BRACKET INSTALLATION

Clamp the bracket around the handlebars and tighten in place. All Vetta cycle computer brackets are designed
to work with 26.0 - 26.4mm standard diameter road handlebars. Shims are provided to fit smaller 25.4mm
mountain and road bars.
NOTE: Make sure not to over tighten the bracket as this may result in breakage. The bracket only needs to be
tightened enough to keep it from spinning on the handlebar during normal riding.
NOTE: When installing the C-25 mounting bracket be sure to leave enough room between the bracket,
handlebar stem and other items attached to the handlebars to allow the head of the computer to be installed
without interference.
HEAD UNIT INSTALLATION
The C-25 utilizes an exclusive twist mount style bracket designed to eliminate the
chance of the head unit coming out of the bracket during rough riding or in the
event of a crash. The bracket also utilizes isolated split contact pins to reduce the
possibility of the unit shorting out when it is used in a wet environment.
STEP 1
Place the head unit in the bracket with the "A" and "B" buttons toward the rear of
the bicycle.
STEP 2
Twist the head unit clockwise 1/4 turn until it is parallel with the handlebars and
locks into place in the bracket.
NOTE: The heads of all Vetta computers are designed to lock into their brackets.
When installing your computer head into the bracket you should hear an audible
"SNAP" indicating that the unit is locked firmly in place.
