6
Stud
Level
Screw Ezy-Mount on the
wall with 3 x screws;
make sure it is level.
Tilt Screen
2
Hook screen onto
top edge on ezy-
15°
mount 15° from verti-
8
cal then let it drop
into position.
You can slide screen sideways
until it lines up with the image
horizontally. Make sure projector
sits perpendicular to the screen.
33mm
Power Drill
7
1
For more information please go to
www.grandviewscreens.com.au
or call 1300 730 025
Nov 2005 v1.1
Grandview Frame Screen Installation Manual
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Grandview GVFA100V
Summary of Contents for Grandview GVFA100V
- Page 1 Power Drill Tilt Screen Hook screen onto top edge on ezy- 15° mount 15° from verti- Grandview Frame Screen Installation Manual cal then let it drop into position. For more information please go to www.grandviewscreens.com.au You can slide screen sideways...
- Page 2 1. Drive corner stakes into Required frame sections 2. Insert angle brackets 3. Secure angle brackets with supplied tek screws Rubber Mallet Level Electric drill Screw Driver Crease Corner Stake PUSH 3 x Screws Drive corner stakes into to suit Wall frame sections using Rubber Mallet...
