R
O
DRINKING WATER SYSTEM
.
.
MODEL T.F.C.-400
INSTALLATION, OPERATION & SERVICE MANUAL
IMPORTANT NOTICES:
This reverse osmosis system contains replaceable treatment components critical for effective performance. It is the user's responsibility
to, and the manufacturer strongly recommends that the user, periodically test the product water to verify the system is performing
satisfactorily.
DO NOT uSE wITh wATER ThAT IS MICRObIOlOgICAlly uNSAfE OR Of uNkNOwN quAlITy, wIThOuT
ADEquATE DISINfECTION bEfORE OR AfTER ThE SySTEM.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T.F.C.-400 and is the answer not in the manual?

Questions and answers

Related Manuals for Clack T.F.C.-400

Summary of Contents for Clack T.F.C.-400

  • Page 1 DRINKING WATER SYSTEM MODEL T.F.C.-400 INSTALLATION, OPERATION & SERVICE MANUAL IMPORTANT NOTICES: This reverse osmosis system contains replaceable treatment components critical for effective performance. It is the user's responsibility to, and the manufacturer strongly recommends that the user, periodically test the product water to verify the system is performing satisfactorily.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Page SECTION I. INTRODUCTION ...................3 SECTION II. SPECIFICATIONS ................5 SECTION III. INSTALLATION STEPS ................6 A. Faucet Installation ................6 B. Feed Water Saddle Valve Installation ..........8 C. Drain Clamp Installation ..............8 D. R.O. Manifold Assembly Installation ..........9 E. Position the Drinking Water Holding Tank and Make the Final Hose Connections .........10 Start Up ..................10 SECTION IV.

  • Page 3: Introduction

    SECTION I. INTRODUCTION the water. Minerals picked up in the environment by Your new Reverse Osmosis (R.O.) Drinking Water the water are measured as Total Dissolved Solids System uses a combination of filtration technologies to (TDS). In the Reverse Osmosis process, dissolved reduce unwanted contaminants in a water supply.
  • Page 4 OPTIONAL T.F.C.–400 BASEMENT INSTALLATION DIAGRAM Close-up of Manifold DIspensIng FauceT See Page 9 nOTe: FOr reFrIgeraTOr waTer DIspenser Or Ice maKer hOOKup, Tee InTO 3/8" Blue TuBIng TO prODucT DIspensIng FauceT. (3/8” Blue) hOlDIng TanK shuTOFF ValVe (Open position) FlOOr In-lIne TanK acTIVaTeD...

  • Page 5: Specifications

    SECTION II. SPECIFICATIONS TABLE A – QUALIFIED SYSTEM PERFORMANCE Because the performance of an R.O. Membrane is highly dependent upon pressure, temperature and TDS, the following should be used for comparison purposes only. U.S. Metric Membrane Production 40-60 gpd 151–227 lpd Membrane TDS Reduction 93% minimum 93% minimum...

  • Page 6: Installation Steps

    SECTION III. INSTALLATION STEPS 2c. Drilling a counter top: All plumbing should be done in accordance with NOTE: The counter top must be less than state and local plumbing codes. 1¼" thick. Treat ceramic tile as porcelain until NOTE: Some codes may require installation by a the tile is penetrated, then use the carbide licensed plumber;...
  • Page 7 4. Place the Base Assembly through the mounting hole on the sink or counter top. 6. Determine which direction the handle should face (right or left). As shown, it can Drop the handle of the Wrench through the Faucet Base opening. This will separate and be mounted in two directions.

  • Page 8: Feed Water Saddle Valve Installation

    2b. To install on (hard) Steel or Brass Tubing FEED WATER SADDLE VALVE supply line. Cold Water •The supply line should now be drained. Use Line a battery powered or properly grounded drill Saddle to avoid shock hazard. Reversible Back Plate •Drill a "...

  • Page 9: Manifold Assembly Installation

    2. Use a battery powered or properly grounded drill. Using the Clamp port as a drill guide, drill a " hole through the wall of the drain pipe. Do NOT penetrate the opposite side of the pipe. 3. Locate the "...

  • Page 10: Position The Drinking Water Holding Tank And Make The Final Hose Connections

    E.  Position the Drinking Water Holding Tank  •Remove the plugs labeled “ACTIVATED and Make the Final Hose Connections.  CARBON” and “MEMBRANE” from the underside of the manifold. To each of the 1. Check the tank precharge pressure. Make remaining white Housings, add one capful sure it is between 5 to 7 psig. If not, use a of bleach.

  • Page 11: Operation And Maintenance

    B.  Changing Filters  When the Faucet is first opened, expect air and carbon fines (very fine black powder) THIS R.O. SYSTEM CONTAINS FILTERS from the In–Line Activated Carbon Post WHICH MUST BE REPLACED AT REGULAR Filter to be rinsed out. This is normal for the INTERVALS TO MAINTAIN PROPER first tank of water or after the In-line filter is PERFORMANCE.

  • Page 12: Changing The In-Line Activated Carbon Post Filter

    IN–LINE ACTIVATED CARBON •The Dispensing Faucet should be open, POST FILTER ASSEMBLY slowly open the Feed Water Saddle Valve. •As soon as water begins to drip out of the Dispensing Dispensing Faucet, close the Faucet. Faucet •Let the system stand for 15 minutes. 3/8"...
  • Page 13 NOTES:...
  • Page 14 NOTES:...
  • Page 15 NOTES:...

  • Page 16: Trouble Shooting Guide

    SECTION V. TROUBLE SHOOTING GUIDE Problem Possible Cause Solution Low quantity of Product Water  Feed Water Saddle Valve is plugged or Open Valve or unclog. from Holding Tank closed. Clogged Sediment Prefilter or Activated Replace filters. Carbon Prefilter. Low water pressure Feed Water pressure must be above 40 psig.
  • Page 17 Problem Possible Cause Solution High Total Dissolved Solids (TDS) in  The Product Water and Drain Water Correct plumbing. the Product Water (continued) lines are reversed. No drain flow, Drain Restrictor is Clear or replace Drain Restrictor. clogged. No drain flow, the drain orifice in Clear or replace Dispensing Faucet. the Dispensing Faucet is plugged.

  • Page 18: Exploded View And Parts List

    EXPLODED VIEW & PARTS LIST MADE IN USA...
  • Page 19 DRAWING NO. PART NO. DESCRIPTION 1 ....S2009 ........ Self Tapping Screw 2 ....S2005-01......ASO Cap 3 ....S2013 ........ ASO Cap O–Ring 4 ....S2011 ........ ASO Diaphragm – Large 5 ....S2007-01......ASO Piston 6 ....S2006-01......ASO Piston Ring 7 ....
  • Page 20 R.O. DRINkINg wATER SySTEM FIVe/One Year lImITeD warranTY What Does This Warranty Cover? This warranty covers any defects in materials and workmanship of the R.O. Drinking Water System when installed and operated within recommended parameters, with the exceptions stated below. How Long Does The Coverage Last? The manufacturer will warrant its R.O.
