 1.3c HDCP compliance Video bandwidth Single-link 225MHz [6.75Gbps] Video support 480i / 480p / 720p / 1080i / 1080p60 HDMI transmission Full HD (1080p)-40m (130ft) [CAT5e] / 50m (165ft) [CAT6] over LAN cable HD (720p/1080i)-50m (165ft) [CAT5e] / 60m (200ft) [CAT6]... -
Page 6: Panel Descriptions
Panel Descriptions Front Panel of ET-HD0101-TC HDMI IN: Connect to a HDMI source with a HDMI male-male cable here IR Blaster: Infrared 3.5mm socket for plugging in the extension cable of IR blaster Rear Panel of ET-HD0101-TC A/V SIGNAL: Plug in a Cat-5/5e/6 cable that needs to be linked to the A/V SIGNAL port of the receiving unit ET-HD0101-TC. - Page 7 Front Panel of ET-HD0101-RC HDMI OUT: Connect to a HDMI display with a HDMI male-male cable here. Signal Level: Adjust the 8-level equalization control to the received HDMI signals. 0 – 7 = strongest – weakest for respective transmission length [long to short]. It is recommended to switch from 7 to 0 to find the optimal visual experience.
-
Page 8: Definition Of Ir Earphone Jack
Panel Descriptions IR Cables IR Blaster IR Receiver IR Sockets ET-HD0101-TC IR Blaster: Plug in an IR blaster here to emit all IR command signals received from the IR receiver to control the HDMI source device. ET-HD0101-RC IR Receiver: Plug in an IR receiver here to receive all IR command signals from the IR remote control of the HDMI source device. -
Page 9: Supported Ir Data Format
Supported IR Data Format Data Format Suitable Recommended TOSHIBA MICOM CODE GRUNDIG CODE SONY 12 BIT CODE SONY 15 BIT CODE SONY 20 BIT CODE RCA CODE RCM CODE MATSUSHITA CODE MITSUBISHI CODE ZENITH CODE JVC CODE M50560-001P MN6125H MN6125L MN6014_C5D7 MN6014-C6D6 MC14457P... - Page 10 Supported IR Data Format 1. Connect your HDMI or DVI source (such as a Blu-ray Disc player) to the transmitting unit ET-HD0101-TC. 2. Connect the IR blaster to the transmitting unit ET-HD0101-TC, and make the IR blaster directly point to the IR sensor of the HDMI source device. 3.
- Page 11 Notice 1. If the DVI or HDMI device requires the EDID information, please use EDID Reader/Writer to retrieve and provide DVI/HDMI EDID information. 2. All HDMI over CAT5 transmission distances are measured using Belden 1583A CAT5e 125MHz solid LAN cable and ASTRODESIGN Video Signal Generator VG-859C. 3.
