MACHINE SET UP - MMA / TIG / MIG / MIG ALUMINIUM
AND MOG WELDING
Below are shown guidelines to set up the machine for a MMA/TIG/MIG/MIG Aluminium
and MOG welding.
ELECTRODE (MMA)
1) Turn off the welding machine
2) Connect the plug of the work clamp to the negative socket "-" and the plug of the
electrode holder to the positive socket "+" of the welding machine. Insert the electrode in
the electrode holder; the diameter and the type must be chosen in function of the welding
current and the thickness and type of workpiece to be welded.
To use the basic or any other special electrode weldable in DC, please always refer to what is
stated on the packaging of the electrodes (in Ex. DC+ or DC- or AC/DC +-).
3) Connect the power supply to the power outlet and turn on the welding machine.
4) Select the MMA welding
5) Select the welding current
7) To use various types of electrodes follow the polarity markings on the package containing
electrodes.
TIG LIFT
1) Turn off the welding machine.
2) Connect the plug of the work clamp to the power positive socket"+" and the plug of the
TIG torch to the negative socket "-" of the welding machine.
3) Connect the work clamp to the work piece.
4) Put the gas cylinder on the rear panel of the welder and fix it with the chain; connect the
gas tube cylinder on the rear panel of the machine
5) Connect the torch gas tube on the front panel
6) Connect the power supply plug to the power outlet and turn on the welding machine.
7) Select the TIG welding.
8) Select the welding current.
9) To stop welding, turn off the machine and close the gas valve.
MIG / MAG
1) Turn off the welding machine.
2) Connect the plug of the work clamp to the Negative socket "-" and the plug of the cable
GAS I NO GAS (Figure 1.A.4) to the Positive socket "+" on the machine.
3) Insert the plug of the MIG torch in the EURO connector on the front panel
(continue over the next page)
